Fire Hose Reel Dimension 1f2j40

REVISED HOSE REEL CABINET

HOSE REEL CABINET

THIS MODEL

MODEL A DOUBLE COMPARTMENT HOSE REEL CABINET

Paint Finish Code No. HRS007-MS-400-RD HRS007-MS-320-RD HRS007-MS-250-RD HRS008-MS-400-RD HRS008-MS-320-RD HRS008-MS-250-RD

TECHNICAL SPECIFICATION 740mm (W) x 1540mm (H) x A (D) Mild Steel 1.5mm Surface / Wall Mounted, Recessed Manual or Automatic swing Hose Reel 3/4” or 1”, & 2pcs Fire Extinguisher Epoxy Powder Red / White, 70 micron min.

Paint Finish

TECHNICAL SPECIFICATION 740mm (W) x 1540mm (H) x A (D) Mild Steel 1.5mm Surface / Wall Mounted, Recessed Manual or Automatic Fixed Type Hose Reel 3/4” or 1”, & 2pcs Fire Extinguisher Epoxy Powder Red / White, 70 micron min.

Dimension A (Depth) mm Code No. HRS002-MS-420-WH 420 HRS002-MS-450-WH 450 HRS005-MS-420-WH 420 HRS005-MS-450-WH 450

Type Surface / Wall Mounted Surface / Wall Mounted Surface / Wall Mounted Recessed Recessed Recessed

Dimension A (Depth) mm 400 320 250 400 320 250 740

Overall Dimension Material Thickness Installation Capacity

Type Surface / Wall Mounted (19” Drum) Surface / Wall Mounted (22” Drum) Recessed (19” Drum) Recessed (22” Drum)

A o

1540

1540

150

A

Overall Dimension Material Thickness Installation Capacity

MODEL B DOUBLE COMPARTMENT PIVOT TYPE HOSE REEL CABINET

Optional: Electrolytic Galvanised (EG) or stainless steel material available on request. The products specified in this brochure are subject to continual development and improvement. Information in this brochure is subject to alteration without notice. All dimensions in mm unless otherwise specified.

31

4/2003

740
