ETL Standards Document

PowerCenter Lifecycle/Standards/Environment Document

Draft version 1.3

Arbitron, Inc.

Page 1

12/12/2013

ETL Standards Document

Revision History Date

Version

Description

Author

December 21, 2004

1.0

Initial Outline for Review

Bhuwan Joshi

January 6, 2005

1.1

Altered Format and Details

Jack Vorsteg

January 11, 2005

1.2

Revised Metadata Extension Names

Mike Ficca

Added Backup and Down Times March 27, 2007

Arbitron, Inc.

1.3

Added System Test environment information

Page 2

Patricia Khan

12/12/2013

ETL Standards Document

Table of Contents 1.

Introduction ................................................................................................................................ 6 1.0 Informatica PowerCenter ................................................................................................. 6 1.1 Scope ................................................................................................................................ 6 1.2 Audience ........................................................................................................................... 6 1.3 ................................................................................................................................ 6

2.

ETL Life Cycle ............................................................................................................................. 7

3.

The Informatica PowerCenter Environments ......................................................................... 11 3.0 Development ................................................................................................................... 11 3.0.1 The DWDEVL1 Repository ............................................................................. 11 3.1 Test / UAT ....................................................................................................................... 11 3.1.1 The DWTEST1 Repository ............................................................................. 12 3.2 Production ...................................................................................................................... 13 3.2.1 The DWPROD1 Repository ............................................................................ 13 3.3 General Environment Settings ...................................................................................... 13 3.3.1 UNIX Environment Variables ......................................................................... 14 3.3.2 Server Variables / Directories ........................................................................ 14

4.

PowerCenter Repositories....................................................................................................... 15 4.0 Privileges ........................................................................................................................ 15 4.0.1 Groups ............................................................................................................. 16 4.0.2 s................................................................................................................ 16 4.0.3 Folders............................................................................................................. 16 4.1 The DWDEVL1 Repository............................................................................................. 16 4.1.1 Developer Folders .......................................................................................... 16 4.1.2 MASTER_SRC_TRGT_OBJS Shared Folder ................................................ 17 4.1.3 Project Folders................................................................................................ 18 4.2 The DWTEST1 Repository ............................................................................................. 19 4.2.1 Developer Folders .......................................................................................... 20 4.2.2 MASTER_SRC_TRGT_OBJS Shared Folder ................................................ 20 4.2.3 Project Folders................................................................................................ 20 4.3 The DWPROD1 Repository ............................................................................................ 20 4.3.1 Developer Folders .......................................................................................... 20 4.3.2 MASTER_SRC_TRGT_OBJS Shared Folder ................................................ 20 4.3.3 Project Folders................................................................................................ 21

5.

PowerCenter Standards ........................................................................................................... 21 5.0 PowerCenter Repository Manager Standards ............................................................. 21 5.0.1 Repository Server ........................................................................................... 21 5.0.2 Repository Name ............................................................................................ 21 5.0.3 Repository Schema Owner ............................................................................ 21 5.0.4 Repository Folder ........................................................................................... 21 5.0.5 Repository Group Name ................................................................................ 21 5.0.6 Repository Name ................................................................................... 22

Arbitron, Inc.

Page 3

12/12/2013

ETL Standards Document 5.1

5.2

5.3

PowerCenter Designer Standards ................................................................................ 22 5.1.1 Mapping Standards ........................................................................................ 22 5.1.2 Mapplet Standards.......................................................................................... 22 5.1.3 Source Object Standards ............................................................................... 23 5.1.4 Target Object Standards ................................................................................ 23 5.1.5 Source Qualifier Standards ........................................................................... 24 5.1.6 Advanced External Procedure Standards .................................................... 24 5.1.7 Aggregator Standards .................................................................................... 24 5.1.8 Expression Standards .................................................................................... 24 5.1.9 Filter Standards .............................................................................................. 24 5.1.10 er Transformation Standards ................................................................. 25 5.1.11 Normalizer Transformation Standards ......................................................... 25 5.1.12 Ranker Transformation Standards ................................................................ 25 5.1.13 Router Transformation Standards ................................................................ 25 5.1.14 Sequence Generator Transformation Standards ......................................... 25 5.1.15 Stored Procedure Transformation Standards .............................................. 25 5.1.16 Update Strategy Transformation Standards ................................................ 26 5.1.17 Lookup Transformation Standards ............................................................... 26 5.1.18 Other Transformation Standards .................................................................. 27 5.1.19 Miscellaneous Standards ............................................................................... 27 PowerCenter Workflow Manager Standards ................................................................ 27 5.2.1 Informatica Power Center Server .................................................................. 27 5.2.2 Workflow Standards ....................................................................................... 27 5.2.3 Worklet Standards .......................................................................................... 28 5.2.4 Session Standards ......................................................................................... 28 5.2.5 Miscellaneous Workflow Standards.............................................................. 28 Power Centers Web Services Standards ..................................................................... 29

Appendix A: Code Review................................................................................................................ 30 Mapping Checks ....................................................................................................................... 30 Data and Unit Testing............................................................................................................... 32 Reviewer’s Additional Comments ........................................................................................... 32 Appendix B: Mapping Specification Templates ............................................................................. 33 Mapping Specification Template .................................................................................... 33 High Level Process Overview ......................................................................................... 34 Processing Description (Detail) ...................................................................................... 34 Stored Procedures ........................................................................................................... 34 External Procedures ........................................................................................................ 35 Mapplets ........................................................................................................................... 35 Aggregators ..................................................................................................................... 35 Ranks ................................................................................................................................ 36 Router ............................................................................................................................... 36 er ................................................................................................................................ 36 Comments ........................................................................................................................ 37 [Note: Please copy and paste your comments from your Informatica Object here] .. 37 Normalizer ........................................................................................................................ 37 Expressions ..................................................................................................................... 37 Arbitron, Inc.

Page 4

12/12/2013

ETL Standards Document ETL Estimations ................................................................................................................................ 38 Source to Staging, ODS or 3NF Model ................................................................................... 38 Staging to ODS or 3NF Model ................................................................................................. 38 PSA to MDA or Mart ................................................................................................................. 38

Arbitron, Inc.

