Physics Module Form 4
4
4.1
Chapter 4 - Heat
GCKL 2011
UNDERSTANDING THERMAL EQUILIBRIUM
What is thermal equilibrium ?
1.
( Heat, Temperature ) is a form of energy that flows from a hot body to a cold body.
2.
The SI unit for ( heat , temperature) is Joule, J.
3.
( Heat , Temperature ) is the degree of hotness of a body
4.
The SI unit for (heat , temperature) is Kelvin, K.
5.
When thermal equilibrium is reached, the net rate of heat flow between the two bodies is (zero, equal)
6.
There is no net flow of heat between two objects that are in thermal equilibrium. Two objects in thermal equilibrium have the …same… temperature irrespective of shape, mass, size or type of surface.
Calibration of thermometer
7.
The thermometric property of an object is important in the construction of a thermometer. It is a physical quantity which is sensitive to and changes linearly with the change in temperature of the object. 4-1
Physics Module Form 4
Chapter 4 - Heat
GCKL 2011
: the temperature of pure melting ice/00C
8.
Lower fixed point (l 0 )/ ice point
9.
Upper fixed point( l 100)/steam point: the temperature of steam from water that is boiling under standard atmospheric pressure /1000C
10.
The lengths of the mercury column in the mercury-in-glass thermometer is 2.6 cm at 0OC and 22.6 cm at 100OC. When the thermometer is placed in hot water, the length of the mercury column is 16.9 cm. Calculate the temperature of the hot water.
Liquid-in-glass thermometer
11.
The liquid used in glass thermometer should
(a) Be easily seen (b) Expand and contract rapidly over a wide range of temperature (c) Not stick to the glass wall of the capillary tube 12.
List the characteristic of mercury
(a) Opaque liquid (b) Does not stick to the glass (c) Expands uniformly when heated (d) Freezing point -390C (e) Boiling point 3570C 13.
Which modification increases the sensitivity of the thermometer ? A. Increasing the size of the bulb B. Increasing the thickness of the bulb C. Reducing the diameter of the capillary tube D. Reducing the length of the capillary tube
4-2
Physics Module Form 4
Chapter 4 - Heat
GCKL 2011
Check Yourself 1 1. The diagram below shows a thermometer is used to measure the temperature of hot water. When the thermometer and the hot water are in thermal equilibrium, which of the following is not correct ?
4.
A.
The temperature of hot water is equal to the temperature of the thermometer
B.
No heat flow between thermometer and hot water
C.
Heat flows from hot water to thermometer
D.
Heat flows from thermometer to hot water
Diagram below shows the liquid levels from the bulb in three thermometers P, Q and R at certain temperatures.
What is the temperature reading at thermometer R ?
2.
Which of the following characteristics does a liquid-in-glass thermometer work ?
A. 70.8 OC
A.
Volume of a fixed mass of liquid
B. 65.4 OC
B.
Length of the liquid
C. 62.5 OC
C.
Resistance of the liquid
D. 57.7 OC
D.
Pressure of the liquid
3.
Which of the following temperatures corresponds to zero on the Kelvin scale ? A. 273 OC B. 0 OC C. -273 OC D. 100 OC
4-3
Physics Module Form 4
4
4.2
Chapter 4 - Heat
GCKL 2011
UNDERSTANDING SPECIFIC HEAT CAPACITY
Definition of Heat Capacity
1. Quantity of heat energy required to raise the temperature of an object by 10C. 2. The unit of heat capacity is J0C-1 3. Beaker A has (greater, same, less) heat capacity than beaker B.
B A
A A
4. This means that the (bigger, smaller) the mass, the (larger, smaller) the amount of heat stored.
Definition of Specific Heat Capacity
1. Quantity of heat energy required to raise the temperature of 1 kg of a substance by 10C. 2. The unit of specific heat capacity is Jkg-1 0C-1 3. An object with low specific heat capacity can be heated up quickly, as it requires less heat to increase its temperature by 10C. It can be cooled quickly due to little amount of heat stored in it. 4. An object with high specific heat capacity takes longer time to heat up, as it requires more heat to increase its temperature by 10C. It is harder to cool down due to larger amount of heat stored in it.
