Three-Wheel Electric Lift Trucks 3,000-4,000 lb Capacity

Comfort And Productivity Rugged, highly versatile three-wheel electric Cat® lift trucks can help your productivity. Their size and agility make them a smart choice in warehouses, on docks, and for loading and unloading trailers. Model

Capacity at 24 in Load Center

EP16KT

3000 lb

EP18KT

3500 lb

EP20KT

4000 lb

Each truck is available in 36-volt or 48-volt systems.

2

Spacious Floor Area Unlike compact trucks that compromise on the operator’s space, this truck offers an unusually large, flat, and uncluttered floor area. Additionally, the seat can be adjusted over a full six inches to give operators generous leg room. The cowl-mounted mechanical parking brake lever also frees up floor space.

3

Flex-Comfort Seat Belt

Easy Entry And Exit

An innovative Flex-Comfort seat belt is standard. It features a resilient section that gives the operator an extra measure of freedom when turning constantly to the side in reverse travel. An operator-presence switch under the seat is designed to disable drive and hydraulic motors when the operator leaves the seat.

A low-positioned, slip-resistant, open step and convenient grab bar allow any operator to step up and step down easily. The floor mat features a textured, slip-resistant rubber surface that helps reduce operator fatigue while muting drivetrain sounds.

Genuine Comfort And Body The seat’s contoured fit is designed for the operator who must shift and reposition the body repeatedly. A molded lip on the seat back helps give comforting arm and leverage to relieve back stress when moving the truck in a reverse direction. The bottom cushion is sculpted with side bolsters for thigh , and the back cushion provides lumbar and torso . A tough, wearresistant cloth seat breathes for cool comfort.

Low-Cost Replacement The seat’s practical two-piece design saves money; you replace only one piece at a time, not the entire seat assembly.

4

Infinitely Adjustable Tilt Steering Wheel The tilt steering wheel accommodates many operator comfort preferences. The system provides smooth positioning of the wheel over seven degrees of movement. The instrument is also mounted on the tilting column, so the operator can view truck functions at a glance.

Quick-Reach Conveniences A storage tray helps keep pens, markers, tools, and other materials handy. A beverage holder helps reduce spills during travel and cowl-mounted hydraulic controls are within easy reach.

Good Visibility Mast Operators who can view the forks and surroundings without contorting their bodies are more productive. Visibility through the mast is achieved with narrow flanges and deep web channels. Hose and chain routings are behind the mast. Square fork bars help optimize visibility through the carriage.

5

Informative Operator Display Lighted LCD displays include battery discharge indicator, travel speed, truck operating hours, drive motor hours, hydraulic motor hours, and clock. Real-time diagnostics include LED indicators for service interval, brush wear, over-temperature, low-battery warning, brake fluid levels, fault detection, and park brake.

On-Board Diagnostics A sophisticated, built-in monitoring and diagnostics system is standard—no external handset is required. The system displays the truck’s operational status on the operator’s console. If a fault occurs, the display signals the operator to take corrective action before permitting continued operation of the truck. These early indicators are designed to help keep the truck up and running.

Added Troubleshooting Capabilities The truck history folder allows the service technician to troubleshoot the truck historically by reviewing the last 32 fault codes. Each fault code includes battery state of charge and truck operating hours to indicate when the fault occurred. This data helps identify potential concerns.

Hydraulic Lift System A powerful, high-performance pump motor helps deliver fast lift and tilt speeds, and helps reduce the risk of overheating. Energy-efficient transistor-controlled hydraulics are standard and can deliver fully programmable, infinitely controlled hydraulic speeds with an exceptionally smooth, quiet operation.

6

62˚ 72˚ 90˚

Simplified, Quiet Controller

Wheel Angle Sensor

The Cat MicroCommand SX control system helps give this three-wheel lift truck its excellent performance and energy efficiency. The exclusive technology combines rugged dependability and remarkable simplicity with quiet operation and easy servicing. The MicroCommand SX controller uses substantially less serviceable parts compared to a traditional controller. Directional ors are eliminated, reducing the number of replacement parts. The controller is mounted to the counterweight, which serves as an integrated, efficient heat sink, so the system operates at low temperatures. All controller components are protected by a weather-resistant metal cover and can be accessed without special tools.