Page 5

12/12/2013

ETL Standards Document

1.

Introduction 1.0

Informatica PowerCenter Current Version: 7.1.1 Description: Informatica‟s ETL Software product used to address the complete lifecycle of all data integration and delivery needs.

1.1

Scope The scope of this document is to provide the standards and to describe the development lifecycle that properly trained individual must follow to develop high performance ETL Mappings and Workflows. Deviations from this document must be approved on a case by case by both an ETL and the Enterprise Informatica Owner.

1.2

Audience This document is intended for:   

1.3

PowerCenter PowerCenter Development Team Others with a good understanding of Informatica PowerCenter

PowerCenter: The Data Integration Platform software produced by Informatica. It has many pieces that are referred to within this document: Data Integration Engine, Repository Server, a Repository Database, and various Client Tools. The client tools are: Designer, Workflow Manager, Workflow Monitor, Repository Manager, and Repository Server istration Console. Shareable: Refers to objects that are found in a shareable folder. These objects can be used in any folder within a repository by simply dragging and dropping into the target folder. Shareable objects can be sources, targets, mapplets, mappings, and transformations in the Designer, as well as commands, emails, sessions, and worklets in the Workflow Manager. Note: When deciding on using shared objects, keep in mind that if a change is made to the object, everything using that object is affected. Let’s put this in perspective. If Project A and B are using a shared object, and Project A must change that object for their new development effort, then Project B must incorporate the change as well, whether they are ready for it or not. If Project B refuses to implement the change, then Project A might be late on their deliverable.

Arbitron, Inc.

Page 6

12/12/2013

ETL Standards Document Reusable: Refers to transformations that are found in a regular folder. These transformations are restricted to the folder in which they were created. Other folders do not have access to them in the same manner as the shareable transformations, unless they are copied. Transformations can be made reusable and will appear under the Transformations list in the folder. Mapplets, sources, targets, and mappings are automatically created as reusable. ETL or ETL : Refers to the PowerCenter Repository id that has all the rights and privileges to work within the Informatica environment. It does not refer to any specific individual or individuals on the Data Management team. ETL Developer: Refers to the PowerCenter Repository id that has all the rights and privileges to work within their own Informatica Folder. The s will also have execute permission within folders of projects they are assigned to. Data Architects or DA: Refers to the Arbitron employee assigned to the project and creator of either a source or target data model (or both). This is responsible for the source to target mappings documentation as well as the schema implementation. Database or DBA: Refers to the Arbitron employee assigned as the database of the project.

2.

ETL Life Cycle The following diagram documents the lifecycle of Mappings and Workflows through the Arbitron ETL working environments. It is not the intention of this lifecycle to burden developers with additional documentation, but rather generalize tasks and create channels of communication between the ETL Developers and s. It is assumed that system documentation will be created as part of the overall project document and there is no need to create individual documents based on singular mappings and workflows. When in compliance with the Standards set forth in this document, the Informatica Repository will become self documenting and any necessary information can easily be reported from within the repository metadata.

Arbitron, Inc.

Page 7

12/12/2013

ETL Standards Document Life Cycle Strategy Flow Diagram STEP 1 SPRINT TASK/ERWIN MODEL/WORK REQUEST/SCR The delivery of a work assignment to a ETL developer. The ETL Developer will provide rough estimates on development times based on the ETL WORK LEVEL ESTIMATES . Appendix A

STEP 2 IMPLEMENTATION/MODEL REVIEW The ETL Developer will meet with appropriate DA or persons to review the Data model and/or SRC and discuss the implementation strategy . This discussion shall include the methods to be developed in the event of a required historical backfill of data. NOTE: At this time there is no formal document required. The ETL Developer should be prepared to discuss the solution.

STEP 3 ETL IMPLEMENTATION REVIEW The Implementation Strategy developed during step 2 shall be discussed with at least one ETL . NOTE: At this time there is no formal document required. The ETL Developer is expected to provide enough detail so that the ETL is aware of the overall development effort.

STEP 4 DEVELOPMENT/ UNIT TESTING The ETL Developer shall Develop and Unit Test all mappings and Workflows in their own folder in the DWDEVL1 repository. All Source, Targets and Reusable Objects used in mappings shall be links to the MASTER_SRC_TGT_OBJ folder. The ETL Developers are dependent upon the DA to have the Schema in place in the correct development environment. The ETL is responsible for Importing all the necessary Source and Targets necessary for the ETL Developer to create their mappings. It is the ETL s responsibility to perform a impact analysis in the event that a Source or Target definition is being updated.

Arbitron, Inc.

Page 8

12/12/2013

ETL Standards Document STEP 5 STANDARDS AND METHODS REVIEW The ETL Developer shall present the developed Mappings and Workflows to 2 or more fellow ETL DEVELOPERS. ( One of which should be a ETL ). The Mappings and Workflows will be reviewed for methods and standard compliance PRIOR to the mappings being migrated to the projects centralized folder in the DWDEVL1 repository. items presented to this meeting should include: 1. Repository Report for each Mapping and Workflow 2. SQL EXPLAIN PLANS for all SQL Overrides 3. TBD by ETL S NOTE: The Repository Report has yet to be created and will be part of the Informatica POWERANALYZER APP. Development will return to STEP4 in the event of any issue

Issue: Go to Step 4

STEP 6 DEVELOPER-to-PROJECT FOLDER MIGRATION DEVELOPMENT SYSTEM INTEGRATION TESTING The ETL shall be responsible form the migration of the developers mappings and workflows from the Developers personal folder to the project folder. The Developer will then be responsible for a complete system integration test of the mappings and workflows in the overall environment. The Developer shall be responsible for scheduling the workflows in their correct order and ing their execution.

Issue: Go to Step 4

STEP 8 DA/ETL DEVELOPER REVIEW The ETL Developer and the DA assigned to the project shall conduct a brief data analysis to review the data against the source to target mapping requirements. This review is not meant to identify errors in the mappings, but rather to help the data is loaded as intended

Issue: Go to Step 4

STEP 9 SYSTEM TEST MIGRATION/SYSTEM TEST The ETL Developer shall notify the ETL when mappings and/or workflows are ready to be migrated to the DWSTEN1 repository. It shall be the responsibility of the DA to be certain that the Source and Target definitions are in place prior to the scheduling of the Mappings. The TESTER assigned to the project will be responsible for running the workflows and following all standards outlined by ARBITRONS BEST PRACTICES for TESTING. It is the responsibility of the ETL Developer, DA and TESTER and Community to decide on the best methods for System Testing.