Q = Pt Pt = mc Q = Heat supplied P = Power of heater T = Time in seconds M = mass of substance C = Specific heat capacity = Increase in temperature
4-4
Physics Module Form 4 Determining the heat capacity of aluminium block
Chapter 4 - Heat
GCKL 2011
1. The purpose of wrapping the aluminium blok with wool heat loss to or absorption of heat from the surrounding. 2. Oil in the holes for housing thermometer and the immersion heater is to improve the conduction of heat from the heater to the thermometer through the aluminium block. 3. The immersion heater of 50 W rated power is used for 5 minutes to heat up the aluminium block. If the mass of the alumimium block is 1.0 kg and the rise in temperature is 160C, what is the specific heat capacity of aluminium ?
C
Pt 15000 937.5 Jkg-10C-1 m 1 16
4. Specific heat capacity calculated is usually larger than the standard value because some heat is lost to the surroundings.
Aim
To investigate the relationship between temperature rise and mass of water
Experiment
800C
Hypothesis
600C
800C
400C
When the mass of water …increases… the temperature rise will …decrease….
Manipulated variable
Mass of water
Responding variable
Rise in temperature
Fixed variable
Heating duration, water, weighing scale, power rating of heater used
Apparatus
Thermometer, water, beaker water, weighing scale
Setup
4-5
Physics Module Form 4
Chapter 4 - Heat
GCKL 2011
Procedure 1. 100 ml of water is placed in a 500 ml beaker. 2. A heater is placed in the water. 3. Heating process is carried out for 1minute. 4. Highest temperature achieved is recorded. 5. Step 2 to 4 is repeated for 200ml, 300ml, 400ml and 500ml of water. Analysis Volume of water used, V (ml)
Final temperature, T2 (0C)
Initial temperature, T1 (0C)
100 200 300 400 500
V Conclusion
1/
Applications of specific heat capacity
Water as heating agent in heating radiator
4-6
Rise in temperature, = T2 – T1 (0C)
1/ (0C-1)
Physics Module Form 4
Chapter 4 - Heat
GCKL 2011
2. Heat from hot water is released to the cooler surroundings of a room to achieve thermal equilibrium 3. Cold water will be recirculated to repeat the process continously
1. Cool water is pumped into the hot water reservoir to absorb a large amount of heat due to its high specific heat capacity.
Water as a coolant in car engine
4. Hot water is cooled by the air from the cooling fins and the fan
2. High specific heat capacity of water allows it to absorb a large amount of heat from the engine
3. Cool water is recirculated through the engine blocks and the process continues while the engine is running
2. Hot air rises up from the land
Sea Breeze (wind from the sea)
Land Breeze (wind from the land)
1. During the day land gets hotter than the sea because c land < c sea
3. Cooler air blows from the land to replace the space left by the hot air and convection currents in the air are formed.
1. Cool water is pumped into the hot engine
3. Cool air blows from the sea to replace the space left by the hot air and convection currents in the air are formed
2. hot air rises from the sea
1. During the night, the sea is hotter than the land because c land < c sea
4-7
Physics Module Form 4
Chapter 4 - Heat
GCKL 2011
Plastic handle High specific heat capacity
Household apparatus and utensils Steel High specific heat capacity
3. Diagram below shows a bullet moving at a velocity of 60 ms-1 is embedded in a wooden block.
Check Yourself 1 1. Table below shows four types of liquid with their respective specific heat capacities and boiling points. All the liquids have the same mass and same temperatures of 30oC. If the same amount of heat is supplied to them, which liquid, A, B, C or D will boil first ? Liquid
Specific heat capacity (Jkg-10C-1)
Boiling point (oC)
A
3.0
50
B
5.0
80
Assuming all the energy lost by the bullet is converted to heat energy and is absorbed by the bullet. What is the rise in temperature of the bullet ? ( Specific heat capacity of the bullet = 120 Jkg-10C-1)
C
4.2
100
A. 0.5 oC
D
0.2
200
B. 2.0 oC C. 30.0 oC D. 60.0 oC
2. Table below shows the specific heat capacity of four different metals.
4. Diagram below shows 200 g of water at 0 oC is poured into a cup containing 400 g of water at 80 oC . Assuming there is no heat loss to the surroundings.
