AVEVA Catalogue 2.1 Structural Catalogues
www.aveva.com
Steel Profile Catalogue A steel profile catalogue is provided with AVEVA E3D2.1 The catalogue provides profiles from the latest National Standards and includes profiles from the following countries: – – – – – – –
Australia/New Zealand Canada Chile China Europe India Japan
– – – –
Russia South Africa UK USA
Copyright © 2015 AVEVA Solutions Limited and its subsidiaries. All rights reserved.
‘Old’ Steel Profile Catalogues Prior to E3D2.1, a different structural profile catalogue was used. These catalogues have not been withdrawn to preserve legacy data. The Purpose attribute of the SPEC elements for the previous profile catalogue have been changed to unset so they cannot be selected from the appware in Model. A conversion tool is provided to modify the Spref attribute of existing profiles in Model to the new catalogue.
Copyright © 2015 AVEVA Solutions Limited and its subsidiaries. All rights reserved.
Gtypes The following table shows the Gtypes: Gtype
Description
PFI
Parallel Flange I
PFC
Parallel Flange Channel
PFT
Parallel Flange Tee
TFI
Tapered Flange I
TFC
Tapered Flange Channel
TFT
Tapered Flange Tee
TWT
Tapered Web Tee
TFWT
Tapered Flange, Tapered Web Tee
ANGL
Equal or Unequal Angle
RTUB
Rectangular or Square Tube
CTUB
Circular Tube
ZED
Z Profile
CEE
Flanged C Profile
BFLA
Bulb Flat
PLTG
Plate Girder
BOXG
Box Girder
FBAR
Flat Bar
RBAR
Round Bar
HBAR
Hex Bar
Copyright © 2015 AVEVA Solutions Limited and its subsidiaries. All rights reserved.
Parameters The following table shows the parameters: No. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 `15 16 17 18 19 20 21 22 23
Parameter Description Depth Width A Width B Width C Web Thickness Flange Thickness A Flange Thickness B Radius A Radius B Radius C CofG X Axis Offset CofG Y Axis Offset Flange Thickness Centre Offset Flange Slope (degrees) Web Slope (degrees) Gage Line A Gage Line B Gage Line C Maximum Bolt Diameter A Maximum Bolt Diameter B Mass per Unit Length Surface Area per metre Cross Sectional Area
Dkey DPTH WIDA WIDB WIDC WTHK FTKA FTKB RADA RAD B RAD C CGXO CGYO FTCO FSLO WSLO GLNA GLNB GLNC MBDA MBDB MAUL SAPM XSAR
Data Type Geometry Geometry Geometry Geometry Geometry Geometry Geometry Geometry Geometry Geometry Geometry Geometry Geometry Geometry Geometry Data Data Data Data Data Data Data Data
Copyright © 2015 AVEVA Solutions Limited and its subsidiaries. All rights reserved.
Parameters on Different Gtypes
Gtype PFI
Gtype PFC
Gtype ANGL Copyright © 2015 AVEVA Solutions Limited and its subsidiaries. All rights reserved.
Plines (1) All Gtypes will have common set of 14 standard Plines. 9 Plines will be at corners, mid-points and centre of a bounding box around the profile
Copyright © 2015 AVEVA Solutions Limited and its subsidiaries. All rights reserved.
Plines (2) 1 Pline is at the Neutral Axis (NA) and 4 Plines are positioned where lines drawn through the NA in the X and Y directions cross the bounding box.
Copyright © 2015 AVEVA Solutions Limited and its subsidiaries. All rights reserved.
Plines (3) Symmetrical profiles will have some coincident Plines. Asymmetrical profiles will have no coincident Plines.
Copyright © 2015 AVEVA Solutions Limited and its subsidiaries. All rights reserved.
Plines (4) Gtype specific Plines are added, as highlighted in red, where required to facilitate trimming of attached in all cases.
Copyright © 2015 AVEVA Solutions Limited and its subsidiaries. All rights reserved.
Plines (5) The Cconnect attribute of Standard Plines and Gtype Specific Plines, as highlighted in red, are set to ANY, as required.