Arbitron, Inc.

Page 9

12/12/2013

ETL Standards Document

Issue: Go to Step 4

STEP 10 TEST MIGRATION/TESTING/UAT The ETL Developer shall notify the ETL when mappings and/or workflows are ready to be migrated to the DWTEST1 repository. It shall be the responsibility of the DA to be certain that the Source and Target definitions are in place prior to the scheduling of the Mappings. The TESTER assigned to the project will be responsible for running the workflows and following all standards outlined by ARBITRONS BEST PRACTICES for TESTING. It is the responsibility of the ETL Developer, DA and TESTER and Community to decide on the best methods for UAT.

Issue: Go to Step 4

STEP 11 PRODUCTION MIGRATION The ETL Developer shall notify the ETL when mappings and/or workflows are ready to be migrated to the DWPROD11 repository after the final SPRINT REVIEW and/or Acceptance. It shall be the responsibility of the DA to be certain that the Source and Target definitions are in place prior to the scheduling of the Mappings. The ETL will migrate the associated mapping based on the standards outlined in the ETL Migration Strategy Document. The ETL developer and DA are responsible for communicating the scheduling requirements and entering this information into the METADATA schema if applicable.

Issue: OPEN SCR Go to Step 1

STEP 12 MAINTENANCE

Issue: OPEN SCR Go to Step 1

STEP 1

Arbitron, Inc.

Page 10

12/12/2013

ETL Standards Document

3.

The Informatica PowerCenter Environments 3.0

Development UNIX Box: DIUETL01 Solaris 5.8 SPARC Repository Server Name: DWDEVL1 Repository Server Port: 5004 Repository Server Home: /app/informatica/powercenter/repositoryserver Server Name: diuetl01_DEVL1 Server Port: 4004 Server Home: /app/informatica/powercenter/server Server Scripts: /app/informatica/powercenter/server/scripts Web Services Server Name: diuetl01_ws_devl Web Services Server Port: 5555 Web Services Server Home: /app/informatica/powercenter/webserviceshub 3.0.1 The DWDEVL1 Repository Database: Oracle 9i Schema Owner: PM_REPO_DEVL1 Instance: DWDEVL1 Backup: Monday – Friday 6AM and 12noon Scheduled Downtime: Sunday 6PM – Sunday 8:30PM The dwdevl1 repository is where Development and Unit Testing will take place. Each developer will have their own folder for development, maintenance, and Unit Testing efforts. The developers will be responsible for preparing the workflows to execute in the dwdevl1 repository. This includes all components such as scripts, procedures, etc. When testing has been completed by the developer, the will move the mappings and workflows to the project folder(s) in the dwdevl1 repository after a review. Once the mappings and workflow are migrated to the project folder(s), the developer will be responsible for performing a complete system integration test in the overall development environment. General developers may have select permission upon request to Views to query the repository.

3.1

System Test UNIX Box: DIUETL01 Solaris 5.8 SPARC Repository Server Name: DWSTEN1 Repository Server Port: 5006 Repository Server Home: /app/sten/informatica/powercenter/repositoryserver Server Name: diuetl01_STEN1 Server Port: 4005 Server Home: /app/sten/informatica/powercenter/server

Arbitron, Inc.

Page 11

12/12/2013

ETL Standards Document Server Scripts: /app/sten/informatica/powercenter/server/scripts Web Services Server Name: diuetl01_ws_sten Web Services Server Port: 5556 Web Services Server Home: /app/sten/informatica/powercenter/webserviceshub 3.1.1 The DWSTEN1 Repository Database: Oracle 9i Schema Owner: PM_REPO_STEN1 Instance: DWSTEN1 Backup: Monday – Friday 6AM and 12noon Scheduled Downtime: Sunday 6PM – Sunday 10PM The dwsten1 repository is where System Testing will take place. At this point all workflow problems should have been identified during the Unit Test phase. If a problem is discovered, developers will correct the problem in the dwdevl1 repository in their own folders. Once the complete Unit Testing cycle has been completed, the will re-migrate the corrected object(s) into dwsten1 repository. General developers, testers and s may have select permission upon request to Views to query the repository. 3.2

Acceptance Test UNIX Box: ARBETL1 Solaris 5.8 SPARC Repository Server Name: DWTEST1 Repository Server Port: 5004 Repository Server Home: /app/informatica/powercenter/repositoryserver Server Name: arbetl1_TEST1 Server Port: 4004 Server Home: /app/informatica/powercenter/server Server Scripts: /app/informatica/powercenter/server/scripts Web Services Server Name: arbetl1_ws_test Web Services Server Port: 5555 Web Services Server Home: /app/informatica/powercenter/webserviceshub 3.2.1 The DWTEST1 Repository Database: Oracle 9i Schema Owner: PM_REPO_TEST1 Instance: DWTEST1 Backup: Monday – Friday 6AM and 12noon Scheduled Downtime: Sunday 6PM – Monday Midnight The dwtest1 repository is where Acceptance Testing will take place. At this point all workflow problems should have been identified during the System Test phase. If a

Arbitron, Inc.

Page 12

12/12/2013

ETL Standards Document problem is discovered, developers will correct the problem in the dwdevl1 repository in their own folders. Once the complete Unit Testing cycle has been completed, the will re-migrate the corrected object(s) into the dwsten1 respository for System Testing. After System Testing is completed successfully, the will re-migrate the corrected object(s) into the dwtest1 repository. General developers, testers and s may have select permission upon request to Views to query the repository. 3.3

Production UNIX Box: PIUETL01 Solaris 5.8 SPARC Repository Server Name: DWPROD1 Repository Server Port: 5004 Repository Server Home: /app/informatica/powercenter/repositoryserver Server Name: piuetl01_PROD1 Server Port: 4004 Server Home: /app/informatica/powercenter/server Server Scripts: /app/informatica/powercenter/server/scripts Web Services Server Name: piuetl01_ws_prod Web Services Server Port: 5555 Web Services Server Home: /app/informatica/powercenter/webserviceshub 3.3.1 The DWPROD1 Repository Database: Oracle 9i Schema Owner: PM_REPO_PROD1 Instance: DWPROD1 Backup: Monday – Saturday 11:59PM Scheduled Downtime: Sunday 3AM – Sunday 3:05AM

The dwprod1 repository is where the Production run takes place. Since all the development and testing will be done in development and test environments, this repository will have no write permissions other than the who has full access. There will be a id created which has only enough permissions and privileges to execute the workflows via scripts, but the actual will be encrypted. The Developers will have select permission to this environment, and will be responsible for confirming all scheduled workflows.