When the operator turns the wheel, the MicroCommand SX control system uses a wheel angle sensor to distribute proportional power to the independent motor driving each wheel. The inside wheel slows until, at 62˚, power is minimized. At 72˚, the inside wheel begins reversing with increasing speed, until in a maximum turn, it moves in reverse at a speed equal to the forward-moving outside wheel. This continuous, proportional control helps allow the truck to turn within its own length, while improving traction on wet and uneven surfaces.

Customized Performance Receiving Office

B

E

Shipping

C

A

Outside Storage

D

Customers can choose from five programmable operating modes to help match performance characteristics to any application. Authorized personnel can further adjust a number of performance settings individually within a mode, offering customization involving a change in operators or application demands. This customer-oriented versatility helps ensure product protection, efficient energy management, and maximum productivity. Full Range of Programmable Modes: • APPLICATION A: General warehouse utility: high travel speeds, moderate lift requirements • APPLICATION B: High performance: fast acceleration, high lift/tilt speeds • APPLICATION C: Economy: slow acceleration, low travel speeds, moderate lift/tilt speeds • APPLICATION D: Long travel: high travel speeds, moderate lift/tilt speeds • APPLICATION E: Short shuttle (dock work): low travel speeds, fast tilt speeds, moderate lift speeds

7

Powerful, High-Torque Drivetrain These Cat lift trucks feature an exclusive, heavy-duty, geared drivetrain that delivers high performance at noticeably quiet operating levels. Dual-drive motors produce a power-packed 4.5 kw each. Three-stage helical gears provide main reduction for essential hightorque performance and travel speeds up to 9.9 mph. You approach the performance of a four-wheeler with the maneuverability of a three-wheeler.

Cushion Tires Are Standard Cushion tires offer low rolling resistance with excellent capacity retention and stability at high lift in indoor applications. To extend the truck’s versatility to indoor and outdoor work, solid pneumatic-shaped tires are available. Pneumatic-shaped tires help provide greater operator comfort, more shock absorption, and traction on wet surfaces.

Dual-Steer Tires Are Standard Unlike single-steer tire systems, dual-steer tires distribute turning stress and wear over a greater area. This reduces bearing and spindle loads and saves changeouts of components and tires. The double footprint also helps increase traction and capacity retention.

Rack-And-Pinion Steering Also standard on this three-wheeler is power-assisted, hydrostatic rack-and-pinion steering, which reduces steering effort. The steering axle is linked to two symmetrically arranged rear wheels. Loads are ed by the steer axle and the tapered roller bearings of the pinion gear.

Effortless Braking Extra-thick rotors and an enlarged pad-to-rotor area quickly dissipate heat. Operators will sense that minimal foot pedal pressure can provide effective braking. The outboard location of the brakes also enhances cooling and makes them easily accessible to service. Regenerative braking is standard. When the operator changes direction, the MicroCommand SX system induces electric braking, which helps extend both brake and brush life, and displaces heat build-up in the motor.

8

Ask For A Demonstration The advantages of the 3,000-4,000 lb capacity three-wheel electric lift truck become obvious with a demonstration. See strong proof that Cat lift trucks and your Cat lift truck dealer can offer you more productivity-driven benefits for a strong return on your equipment investment. Call for an appointment today.

9

SPECIFICATIONS CHARACTERISTICS CHARACTERISTICS 1 2 3 4 5

Capacity Power Tire type Wheels (x = driven)

EP16KT MODEL

at rated load center at load center – distance diesel, gasoline, LP gas, electric cushion, pneumatic number front / rear

lb kg in mm

3000 24

EP18KT MODEL 1600 500

3500 24

EP20KT MODEL 1800 500

4000 24

2000 500

electric cushion 2x/2

electric cushion 2x/2

electric cushion 2x/2

177 3730 130 3330 4.5 115 1.4x42x4 35x1067x100 9.4/36 240/920 6/7 74.5 1900 42 1070 42 1070 83 2105 40 1016 80.5 2040 179 4550 60 1520 15 381 75 1900

