EL ESTADO DE PLASMA El plasma es por mucho la forma más común de la materia. El plasma en las estrellas y en el espacio constituyen más de 99% del universo visible y quizás la mayoría de lo que no es visible. El plasma consiste en una colección de electrones de libre movimiento e iones de átomos que han perdido electrones. Se necesita energía para despojar electrones de los átomos y hacer plasma. La energia puede ser de varios origenes : térmica, eléctrica, o luz (ultravioleta o la intensa luz visible de un láser).

El plasma puede acelerarse y ser dirigido por campos eléctricos y magnéticos que permiten controlarlo y aplicarlo. La investigación del plasma está rindiendo una comprensión mayor del universo.. También proporciona muchos usos prácticos: nuevas técnicas industriales, productos para el consumidor, y la perspectiva de energía abundante. 3/74

EL ESTADO DE PLASMA

4/74

EL ESTADO DE PLASMA Ejemplos.) El Relámpago, Aurora, Nebulosa, Llamas, Señal de Neón, Núcleo Solar,…

5/74

EL ESTADO DE PLASMA El elemento central en una luz fluorescente es el Plasma, un gas compuesto de iones con libre movimiento (átomos cargados eléctricamente) y electrones (partículas cargadas negativamente). Bajo condiciones normales un gas se compone principalmente de partículas no cargadas. Esto significa que cada átomo de gas incluye igual número de protones (partículas positivamente cargadas en el núcleo del átomo) y electrones. Los electrones negativamente cargados equilibran perfectamente a los protones positivamente cargados, así que el átomo tiene una carga neta de cero. Si se introducen muchos electrones libres en el gas por medio de un voltaje eléctrico a través de él, la situación cambia muy rápidamente. Los electrones libres chocan con los átomos, al golpearlos liberán otros electrones. Con un electrón perdido, un átomo pierde su equilibrio, Ahora tiene una carga neta positiva, convirtiendolo en un ion positivo. En un plasma con una corriente eléctrica que lo atraviesa, las partículas negativamente cargadas están apresurándose hacia el área positiva del plasma, y las partículas positivamente cargadas están apresurándose hacia el área negativa. 6/74

EL ESTADO DE PLASMA Las partículas están chocando constantemente entre ellas. Estas colisiones excitan los átomos de gas en el plasma, originando la liberación de fotones de energía.

7/74

LA CELDA DE PLASMA En su forma más simple, una celda de Plasma consiste en dos placas de vidrio separadas por un espacio lleno de gas. El color es dependiente de la mezcla del gas. En las caras Internas de las placas estan dos electrodos transparentes fijos horizontal y verticalmente cubiertos por una capa delgada de vidrio aislante.

Los electrodos se conectan a una fuente de poder, esta fuente genera corriente alterna al modelo de carga. La dirección positiva ( + ) (no el lado cargado positivamente) es mostrado en la figura y la dirección negativa es la designada por el signo negativo ( - ). 8/74

LA CELDA DE PLASMA •La fuente de poder genera un Voltaje de Sostenimiento (Vs – sustain voltage) igual a medio Voltaje de Encendido (1/2Vf - firing voltage ) para la mezcla gas. •Para encender la celda es necesario una Señal de Encendido (Vfs - firing signal voltage) igual tambien a 1/2 Vf. •Una vez que esto ocurre las dos cantidades se suman ( Vs + Vfs = Vf ) y se enciende el gas. •Esto es solo la medio ciclo. •Vfs se desconecta y Vs se pone en cero (0) por un instante y sólo hay un voltaje en el interior de la celda (V1) qué es igual a 1/2 Vf en ese instante y ningún voltaje externo (Vs), cuando el generador cambia de d irección hay una cantidad de electrones y carga positiva en el interior de la celda (V1). •Al sumar los voltajes V1+Vs obtenemos Vf nuevamnete y la celda se enciede. •Vfs firing signal voltage : es solo necesario para iniciar el encendido •Cambiar el voltaje (Vs) de las paredes de cristal mantiene encendida la celda 9/74

LA CELDA DE PLASMA EL PDP es la última tecnología de pantallas y la mejor manera de lograr imagenes con calidad excelente y los tamaños grandes visibles en cualquier ambiente. El PDP puede verse como un descendiente de la lámpara de neón y también ha sido sido modelado como una serie de lámparas fluorescentes. PDP es una serie de celdas conocidas como pixeles que estan compuestas de 3 subpixeles, correspondiendo a los colores rojo, verde, y azul. El Gas en un estado de plasma se usa para reaccionar con Fósforo en cada uno de los sub-pixeles para producir luz de color. Estos Fósforos son del mismo tipo que los usados en el “CRT” para los dispositivos como televisiones y monitores de computadora. Usted obtiene los colores vivos y dinámicos que espera. Cada sub-pixel es controlado individualmente por electrónica avanzada para producir más de 16 millones de colores diferentes. Todos esto significa que usted consigue imágenes perfectas que son fácilmente visibles en una pantalla que tiene menos de 5 pulgadas de grueso. 10/74

LA CELDA DE PLASMA Los electrodos transparentes estan rodeados por un material dielectrico y son cubiertos por una capa protectora de óxido de magnesio, estan montados sobre la celda a lo largo de la placa frontal de vidrio.

Los electrodos para despliege de imagen se colocan en filas horizontales a lo largo de la pantalla y los electrodos de dirección se colocan en columnas vertical es, los electrodos verticales y horizontales forman una reja básica (matriz). 11/74

LA CELDA DE PLASMA Para ionizar el gas en una celda particular, el ordenador de la pantalla carga los electrodos que se cruzan en esa celda, esto lo hace miles de veces en un pequeño fragmento de segundo, cargando cada celda a la vez.

12/74

LA CELDA DE PLASMA Los fotones ultravioletas liberados interactúan con el material de fósforo que recubre la pared interior de la celda. El fósforo es substancia que emite luz cuando se le expone a otra luz. Cuando un fotón ultravioleta golpea a un átomo del fósforo en la celda, uno de los electrones de fósforo salta a un nivel de energía más alto y el átomo se calienta, cuando el electrón regresa a su nivel normal, suelta energía en forma de fotón visible.

13/74

LA CELDA DE PLASMA Variando los pulsos de corriente a través de las diferentes celdas, el sistema de control puede aumentar o disminuir la intensidad de cada subpixel de color para crear centenares de combinaciones diferentes de rojo, verde y azul.

14/74

LA CELDA DE PLASMA

15/74

LA CELDA DE PLASMA

DESCARGA EN GAS

GENERA UV 16/74

LUZ VISIBLE

IMAGEN

LA CELDA DE PLASMA

17/74

Flujo de fabrication

18/74

ESTRUCTURA BASICA DE FILTRO OPTICO (Screen Filter)

Características de Filtro Optico -. Reducir Radiacion Electromagnetica y NIR (emision de luz infraroja). -. Regulacion EMI (FCC clase-A para uso en Industria, clase-B para uso domestico) -. Control de transparencia (40 ~ 70%), ex) FCC -. Control del color : Temperatura del color \ -. Reducir Reflection en superficie -. Mejora of Contrast -. Proteccion de PDP

19/74

Estructura Asimétrica de la Celda PDP es innovador en su estructura de la celda asimétrica (anchura diferente del fósforo) esto mejora el equilibrio luminoso de los tres colores primarios, produciendo un brillo alto y puro, un blanco vivo con temperatura de color alta. R

G

R

B

Estructura Convencional

G

Estructura asimetrica * Mejora de la calidad del color * Alto Brillo

20/74

B

El Plasma Display (PDP)

Diagrama de Pixeles 639th pixel column

1st pixel 2nd pixel column column

Pixel Pitch(width)

R G

B R G

R G

B

R G B

pitch(height)

Pixel

Cell pitch R : 0.336mm G : 0.417mm B : 0.504mm Cell

1.257mm

1st pixel row

640th pixel column

B R G

B

R G B

B R G

B

R G

B R G

B

R G

B R G

B

R G

B R G

B

479th pixel row

R G

B R G

B

R G

B R G

B

480th pixel row

R G

B R G

B

R G

B R G

B

3rd pixel row

1.252mm

R G

2nd pixel row

21/74

El Plasma Display (PDP) Address ( Data ) ( X )

Pulse

Sustain Pulse Scan Base Pulse

Scan1 Scan 2

Scan Pulse

Scan 480

Data

Data Pulse

22/74

Sustain Pulse

El Plasma Display (PDP)

Sustain output

Scan output

① : set-up ② : set-down ③ : scan base ④ : scan ⑤ : sustain ⑥ : sustain ⑦ :eraser

23/74

El Plasma Display (PDP) PDP TV/ Monitor

24/74

El Plasma Display (PDP)

Controller B/D Block

26/74

X Driver B/D Block

DRIVE IC

27/74

Y Driver B/D Block

28/74

Y_waveform

29/74

Z Driver B/D Block

30/74

Z waveform 180v

set_up

Address

E/r_up

E/r_dn Sus_up Sus_dn Rmp_up

31/74

sustain

Set up

Set down

280 V

Scan(Y)

180 V

180 V 70 V

Common sustain(Z)

180 V

180 V

70 V

Data (X)

Setup

Scan ( Address )

32/74

Sustain

Erase

SUSTAIN TIME CHART Y-ER-UP

Y-SUS-UP

Y-ER-DN

Y-SUS-DN

Z-ER-UP Z-SUS-UP

Z-ER-DN

Z-SUS-DN

2450 Y-SUS

2325 Z-SUS

0

33/74

34/74

Sustain output

①

②

③④

③

⑤⑥

① : set-up ② : set-down ③ : scan base ④ : scan ⑤ : sustain ⑥ : sustain ⑦ : eraser

35/74

⑦

Y

Z

36/74

37/74

Brightness Control

38/74

ADS

39/74

40/74

41/74

write, sustain, erase

3. writing, sustain, erase

42/74

Supply Voltage Sequence

Power On/Off sequence Turn On Sequence : +5V → +15V → Va → Vs, Vset up, Vsc Turn Off Sequence : Vs, Vset up, Vsc → Va → +15V → +5V 43/74