3.4

General Environment Settings The following information is consistent across all environments. Substitute above values as necessary.

Arbitron, Inc.

Page 13

12/12/2013

ETL Standards Document 3.4.1 UNIX Environment Variables repo1_name=DWTEST1 - The Current Environment Repository repo_host=arbetl1 - The Current UNIX Repository Host repo_port=5004 - The Current Repository Port runpm_=ND87NKGOFKM:N - The runpm runpm_=runpm - The general pmcmd for scripts server_host=arbetl1 - The Current UNIX Server Host server_port=4004 - The Current Unix Server Port 3.4.2 Server Variables / Directories $PMWorkflowLogDir /data/informatica/powercenter/WorkflowLogs $PMWorkflowLogCount 0 $PMLookupFileDir /data/informatica/powercenter/LkpFiles $PMRootDir /app/informatica/powercenter/server $PMSessionLogDir /data/informatica/powercenter/SessLogs $PMBadFileDir /data/informatica/powercenter/BadFiles $PMCacheDir /data/informatica/powercenter/Cache $PMTargetFileDir /data/informatica/powercenter/TgtFiles $PMSourceFileDir /data/informatica/powercenter/SrcFiles $PMExtProcDir $PMRootDir/ExtProc $PMTempDir $PMRootDir/Temp $PMSuccessEmail [email protected] $PMSessionLogCount 2 $PMSessionErrorThreshold 1 Arbitron, Inc.

Page 14

12/12/2013

ETL Standards Document Where: $PMRootDir = /app/sten/informatica/powercenter/server

4.

PowerCenter Repositories The Repository Manager is used to configure security at the folder, group and level for each folder in a repository. This is not to be confused with the connection security defined in the Workflow Manager. Although it appears to be at the repository level, security is applied at the folder level. The permissions and privileges given to a and group will determine what a can do and see in the repository. Before a folder is created, s and groups are defined. Once that is done, a folder can be created and given ownership to a and a group that the belongs to. that a can be associated to multiple groups but from a folder perspective only 1 group can be specified for any given . This is important when asg group permissions to the folder. 4.0

Privileges Privileges provide the base levels of a given security structure because they are assigned to s and Groups. New Privileges may not be created. A good understanding of these will help when creating your Groups and s. Privileges are assigned in the Repository Manager in Security | Manage Privileges. The or of the s group can change privileges as they have the ister Repository privilege. The Table below should provide you with a high-level picture of the available privileges. For a more in depth description of each privilege, please refer to the Informatica PowerCenter Documentation. Privilege Use Designer Browse Repository Use Workflow Manager

Workflow Operator

Arbitron, Inc.

Brief Description Connect to Repository using the Designer tool. Folder permissions then dictate how much one may access there. Connect to Repository using the Repository Manager Tool. You may run reports from here. Connect to Repository using the Workflow Manager tool. You can Monitor sessions/workflows through Workflow Monitor tool. Folder permissions then dictate how much one may access. Connect to the Informatica Server engine. Start jobs where Folder permissions have been granted.

Page 15

12/12/2013

ETL Standards Document ister Repository ister Server

Manage s, Groups, and Privileges. Upgrade, Restore, and Backup Repository. Manipulate Folders where appropriate permissions apply. Start / Stop the Informatica Server Engine

Super

The sky is the limit. Table 1 Background of Privileges

4.0.1 Groups Groups are created and maintained in the Repository Manager in the Security menu item. The or of the s group can create or maintain groups as they have the ister Repository privilege. It is advisable that each repository contains only the s and groups that it needs. If all the repositories contain the same s and groups a security breach could ensue. 4.0.2 s s are created and maintained in the Repository Manager in the Security menu item. The or of the s group can create or maintain groups and s as they have the ister Repository privilege. 4.0.3 Folders Folders are created and maintained in the Repository Manager in the Folder menu option. The or of the s group can create or maintain folders as they have the ister Repository privilege. Since you can only have one Owner, and one Group assigned to a Folder, it is very important how these are assigned to insure the proper security. Please also note that there are no Sub-Folders. 4.1

The DWDEVL1 Repository 1. All Developers will be assigned to Project Groups 2. All Testers will only be assigned to the PUBLIC Group 4.1.1 Developer Folders Each developer will have his/her own folder with FULL read/write and execute permission. All development and Unit Testing should happen within this folder. This Developer shall be assigned to the DEVELOPER group and this group will have read permissions only to the Folder. The repository public s will also

Arbitron, Inc.

Page 16

12/12/2013

ETL Standards Document have read permission to individual developer‟s folders. The following image is an example of general developer‟s folders permissions.

4.1.2

MASTER_SRC_TRGT_OBJS Shared Folder The MASTER_SRC_TRGT_OBJS is a centralized shared folder owned by the REPO_ that contains all the Source, Target and Reusable Transformations used by every Project and/or Developers folders. Every Source and Target in other folders MUST be a shortcut to this folder. This will aid the repository s when determining impact analysis of changes as well as migrations. Reusable Transformation transformations will be considered on a case-by-case basis, but it is not recommended at this time to reuse these transformations across folders. s and Senior Developers assigned to the group MASTER_SRC_TRGT_OBJS, will have permission to write to this folder. In the event of an update, it will be their responsibility to take care of the other projects affected. (Notice that Allow Shortcut is selected).

Arbitron, Inc.