Which of the following is the most suitable metal to be used in a rice cooker for fast heating ?
What is the final temperature of the mixture ? [ Specific heat capacity of water = 4200 Jkg-10C-1]
A. P
A. 53 oC
B. Q C. R
B. 60 oC
D. S
C. 66 oC D. 70 oC 4-8
Physics Module Form 4
Chapter 4 - Heat
5. Diagram below shows the temperaturetime graph of two solids X and Y of equal mass but of different substances are heated simultaneously by identical heaters. Which of the following comparison is correct? A. Cx > Cy B. Cx < Cy
C. Cx = Cy
4-9
GCKL 2011
Physics Module Form 4
4
4.3
Definition of Latent Heat
Chapter 4 - Heat
UNDERSTANDING
SPECIFIC
GCKL 2011
LATENT
HEAT
1. Latent Heat is the total energy absorbed or released when a substance changes its physical state completely at a constant temperature.
2. Latent Heat of fusion is heat absorbed when solid changes into liquid or heat released when liquid changes into solid at constant temperature. 3. Latent Heat of vaporization is heat absorbed when liquid changes into vapour or heat released when vapour changes into liquid at constant temperature. 4. Unit for latent heat is Joule (J). 5. Process in which solid directly changes into vapour is called sublimation. 1. Specific Latent Heat of fusion is heat absorbed when1 kgsolid changes into liquid or heat released when liquid changes into solid at constant temperature. Definition of Specific Latent Heat
2. Specific Latent Heat of vaporization is heat absorbed when1 kgliquid changes into vapour or heat released when vapour changes into liquid at constant temperature. 3. Unit for latent heat is Jkg-1.
4. When temperature remain constant, kinetic energy of the molecules remain constant. However energy absorbed is used to overcome forces of attraction and atmospheric pressure.
4 - 10
Physics Module Form 4
Chapter 4 - Heat
GCKL 2011
Heating curve Fill the empty boxes for the heating curve below with the following words Solid, liquid, gas, boiling point, melting point, latent heat of fusion, latent heat of vaporization
Calculation of specific latent heat of fusion
Mass of water collected in Set A = 49.2 g Mass of water collected in Set B = 6.4 g Power of heater = 80 W Time interval of switching on the heater = 3 minutes 1. Calculate energy supplied by the heater. Q = Pt = (80)(3x60) = 14400 J 2. What is the mass of ice melted due to the heat absorbed from the surroundings?6.4 g 3. Determine the specific latent heat of fusion of ice. L=
14400 (80)(3 60) Pt = = = 3.364×105Jkg-1 3 m (49.2 6.4) 10 42.8 103
4 - 11
Physics Module Form 4
Chapter 4 - Heat
GCKL 2011
Check Yourself 1 1. Diagram below shows the cooling curve of a Gas. Temperatures T1 and T2 represents
T1
T2
A. Solidification
Room temperature
B. Boiling Point
Solidification point
power of 1 kW. The beaker and its content is resting on an electronic balance which measures the mass of the beaker and its content.
When the water is boiling, it is found that 80 g of water is boiled away in 3 minutes. What is the specific latent heat of vaporization of water ?
C. MeltingPoint Freezing Point D. Melting Point
Room temperature
A. 2.10 x 106 Jkg-1
2. Diagram below shows the heating curve of a solid Y of mass 2 kg which is heated by a heater of 70 W power. Which statement below is NOT true ?
B. 2.15 x 106 Jkg-1 C. 2.20 x 106 Jkg-1 D. 2.25 x 106 Jkg-1
4. Diagram below shows the arrangement of apparatus used to determine the specific latent heat of fusion of ice. There are two identical sets. One of the sets is called a control set which is without a power supply.
A. Specific latent heat of Y is 10500 Jkg-1. B. Specific heat capacity of solid Y and liquid Y are the same C. Total heat used is 1120 J
D. Melting point of Y is 10oC 3. Diagram below shows the arrangement of apparatus used to determine the specific latent heat of vaporization of water. The water in the beaker is heated by an immersion heater with a
The aim of the control set is 4 - 12
Physics Module Form 4
Chapter 4 - Heat
GCKL 2011
A. To find the mass of ice melted due to the heat absorbed from the surroundings
C. To detect any changes in the melting point of the ice
B. To find the mass of water formed by condensation from the vapour in the air
D. To find the mass of water evaporated
5.