Input Signal Timing(Non-interlaced Mode)

44/74

COMPOSICION DEL PLASMA

45/74

COMPOSICION DEL PLASMA

46/74

PSU & VSC Board

47/74

COMPOSICION DEL PLASMA

48/74

Function Descriptions

49/74

Block Diagram of PDP Module(40 Inch)

50/74

PDP Display(TV) Block Diagram (40” Inch : MN-40PA10)

51/74

PDP Tuner Block Diagram(1) (40” NTSC STB)

52/74

VSC Block Diagram(1)

MN--40PA10 MN--40PA10 VSC VSC Board Board Block Block Diagram Diagram

53/74

54/74

VSC Block Diagram(2)

40”/42” 40”/42” Multi Multi PDP PDP VSC VSC BLOCK BLOCK DIAGRAM DIAGRAM

R,G,B,Hs,Vs 오디오 앰프

STB STB_L, STB_R

Flat 형식으로 신호를 변환

L,R LA4282

STB/Video음성 선택 switch L,R

PC

2M-SDRAM

MICOM CXP750010

Buffer HC541

MX88L284

R,G,B,Hs,Vs LA7222

L,R

CXA2022S PDP module

clk P_V Vs와 Hs동기화

CVBS

R,G,B

음성신호 처리 Video

HC74

L,R

Vs

P_H

Y,U,V DVD

VPC3230

Y,U,V,Hs,Vs

Y,U,V,Hs,Vs

SDA9410

CXA2101

R,G,B,Hs,Vs

THS8083

Y,Pb,Pr

R,G,B,Hs,Vs,Y,Pb,Pr Comb filter 영상신호를 디지털화

Interlace주사를 Progressive주사로 변환 15KHz→31KHz

55/74

ADC Multi-Component Processor Analog R,G,B출력

EU/N-EU Multi PDP MNT VSC

VSC Block Diagram(3)

42”/60” 42”/60” New New VSC VSC BLOCK BLOCK DIAGRAM DIAGRAM MONOSTABLE MULTIBIB. (74LS123)

RGBHV 5

VIDEO SWITCH (M52758FP)

RGBHV 5

CLAMP_AD

SOG_OUT

RGB 3

MEMORY (6M-BYTE)

8bit 135Mhz ADC(3), PLL(3), PIP,Gamma, High Order 3’rd generation Scaling

A/D CONVERTER H

3

(CXA3516R)

SCALER

PLLH/CLK 2

TMDS TX 4

(JAG200)

H/V SOG Y/C

H/V/DE/CLK

8

(SII150)

V H

CVBS

RGB 3 DISP_EN

H/V 2 YCbCr/ YPbPr

COLOR DECODER (VPC3230D)

Digital Component Video Doubler

5

H/V/ De-Interlacer/Line FIELD/ LLC1 4

2 YUV

Comb Filter Video Processor high quality video front -end, which is targeted for 4:3 for 16:9, 50/60 & 100/120Hz TV sets, color decoder PAL/NTSC/SECAM PIP processing

DEINTER -LACER (FLI2200)

MEMORY (4M-BYTE)

RGBHV H

Digital Video Enhancer (FLI2220)

H/V 2

V H/V/CLK/ HBLK/VBLK

Y,U,V,H,V

5

COLOR CONTROL & VIDEO SWITCH (CXA2101Q)

Y,Pb,Pr(MNT) 3 Y,Pb,Pr(STB) 3

AUDIO R

L

AUDIO AMP LA4282 (L & R)

PORT EXP (M62320X4)

(74HCT373)

MICOM

AUDIO SWITCH (LA7222)

ROM (AT29C010)

EEPROM X2416P

56/74

EPLD

5 Clamp

(GEN. CLAMP)

Multi-Component Processor (Baseband Video Signal Processor) bipolar IC which integrates baseband signal processing, RGB signal processing and 4 video switching systems (including HV sync signal processing) using YCbCr inputs developed for multi -scan TV & configuring high-end TV systems

(JAG200 & FLI2200)

21P

PSU Block Diagram(1)

PDP Display 36”/40” Power Board

Vsc TRANS

B Vsetup TRANS

CEMENT 저항

C

H CEMENT

CEMENT

VR 3 805 CEMENT Vset

I

5V Inductor HEAT SINK

Multi Inductor

VR803 (Va)

HEAT SINK

MULTITRANS

VR801 (32V Adj.)

Vs TRANS

Drive

E

VR802 (5V Adj.)

Vs INDUCTOR TRANS

4 VR CEMENT 804 Vs Vs

D

Va Inductor

1

VR 2 806 Vsc

HEAT SINK

HEAT SINK

A

F

VR802 : Va adjust (typ.70±5V) VR804 : Vs adjust (typ.180±5V) VR805 : Vsetup adjust (typ.275V) VR806 : Vsc adjust (typ.75V)

Multi Drive

ST-BY TRANS

CEMENT

HEAT SINK

HEAT SINK

HEAT SINK

J G

A: Vsc(75V)Trans B: Vsetup(275V) Trans C: Va Inductor Trans D: 5V Inductor Trans E: Multi Inductor Trans F: Multi(5V/15V/12V/30V/Va)Trans G: St-By(5V/15V)Trans H: Vs Inductor Trans I : Vs(180V)Trans J: PFC Inductor Trans

TRANS PFC Inductor

AC In

EMI(Line Filter) 57/74 Pack

EMI

Power Switch

PSU Block Diagram(2) AC Input 90Vac~265Vac Rectifier DIODE

ST-BY

5V

STR-G6100

15V

Relay

380V PFC MC33262

5V Forward Type TL494

15V 12V 30V

Rectifier DIODE

36”,40”PDP POWER BLOCK Diagram

58/74

RCC Type TL494

Va 75V

Half-Bridge Type TL494

Vs 180V

RCC Type TL494

VSC 75V Vsetup 275V

PDP Tuner (Set Top Box)

SMPS Board

RT-BA10(N-EU Multi) RZ-BA10(EU Multi) RN-BA10(NTSC) RP-BA10(Latin America)

Interface Board

Top View

Back (Signal Input) Main Board

Inside

59/74

TD-620(PD-40X2/FD-60X3R STB)

12P

STB-CONTROL B/D

PF01

P001 12 P

Power Switch

STB - MAIN P403 Tuner

P002 10P

P402

P401

12P

10P

7P P003

8P

10P P810S

STB POWER 8P P870S

12P PX002

10P

7P

PX001

PX003

STB Interface B/D

60/74

PDP Tuner Block Diagram(2)

40”/42” 40”/42” Multi Multi STB STB Main Main BLOCK BLOCK DIAGRAM DIAGRAM RT-BA10/RZ-BA10 (EU/N-EU Multi System STB) L/R

PC RF

IF IC TDA4474A

TUNER

2’nd SiF

MSP3410D

CVBS

S-VHS

Sound Processor L/R(tv)

Y/C

SRS Block

L/R

※ AUDIO

Ext.Input 3

MNT-OUT

CVBS.3

CXA2069Q

C

TPU3050

CVBS1/Y

TELETEXT

A/V SW H

TV, L/R

VPC3230D (SUB) Video Proessor

FB

VPC3230d (MAIN)

C DVD_Y L/R

RGB CXA2101Q

Y,Pb,Pr(DTV)

V WE

Ext. Input 1

RE

Vido Proessor

Y,Pb,Pr(DTV) EXT_RGB

(RCA JACK)

61/74

81V04160 FIFO Memory

RGB

SDA9410 1H/1V=> 2H/ 1V DW / PIP / MPIP

Y,Cr,Cb (DVD)

DVD/DTV

H/V

RGB Processor

RGB

V, L/R

(SCART1: FULL)

RGB S/W

CVBS.2/Y V, L/R

(SCART2 : HALF ) (or RCA Jack in/out) TV-OUT

RGB

V, L/R

(RCA JACK)

Ext.Input 2

BA7657F RGB(PC)

PDP Tuner Block Diagram(3)

RT-BA11(STB) RT-BA11(STB) Board Board Block Block Diagram Diagram

RGB(PC)

PDP Tuner Receiver Block with 2 Tuner PIP

(Korea/USA/Latin America)

Ro

L/R

PC

Lo MSP3401G 2’nd SiF TUNER.1

TUNER.2

RGB(PC)

Sound Processor

TV (M)

M52758FP RGB/YUV S/W

RGB (DTV)

L/R(tv) TV (S)

L/R(tv)

M52756FP CVBS Y,Pb,Pr(DTV)

VPC3230D (SUB) Video Proessor

Y/C

S-VHS

Y/C

CXA2069Q

※ AUDIO

Ext. input1

OPTION

RGB

RGB/YUV S/W

RGB(OSD)

CXA2119M S/W

Y/C V, L/R

A/V SW

CVBS

DCF WE

MS81V04160 Ext.Input2

V, L/R

VPC3230D

Y/C

LGTV1001 DRP

Vido Proessor

Y,Cr,Cb (DVD) Y,Pb,Pr(DTV)

DVD/DTV (RCA JACK)

FRAME MEMORY

(MAIN)

DVD_Y MNT_OUT

RE

62/74

+

YUV

MT-40PA10 Inter-Connection(1)

6p

4p

CON302

PDP MODULE (Upper X-Board)

6p

CON301

Z-Board (Sustain)

8p

CON3 CON2

Y-Board (Scan)

8P CON300 PDP Control 40P Board 12P CON102

8P CON102 12P CON101

CON100 CON304

PDP MODULE (Lower X-Board)