Page 17

12/12/2013

ETL Standards Document

4.1.3 Project Folders The individual project folders are owned by the REPO_ and contain all mappings and workflows associated with a project. A group will be created that contains all the individual developers associated with the project. All source and targets defined in these folders must be shortcuts to the centralized shared folder MASTER_SRC_TRGT_OBJS. No transformations may be shared from these project folders to other folders for any reason. s will have permission to write to this folder after the mappings and workflows have been Unit Tested and reviewed for standards compliance. Once mappings and workflows are migrated to the Project Folders, all Developers assigned to the folders group will have both read and execute permission in order to perform system integration testing.

Arbitron, Inc.

Page 18

12/12/2013

ETL Standards Document

4.2

The DWSTEN1 Repository 1. The Developers will only be assigned to the Public Group 2. Testers will be assigned to Project Groups 4.2.1 Developer Folders Developer folders will not exist in the dwsten1 repository. Developers will have read only permission in this repository. 4.2.2 MASTER_SRC_TRGT_OBJS Shared Folder The MASTER_SRC_TRGT_OBJS folder is owned by the REPO_ in the DWSTEN1 repository. Only ETL s will have permission to write to this folder. All other s, Developers and Testers will have read-only permissions.

Arbitron, Inc.

Page 19

12/12/2013

ETL Standards Document 4.2.3 Project Folders All Project Folders are owned by the REPO_ in the DWSTEN1 repository. Only ETL s will have permission to write to these folders. Testers assigned to the Project Folder will be granted Execute permission to perform System Testing. 4.3

The DWTEST1 Repository 1. The Developers will only be assigned to the Public Group 2. Testers will be assigned to Project Groups 4.3.1 Developer Folders Developer folders will not exist in the dwtest1 repository. Developer will have read only permission in this repository. 4.3.2 MASTER_SRC_TRGT_OBJS Shared Folder The MASTER_SRC_TRGT_OBJS folder is owned by the REPO_ in the DWTEST1 repository. Only ETL s will have permission to write to this folder. All other s, Developers and Testers will have read-only permissions. 4.3.3 Project Folders All Project Folders are owned by the REPO_ in the DWTEST1 repository. Only ETL s will have permission to write to these folders. Testers assigned to the Project Folder will be granted Execute permission to assist in UAT testing. There is no plan in place to allow s to directly execute any Power Center workflow from the Informatica Client applications.

4.4

The DWPROD1 Repository 1. The Developers will only be assigned to the Public Group. 2. Testers will only be assigned to the Public Group. 4.4.1 Developer Folders Developer folders will not exist in the dwprod1 repository. Developer will have read only permission in this repository. 4.4.2 MASTER_SRC_TRGT_OBJS Shared Folder The MASTER_SRC_TRGT_OBJS folder is owned by the REPO_ in the DWPROD1 repository. Only ETL s will have permission to

Arbitron, Inc.

Page 20

12/12/2013

ETL Standards Document write to this folder. All other s, Developers and Testers will have read-only permissions. 4.4.3 Project Folders All Project Folders are owned by the REPO_ in the DWPROD1 repository. Only ETL s will have permission to write, schedule and execute within these folders on a normal basis. Execute permission will be granted on a case-by-case basis when deemed necessary. The general runpm will be used for normal script and web services execution as necessary.

5.

PowerCenter Standards 5.0

PowerCenter Repository Manager Standards When the ETL is creating new objects associated with a repository, the following standards and conventions should be adhered to. 5.0.1

Repository Server 

Name is same as the UNIX Host name



This name is determined by system Services.



Ex. DIUETL01

5.0.2 Repository Name 

The Repository name is the same as the Oracle Instance in which it resides.



Ex. DWDEVL1

5.0.3 Repository Schema Owner 

PM_REPO_(ENVIRONMENT)#



The name based upon the environment as well as the number of repositories for that environment.



Ex. PM_REPO_DEVL1

5.0.4 Repository Folder 

Any abbreviated Arbitron system or a unique value agreed upon by the ETL .



Project Folder names shall be in Upper Case



Developers Folder names shall be in Lower Case



Ex. EDD, EDW, ODS

5.0.5 Repository Group Name  Arbitron, Inc.

Each Repository Folder will have an associated Group with the exact same name. Page 21

12/12/2013

ETL Standards Document 5.0.6 Repository Name

5.1



Each name will consist of the ‟s first initial and complete last name



Ex. jvorsteg



ETL s may create system s that do not follow the developer naming convention

PowerCenter Designer Standards When the ETL Developer is creating new mappings or editing a mapping, the following standards and conventions will be adhered to. 5.1.1 Mapping Standards 

Ex. M_GDR001_LOAD_ODS_SRVY_FROM_GDR_PROD



All Upper Case



Name should start with M_ and then followed by abbreviated source database name then followed by numeric representation (3 numbers e.g. 001,002).



Source database representation should be followed by the operation e.g. Insert/Update/Delete/Truncate or Load (generic).



Operation should be followed by target table name. In case of multiple targets use the major target name.



Target table name may be followed by the optional description of the mapping.



All the above components of mapping name should be separated by “_”.



Mapping name will not exceed 80 characters.



Mappings will cover only one data flow. Mappings can have multiple sources and/or multiple targets but they can not have two entirely separate data streams in the same mapping.



All mappings will have comments starting with date and initials of the person writing comments. These comments should be added in the mapping itself. Ex. 01/01/2002 JBV COMMENT…….



If a mapping is modified, comments with the name of the transformations being modified must be appended to the original comments. The actual transformations modified shall contain the date, initials and a brief description in the transformations AUDIT metadata extension.

5.1.2 Mapplet Standards

Arbitron, Inc.



The Mapplet will reside either in the respective project folder as reusable or in the Common Transformations folder.



Mapplets will follow the same standards as mappings where applicable.



Mapplets names will begin with MPL_ Page 22

12/12/2013

ETL Standards Document 

Mapplets will have an AUDIT metadata extension. Audits will include the Developers Name, Date and change description.

5.1.3 Source Object Standards

5.1.4

Arbitron, Inc.



Database Source names will remain the same as the value imported from data base.



Flat file source names will have the same name as the flat file Source.