Heat produced in an engine block of car needs to be transferred out promptly to prevent overheating. This is done by circulating a suitable cooling liquid through the engine block. (a) What is meant by ‘specific heat capacity of water is 4200 Jkg-1oC-1 ? 4200 J of heat is required to raise the temperature of 1 kg of water by 1oC. (b) Based on the table above, (i) Explain the suitable characteristics of the cooling liquid to extract heat out of an engine block. High Specific Heat Capacity More heat can be extracted from the engine High specific latent heat of More heat can be extracted from the engine vaporization High boiling point Do not vaporize fast and cause unnecessary pressure to engine Low rusting rate Engine can last longer (ii) Decide which liquid is the most suitable and give reasons for your choice. Liquid B, high specific heat capacity, high specific latent heat of vaporization, high boiling point and low rusting rate. (c) Total energy released by an engine in 1 hour = 9.0 x 107 J Energy breakdown : mechanical 40% and heat 60% Mass of cooling liquid circulating in 1 hour = 150 kg Temperature of water entering the engine = 30oC Temperature of water exiting the engine = 60oC Based on the information above, (i) Calculate the power of the engine P = 9.0 x 107 J/3600 s = 2.5 x 107 W (ii) Calculate the amount of heat produced by the engine in one hour. Q = (60%)(9.0 x 107 J) = 5.4 x 107 J (iii) Calculate the specific heat capacity of the cooling liquid. Q = mc 5.4 x 107 J= 150(c)(60-30) c = 12,000 Jkg-1oC-1 4 - 13
Physics Module Form 4
Chapter 4 - Heat
(d) Suggest two ways to dissipate the heat from the cooling liquid. 1. Use a cooling fan 2. Increase the surface area of the cooling coil
4 - 14
GCKL 2011
4
4.1
Chapter 4 - Heat
GCKL 2011
UNDERSTANDING THERMAL EQUILIBRIUM
What is thermal equilibrium ?
1.
( Heat, Temperature ) is a form of energy that flows from a hot body to a cold body.
2.
The SI unit for ( heat , temperature) is Joule, J.
3.
( Heat , Temperature ) is the degree of hotness of a body
4.
The SI unit for (heat , temperature) is Kelvin, K.
5.
When thermal equilibrium is reached, the net rate of heat flow between the two bodies is (zero, equal)
6.
There is no net flow of heat between two objects that are in thermal equilibrium. Two objects in thermal equilibrium have the …same… temperature irrespective of shape, mass, size or type of surface.
Calibration of thermometer
7.
The thermometric property of an object is important in the construction of a thermometer. It is a physical quantity which is sensitive to and changes linearly with the change in temperature of the object. 4-1
Physics Module Form 4
Chapter 4 - Heat
GCKL 2011
: the temperature of pure melting ice/00C
8.
Lower fixed point (l 0 )/ ice point
9.
Upper fixed point( l 100)/steam point: the temperature of steam from water that is boiling under standard atmospheric pressure /1000C
10.
The lengths of the mercury column in the mercury-in-glass thermometer is 2.6 cm at 0OC and 22.6 cm at 100OC. When the thermometer is placed in hot water, the length of the mercury column is 16.9 cm. Calculate the temperature of the hot water.
Liquid-in-glass thermometer
11.
The liquid used in glass thermometer should
(a) Be easily seen (b) Expand and contract rapidly over a wide range of temperature (c) Not stick to the glass wall of the capillary tube 12.
List the characteristic of mercury
(a) Opaque liquid (b) Does not stick to the glass (c) Expands uniformly when heated (d) Freezing point -390C (e) Boiling point 3570C 13.