6p

7p Local Key Board Local Key Board 7P P004A

VSC

P003A

6P

P002A

P007A 4P

P006A 4P

4P P007A

CON303

P801 P802

POWER SW.B/D 8P P801

4p

8p

P802 P803

6P P814

6P P812 6P P811

6P P813 4P P810

40P PD501

SPEAKER

6p

8P P807

POWER

12P P005A

12P P809

7P

7P P815 2P CN801

P003A

63/74

2P

EMI pack

MT-40PA10 Inter-Connection(2) MT-40PA10 MODULE 6P

600mm G04K

PDP PDP MODULE MODULE (Upper (Upper X-Board) X-Board)

CON302

4P

8P

CON3

CON2

Y-Board (Scan)

CON300 8P 7P P004A

OK 8P P801

P002A 6P

(G04D) 250mm

4P P007A

4P P810

aa 150mm G12B

12P P809

P003A 7P

150mm G07B

7P P815

1000mm G06P

700mm(G06L)

P003A

8P CON102

P812 6P P811 6P

6P P813

SPEAKER

CON304

8P

P802 P803

P005A12P

150mm(G04B) P007A 4P

4P

6P P814

VSC

4P

6P

300mm G06E

CON100 100mm 40P 40P PD501 P006A

7P

CON301

500mm(G06J) 400mm G08G

950mm G07P

6P

PDP MODULE (Lower X-Board)

6P

CONTROL

POWER

P807 8P

OK

Z-Board (Sustain)

2P CN801 2P

EMI Pack

CON303 P801 P802

POWER SW. 64/74

PSU Block Diagram(3) PDP Display 60” POWER BOARD Structure

AC - DC

DC - DC 60” Power Board

A 저 항

A: St-By(5V) Trans F U S E

MULTI TRANS

CAP

B: PFC Inductor

D

C: Trans for Vs,Va Vcc PFC

D: Multi(5V/6V/12V/30V)

Inductor

B

E

G

F

VS

VS

trans

trans

Trans VA

E: Vs(175V) Trans 1

trans 저

저

저

항

항

항

F: Vs(175V) Trans 2

CEMENT 저항 CEMENT 저항

R R R C CAP

CAP

CAP

65/74

G: Va(75V) Trans

PSU Block Diagram(4) Rectifier DIODE

60”PDP POWER BLOCK DIAGRAM ST-BY

AC Input 90Vac~265Vac

5V

TINY 255P Relay

380V PFC UC 3854 TINY 255P

FLY BACK Type STR-F6668B

5V 6V 12V 30V

Rectifier DIODE

66/74

CURRENT RESONANT Type UC 3863 IR 2113

Va 75V

CURRENT RESONANT Type UC 3863 IR 2113

Vs 175V

PSU Block Diagram(5) 60” Power Board Check Sheet

DC – DC

MICOM

R 8 5 3 8 (Yellow) LED D017

VSC

P8011(5V) RR 8 8 5 5 3 4 9 0

AC – DC R8301 R8302 R8303 EMI

AC IN

Va P8012(Va/Vs) Vs

Symptom : Return to ST-BY mode after several seconds 1.Check Cement Resistors 8301, R8302, R8303- on AC-DC Board(10W 4.7 Ohm) => They can be damaged from in-rush current 2.Check R8538,R8539 & R8540 on DCDC Board (10W 6.8 Ohm) 3.Check the connection of 4 Sub-Pack ASSYs of AC-DC & DC-DC Board. 4.Check between Va of P8012 and GND and Vs and GND, respectively(ON & OFF condition) -.Va Voltage(Normal) : 165 ~ 175Vdc -.Vs Voltage(Normal) : 65 ~ 80Vdc 5.Check between 5V and GND terminal of P8011. * If 5V/Va/Vs terminals are short to GND, there is some problem on Drive of PDP module. Check DC-DC Board of PDP module.

* If any fan out of three fans located above doesn’t operate, it is Fan Fail Mode. In this case, you can forcibly stop Power off operation by Fan Fail Mode by connecting two pins-Yellow wire and Black wire connected-of connector on VSC Board which defect Fan connected. LED(D017) on VSC Board warns you Fan Fail Mode.(In Fan Fail Mode, LED turns on.)

67/74

PDP Module Inter-Connection ZCNT TOP B/D ASSY

X LEFT TOP B/D ASS’Y

X RIGHT TOP B/D ASS’Y

EXTERNAL CABLE CONNECTION

P301

P302

Connector

Label

P15

P301~P304 P15 P14 P102 P300

P14 P300

P102

VR1

P100

ZSUS B/D ASSY YDRV B/D ASSY

CTRL B/D ASSY SUS_OUT

TP3

GND

GND

VR2

VR27

P304

X LEFT BOTTOM B/D ASS’Y

X RIGHT BOTTOM B/D ASSY

P303

ZCNT BOTTOM B/D ASSY

YDRV B/D ASSY

68/74

Supply Voltage 5V, 15V, VA VSC, VSETUP 5V, 15V, VS 5V, 15V, VS 5V

PDP Module Heat Sink

Power Board

69/74

MN-40PA10 (PDP) connection Interface between MN-40PA10 Korean PDP TV and other connector MN-40PA10 connection

RGB-PC input(VGA,SVGA) RGB-DTV(480P/720P/1080i)

External Input (Right-Voice Left-Image

Voice input Right - Left RGB-PC/DTV

Y, PB, PR

COMPONENT ( 480i /480P/720P/1080i ) DVD / DTV INPUT

Component Voice

Composite Video (Input output)

DVD ( 480i / 480P )

Set Top Box ( HD STB )

70/74

MN-40PA10 (PDP) connection MN-40PA10 MNT RN-BA10 Analog STB connection

RGB-PC input (VGA, SVGA)

PC

RGB-DTV input (480P/720P/1080i) RGB INPUT/CONTROL VOICE OUTPUT right/left 25Pin D-Sub.

RGB-PC / DTV output

COMPONENT 2 ( 480P/720P 1080i )

Set Top Box ( HD STB )

DVD/DTV INPUT output ( right-voice,left-image )

S image input

ANT IN

Component 1 ( 480i input )

DVD

input1,2 (R-voice, L-image)

VCR

71/74

MN-40PA10 (PDP) connection MN-40PA10 MNT

SK-010T HD STR (in case of Cable)

※. The pressure of SK-010T input terminal Spec

RGB-PC input (VGA, SVGA)

RGB output/control voice output (R),(L) Pin D-Sub. DVD input Y, PB,PR

Composite Video Audio R/L VCR input

72/74

PC

MN-40PA10 (PDP) connection PDP operation function

1. Monitor operation only

external IN/OUT terminal 1. RGB input/control 2. RGB- PC input ( VGA, SVGA ) RGB- DTV input(480P/720P/1080i) 3. component( 480i/480P/720P/1080i) ( DVD/DTV input) 4. Voice input right/left 5. External input Right, Left (mono), image 6. External speaker(8Ω) 7. AC input

1. Analog STB ( RN-BA10 ) only 2. VESA Standard PC Signal( VGA,SVGA 85Hz) RGB/HV - DTV ( 480P / 720P / 1080i) 3. component ( 480 I / 480 P ) DTV Standard Signal ( 480P / 720P / 1080i ) 4. Voice input (L/R-RGB-PC/DTV 5. Audio R, L, Composite Video (NTSC Standard) 6. 8Ω speaker connection ( Max 20W ) 7. AC110V ~ 240V 50/60 Hz

1. RGB input/control

1. Analog STB ( RN-BA10 ) only

2. RGB- PC input ( VGA, SVGA )

2. VESA Standard PC Signal( VGA,SVGA 85Hz)

3. RGB- DTV input(480P/720P/1080i)

3. RGB/HV-DTV(480P/720P/1080i)

4. Component 2( 480i/480P/720P/1080i)

4. DTV Mode-- 480 P / 720P / 1080i

(DVD/DTV input)

2. Monitor + RN-BA10 Analog STB

terminal input SPEC

DVD -- 480P

5. component 1 (480i) DVD input

5. DVD -- 480i

6. External input 1,2 --R, L(mono),image

6. External input terminal-- R -L(mono) , image

7. Image output --R-voice, L-image)

7. Image output ( R,L, image) -- monitor output

8. S image

8. Y, C input

9. ANT IN

9. RF input(NTSC)

10. Voice output-R,L

10. Voice output(Analog STB only)

11. AC input

11. AC220V / 60 Hz

73/74

MN-40PA10 (PDP) connection PDP operation function

external IN, OUT terminal

3. Monitor + SK-010T

1.RGB input/control 2.RGB- PC input ( VGA, SVGA ) RGB- DTV input(480P/720P/1080i) 3. component( 480i/480P/720P/1080i) ( DVD/DTV input) 4. External input Doesn’t work R,L(mono),image 2.voice input R/L 3.external speaker(8Ω) 4.AC input

terminal input Spec 1. Works only by inputting HD STB -- see STB input Spec

2. HD STB voice output terminal(R,L) 3. 8Ω speaker connection( Max 20W ) 4. AC220V / 60 Hz

The function of input/output terminal

74/74

1. Block Diagram of VSC main 2. Block Diagram of STB main 3. IC SPEC

1/40

MT-40PA10 MT-40PA10 VSC VSC Board Board Block Block Diagram Diagram STB-POWER VSC DET/POWER HDSTB_DET STB_SCL/SDA ANA_STB_DET

DS101 D-sub

STB-R/G/B/HS/VS(A)

25

OSD_HS/VS IC002 IC002 24C16 24C16

7

IC001 IC001 M37270 M37270 EEPROM EEPROM Micro-Com Micro-Com

5 P601 L/R

Display Processor & Scan Rate Converter (Format Converter) Interlace to Progressive 15KHz 31KHz(2H X 1V)

D-sub 15 DS102

3

TV-Y/U/ V/HS/VS (A)

1 CVBS (A)

P101 V/R/L

3

HS/VS

IC203 IC203 VPC3230 VPC3230 Decoder Decoder Y,Cb,Cr 80Pin 80Pin (A) 8

5 IC204 IC204 SDA9410 SDA9410 Deinterlace Deinterlace & & D/A D/A 100Pin 100Pin

STB/PC/DTV1

2

PVS/PHS_OUT

HS/VS_OUT

D16-31

IC502

8

IC401 IC401 MX88L284 MX88L284 3X2M 3X2M Scan Scanconverter converter 208Pin 208Pin