Add Three/Four characters for the abbreviated source system name if needed for clarification



When creating a mapping that uses new Sources you will first need to have the ETL import these into the MASTER_SRC_TRGT_OBJS Shared Folder. You then create a Shortcut to that Object in your own development folder in order to use it in the Mapping.



Make sure to first create a shortcut for the sources in your Source Analyzer work space before they are used in your mapping. This will allow you to edit the Name. You shall remove the 'Shortcut To_' from the name and save.



Source Transformations will have an AUDIT metadata extension. Audits will include the Developers Name, Date and change description.



The $Source server variable should be used (wherever applicable) for transformations that connect to the database.

Target Object Standards 

Database Target names will remain the same as the value imported from data base.



Flat file Target names will have the same name as the flat file Target.



Add Three/Four characters for the abbreviated source system name if needed for clarification



When creating a mapping that uses new Targets you will first need to have the ETL import these into the MASTER_SRC_TRGT_OBJS Shared Folder. You then create a Shortcut to that Object in your own development folder in order to use it in the Mapping.



Make sure to first create a shortcut for the targets in your Warehouse Designer work space before they are used in your mapping. This will allow you to edit the Name. You shall remove the 'Shortcut To_' from the name and save.



Target Transformations will have an AUDIT metadata extension. Audits will include the Developers Name, Date and change description.



Target Names should be unique in the mapping. When multiple instances of the same target table exist they will be distinguished by operation.



The $Target server variable should be used (wherever applicable) for transformations that connect to the database. Page 23

12/12/2013

ETL Standards Document 

If the Target Update Override is used, then the target name must begin with OVR_



Target Transformations will have a UPD_OVR metadata extension with a default value of „N‟. If an Update override is created, then the update SQL shall be copied to the metadata extension and along with all the future changes.

5.1.5 Source Qualifier Standards 

Source Qualifier names will begin with SQ_ followed by a unique description.



Source Qualifier names will begin with SQ_OVR_ if the SQL is over written.



Import all the tables which are used in the source qualifier. Even if no column has been selected from the table, still import the table and drag any column to SQ. This will avoid hiding any table in query override.



Source Qualifiers will have a SQL_OVR metadata extension with a default value of „N‟. If a SQL override is created, then the SQL shall be copied to the metadata extension and along with all the future changes.

5.1.6 Advanced External Procedure Standards 

Advanced External Proc names will begin with AEP_ followed by a unique description.



Advanced External Procedure Transformations will have an AUDIT metadata extension. Audits will include the Developers Name, Date and change description.

5.1.7 Aggregator Standards 

Aggregator names will begin with AGG_ followed by a unique description.



Aggregator names expecting sorted input data begin with AGG_SI_.



Aggregators will have an AUDIT metadata extension. Audits will include the Developers Name, Date and change description.

5.1.8 Expression Standards 

Expression names will begin with EXP_ followed by a unique description.



Expression transformations will have an UNCONNECTED_LKP metadata extension to hold the name of the Lookup. The extension will have a default value of „N‟.



Expression transformations will have an UNCONNECTED_SP metadata extension to hold the name of the Stored Procedure. The extension will have a default value of „N‟.



Expression transformations will have an AUDIT metadata extension. Audits will include the Developers Name, Date and change description.

5.1.9 Filter Standards  Arbitron, Inc.

Filter names will begin with FIL_ followed by a unique description. Page 24

12/12/2013

ETL Standards Document 

Filter transformations will have an AUDIT metadata extension. Audits will include the Developers Name, Date and change description.

5.1.10 er Transformation Standards 

er names will begin with JNR_ followed by the name of the type of , then the Master Table, then 2 underscores “__”, and then the detail table.



Ex. JNR_OUT_MDA_MARKET_DIM__MDA_SOSO_FACT



If the er expects filtered inputs, then the name shall begin with JNR_SI_.



er transformations will have an AUDIT metadata extension. Audits will include the Developers Name, Date and change description.



Type abbreviations are IN, OUT.

5.1.11 Normalizer Transformation Standards 

Normalizer names will begin with NMR_ followed by a unique description.



Normalizer transformations will have an AUDIT metadata extension. Audits will include the Developers Name, Date and change description.

5.1.12 Ranker Transformation Standards 

Rank names will begin with RNK_ followed by a unique description.



Rank transformations will have an AUDIT metadata extension. Audits will include the Developers Name, Date and change description.

5.1.13 Router Transformation Standards 

Router names will begin with RTR_ followed by a unique description.



Router transformations will have an AUDIT metadata extension. Audits will include the Developers Name, Date and change description.



Router groups must have a valid condition name.

5.1.14 Sequence Generator Transformation Standards 

Sequence Generator names will begin with SG_ followed by a unique description that preferably matches the table the sequence is used for.



Sequence Generator transformations will have an AUDIT metadata extension. Audits will include the Developers Name, Date and change description.



Sequence Generators will reset to 0 upon session initialization to avoid sequence contention between environments.

5.1.15 Stored Procedure Transformation Standards

Arbitron, Inc.



Stored Procedure names will begin with SP_ followed by the Schema (Without the environment) and the actual Procedure.



Ex. SP_GDR_PPMRE1001P

Page 25

12/12/2013

ETL Standards Document 

Stored Procedure transformations will have an AUDIT metadata extension. Audits will include the Developers Name, Date and change description. Changes captured here must include a reference to the procedure in the event that only the stored procedure has changed.



Stored Procedure transformations will have an RDBMS_TYPE metadata extension with a default value of Oracle.

5.1.16 Update Strategy Transformation Standards 

Update Strategy names will begin with UPD_ followed by the operation and finally the target name.



Ex. UPD_INSERT_GDR_MKT_AREA



Operations shall include INSERT, UPDATE, DELETE and REJECT.



The UPDATE strategy data driven command shall be based on the PowerCenter variables dd_insert, dd_update, dd_delete and dd_reject. The data driven command shall not be performed based upon the numeric value.



Update strategy will not be used for mappings only performing inserts.

5.1.17 Lookup Transformation Standards 

Lookup Transformations names will begin with LKP_ followed by the table name.



Lookup Transformations that contain a SQL Override shall be named starting with LKP_OVR_ followed by the Primary Lookup table.



Lookup Transformations that are unconnected names will begin with UN_LKP_.