Copyright © 2015 AVEVA Solutions Limited and its subsidiaries. All rights reserved.
Display Levels & Obstruction Values Generally Gtypes have two representations: – Simple, i.e. not root or toe radii – Actual, i.e. the actual shape of the profile
The Display Levels and Obstruction values are: Representation Simple Actual Obstruction
Display Levels 0-3 4-8 9 - 10
Obstruction Value 0 2 1
Gtypes CTUB, PLTG, BOXG, FBAR, RBAR and BFLA only have an Actual representation so Displays Levels are 0 – 8.
Copyright © 2015 AVEVA Solutions Limited and its subsidiaries. All rights reserved.
Display Levels & Obstruction Values Only ‘enclosed’ Gtypes, i.e. RTUB, CTUB and BOXG have obstruction geometry set to Levels 9-10
Copyright © 2015 AVEVA Solutions Limited and its subsidiaries. All rights reserved.
Design Parameter Profiles (1) Equivalent Design Parameter profiles are provided for most Gtypes: Gtype
Description
DPFI
Design Parameter Parallel Flange I
DPFC
Design Parameter Parallel Flange Channel
DPFT
Design Parameter Parallel Flange Tee
DANG
Design Parameter Equal or Unequal Angle
DRTU
Design Parameter Rectangular or Square Tube
DCTU
Design Parameter Circular Tube
DZED
Design Parameter Z Profile
DCEE
Design Parameter Flanged C Profile
DPLG
Design Parameter Plate Girder
DBXG
Design Parameter Box Girder
DFBA
Design Parameter Flat Bar
DRBA
Design Parameter Round Bar
DHBA
Design Parameter Hex Bar
DCON
Design Parameter Cone
DTWI
Design Parameter Tapered Web I
Copyright © 2015 AVEVA Solutions Limited and its subsidiaries. All rights reserved.
Design Parameter Profiles (2) Design Parameters are based on the common parameters for standard profiles and the same DKEYs are used. Only the required Design Parameters are used for each Gtype so there is no common data set and each Design Parameter Gtype has it’s own Data Set, Geometry Set and Pline Set. Examples of non-prismatic profiles using Design Parameters are also provided in the new profile catalogue.
Copyright © 2015 AVEVA Solutions Limited and its subsidiaries. All rights reserved.
Preferred Profile List (1) A list of ‘preferred’ profiles to be used on a project can be created in Paragon. The list contains only profiles, possibly from more than one Standard, that are available to the on a project. The list is created in Paragon using the Preferred Profiles button in the Create group on the SPECIFICATION tab.
Copyright © 2015 AVEVA Solutions Limited and its subsidiaries. All rights reserved.
Preferred Profile List (2) The Preferred Structural Profile Manager form enables Standards, Gtypes and Profiles to be selected.
Copyright © 2015 AVEVA Solutions Limited and its subsidiaries. All rights reserved.
Preferred Profiles (3) The form creates a Preferred Specification World (PSPWL) that contains TABGRO, CTABLE and TABITE elements representing the Standard, Gtype and Profiles respectively.
This ensures that the Spref attribute for a GENSEC is always set to the original catalogue reference. Copyright © 2015 AVEVA Solutions Limited and its subsidiaries. All rights reserved.
Preferred Profiles (4) If a PSPWL exists in a Project the profile selection gadgets in the Defaults group of the SECTIONS tab only display profiles in the Preferred Profile list.
Copyright © 2015 AVEVA Solutions Limited and its subsidiaries. All rights reserved.
ts and Fittings Catalogue (1) To compliment the steel profile catalogue, a ts and fittings catalogue of sample data has been provided. Sample ts include – – – –
Beam to beam ts Beam to column ts (web and flange) Splice ts Bracing ts
Sample ts include catalogue and template ts.
Copyright © 2015 AVEVA Solutions Limited and its subsidiaries. All rights reserved.
ts and Fittings Catalogue (2) Sample fittings include: – – – – – –
Baseplate fittings Stiffener fittings Lifting Lug fittings Padeye fittings Shear Stud fittings Scaffold Clip fittings
Copyright © 2015 AVEVA Solutions Limited and its subsidiaries. All rights reserved.