8 DOR0-7

3X8

8 DOB0-7

PD501 (41Pin)

8 DOG0-7 IC503 8 74F541 Buffer PAG0-7

8

IC504 PAB0-7

IC304 IC304 THS8083 THS8083 100Pin 100Pin

Video&Chroma Video&Chroma

80Pin 80Pin

74F541

Chip for flat display application VGA XGA scale up/down

PDP Module CAXHS/VS 3 CXA-R/G/B(A )

(D)

AV/DVD/DTV2

IC501 74F541

(R/G/B)(D)

IC303 IC303 CXA2101AQ CXA2101AQ

8 LU0-7

P102 DVD

2

74F541PAR0-7

SDRAM

IC203,204,303,304,40 7 2

CHR0-7

Comb Filter Video Process CVBS(Composite Video Baseband Signal) Input to Y/C(Y,U,V) Output

A0-10 11 16 IC403 16 2M

I²C

PC-R/G/B/HS/VS (A) 5 DTV-Y/Pb/Pr (A)

IC402 2M SDRAM

D0-16

SDA2 SCL2

2

IC407 IC407 SC786102DW SC786102DW OSD_R/G/B/YS 4

Multi-Component Processor Triple 8Bit, 80MSPS, 3.3V Video&Graphic Digitizer (Baseband Video Signal Processor) with Digital PLL STB, PC, DTV, TV signals Input to Analog R/G/B Output Analog R/G/B Input to 3X8 Digital R/G/B Output

IC604 IC604 LA7222 LA7222 (Audio (Audio S/W) S/W)

2 L/R

IC603 IC603 LA4282 LA4282

IC602 IC602 CXA2022S CXA2022S

(Tone (Tone Control) Control)

2/40

L/R

2

Audio Audio Amp. Amp. (12Wx2) (12Wx2)

P007A (Spk. Jack) 2

L/R

RTRT- BA10 BA10 STB STB Main Main Block Block Diagram Diagram R/G/B/HS/VS(A)

PC- IN

7input/3output wideband video Amp(20MHz, -3dB) Y/C mix circuit A/V switch featuring I2C BUS

2001.4.27 PHIL KIM

PC Audio(Stereo)

PC- OUT

IF IF IC IC TDA4474 TDA4474 DC5V DC5V

TUNER TUNER I2C

SVHS

2’nd SIF

CVB S

DC DC8V 8V

Y/C

MNT OUT

I2C

V, L/R

SCL-A SDA-A

SCL-A SDA-A

CVBS2/Y

V, L/R

CXA2069Q CXA2069Q A/V A/V SW SW

CVBS.3

C CVBS1/Y

TPU3052S TPU3052S TELETEXT TELETEXT DC5V DC5V

H

C

TV, L/R

DVD Y/Cr/Cb (A)

V, L/R

V

WE

VPC3230D VPC3230D MAIN MAIN [ADDR: [ADDR: 47] 47] Video Video Processor Processor DC DC6V 6V

RE I2C

EXT_RGB

(RCA JACK)

I2C

81V04160 81V04160 FIFO FIFO Memory Memory

SCL-D SDA-D

SCL-D SDA-D

SCL-A SDA-A

I2C

3/40

R/G/B HS/VS(A)

DS 701 (25Pin Cable)

R/G/B HS/VS(A) CXA2101AQ CXA2101AQ RGB RGB Processor Processor DC9V DC9V R/G/B HS/VS(A)

SCL-D SDA-D

9 10

I2C

Multi-Component Processor Analog R/G/B Output

SDA9410 SDA9410 1H/1V=> 1H/1V=> 2H/ 2H/ 1V 1V DW DW // PIP PIP // MPIP MPIP DC DC 3.3V 3.3V

Y/ C/HS/VS (D)

DTV Y, Pb, Pr (A) 7input/3output wideband video Amp(20MHz, -3dB) Y/C mix circuit A/V switch featuring I2C BUS

I2C

Comb filter video processor TV Signal to Digital Y/Cr/Cb Multi-standard color decoder A/D converter

L/R

DVD/DTV

BA7657F BA7657F RGB RGB S/W S/W DC DC5V 5V

RGB

AV1 (SCART1: FULL)

VPC3230D VPC3230D SUB SUB [ADDR: [ADDR: 44] 44] Video Video Processor Processor DC6V DC6V

FB

DC DC12V 12V

* SCART2 : HALF * RCA Jack Common Use *PCB LayOut) TV OUT

IC IC 001 001 M37272 M37272 u-COM u-COM

KIN

L/R

(RCA JACK)

AV2

SCL-A/D SDA-A/D

KOUT

L/R(TV)

P801 7PIN

L/R OUT Input select switch for high definition display Internal broadband RGB s/w

KEY-1

Sound Sound Processor Processor

※ AUDIO COMMON USE

AV3

SCL-A SDA-A

MSP3411G MSP3411G

SCL-A SDA-A

RF

I2C

Format converter Interlace to Progressive

VPC 3230 Comb Comb Filter Filter Video Video Processor Processor

4/40

Description The VPC3230xD/324xD is a high quality, single-chip video front-end, which is targeted for 4:3 and 16:9, 50/60 and 100/120Hz TV sets. It can be combined with other of the DIGIT3000 IC family (such as DDP 33x0A/B, TPU 3040) and/or it can be used with 3rd-party products.

Features Four CVBS, one S-VHS input, one CVBS output Two RGB/YCrCb component inputs, one Fast Blank(FB) input High-performance adaptive 4H comb filter Y/C separator with adjustable vertical peaking Multi-standard substandards

color

decoder

PAL/NTSC/SECAM

One 20.25MHz crystal, few external components 6V supply voltage 5/40

including

all

SDA9410 Display Display Processor Processor & & Scan Scan Rate Rate Converter Converter

Description The SDA 9410 is a new component of Siemens MEGAVISION IC set, which enables the system to reduce large area and line flickering of interlaced TV standards.

6/40

74F541

SDA9410

3-state 3-state Buffer Buffer

Display Processor & Scan Rate Converter Features

Description The 74F541 are octal buffers that are ideal for driving bus lines or buffer memory address s. The outputs are capable of sinking 64mA and sourcing up to 15mA, producing very good capacitive drive characteristics. The devices feature input and outputs on opposite sides of the package to facilitate printed circuit board layout.

Digital interlaced Y/C input, progressive analog Y/U/V output High performance scan rate converter 4:2:2 luminance and chrominance parallel (2x8 wires) Scan rate conversion - Motion compensated 100/120 Hz interlaced scan conversion

Features

- Motion compensated 50/60 Hz progressive scan conversion

High impedance NPN base inputs for reduced loading (20uA in High and Low states)

D/A converters - 9 bit amplitude resolution for Y, -(R-Y), (B-Y) output

Octal bus interface

3.3V + 5% supply voltage

3-state buffer outputs sink 64mA 15mA source current

7/40

THS8083 Video&Graphics Video&Graphics Digitizer Digitizer with with Digital Digital PLL PLL

8/40

Description THS8083 is a complete solution for the digitalizing of video & graphic signals in RGB or YUV/YCbCr color spaces. The device s pixel rates up to 80 MHz to 95 MHz, depending on the speedgrade of the device

Features Three digitalizing channels, each with independently controllable Clamp, PGA and ADC ADC: 8 bit 80MSPS for 4:4:2 and 4:2:2 (ITU.BT-601 style output modes to reduce board traces and video ASIC’S Fully integrates digital PLL(including loop filter) for pixel clock generation 3.3V supply voltage 9/40

CXA2101AQ Multi-Component Multi-Component Processor Processor (Base (Base Band Band Video Video Signal Signal Processor Processor IC) IC)

10/40

Description The CXA2101AQ is a bipolar IC which integrates the following functions on a single chip; base band signal processing, RGB signal processing , and video switching for 4 systems (including HV sync signal processing) using Y/Cb/Cr inputs. It was developed for multiscan TVs, and enables high-end TV systems to be configured.

Features On-chip video switching for 4 systems Y/Cb/Cr input for one system, external Y/Cb/Cr input for 1 system Analog RGB input for 2 systems Normal, PAL-FF, HD-TV ed 9V supply voltage 11/40

MX88L284 Scan Scan Converter Converter

Description The MX88L284 is a highly integration chip for Flat Display application. With Macronix’s Smartscaling – 2 filter, it provides high quality scaled video image and format conversion. General features Converts NTSC/PAL and PC video signal into flat display device timing and resolution. 12/40

Built-in OSD generator with 64 ROM fonts, and 64 programmable RAM fonts. configurable SDRAM/SGRAM(x0 x1 and x2) for different resolution to minimize the system cost. Input PC Video up to 1024x768 @ 85Hz operation mode YCrCb422,RGB888 mode (interlaced and Non-interlaced) input H/V sync. Polarity and odd/even field detection digital input capability SDRAM/SGRAM x0x1 and x2 configuration 3.3V power supplier Output following resolution and frequency

Resolution

800x600 (SD)

1024x768

1280x1024

Horizontal frequency

22~55

20~70

64

Vertical frequency (Hz)

50~75

50~75

60

Dot clock (MHz)

32.5~60

25~80

108

Single (18/24) and Dual (36/48) bit RGB data output OSD MUX capability for On-Screen-Display chip input Built-in OSD generator U Interface direct 8 bit uP interface and serial bus (high-speed) interface

13/40

SDRAM-KM416S1020C Description The KM416S1021C is 16,777,216 bits synchronous high data rate Dynamic RAM organized as 2 x 524,288 words by 16 bits, fabricated with high performance CMOS technology. Synchronous design allows precise cycle control with the use of system clock I/O transactions are possible on every clock cycle. Range of operating frequencies, programmable burst length and programmable latencies allow the same device to be useful for a variety of high bandwidth, high performance memory system applications.