177 4120 130 3330 4.5 115 1.4x42x4 35x1067x100 9.4/36 240/920 6/7 79 2000 42 1070 42 1070 83 2105 40 1016 80.5 2040 179 4550 64 1620 15 381 79 2000

178 3580 130 3330 4.5 115 1.4x42x4 35x1067x100 9.4/36 240/920 6/7 80 2035 42 1070 44.5 1130 83 2105 40 1016 80.5 2040 179 4550 65 1645 15.4 392 80 2035

DIMENSIONS DIMENSIONS 10 11 12 13 14 15 16 17 18 19 20 21 22 23

Lift Lift with standard two-stage mast

maximum fork height with rated load maximum fork height free fork height Forks thickness x length x width Fork spacing out-to-out minimum / maximum Tilt forward / backward length to fork face with standard cushion tires width w/optional solid pneumatic tires Overall with lowered mast dimensions seat height height to top of overhead guard with extended mast Minimum outside turning radius Load moment constant Minimum aisle – 90° stack – zero clearance + load length

in in in in in

mm mm mm mm mm

in in in in in in in in in in

mm mm mm mm mm mm mm mm mm mm

PERFORMANCE\ PERFORMANCE 40 41

36V 48V 36V lift speed loaded / empty 48V 36V lowering speed loaded / empty 48V 36V loaded (60 min. rating) 48V loaded maximum (5 min. rating) 36V 48V 36V loaded at 1 mph (1.6 km) 48V 36V maximum loaded / empty 48V travel loaded / empty

Speeds

42

43

Drawbar pull

44

Gradeability

mph km/h mph km/h fpm m/s fpm m/s fpm m/s fpm m/s lb N lb N lb N lb N % % % %

8.1/9.3 8.7/9.9 59/89 79/120 100/98 100/98 600 600 1360 1360

13/15 14/16 .3/.45 .4/.6 .52/.5 .52/.5 2660 2660 6070 6070

8.1/9.3 8.7/9.9 57/89 77/120 100/98 100/98 580 580 1340 1340

13 13 19 / 30 19 / 30

13/15 14/16 .29/.45 .39/.6 .52/.5 .52/.5 2570 2570 5980 5980

8.1/9.3 8.7/9.9 55.1/89 75/120 100/98 100/98 560 560 1320 1320

12 12 17 / 28 17 / 28

13/15 14/16 .28/.45 .38/.6 .52/.5 .52/.5 2470 2470 5890 5890

11 11 15 / 26 15 / 26

WEIGHT WEIGHT 50

Empty

w/minimum weight battery with rated load

51

Axle load without load

front rear front rear

lb lb lb lb lb

kg kg kg kg kg

6800 8660 1140 3300 3500

3100 4180 520 1510 1590

7300 9500 1300 3550 3750

3300 4510 590 1600 1700

7700 10270 1430 3500 4200

3525 4875 650 1615 1910

CHASSIS CHASSIS 60 61 62 63 64 65 66 67 68 69 70

Tire size

front, standard cushion tires front, optional solid pneumatic tires rear cushion tires

Wheelbase Tread width Ground clearance Brakes

front, standard cushion tires front, optional solid pneumatic tires rear cushion tires at lowest point @ mast at center of wheelbase service parking

in in in in in in in in in

mm mm mm mm mm mm mm mm mm

18x7x12 18x7-8 15x5x11.25

51.5 35 36 6.5 2.9 3.9

457x178x305 457x178x203 381x127x286

1305 894 913 170 75 100 mech / hyd mechanical

18x7x12 18x7-8 15x5x11.25

55.5 35 36 6.5 2.9 3.9

457x178x305 457x178x203 381x127x286

1410 894 913 170 75 100 mech / hyd mechanical

18x7x12 457x178x305 200/50-10 15x5x11.25

55.5 35 37 6.5 2.9 3.9

381x127x286

1410 894 935 170 75 100 mech / hyd mechanical

POWERTRAIN POWERTRAIN 80 81 82 83 84 85 86 87 88 89 90 91

Battery

Motors

Controls Relief pressure Noise level

type voltage / capacity @ 5 hr. discharge volts / AH voltage / capacity @ 5 hr. discharge volts / AH weight, minimum lb kg traction output 36V (60 min. rating) HP kW traction output 48V (60 min. rating) HP kW lift output 36V (20% rating) HP kW lift output 48V (20% rating) HP kW drive type / speed hydraulic type / speed for attachments psi bar mean value at operator’s ear dB(A)

