For the Volkswagen at B6 (3C) 2005, 2006, 2007, 2008, 2009, 2010, 2011 model year. Fuse box location.
CATEGORIES Alfa Romeo Audi BMW Chevrolet Chrysler Citroen Dodge Fiat Ford Honda Hyundai Iveco Jeep Kia
FIAT
Land Rover Lexus Mazda Mercedes Mercury Mitsubishi Nissan Opel/Vauxhall Peugeot Range Rover Renault Suzuki Toyota Volkswagen Fuse box in engine compartment Volkswagen at B6. Fuse box location.
RECENT POSTS
The electronics box is mounted at the front right in the engine compartment.
Fuse box diagram Audi A4 (B7) Fuse box diagram Audi A2 Fuses and relay Audi A1 Fuses and relay Alfa Romeo Mito Fuses and relay Alfa Romeo GTV Fuses and relay Alfa Romeo GT Fuses and relay Alfa Romeo Giulietta Fuses and relay Alfa Romeo Crosswagon Fuses and relay Alfa Romeo Brera Fuses and relay Alfa Romeo 75
SPONSORED SEARCHES
fuse box
relay switch
ac and heater
power fuses
fuse box diagram (type 1 – pre 04.2005)
SPONSORED SEARCHES
power fuses
vw at
telephone systems
engine diagram
legend (type 1) R1
Ignition main circuits relay
R2 R3 R4 F1
(5A/15A) Transmission control module (TCM)
F2
(30A) Anti-lock brake system (ABS)
F3
(20A) Multifunction control module 2
F4
(5A) Multifunction control module 1
F5
(20A) Horn
F6
(20A) Engine management
F7
(5A) Clutch position potentiometer (AXX/BPY/BWA)
F8
(10A) Engine coolant blower motor control module, engine management
F9
(5A/10A) Engine management
F10
(5A/10A) Engine management
F11
(25A) Engine management-petrol
F12
(15A) Engine management
F13 F14 F15
(10A) Engine management
F16
(15A) Steering column function control module
F17
(10A) Instrumentation control module
F18
(30A) Audio unit output amplifier
F19
(15A) Audio system, navigation system
F20
(5A) Aerial module, telephone
F21
(10A) Audio unit, television tuner
F22
(7,5A) Telematics control module
F23 F24
(10A) CAN data bus gateway control module
F25 F26
(10A) Engine management
F27 F28
–
F29
–
F30
(20A) Auxiliary heater control module
F31
(30A) Windscreen wipers
F32
(10A) Engine management
F33
(15A) Engine management
F34
–
F35
–
F36
–
F37
–
F38
–
F39
–
F40
–
F41
–
F42
–
F43
–
F44
(10A) Engine management
F45
(10A) Engine management
F46
(10A) Engine management
F47
F48
(40A) LH headlamp, LH tail lamp, multifunction control module 1, RH front side lamp, RH tail lamp (40A) LH side lamp, LH tail lamp, multifunction control module 1, RH headlamp, RH tail lamp
F49
(50A) Multifunction control module 1
F50
(60A) Split charge relay
F51
–
F52
(60A) Heated rear window
F53
F54
(50A) Fascia fuse box/relay plate 1 (F40-F42), fascia fuse box/relayplate2(F39), multifunction control module 1 (50A) Glow plug control module
legend (type 2) – fuse box type 1 (pre 04.2005). 1
Ignition main circuits relay
2 3 4 F1
(5A/15A) Transmission control module (TCM)
F2
(30A) Anti-lock brake system (ABS)
F3
(20A) Multifunction control module 2
F4
(5A) Multifunction control module 1
F5
(20A) Horn
F6 F7 F8 F9 F10 F11 F12 F13 F14 F15 F16
(15A) Steering column function control module
F17
(10A) Instrumentation control module
F18
(30A) Audio unit output amplifier
F19
(15A) Audio system, navigation system
F20
(5A) Aerial module, telephone
F21 F22
(7,5A) Telematics control module
F23
(10A) Engine management
F24
(10A) CAN data bus gateway control module
F25 F26
(10A) Engine management
F27
(10A) Engine management-Diesel
F28
(25A/30A) Engine management
F29
(10A/15A) Engine management
F30
(20A) Auxiliary heater control module
F31
(30A) Windscreen wipers
F32
–
F33
–
F34
–
F35
–
F36
–
F37
–
F38
(10A) Engine coolant blower motor control module, engine management
F39
(10A) Engine management
F40
(10A/15A) Engine management
F41
–
F42
–
F43
–
F44
–
F45
–
F46
–
F47
F48
(40A) LH headlamp, LH tail lamp, multifunction control module 1, RH front side lamp, RH tail lamp (40A) LH side lamp, LH tail lamp, multifunction control module 1, RH
headlamp, RH tail lamp F49
(50A) Multifunction control module 1
F50
(60A) Split charge relay
F51
–
F52
(60A) Heated rear window
F53
F54
(50A) Fascia fuse box/relay plate 1 (F40-F42), fascia fuse box/relayplate2(F39), multifunction control module 1 (50A) Glow plug control module
fuse box diagram (type 2 – since 2005).