Features JEDEC standard 3.3V power supply SSTL_3 (Class II) compatible with multiplexed address Dual banks operation MRS cycle with address key programs - CAS latency (2 & 3) - Burst length (1, 2, 4, 8 & Full page) - Burst type (Sequential & Interleave) All inputs are sampled at the positive going edge of the system clock. Burst read single-bit write operation Auto & self refresh 64ms refresh period (4K cycle)

14/40

CXA2022

LA4282

II22C C Bus Bus Sound Sound Processor Processor for for TV TV

2-channel 2-channel 10w 10w AF AF Power Power Amplifier Amplifier for for Use Use in in Home Home Stereo, Stereo, TV TV Applications Applications

Description The CXA2022S is a bipolar IC designed as an IC bus control sound processor for TV.This IC has simulate stereo, surround, tone control, balance, volume, muting, AGC and other functions.

Description The LA4282 is an IC which seals a highoutput power amplifier for TVs and monitors in a compact package.

Features

Features

Allows control I2c bus

High-power 2-channel AF power amplifier

Employs a special surround system to prevent “vocal missing” in the surround mode

Low pop noise at the time if power supply ON/OFF

Adopts an AGC circuit to absorb the difference in sound level between input sources and improves S/N ratio of hearing characteristics 14V supply voltage

15/40

Good ripple rejection (58 db typ) External muting available

CXA2069

TDA4474

S2-Compatible 7-Input 3-Output Audio/Video Switch

Multistandard Video-IF and Quasi Parallel Sound Processing Description The TDA4474 is an integrated bipolar circuit for full multistandard video/sound IF(VIF/SIF) signal processing in TV/VCR and multimedia applications. The circuit processes all TV video IF signals with negative modulation (e.g. B/G standard), positive modulation(e.g. L standard) and the AM, FM/NICAM sound IF signals.

Description The CXA2069Q is a 7-Input 3-Output Audio/Video Switch featuring I2C bus compatibility for TVs. This IC has input pins that are compatible with S2 protocol.

Features

Features

Four IF inputs (2xVIFin and 2xSIFin)

7 inputs 3 outputs

Very linear video demodulation, good pulse response and excellent inter modulation figures

4 inputs that are compatible with S2 protocol Wide band video amplifier (20 MHz,-3 dB)

VIF-AGC for negative modulated signals(peak sync. detection) and for positive modulation(peak white/black level detector)

Y/C MIX circuit Serial control with I2C bus High impedance maintained by I2C bus lines (SDA, SCL) even when power id OFF

Alignment-free quasi parallel sound(QPS) mixer for FM/NICAM sound IF signals

12V Supply voltage

16/40

5V supply voltage; low power consumption

MSP 3411G Multistandard Multistandard Sound Sound Processor Processor with with Virtual Virtual Dolby Dolby Surround Surround

Description The MSP 34x1G family of single-chip Multistandard Sound Processors covers the sound processing of all analog TV-Standards worldwide, as well as the NICAM digital sound standards. The full TV sound processing, starting with analog sound IF signal-in, down to processed analog AF-out, is performed on a single chip. The MSP4x1G has all functions of the MSP3401G with the addition of a virtual surround sound feature

17/40

MSP 3411G Multistandard Sound Processor with Virtual Dolby Surround

BA7657F Input selector switch for high definition displays

Features Four Stereo SCART (line) inputs, one Mono input; two Stereo SCART output

Description The BA7657F is for high definition displays, and have internal switches for switching between broadband RGB signals and HD/VD signals, as well as an internal synchronization separator. These ICS simplify the deg of input units for deluxe displays

Complete SCART in/out switching matrix Standard Selection with single I²C transmission Two selectable sound IF (SIF) inputs Automatic Sound Selection (mono/stereo/bilingual), new s MODUS, STATUS

Features

3D-panorama virtualizer (approved by Dolby Laboratories) with noise generator

Internal broadband RGB switch (frequency characteristics : 250MHz, -3dB)

AVC: Automatic Volume Correction

Internal HD/VD switch

Demodulation of the FM-Radio multiplex signal

Internal synchronization separator for synchronizing signals superimposed onto G signals.

8V power supply

18/40

5V power supply

Connection Diagram of MT-40PA10 X-B/D

6p

6p

8P 4p

P004A 7P

9p

VSC Y-B/D

41P

P002A 6P

P806 6P

P007A 4P

P802 4P

P803 9P

POWER

P811 6P

41P

P006A 4P

4P

P801 8P

8P

P805 6P P804 8P

P810 4P

P005A 12P

P807 6P

Z-B/D

P809 12P

P003A 7P

P808 7P

SPEAKER B/D

CN801 2P

Line LineFilter Filter 5V G 15V G N/C VA

CON304 6P 7P

CONTROL B/D

Angle - Type Wafer

X-B/D

VA N/C G 15V G 5V

CON303 6P POWER KEY

19/40

Pin Detail of MT-40PA10

P004A 7PIN

VSC 41P PD501 P005A 12PIN

V V GND GND

30 30 P006A

5V 5V 5V GND GND GND 12V 12V GND GND N/C N/C

4PIN

GND R-SPK GND L-SPK

P007A 4PIN

AC-DET RL-ON STBY P003A GND 7PIN VAVS-ON 5V-MNT N/C

: A Symbol of starting of the PIN number

VA N/C GND 15V GND 5V VA N/C GND 15V GND 5V 32V 32V GND GND

8P

5

5

P801

P801

8P

8P

P806

VSC

6P

CNTL

P807 6P

POWER P811

VSETUP CNTL

6P

P805 6P

VS CNTL

P810 4P

VA CNTL

P804

5VS 5VS 5VS GND GND GND 12V 12V GND GND N/C N/C

P809

ACD RLY 5V GND VsON 5VD N/C

P808

20/40

VS VS N/C N/C N/C GND V GND V

SCL-E SDA-E P002A SCL-N 6PIN SDA-N FS GND

P801

GND GND VSC VSETUP

KET-IN R-LED G-LED GND STBY GND TX

5V 5V 5V 5V GND GND GND GND

8P

5V CNTL

12P

32V CNTL PFC ADJ

VSC

7P

CNTL

CN801 2P

VA N/C GND 15V GND 5V VA N/C GND 15V GND 5V 5V GND 5V GND N/C VS N/C GND

Connection Diagram of RT-BA10 STB-CONTROL B/D

12PIN

STB - MAIN P001 12PIN

P301B 12PIN P801M

P301A 12PIN

P818B 10PIN

P810A 10PIN

P870 8PIN

P870A 8PIN

P305B 3PIN

P302B 12PIN

P303B 10PIN

STBPOWER

P801S

P304B 7PIN

P302A 12PIN

P305B 3PIN

P304B 7PIN

STB D-SUB B/D 21/40

P303B 10PIN

Lightning Wire

Pin Detail of RT-BA10 STB-CONTROL B/D

P001 12PIN

STB - MAIN

GND KOUT GND

KIN1 KIN2 KIN3 KOUT1 KOUT2 KOUT3 GND R-LED G-LED GND 5V GND

2

P302B 12PIN

P302A 12PIN

STB D-SUB B/D

P305B 3PIN

5

P304B 7PIN

22/40

PC-B GND PC-G GND PC-R GND PC-HS GND PC-VS GND

P301A 12PIN

2

P810A 10PIN

POW GND ST5V GND 6V GND 13V GND 30V GND

STBPOWER

S-WOOFER GND OUT-L OUT-R GND MUTE GND

P870A 8PIN

P801M

PC-L GND PC-R GND GND V

3

OUT-L OUT-R GND MUTE GND

P304B 7PIN

GND KOUT GND

3

DVD-Y GND DVD-Pb GND DVD-Pr GND DVD-L GND DVD-R GND GND GND

S-DET GND S-CIN GND S-YIN GND VIN -V GND VIN -L GND VIN -R 3

POW GND ST5V GND 6V GND 13V GND 30V GND

P870B S-WOOFER GND 8PIN

PC-B GND PC-G GND PC-R GND PC-HS GND PC-VS GND

PC-L GND PC-R GND GND V 5

P801M

P303B 10PIN

DVD-Y GND DVD-Pb GND DVD-Pr GND DVD-L GND DVD-R GND GND GND

3

3

P818B 10PIN

P305B 3PIN

P301B 12PIN

S-DET GND S-CIN GND S-YIN GND VIN -V GND VIN -L GND VIN -R 3

12PIN

P303B 10PIN

: A Symbol of starting of the PIN number

Trouble Shooting Guide X - Board COF Connector separation

Lift up X-BOARD CONNECTOR and separate COP CONNECTOR by pulling up.

Lift up the right and left of X-BOARD CONNECTOR.

When you handle COF CONNECTOR, don’t pressure. First release LOCK and separate. COF Connector If COF CONNECTOR is damaged you should replace MODULE ASS’Y. so be aware of this!!

warning warning

When When you you exchange exchange X-Board, X-Board, first first you you should should separate separate COF Connector. Be careful not to damage it. COF COF Connector. Be careful not to damage it. COF Connector Connector is is attached attached to to Module. Module. Since Since COF COF Connector Connector is is torn, torn, Module Module Ass’y Ass’y must must be be replaced replaced aa new new one. one. Be Be careful! careful!

23/40

XX--Board BoardConnector Connectorseparation separation

Lift up each edge of left/right.

Lifted condition Be careful to handle LOCK or it can be hurt. When LOCK is hurt, replace a new X-BOARD. warning warning

It’s easy to separate it by releasing Connector Lock . Do not pressure. Be careful to handle LOCK or it can be hurt. When LOCK is hurt, replace a new XBOARD

24/40

YY--Board BoardCOF COF Connector Connectorseparation separation

Pull the white LOCK as shown in arrow

Pull the white LOCK as shown in arrow. Separate COF CONNECTOR by pulling in the left. warnign warnign

Be careful to handle LOCK part and COF Connector when LOCK part is damaged, you should replace a new Y-Board. In case of COF Connector, Module Ass’y

25/40

ZZ--Board BoardCOF COF Connector Connectorseparation separation

Separate the fixed Screw of Z-Board.. Pull out Lock as shown in arrow. warning warning

Condition in Lock part is pulled COF Connector

be careful not to tear COF Connector. If COF Connector is torn, replace a new Module Ass’y.