Which modification increases the sensitivity of the thermometer ? A. Increasing the size of the bulb B. Increasing the thickness of the bulb C. Reducing the diameter of the capillary tube D. Reducing the length of the capillary tube
4-2
Physics Module Form 4
Chapter 4 - Heat
GCKL 2011
Check Yourself 1 1. The diagram below shows a thermometer is used to measure the temperature of hot water. When the thermometer and the hot water are in thermal equilibrium, which of the following is not correct ?
4.
A.
The temperature of hot water is equal to the temperature of the thermometer
B.
No heat flow between thermometer and hot water
C.
Heat flows from hot water to thermometer
D.
Heat flows from thermometer to hot water
Diagram below shows the liquid levels from the bulb in three thermometers P, Q and R at certain temperatures.
What is the temperature reading at thermometer R ?
2.
Which of the following characteristics does a liquid-in-glass thermometer work ?
A. 70.8 OC
A.
Volume of a fixed mass of liquid
B. 65.4 OC
B.
Length of the liquid
C. 62.5 OC
C.
Resistance of the liquid
D. 57.7 OC
D.
Pressure of the liquid
3.
Which of the following temperatures corresponds to zero on the Kelvin scale ? A. 273 OC B. 0 OC C. -273 OC D. 100 OC
4-3
Physics Module Form 4
4
4.2
Chapter 4 - Heat
GCKL 2011
UNDERSTANDING SPECIFIC HEAT CAPACITY
Definition of Heat Capacity
1. Quantity of heat energy required to raise the temperature of an object by 10C. 2. The unit of heat capacity is J0C-1 3. Beaker A has (greater, same, less) heat capacity than beaker B.
B A
A A
4. This means that the (bigger, smaller) the mass, the (larger, smaller) the amount of heat stored.
Definition of Specific Heat Capacity
1. Quantity of heat energy required to raise the temperature of 1 kg of a substance by 10C. 2. The unit of specific heat capacity is Jkg-1 0C-1 3. An object with low specific heat capacity can be heated up quickly, as it requires less heat to increase its temperature by 10C. It can be cooled quickly due to little amount of heat stored in it. 4. An object with high specific heat capacity takes longer time to heat up, as it requires more heat to increase its temperature by 10C. It is harder to cool down due to larger amount of heat stored in it.
Q = Pt Pt = mc Q = Heat supplied P = Power of heater T = Time in seconds M = mass of substance C = Specific heat capacity = Increase in temperature
4-4
Physics Module Form 4 Determining the heat capacity of aluminium block
Chapter 4 - Heat
GCKL 2011
1. The purpose of wrapping the aluminium blok with wool heat loss to or absorption of heat from the surrounding. 2. Oil in the holes for housing thermometer and the immersion heater is to improve the conduction of heat from the heater to the thermometer through the aluminium block. 3. The immersion heater of 50 W rated power is used for 5 minutes to heat up the aluminium block. If the mass of the alumimium block is 1.0 kg and the rise in temperature is 160C, what is the specific heat capacity of aluminium ?
C
Pt 15000 937.5 Jkg-10C-1 m 1 16
4. Specific heat capacity calculated is usually larger than the standard value because some heat is lost to the surroundings.
Aim
To investigate the relationship between temperature rise and mass of water
Experiment
800C
Hypothesis
600C
800C
400C
When the mass of water …increases… the temperature rise will …decrease….
Manipulated variable
Mass of water
Responding variable
Rise in temperature
Fixed variable
Heating duration, water, weighing scale, power rating of heater used
Apparatus
Thermometer, water, beaker water, weighing scale
Setup
4-5
Physics Module Form 4
Chapter 4 - Heat
GCKL 2011
Procedure 1. 100 ml of water is placed in a 500 ml beaker. 2. A heater is placed in the water. 3. Heating process is carried out for 1minute. 4. Highest temperature achieved is recorded. 5. Step 2 to 4 is repeated for 200ml, 300ml, 400ml and 500ml of water. Analysis Volume of water used, V (ml)
Final temperature, T2 (0C)
Initial temperature, T1 (0C)
100 200 300 400 500
V Conclusion
1/
Applications of specific heat capacity
Water as heating agent in heating radiator
4-6
Rise in temperature, = T2 – T1 (0C)
1/ (0C-1)
Physics Module Form 4
Chapter 4 - Heat
GCKL 2011
2. Heat from hot water is released to the cooler surroundings of a room to achieve thermal equilibrium 3. Cold water will be recirculated to repeat the process continously
1. Cool water is pumped into the hot water reservoir to absorb a large amount of heat due to its high specific heat capacity.