Lookup transformations will only have the ports to and from the transformation necessary to complete the lookup. Default Lookup policy is “Report Error”. Do not make dynamic Lookups reusable unless explicitly directed to be the ETL . Dynamic lookup names will begin with DLKP_.

 

Arbitron, Inc.



Lookup Transformations will have a SQL_OVR metadata extension with a default value of „N‟. If a SQL override is created, then the SQL shall be copied to the metadata extension and along with all the future changes.



Lookup Transformations will have a SQL_OVR_TABLES metadata extension to store the current SQL Override statements tables. The tables shall be listed as a continuous string with the different tables delimited by double pipes “||”. This will have a default value „N‟.



Lookup Transformations will have an AUDIT metadata extension. Audits will include the Developers Name, Date and change description.



Lookup Transformations will have an CONNECTED_LKP metadata extension with a default value „Y‟.

Page 26

12/12/2013

ETL Standards Document 

Unconnected lookups shall be used with caution. As a rule of thumb, if more than 10% of rows use the lookup, the lookup should be connected.

5.1.18 Other Transformation Standards 

As other transformation are introduced by Informatica and used by developers, standards will be determined during Step 3 of the PowerCenter lifecycle and added to the document as necessary.

5.1.19 Miscellaneous Standards

5.2



Input Ports shall be named based on the connect source when possible. A reasonable name is acceptable. At no time is any default name acceptable.



Output Ports shall be named based on the connect source when possible. A reasonable name is acceptable. At no time is any default name acceptable.



Variable ports shall be named beginning with v_ followed by a reasonable name.



Ports based upon an unconnected Lookup shall begin with lkp_.



Mapping Parameters names shall begin with $$.



Mapping Variables names shall begin with $$V_.

PowerCenter Workflow Manager Standards When the ETL Developer is creating new workflow or editing a workflow, the following standards and conventions will be adhered to. 5.2.1 Informatica Power Center Server 

The Informatica Server name is based on the UNIX machine where it is located followed by a „_‟, followed by the environment of the server.



Ex. piuetl01_prod1

5.2.2 Workflow Standards

Arbitron, Inc.



If a workflow is scheduled its name shall start with SCHED_.



If a workflow is web service enabled its name shall start with WS_.



The Workflow name shall include the Project name and any other reasonable details.



Default Error Handling shall be “Suspend on Error”.



If any database connections are required other than the standard ones, create a temporary one with prefix as your initials. This will help removing them later. E.g. If a database connection is required by Naresh for testing from production then the database connection name should start with Naresh_. ETL s will create and destroy all database connections as necessary.

Page 27

12/12/2013

ETL Standards Document 5.2.3 Worklet Standards 

Worklet names shall start with WL followed by numeric representation (2 characters) e.g. WL01, followed by a reasonable name associating it to a project.



For worklets within a worklet, the numeric representation should be followed by an alphabet. E.g. If a worklet is within a worklet starting with WL01 then the worklet under this should start with WL01A.



If more than two levels of hierarchical arrangement are required for worklets, then alternate the alphabet representation with the numeric representation. E.g. WL01 then WL01A then WL01A01 then WL01A01A and so on.

5.2.4 Session Standards 

Sessions names shall begin with S_ followed by a name that clearly represents the mapping associated to it.



Sessions should have a session log named exactly the same as the session name.



Bad file names should be unique.



Historical loads (or other ad-hoc) may use multiple sessions per workflow. If multiple sessions for same mapping are needed, use a reusable session. Session instance names should be unique and descriptive with matching session log names.



By default sessions should use standard db connections previously created. Developers should submit a request for a new connection (if needed) to an .



By default sessions should have target load type defined as “normal”.



Target properties should only have db operations checked that are needed. I.e. Do not check update box if the job is insert-only.



Whenever possible, server variables such as $source, $target, $PMRoot should be used.



The SQL_OVR metadata extension shall be used if the SQL is modified at session level. The default value is „N‟.



Default error handling shall be set as “Fail Parent If Task Fails”.



The DTM buffer size shall be set to 24M.



The block buffer size shall be set to 128K.



If a session calls a UNIX script, the metadata extension UNIX_SCRIPT shall include the name and full path of the UNIX script with a brief description. The default value is „N‟.

5.2.5 Miscellaneous Workflow Standards

 Email Tasks shall be named EMAIL_ followed by the name of the associated distribution list. Arbitron, Inc.

Page 28

12/12/2013

ETL Standards Document

 Command Tasks shall be named CMD_ followed by the name of the UNIX          5.3

script or any other reasonable name. Relational Connections shall be named at the discretion of the ETL s. Queue Connection TBD. FTP Connections shall be named FTP_ followed by the name of the targeted server. Application Connection TBD. Loader Connection shall be named as the discretion of the ETL s. Workflow Parameters shall be named $$W_ followed by any reasonable name. Workflow Variables shall be named starting with $$WV_ followed by any reasonable name. Workflow Parameter Files shall be named starting with W_PARAM followed by the workflow it belongs to. Session Parameter Files shall be named starting with S_PARAM followed by the session it belongs to.

Power Centers Web Services Standards

 TBD There is a meeting scheduled 1/12/2004

Arbitron, Inc.

Page 29

12/12/2013

ETL Standards Document

Appendix A: Code Review Upon Completion of Step 5 of the PowerCenter Lifecycle, a mapping and workflow review shall take place to confirm development was completed following Enterprise Standards. The code review shall be conducted by at least one ETL and another ETL Developer. The developer shall bring 4 items for every mapping/workflow to be reviewed o o o o o o

Code Checklist Power Analyzer Mapping Standards Report Power Analyzer Workflow Standards Report Erwin Model of the Source and Targets or File Definitions Source to Target Mapping Requirements Screen shots of Mappings to be reviewed

Code Checklist The following is a checklist to be completed prior to the Code Review. Please review each mapping to ensure that you have completed the following steps and place an „X‟ in the box when you have confirmed that the step is completed. This will be the basis for Code Review.

Source file name (s) Target table name(s) Mapping name Workflow name Session name(s) Folder mapping is located in Developer name Date mapping completed Code Reviewed by Date Review Completed

Checks and Balances

Completed

Comments

Mapping Checks Did you follow all naming standards? Did you add mapping comments including your initials and changes to the change log? Did you put comments into key transformations, and are the Arbitron, Inc.