26/40

Pull COF Connector as shown in arrow. It’s easy to separate COF on condition that Z-Board Screw is separated. In case Z-Board is assembled, it’s really hard to separate.

each eachConnector Connectorseparation separation Push LOCK and pull out PUSH

PUSH

PUSH

PUSH

PUSH

27/40

PULL

Controller ControllerBoard Board VSC VSCBoard BoardConnector Connector

28/40

Gas Gasinjection injection(sealing (sealingup) up)condition condition

Be sealed up after gas injection

Be sealed up after gas injection

warning warning

Be careful to handle the sealed-up part after gas injection. If it is broken the gas escapes. So replace a module.

29/40

Power Poweris ison onand andoff off 22~~33 minutes minuteslater later (( Protect Protect )) Power PowerisisOn Onand andoff off2~3 2~3minutes. minutes. (Protect) (Protect) P301 P301Connector ConnectorOpen Open Check. Check.

OK

XX--Board BoardTop TopRight Right Change. Change. OK

P302 P302Connector ConnectorOpen Open Check Check

P303 P303Connector ConnectorOpen Open Check Check

XX--Board BoardTop TopLeft Left Change. Change. OK

P304 P304Connector ConnectorOpen Open Check Check

XX--Board BoardBottom BottomRight Right Change. Change. OK

XX--Board BoardBottom BottomLeft Left Change. Change. OK

P102 P102Connector ConnectorOpen Open Check Check

P3, P3,P2 P2Connector ConnectorOpen Open Check Check PROTECT PROTECT operation operation when when the the electrical electrical load load voltage voltage is is Short. Short. When When each each voltage voltage doesn’t doesn’t work work (in (in general general))

ZZ--Board Board Change. Change. OK

P005, P005,P003 P003Connector ConnectorOpen Open Check Check

P006 P006Connector ConnectorOpen Open Check Check

Power Power Board Board Change Change

30/40

YY--Board Board Change. Change.

OK

VSCVSC-Board Board Change. Change. OK

VSC VSC--Board Board Change. Change. Sound Output Sound OutputIC ICShort ShortCheck Check

As Assoon soonas asthe thePower PowerisisOn, On,it’s it’soff offin in22~~33minutes. minutes.((Protect Protect))

L813 dry t

Inferior phase : as soon as the power, it’s off in 2 3minutes. (PROTECT circuit operation) inferior cause : no VS voltage L813 Coil dry t.

Check Check

Open the Connector connecting to each Board to check the power is off. if each Board is same, check the Power Board and voltage.

31/40

ADD ADD BAR BAR inspection inspectionand andrepair repair Press the ADJ KEY and check the position of add bar by changing WHITE or RED or BLUE or GREEN

HEATRUN : WHITE

Top Right

Bottom Right

Top Left

Bottom Left

PD-40X2 uses 4 board such as left,right, top and bottom. Divide the screen in 5 and once you see ADD BAR check COF CONNECTOR between MODULE and X-BOARD. If there is no defect in COF CONNECTOR replace X-BOARD. But the problem still remains and check the connector between X-BOARD and CONTROL BOARD. And if you can’t find defect, check CONTROL.

PD-40X2

Top

PD-60X3 uses 2 X-BOARDs such as top and bottom so when the problems occur in top or bottom, check ADD BAR first and then CONNECTOR, X-BOARD, CONNECTOR and CONTROL BOARD

Bottom PD-40X3, PD-60X3

32/40

DND C/S the analysis of inferior goods 1.June 13 inferior receipt PD 40X 2 Filed inferior good Set No : 912KC 00036 Module No : P239102815-215 customer : in kyeongi province contents: tape droop management: tape rework

13 inferior receipt PDP 40 NVDN 4 Set No : 104KC 00176 Module No : 503007 PRODUCT RECORD : DND sends it to C/S after reworking POWER B/D . contents : B color Address Open 1line causes : dented COF : no inferior phase in DND process, assumed that inferior happens during the analysis in DND ,due to Power B/D COF dented

33/40

inferior receipt PDP 40NVDN 4 Filed Set No : 104KC 00206 Module No : 32184 customer : a surgeon in Kyeongi province contents : Address R color inferior cause : DATA output inferior by X-L-TOP IC14,16 pin dry t ( normal curve by tearing off IC Pin) management : X-L-TOP replacement IC14

Dry t Curve inferior normal curve

34/40

Inferior phase

causes

Under 14V 15V Line, electric discharge inferior occurs and the power’s off because protect circuit is off.

The blue spreads on the screen (electric discharge inferior) and the power’s off in 2 3 minutes this phase repeats whenever the power is on.

-. The power board SMPS not winded enough has the electric discharge inferior because of the short of the voltage capacity.

management The power board PCB replacement of SMPS TRANS replacement (B,D Type) X-Board replacement

inferior X-Board

-. X-Board TR Short, over-electrical load Protect circuit .

Check Check

Measure SMPS 2차 측 15V Line by Digital Multi Meter and check the voltage changes. If it is less than 14V, the screen ins broken with the blue. As soon as the power is ON and it’s off showing this kind of screen. Remove all connectors and check the board not off. . X-Board inferior and the power board SMPS replacement.

35/40

Inferior phase

cause

under 14V 15V Line, electric discharge inferior occurs.

management The power board PCB replacement or SMPS TRANS replacement ( B,D Type)

-. The power board SMPS is not winded enough. because the voltage capacity is short ,electric discharge inferior occurs. The whole screen is broken with the blue (electric discharge inferior) whenever the power is on this phase occurs. OSD is normal. Check Check

Measure SMPS 2 15V Line by Digital Multi Meter and check the voltage changes. If it is less than 14V, the screen ins broken with the blue. (electric discharge inferior )

36/40

Inferior phase

causes

management

Presume X-BOARD inferior. cause : X-BOARD TOP RIGHT 5V doesn’t turn

X-BOARD TOP RIGHT 5V adoesn’t turn

The top left part of screen is broken (X-BOARD TOP RIGHT)

Check Check X-BOARD TOP RIGHT 5V CHECK SMPS ---- X-BOARD TOP RIGHT 5V CHECK

37/40

Inferior phase

causes

Presume X-BOARD inferior. cause : when X-BOARD TOP RIGHT VA(70V) doesn’t turn, this phase occurs.

The pink in the top left part of the screen. (X-BOARD TOP RIGHT)

Check Check X-BOARD TOP RIGHT VA (70V) CHECK SMPS ---- X-BOARD TOP RIGHT VA (70V) CHECK

38/40

management X-BOARD TOP RIGHTVA(70V) doesn’t turn. VA(70V) LINE OPEN.

Inferior phase

Causes

X-BOARD TOP RIGHT 12V doesn’t turn Board VA(70V) doesn’t turn.

management

X-BOARD TOP RIGHT 12V LINE OPEN X-Board Top Right VA(70V) Line Open

the 3/5 top left in the screen isn’t out (X-BOARD TOP RIGHT)

Check Check X-BOARD TOP RIGHT 12V CHECK ( in 0V,this phase.) X-Board Top Right VA(70V) CHECK. (in 0V this phase) SMPS --- X-BOARD TOP RIGHT supplied 12V ,VA(70V) CHECK.

39/40

Inferior phase

causes

management

X-BOARD TOP LEFT 12V doesn’t turn.

X-BOARD TOP LEFT 12V LINE OPEN.

X-BOARD TOP LEFT VA(70V) doesn’t turn.

X-BOARD TOP LEFT VA(70V) LINE OPEN

The 3/5 top right of the screen isn’t out. (X-BOARD TOP LEFT)

Check Check X-BOARD TOP LEFT 12V CHECK ( in 0V) X-BOARD TOP LEFT VA(70V) CHECK(IN 0V) SMPS --- X-BOARD TOP LEFT , 12V,VA(70V) CHECK.

40/40

Inferior phase

causes

X-BOARD TOP LEFT P1 COF Connector Locking Open

The pink in the 1/5 top right (X-BOARD TOP LEFT)

Check Check X-BOARD TOP LEFT P1 CONNECTOR point inferior and LOCK check. The 1/5 top part error so check P1 CONNECTOR LINE emphasis.

1/20

management

X-BOARD TOP LEFT P1 CONNECTOR reassemble

Inferior phase

causes

X-BOARD BOTTOM RIGHT 5V doesn’t turn

the 3/5 bottom left of screen is broken. (X-BOARD BOTTOM RIGHT)

Check Check X-BOARD BOTTEM RIGHT 5V CHECK ( in 0V ,it can happen.) SMPS --- X-BOARD BOTTOM RIGHT 5V CHECK.

2/20

management

X-BOARD BOTTOM RIGHT 5V LINE OPEN

Inferior phase

causes

X-BOARD BOTTOM RIGHT 12V doesn’t turn X-BOARD BOTTOM RIGHT VA(70V) doesn’t turn.

the 3/5 bottom left of the screen isn’t out. (X-BOARD BOTTOM RIGHT)

Check Check X-BOARD BOTTEM RIGHT12V CHECK ( it happens in 0V ) SMPS --- X-BOARD BOTTOM RIGHT ,12V CHECK.

3/20

management

X-BOARD BOTTOM RIGHT 12V LINE OPEN.

Inferior phase

causes

X-BOARD BOTTOMLEFT 5V doesn’t turn

The 2/5 left and right of the screen are broken. (X-BOARD BOTTOM LEFT)

Check Check X-BOARD BOTTEM LEFT 5V CHECK ( it happens in 0V) SMPS --- X-BOARD BOTTOM LEFT, 5V CHECK.

4/20

management

X-BOARD BOTTOM LEFT 5V LINE OPEN

Inferior phase

causes

X-BOARD BOTTOM LEFT 12V doesn’t turn.