Water as a coolant in car engine
4. Hot water is cooled by the air from the cooling fins and the fan
2. High specific heat capacity of water allows it to absorb a large amount of heat from the engine
3. Cool water is recirculated through the engine blocks and the process continues while the engine is running
2. Hot air rises up from the land
Sea Breeze (wind from the sea)
Land Breeze (wind from the land)
1. During the day land gets hotter than the sea because c land < c sea
3. Cooler air blows from the land to replace the space left by the hot air and convection currents in the air are formed.
1. Cool water is pumped into the hot engine
3. Cool air blows from the sea to replace the space left by the hot air and convection currents in the air are formed
2. hot air rises from the sea
1. During the night, the sea is hotter than the land because c land < c sea
4-7
Physics Module Form 4
Chapter 4 - Heat
GCKL 2011
Plastic handle High specific heat capacity
Household apparatus and utensils Steel High specific heat capacity
3. Diagram below shows a bullet moving at a velocity of 60 ms-1 is embedded in a wooden block.
Check Yourself 1 1. Table below shows four types of liquid with their respective specific heat capacities and boiling points. All the liquids have the same mass and same temperatures of 30oC. If the same amount of heat is supplied to them, which liquid, A, B, C or D will boil first ? Liquid
Specific heat capacity (Jkg-10C-1)
Boiling point (oC)
A
3.0
50
B
5.0
80
Assuming all the energy lost by the bullet is converted to heat energy and is absorbed by the bullet. What is the rise in temperature of the bullet ? ( Specific heat capacity of the bullet = 120 Jkg-10C-1)
C
4.2
100
A. 0.5 oC
D
0.2
200
B. 2.0 oC C. 30.0 oC D. 60.0 oC
2. Table below shows the specific heat capacity of four different metals.
4. Diagram below shows 200 g of water at 0 oC is poured into a cup containing 400 g of water at 80 oC . Assuming there is no heat loss to the surroundings.
Which of the following is the most suitable metal to be used in a rice cooker for fast heating ?
What is the final temperature of the mixture ? [ Specific heat capacity of water = 4200 Jkg-10C-1]
A. P
A. 53 oC
B. Q C. R
B. 60 oC
D. S
C. 66 oC D. 70 oC 4-8
Physics Module Form 4
Chapter 4 - Heat
5. Diagram below shows the temperaturetime graph of two solids X and Y of equal mass but of different substances are heated simultaneously by identical heaters. Which of the following comparison is correct? A. Cx > Cy B. Cx < Cy
C. Cx = Cy
4-9
GCKL 2011
Physics Module Form 4
4
4.3
Definition of Latent Heat
Chapter 4 - Heat
UNDERSTANDING
SPECIFIC
GCKL 2011
LATENT
HEAT
1. Latent Heat is the total energy absorbed or released when a substance changes its physical state completely at a constant temperature.
2. Latent Heat of fusion is heat absorbed when solid changes into liquid or heat released when liquid changes into solid at constant temperature. 3. Latent Heat of vaporization is heat absorbed when liquid changes into vapour or heat released when vapour changes into liquid at constant temperature. 4. Unit for latent heat is Joule (J). 5. Process in which solid directly changes into vapour is called sublimation. 1. Specific Latent Heat of fusion is heat absorbed when1 kgsolid changes into liquid or heat released when liquid changes into solid at constant temperature. Definition of Specific Latent Heat
2. Specific Latent Heat of vaporization is heat absorbed when1 kgliquid changes into vapour or heat released when vapour changes into liquid at constant temperature. 3. Unit for latent heat is Jkg-1.
4. When temperature remain constant, kinetic energy of the molecules remain constant. However energy absorbed is used to overcome forces of attraction and atmospheric pressure.