lead-acid 36 / 675 48 / 600

lead-acid 36 / 825 48 / 720

lead-acid 36 / 825 48 / 720

1910 865 6 4.5 6 4.5 11.6 8.7 15.4 11.5 IGBT transistor IGBT transistor 2625 180 68.4

2200 1000 6 4.5 6 4.5 11.6 8.7 15.4 11.5 IGBT transistor IGBT transistor 2625 180 68.4

2200 1000 6 4.5 6 4.5 11.6 8.7 15.4 11.5 IGBT transistor IGBT transistor 2625 180 68.4

NOTE: These specifications assume the use of drive axles, tires and tilt angles specified. Any modification to specifications, or any other combination of specifications made after the shipment of the truck, requires prior written approval from Mitsubishi Caterpillar Forklift America Inc. (“MCFA”). (See ANSI B56.1 Part II 4.2.) Also be advised that overall operating visibility may be affected by the mast configuration and mast options of your lift truck. Therefore, you may need to add ancillary [auxiliary] devices or modify your operating practices. Consult your dealer for further information.

10

14

Call-out numbers shown in the diagram below correspond to the first column of the specifications chart.

20 11

17

19

18

12 68 67 13 22

63 15

13

+

13

64

16

21

13

Standard Battery Compartments* Length in mm

Width in mm

Height in mm

EP16KT

20.9 531

40

1016

24.8 630

EP18KT

24.9 634

40

1016

24.8 630

EP20KT

24.9 634

40

1016

24.8 630

Connector, SB 350 Gray, Lead Length 20 in (505 mm), Position B *Deduct 0.5 in (13 mm) from each dimension for maximum battery size.

23

SAFETY STANDARDS These trucks meet American Society of Mechanical Engineers (ASME) B56.1, part III Safety Standards for powered industrial trucks. UL-Classified by Underwriters Laboratories, Inc., as to fire and electric shock hazard only. Types E, EE (optional), Industrial Trucks. s should be aware of, and adhere to, applicable codes and regulations regarding operator training, use, operation and maintenance of powered industrial trucks, including: • ASME B56.1, part II. • NFPA 505, fire safety standard for powered industrial trucks - type designations, areas of use, maintenance and operation. • Occupational Safety and Health istration (OSHA) regulations that may apply. Specifications, equipment, technical data, photos and illustrations based on information at time of printing and subject to change without notice. Some products may be shown with optional equipment.

11

DD u ra u ra b ibliiltiyt yA & n dS u S up p po or tr t

C a t l i f t t r u c k d e a l e rs p u t

Unlimited Hours Warranty covers parts and labor for one year,

c u s t o m e r n e e d s f i rs t , w i t h

regardless of service hours.

t h e m o s t c o m p re h e n s i ve c u s t o m e r s u p p o r t p ro g ra m s

Parts Fast or Parts Free Guarantee ensures next-business-day delivery of parts for all brands of lift trucks or they are free,

i n t h e i n d u s t r y.

including freight. Free Loaner Service Guarantee provides a lift truck until the repair is done if your lift truck is not repaired right the first time and within the quoted time. your Cat lift truck dealer for complete and conditions of these guarantees.

Cat Lift Trucks offers an extensive range of products and services. Your Cat lift truck dealer can provide options and additional visual and audible warning devices geared toward your specific applications and requirements. Operator training programs are also available to boost productivity and to help reduce the potential for product damage and personal injury. Your Cat lift truck dealer can also provide a variety of financing and leasing options to suit the needs of your business.