The 2/5 left and right part of the screen aren’t out. (X-BOARD BOTTOM LEFT)

Check Check X-BOARD BOTTEM LEFT 12V CHECK (it happens in 0V ) SMPS --- X-BOARD BOTTOM LEFT , 12V CHECK.

5/20

management

X-BOARD BOTTOM LEFT 12V LINE OPEN

Inferior phase

causes

management

X-BOARD BOTTOM LEFT CONNECTOR point inferior

X-BOARD BOTTOM LEFT CONNECTOR reassemble

ADD BAR occurs in the left and right of the screen, (X-BOARD BOTTOM LEFT)

Check Check X-BOARD BOTTEM LEFT CONNECTOR LOCKING check X-BOARD BOTTOM LEFT CONNECTOR reassemble after disassemble reassemble after disassembly

6/20

X-BOARD BOTTOM LEFT CONNECTOR OPEN.

7/20

Inferior phase

causes

P13 CONNECTOR OPEN and CONNECTOR point inferior

management

P13 CONNECTOR reassembly

The screen is divided in top and bottom, and vertical bar appears,

Check Check P13 CONNECTOR point inferior CHECK. P13 CONNECTOR SIGNAL CHEK.

8/20

P13 CONNECTOR

Inferior phase

causes

VSC BOARD CONNECTOR OPEN.

The whole screen is broken and has the vertical bar

Check Check Check connector connecting to VSC BOARD Controller Board. Reassemblly after disassembly VSC BOARD CONNECTOR

9/20

management

VSC BOARD CONNECTOR reassembly

Inferior phase

causes

VSC BOARD CONNECTOR LOOSE.

The screen covered with the blue is broken. (mosaic)

Check Check VSC BOARD CONNECTOR reassembly after disassembly VSC BOARD CONNECTOR.

10/20

management

VSC BOARD CONNECTOR reassembly

Inferior phase

causes

IC203 inferior

the mosaic appears in the screen when it connects to VIDEO IN PUT. (Y-signal low sensibility) the normal screen when it connects to component. Check Check VSC BOARD X201 CHECK. VSC BOARD IC203 VIDEO SIGNAL IN OUT CHECK.

11/20

IC201 (VPC3230D) Decoder IC

management

IC203 (VPC3230D) replacement

VSC VSCBoard Board Block Block

12/20

YY--SIGNAL SIGNAL LOW LOWSENSIBILITY SENSIBILITY

IC201 ( VPC3230 D) Decoder INFERIOR

13/20

Inferior phase

Cause and management

Connector inferior related to controller Board and VSC

Abnormal

normal

Noise with division of colors

Check Check point and signal connect of Connector to Controller Board

14/20

Inferior Connector

PDP inferior examples Inferior

No signal Vertical Bar Inferior phase

chassis

model MN-40PA10

date 2001.05.28

Cause and management 1.cause : IC2 (DA1) inferior 2.countermeasure : 6/7 ~ 6/12 3.applicable model : PDP all model 4.applicable time : ? 5.detailed improvement contents : see PDP technology repor IC2 DA1(Data Arrange) No.162 Pin output is changing depending on the temperature.⇒ abnormal X-B’d Buffer IC * normal temperature : 2.5V (normal Pin = over 2.8V) * heated : 1.5V (normal Pin = 2.7V ) ⇒ IC2 (DA1)inferior

8cm #41839 ( 5/28 shipping goods) reenactment condition of inferior reenactment Ctrl B’d Asic Chip(IC2 DA1 LGD4001) gets high temperature. Inferior appears. (in normal temperature it’s normal )

< curve of normal pin> ─ heated DA1 Buffer

< curve of abnormal pin > ─ heated DA1 Buffer

Buffer(74ACT541) curve abnormally narrows. → in this case impossible to read data in X B/D의 Flip Flop (74AC574)

PDP inferior examples model MN-40PA10

inferior Inferior phase

chassis

date 2001.05.28

Cause and management 1.cause: Y-B’d IPM E/R Up, Down inferior 2.countermeasure: 3.applicable model : all PDPs 4.applicable time: ?

#40658 ( 5/28 출하품 )

#406585 ( 5/28 shipping good ) reenactment 1. Power On / Patten 30)

▶ Y-B’d IPM E/R Up, Down function inferior IPM이 E/R Up, Down Vsus 약 500ns Up Down 100~200ns Vsetdown (with IPM noise ) ▶ condition of inferior reenactment inferiors when IPM has a high temperature. (n normal temperature, normal)

PDP inferior examples 불량명

Add Open (Green 1 Line) Inferior phase

model MN-40PA10

chassis

date 2001.05.28

Cause and countermeasure 1.cause: Add. COF Drive IC inferior 2.countermeasure : 3.applicable model : all PDPs 4.applicable time :

#41725 ( 5/28 shipping good) reenactment

normal Line Data curve

Open Line Data output curve

1. Address open in “G” color

▶ the output of inferior line less than that of the normal Line Add. COF Drive IC inferior COF inspection : 24V Open check (normal 50V)

PDP inferior examples inferior

Vertical bar when Power off/on(electric discharge) Inferior phase

chassis

date 2001.04.19

Cause and management 1.cause : Power off/on時 Control board inferior 2.countermeasure: replace Control board in PDP. 3.changing part : A32_CTRL_03 B/D (PCB Marked) -.R14,17,18,21 : 330 ==> 4.7K (Chip resistance) -.R15,16,19,20 : 22K ==> 4.7K (Chip resistance) -.C504, 505 : 0.1uF / 50V add (Chip capacitor) 4.applicable model: all PDPs 5.applicable time: after marketing/export of the first product 6 improvement contents in detail. : see the PDP’s technical report reporter: shinn

PDP inside Control board

Reenactment 1.PDP Power on Mode extermal input (regardless of wire/wireless signal but it’s easy to reenact in wireless signal) 2. Remove Power Cord (Power’s off) 3.after about 20minutes, insert Power cord (automatically the Power’s on and the vertical bar is shown as above)

External inferior

PDP inferior examples inferior

PDP assembly inferior Inferior phase

model MN-40PA10

chassis

date 2001.04.21

Cause and management 1.cause: manufacturing inferior 2.countermeasure : check after work 3. Applicable model: all PDPs 4. Applicable time : immediately

inferior : Filter is shifted toward the left right : Guide Rib and Gap

Normal(good) assembly

left : completely

5. Trouble Shooting Guide Symptom

Cause

Countermeasure

(Bad X-Board PCB)

Change X board

Red Bar at left lower

PCB Pattern Short

CHECK CHECK Point Point 1. Check after X-Board change 2. Do shortage check neighboring pins of FPC* connector 3. Check soldering condition of defect pin 4. Scan the pattern connected to defect pin with Microsoe

20/20

*FPC : Flat Pin Connector

Symptom Red & Green pin of left lower 4th FPC short

Cause

Countermeasure

Change X-Board

Check Check Point Point 1. Check the status with connector(foreign material, soldering condition) 2. Replace X Board and check again.(If OK, X-Board is defected) 3. By tracing defected line, check the condition of FPC and other connectors, IC output stage and PCB pattern. 4. If no problem, check the connector lead board.

1/21

Symptom

Cause

Pattern Short by connector miss insert

Countermeasure

Re-insert the Connector

Bottom Right 6th FPC R/B Short Check Check Point Point 1. Check the status with connector(foreign material, soldering condition) 2. Replace X Board and check again.(If OK, X-Board is defected) 3. By tracing defected line, check the condition of FPC and other connectors, IC output stage and PCB pattern. 4. If no problem, check the connector lead board.

2/21

Symptom

Cause

Countermeasure

SHORT X-Board Tape Rework

ADD Electrode short at R,G,B Raster or White Screen(Different color display)

Check Check Point Point 1. Trace defected line 2. Check the condition of FPC and connector on the X-Board, IC Output stage and Electrode line.

3/21

Symptom

Countermeasure

Cause

Keep horizontal, or can be defected FPC connector Rework

OPEN

Interfere with mechanical structure when Module assembling

Cold soldering at Connector

1. Outbreak during heat run 2. ADD Electrode open at one color Raster or White screen(No discharge)

▶ Use Connector fixing iron plate ⇒ Keep the point horizontal when interfere with mechanical parts

Check Check Point Point

1. Trace defected line and check the condition of FPC and connector on X-Board, IC Output stage and Electrode line.

4/21

Symptom

Cause

Countermeasure

Replace the

Connected minutely and open slowly as time es ADD open

Check Check Point Point 1. Replace X Board and check again(Still problem, change the ) 2. Check the connection status of side. 3. Check the connection condition of connector of side and the FPC at upper ACF. → If it is OK, check pad

5/21

Symptom & Cause

Countermeasure

Replace the

Check Check Point Point 1. Check the connection condition - Press the connector and reconnect * The difference of ADD open 2. Check the soldering condition of Connector lead and Short ? 3. Replace X Board and check again; connector side or Circuit connector side → Board defect, in case of one line, check the output stage of Drive IC(Cold soldering/Pattern) ADD open : Black vertical bar at Raster If problems in input stage, several lines display ADD short : Different color 4. Observe the FPC :X-board 교환 후 Board의 Board의 Driver IC출력냉땜/ () vertical bar at 4. FPC찍힘 육안관찰:FPC에 * 가: 내 전극open, ACF migration,, X-Board출냉땜/Pattern, Raster FPC찍힘

6/21

Symptom

Cause

Countermeasure

Change Control Board

Check Check Point Point 1. Check the 5V(Logic voltage) input to DC-DC → If it is lower than 5V, it makes similar problem 2. Check X Board(Open or Short circuit) 3. Check the connection condition(conncetion status, foreign material at connector, etc) 4. Check the drive IC at X Board(If defected, change the Board) 5. Confirm the connection of the connector

7/21

Symptom

Cause

Countermeasure

Change X-BOARD

Check Check Point Point Driver clock line at X Driver Board is designed to operate in A and B group ▶ Short circuit at clock line of Drive IC ▶ If problem at input stage, several lines are defected at one point ▶ Replace the X Board of defected point

8/21

Symptom

Cause

Countermeasure

Change X Board

PCB pattern is connected minutely → Foreign material when photo resisting Check Check Point Point 1. Check the connection condition of the Connector. 2. Check the cold soldering.