Page 30

YES YES YES 12/12/2013

ETL Standards Document transformations named in a descriptive and identifying way? Please pay special attention to any SQL Overrides, as the WHERE and clauses should be copied into the comments section of the Source Qualifier. Did you remove the Shortcut_to for all Sources and Targets Did you connect only the necessary ports from the lookup? Did you use $Source and $Target for Location Information Property for Lookup? Did you use an Update Strategy only for updated targets, not for inserts? Did you use DD_UPDATE in the Update Strategy Expression? Did you only connect the ports being updated? Does your mapping have a SQL override in the source qualifier when it is not needed (i.e. you could just use the source filter or defined )? Does your mapping use unique target names distinguished by operation? Workflow / Session Checks Did you assign the Workflow to the correct Server? Is the name of the Session Log the same as the name of the Session? Are all flat file options selected correctly? Example: Fixed Width files that use Spaces to signify NULL should have the following options checked: 1) Change Null Character to Space, 2) Repeat Null Character, 3) Strip Trailing Blanks 4) Line Sequential Format Are you only using the Standard Database Connection names? Is the session using „Normal‟ or „Bulk‟ loading appropriately? For a given Target Instance, did you only check the operations that will be done to that particular Target Instance? Does the bad file name make sense? Is there more than 1 mapping loading a target table at the same time? If yes, have you made the bad files unique? If your session uses a parameter file, did you test reading from that parameter file successfully?

Arbitron, Inc.

Page 31

YES YES

YES YES YES YES

YES

YES YES YES

YES YES YES

YES

YES

12/12/2013

ETL Standards Document

Data and Unit Testing When you viewed the target data, did it look clean? Examples: 1) Are you consistently getting NO data values in a particular column in the target table? 2) Did any string data get truncated? 3) If a Number ed into a String column, are there any decimals in the value, such as 1.000000? (Hint: there should not be.) When the session completed, did you open the session log and look for any records that did not insert due to transformation errors? Did the session log show that any fields are being truncated coming from the source?

YES

YES

YES

Reviewer’s Additional Comments

Arbitron, Inc.

Page 32

12/12/2013

ETL Standards Document

Appendix B: Mapping Specification Templates This section provides templates for mapping specification and transformations created in the repository. It is recommended to use these templates to document enterprise level reusable objects to document mapping details where repository reports are not sufficient. Mapping Specification Template Mapping Name Source System

Target System

Initial Rows

Rows/Load

Short Description Load Frequency Preprocessing Post Processing Error Strategy Reload Strategy Unique Source Fields

Sources Tables Table Name

Schema/Owner

Selection/Filter

File Location

Fixed/Delimited

Files File Name

Additional File Info

Targets Tables

Schema Owner

Table Name

Update

Delete

Insert

Unique Key

Files File Name

File Location

Fixed/Delimited

Additional File Info

Lookups Lookup Name Table

Location

Match Condition(s)

Arbitron, Inc.

Page 33

12/12/2013

ETL Standards Document Filter/SQL Override

High Level Process Overview

Source

Target

Processing Description (Detail) Templates For Reusable Transformations Lookups Folder Name Lookup Name Lookup Type Table

Location

Match Condition(s) Outputs Filter/SQL Override Comments

Created by : Modified by :

Stored Procedures Folder Name

Stored Procedure Trans. Name Call Text

Stored Procedure

Arbitron, Inc.

Page 34

12/12/2013

ETL Standards Document Type Comments

Created by : Modified by :

External Procedures Folder Name

External Procedure Trans. Name I

Inputs Return Value Module / Programmic Identifier Procedure Name Runtime Location Is_Partitionable Comments

Mapplets Folder Name

Mapplet Name

Inputs Outputs Comments

Aggregators Folder Name Aggregator Name Group By Size

Groups

Arbitron, Inc.

Page 35

12/12/2013

ETL Standards Document Sorted Ports Used Number of Output Ports Comments

[Note: Please copy and paste your comments from your Informatica Object here]

Ranks Folder Name Rank Name Number of Groups

Number of Ranks Total Output Column Size Comments

[Note: Please copy and paste your comments from your Informatica Object here]

Router Folder Name Router Name Number of Groups Including Default

Group Names

Group 1 Condition Group 2 Condition Group 3 Condition Default Group Utilized (Yes, No) Output Comments

[Note: Please copy and paste your comments from your Informatica Object here]

er Folder Name er Name Master Source Detail Source Type Condition

Arbitron, Inc.

Page 36

12/12/2013

ETL Standards Document

Commen ts

[Note: Please copy and paste your comments from your Informatica Object here]

Normalizer Folder Name Normalizer Name Occurs Field

Number of Occurs

Occurs Field

Number of Occurs

Occurs Field

Number of Occurs

Comments

[Note: Please copy and paste your comments from your Informatica Object here]

Expressions Folder Name

Expression Name

Inputs Outputs Comments

Arbitron, Inc.

Page 37

12/12/2013

ETL Standards Document

ETL Estimations This section provides the typical work estimates (in man hours) for average ETL work. These estimates may vary significantly depending on the nature of the work. Source to Staging, ODS or 3NF Model Standard Mappings (One source to One target) Additional sources or targets (same mapping) Special Case (One source to One Target) Non-database to database Processing Flat Files Standard mapping UNIX Standard mapping LAN Building mechanism for retrieving files

4 hours 2 hours per additional table 8 hours

4 hours additional 8 hours additional Project Dependent (complexity)

Staging to ODS or 3NF Model Standard mapping (One source to One target) Additional sources or targets

4 hours 2 hours per additional table

PSA to MDA or Mart Mapping (assumes many sources to a single target) Performance tuning

8 hours 8 hours

These estimations include defining the table in Informatica and some query tuning. All special cases outside of these guidelines need written requirements and analysis by ETL developer. It is assumed that all DBMS objects will be created by the DA and/or DBA assigned to the task with their appropriate sizing where applicable and that all mapping documentations will be entered in Designer prior to the start of development efforts.

Arbitron, Inc.

Page 38

12/12/2013