4 - 10
Physics Module Form 4
Chapter 4 - Heat
GCKL 2011
Heating curve Fill the empty boxes for the heating curve below with the following words Solid, liquid, gas, boiling point, melting point, latent heat of fusion, latent heat of vaporization
Calculation of specific latent heat of fusion
Mass of water collected in Set A = 49.2 g Mass of water collected in Set B = 6.4 g Power of heater = 80 W Time interval of switching on the heater = 3 minutes 1. Calculate energy supplied by the heater. Q = Pt = (80)(3x60) = 14400 J 2. What is the mass of ice melted due to the heat absorbed from the surroundings?6.4 g 3. Determine the specific latent heat of fusion of ice. L=
14400 (80)(3 60) Pt = = = 3.364×105Jkg-1 3 m (49.2 6.4) 10 42.8 103
4 - 11
Physics Module Form 4
Chapter 4 - Heat
GCKL 2011
Check Yourself 1 1. Diagram below shows the cooling curve of a Gas. Temperatures T1 and T2 represents
T1
T2
A. Solidification
Room temperature
B. Boiling Point
Solidification point
power of 1 kW. The beaker and its content is resting on an electronic balance which measures the mass of the beaker and its content.
When the water is boiling, it is found that 80 g of water is boiled away in 3 minutes. What is the specific latent heat of vaporization of water ?
C. MeltingPoint Freezing Point D. Melting Point
Room temperature
A. 2.10 x 106 Jkg-1
2. Diagram below shows the heating curve of a solid Y of mass 2 kg which is heated by a heater of 70 W power. Which statement below is NOT true ?
B. 2.15 x 106 Jkg-1 C. 2.20 x 106 Jkg-1 D. 2.25 x 106 Jkg-1
4. Diagram below shows the arrangement of apparatus used to determine the specific latent heat of fusion of ice. There are two identical sets. One of the sets is called a control set which is without a power supply.
A. Specific latent heat of Y is 10500 Jkg-1. B. Specific heat capacity of solid Y and liquid Y are the same C. Total heat used is 1120 J
D. Melting point of Y is 10oC 3. Diagram below shows the arrangement of apparatus used to determine the specific latent heat of vaporization of water. The water in the beaker is heated by an immersion heater with a
The aim of the control set is 4 - 12
Physics Module Form 4
Chapter 4 - Heat
GCKL 2011
A. To find the mass of ice melted due to the heat absorbed from the surroundings
C. To detect any changes in the melting point of the ice
B. To find the mass of water formed by condensation from the vapour in the air
D. To find the mass of water evaporated
5.
Heat produced in an engine block of car needs to be transferred out promptly to prevent overheating. This is done by circulating a suitable cooling liquid through the engine block. (a) What is meant by ‘specific heat capacity of water is 4200 Jkg-1oC-1 ? 4200 J of heat is required to raise the temperature of 1 kg of water by 1oC. (b) Based on the table above, (i) Explain the suitable characteristics of the cooling liquid to extract heat out of an engine block. High Specific Heat Capacity More heat can be extracted from the engine High specific latent heat of More heat can be extracted from the engine vaporization High boiling point Do not vaporize fast and cause unnecessary pressure to engine Low rusting rate Engine can last longer (ii) Decide which liquid is the most suitable and give reasons for your choice. Liquid B, high specific heat capacity, high specific latent heat of vaporization, high boiling point and low rusting rate. (c) Total energy released by an engine in 1 hour = 9.0 x 107 J Energy breakdown : mechanical 40% and heat 60% Mass of cooling liquid circulating in 1 hour = 150 kg Temperature of water entering the engine = 30oC Temperature of water exiting the engine = 60oC Based on the information above, (i) Calculate the power of the engine P = 9.0 x 107 J/3600 s = 2.5 x 107 W (ii) Calculate the amount of heat produced by the engine in one hour. Q = (60%)(9.0 x 107 J) = 5.4 x 107 J (iii) Calculate the specific heat capacity of the cooling liquid. Q = mc 5.4 x 107 J= 150(c)(60-30) c = 12,000 Jkg-1oC-1 4 - 13
Physics Module Form 4
Chapter 4 - Heat
(d) Suggest two ways to dissipate the heat from the cooling liquid. 1. Use a cooling fan 2. Increase the surface area of the cooling coil
4 - 14
GCKL 2011