9/21

Symptom

Cause

Countermeasure

Resistance between 186 pin of U3 and 7 pin of U300 is 62 Ω Normal condition : 2Ω Because of foreign material in Via hole at U300 side

Change Control Board

Vertical bar in every 20mm

Check Check Point Point 1. Measure the resistance of Via holes between U3 and U300 at Control Board and compare with that of normal.(Normal : 2~3 Ω) 2. Resistance increases as temperature rises.

10/21

Symptom

Cause

- Open circuit between pin 7 of U200 and pin 7 of U7 - Resistance between two pins varies from 19 ohm ~ 45Kohm

Check Check Point Point 1. Observe the symptom during Heat-Run at 45 degree. 2. Check the resistance of VIA holes of suspect ICs

11/21

Countermeasure

Replace Control Board

Symptom

Cause

- When Power On, Fan operates but No OSD displays - LED(D3) of Control Board doesn’t operate

1. Because Control data on PROM(U40) doesn’t to FPGA, it can’t generate control signal to X,Y and Z Board. 2. Defected ALTERA.

Check Check Point Point 1. Check D1, D3 & D4 on Control Board - D1 : ON with 5V - D3 : ON when PROM finishes program from ALTERA chip - D4 : ON when signal is applied

12/21

Countermeasure

•Replace Control Board •Replace PROM

Symptom

Cause

Countermeasure

Control Board

Replace Controller board

No signal or at PC mode, dark red raster displays. This is darker than normal Red signal.

Touch point(Marked) Neighboring Pins of U1(FPGA) touch

Check Check Point Point - TV VSC board - Board connector(50 pin) point - Control board of Module

13/21

Symptoms

Cause 1. CN1 on Vs Board cold soldering 2. Spark marks between CN1 and Vs Board -> It makes them open

1. No Raster(ST-BY LED On) 2. Spark noise(Tik-Tik) 3. No Vs, Vsetup & Vsc

Vs board

Check Check Point Point 1. Check Vs, Va with multimeter(No Vs output) 2. Separate SMPS Board and VSC Board and check all voltage output stage 3. Check FET, TR, Diode and Resistor(especially Cement Resistor) 4. Observe PCB Pattern and soldering condition with naked eyes

14/21

Countermeasure Replace DC-DC 2 board

Symptom

Power toggles(On and Off)

Cause

Countermeasure

1. PCB pattern of OVP circuit is wrong (In some SET) 2. The discharging time of Vsetup is long, Replace DC-DC2 if Power On again within discharging board time, this remaining voltage is considered as pulse and shut down control circuit

Defected SET : OVP Circuit

Check Check Point Point 1. Power On/Off function doesn’t work Initial Power On OK 2. Power On : - Fan operates normally - No Vsetup & Vsc of Module 3. Only Module operate : No Vs,Vsetup & Vsc

15/21

Definition of Cell Defect A. Cell Defect Definition

B.Test Condition of Cell Defect

16/21

C.Type of Cell Defect

17/21

D.Comparison of Specification(I) (1) 40” PDP

LG PDP has a tight specification of cell defect in comparison with other companies’ product.

18/21

Dark/unstable Uncontrollable Non-extinguishing

LG_40 18 3 0

Fu_42 20 18 0

Ma_42 36 3 0

Total

≤ 21

≤ 38

≤ 39

D.Comparison of Specification(II) (2) 42” PDP LGE 42˝Spec. of Cell Defect (PDP42WVSN2) Type

A zone (70%)

Dark + Un -stable

N ≤3(cells/RGB scn) N ≤5(cells/RGB scn) conjunction 2 cell≤0 conjunction 2 cell≤2

Uncontroll able Nonexting uishing Defect Distance Total Defect

B zone (30%)

N ≤2(cells/RGB scn) Total N ≤6(cells/full screen)

N=0

Fu_42” Spec. of Cell Defect(’01/4/25) Type

Specification

Dark

N ≤ 5 cell / RGB scn Density : 2cell/㎠ ↓ for each Color

Extinguished size is less than 50%.

Uncontroll able

N ≤ 6 cell / RGB scn Density : 2cell/㎠ ↓ for each Color

ignited size is more than 50%.

Unstable

Total ≤ 5 cell

ignited size is more than 50%.

Nonextinguishing

Total ≤ 0 cell

Total ≤0 cell A & B zone : below then 50 mm

N ≤25 cells/full screen

Ma_42˝Spec. of Cell Defect (MV5501, ‘01/1/13) Type

A zone (25%)

Dark

N ≤2(cells/RGB scn) N ≤4(cells/RGB scn) conjunction 2 cell≤0 conjunction 2 cell≤1

Uncontroll able

Total ≤1cell

B zone (75%)

Total N ≤2(cells/full screen) conjunction 2 cell≤1

Unstable N ≤2(cells/RGB scn) N ≤4(cells/RGB scn) Nonexting Total ≤0 cell uishing Defect A & B zone :below then 100(A)/50(B) mm Distance Total N ≤39 cells/full screen Defect

19/21

Remarks

Comparison of Specification(III) 60” PDP LGE 60˝Spec. of Cell Defect (PDP60WVDN2) Type Dark + Un -stable Uncontrolla ble Nonexting uishing Defect Distance Total Defect

A zone (70%)

B zone (30%)

Pi_50” Spec. of Cell Defect(’01/4/25) Type

N≤11(cells/RGB scn) N≤12(cells/RGB scn) conjunction 2 cell≤0 conjunction 2 cell≤2 N≤2(cells/RGB scn) Total N ≤6(cells/full screen)

N ≤3(cells/RGB scn) Total N ≤9(cells/full screen)

Specification

Dark

Uncontrollab le

Total ≤0 cell D³50 mm, N≤1 (D:Semidiameter)

N ≤35 cells/full screen

Unstable Nonextinguishing

Remarks

N ≤ cell / RGB scn Density : 2cell/㎠ ¯ for each Color

extinguished size is less than 50%.

N ≤ cell / RGB scn Density : 2cell/㎠ ¯ for each Color

ignited size is more than 50%.

Total ≤ cell

ignited size is more than 50%.

Total ≤ 0 cell

NE_50˝Spec. of Cell Defect (MV5501, ‘01/1/13) Type

A zone (%)

B zone (%)

Dark

N ≤(cells/RGB scn) conjunction cell≤0

N ≤(cells/RGB scn) conjunction cell≤1

Uncontrolla ble Unstable Nonexting uishing Defect Distance Total Defect

Total ≤cell N ≤(cells/RGB scn)

LG PDP has a tight specification of cell defect in comparison with other companies’ product.

Total N ≤(cells/full screen) conjunction 2 cell≤1 N ≤(cells/RGB scn)

Total ≤0 cell A & B zone :below then 100(A)/50(B) mm

NE_50

Pi_50

Dark/unstable Uncontrollable Non-extinguishing

LG_60 36 15 0

Total

≤ 35

≤

≤

* SS : Normal cells ³ 99.9% of total cells => It means 3,140 defects will be O.K for 50”

N ≤ cells/full screen

20/21

Cell Defect Spec. 1. Cell Defect Specification Div.

40″

Zone

Non ignition Dot And Unstable Dot

42″

A - Zone

B - Zone

A - Zone

* N ≤ 2 [Cells / RGB scn] Total N ≤ 6 [Cells / full scn]

* N≤ 4 [Cells / RGB scn] Total N≤ 12 [Cells / full scn]

* N≤ 3 [Cells / RGB scn] Total N≤ 9 [Cells / full scn]

* 2cell conjunction point:

* 2cell conjunction point:

* 2cell conjunction point:

N≤ 0 * include Unstable dot: N≤ 3

N≤ 0 * include Unstable dot: N≤ 6

60″

N≤ 0 * include Unstable dot: N≤ 4

B - Zone

A – Zone

B – Zone

* N≤ 5 [Cells / RGB scn] Total N≤ 15 [Cells / full scn]

* N≤ 11 [Cells / RGB scn] Total N≤ 33 [Cells / full scn]

* N≤ 12 [Cells / RGB scn] Total N≤ 36 [Cells / full scn]

* 2cell conjunction point:

* 2cell conjunction point:

* 2cell conjunction point:

N≤ 2

* 3cell conjunction point: N =0

* include Unstable dot: N≤ 7

N≤

2

* 3cell conjunction point: N =0

2

N =0

* include Unstable dot: N≤

N≤

* 3cell conjunction point:

11

* include Unstable dot: N≤

12

Uncontrollable Dot

N=0

N≤ 1 [Cells / RGB scn] Total N≤ 3 [Cells / full scn]

N=0

N≤ 2 [Cells / RGB scn] Total N≤ 6 [Cells / full scn]

N ≤ 2 [Cells / RGB scn] Total N≤ 6 [Cells / full scn]

N ≤ 3 [Cells / RGB scn] Total N≤ 9 [Cells / full scn]

Non extinguishing Dot

N=0

N=0

N=0

N=0

N=0

N=0

Defect Distance

Total Defect

Stain

50mm ≤

N

≤

21 [Cells / full scn]

*1≤ D≤ 5, *D＞5,

D ≥ 5cm, N≤ 1 (D:Semidiameter) ; however, include conjunctive cell, N=0

50mm≤

N≤ 3 N=0

N

≤

25 [Cells / full scn]

* 1≤ D≤ 5, * D＞5,

N≤ 3 N=0

21/21

N≤

35[Cells / full scn]

* 1≤ D≤ 5, N≤ 3 ( Stain Distance : ≥ 50 mm) * D>5, N = 0 ( Stain Distance : ≥ 50 mm)