legend. R1
Secondary air injection (AIR) pump relay
R2
Ignition main circuits relay
F1
(7,5A) Telematics control module
F2
(30A) Anti-lock brake system (ABS)
F3
(20A) Multifunction control module 1
F4
(20A) Multifunction control module 2
F5
(5A) Multifunction control module 1
F6
(5A/15A) Transmission control module (TCM)
F7
(15A) Audio system, navigation system
F8
–
F9
(15A) Steering column function control module
F10
(20A) Engine management
F11
(5A) Instrumentation control module
F12
(5A) Telephone control module
F13
(10A) Engine management
F14
(30A) Engine management
F15
(10A) CAN data bus gateway control module
F16
(10A/15A) Engine management
F17
–
F18
–
F19
(30A) Audio unit output amplifier
F20
(5A/15A) Clutch position potentiometer engine management
F21
(20A) Auxiliary heater control module
F22
(30A) Windscreen wipers
F23
(10A) Engine coolant blower motor control module, engine management
F24
(10A/15A) Engine management
F25
(40A) Multifunction control module 1
F26
(40A) Multifunction control module 1
F27
(60A) Heated rear window
F28
(40A) Engine management-petrol
F29
(50A) Multifunction control module 1
F30
(50A) Multifunction control module 1
Back-up fuse box Volkswagen at B6.
fuse box pre 04.2005.
F1
(150A/180A) Alternator
F2
(80A) Power steering
F3
(50A/80A) Engine coolant blower motor control module
F4
(100A) Fascia fuse box/relay plate 1 (F32-F37),fascia fuse box/relay plate2(F32-F37), fascia fuse box/relay plate 3 (F44/F46)
F5
(80A) Fascia fuse box/relay plate 2 (F22-F27)
F6
(50A) Fascia fuse box/relay plate 1 (F12-F17/F20/F22-F27/F43-F45)
F7
–
fuse box since 05.2005.
F1
(150A) Altemator
F2
(80A) Power steering
F3
(50A/80A) Engine coolant blower motor control module
F4
(100A) Fascia fuse box/relay plate 1 (F32-F37), fascia fuse box/relay plate 2 (F32-F37), fascia fuse box/relay plate 3 (F44/F46)
F5
(80A) Fascia fuse box/relay plate 2 (F22-F27)
F6
(50A) Fascia fuse box/relay plate 1 (F12-F17/F29-F31)
F7
(60A) Split charge relay
F8
(40A) Anti-lock brake system (ABS)
Fuse box in enger compartment Volkswagen at B6. Fuse box, in right-hand side of dash .
fuse box diagram. left hand drive
right hand drive
F1
–
F2
(5A) Anti-lock brake system (ABS), parking brake control module
F3
(5A) Parking aid control module, navigation system
F4
(5A) Cruise control
F5
(10A) RH gas discharge headlamp
F6
(5A) Transmission mode selection switch
F7
(5A) Headlamp level control module
F8
(5A) Engine management
F9
(10A) Supplementary restraint system (SRS)
F10
(5A) Engine management (BLF/BLR/B LY/AXX/B PY/B LX/BVX/BVY/BVZ/BWA)
F12
(10A) Door function control module, left front
F13
(10A) Parking aid control module
F14
(10A) Assisted door closing control module relay
F15
(5A) Heater/air conditioning (AC)
F16
(5A) Transmission mode selection switch
F17
(10A) Anti-lock brake system (ABS), parking brake control module
F18
–
F19
–
F20
–
F21
–
F22
(30A) Accessories connector
F23
(30A) Door function control module, left rear, door function control module, right rear
F24
(30A) Assisted door closing control module, left rear
F25
(30A) Assisted door closing control module, right rear
F26
–
F27
(25A) Heated seats
F28
(15A) Engine management
F29
F30
(30A) Door function control module, driver, door function control module, left front (20A) Parking brake control module
F31
(20A) Parking brake control module
F32
–
F33
(20A) Accessories connector
F34
(15A) Engine management (AXX/BLF/BLR/BLX/BLY/BPY/BVX/BVY/BVZ/BWA)
F35
(20A) Cigarette lighter
F36
–
F37
–
F38
–
F39
(10A) Heater/air conditioning (AC), heated seats, heated wind screen waterjets, split charge relay
F40
(5A) Crash control module (taxi/police)
F41
auxiliary power sockets(luggage compartment)-taxi, interior lamps-taxi,
(15A) Alarm system (taxi), auxiliary power sockets (glove box) – taxi, roof sign lamp-taxi, taximeter F42
(20A) Auxiliary power sockets(glove box)-taxi (5A) Alarm system (taxi), auxiliary power sockets (police), auxiliary
F43
F44
power sockets (glove box) – taxi, auxiliary power sockets (luggage com partment) -taxi (20A) Alarm system (taxi), auxiliary power sockets- taxi, auxiliary power sockets (police)
Fuse box, on left in dash pane Volkswagen at B6. fuse box location.
fuse box diagram.
F1
(10A) Datalink connector (DLC)
F2
(5A) Anti-lock brake system (ABS)
F3
(5A) Power steering
F4
(5A) Brake pedal position (BPP)switch
F5
(10A) LH gas discharge head lamp, head lamp level control module, head lamp adjustment motor, left or single, head lamp adjustment motor, right
F6
(5A) Trailer control module
F7
(5A)Databusconnection,enginemanagement,instrumentationcontrolmodule
F8
(5A) Garage door opener, interior rearview mirror, rear window blind
F9
(5A) Four-wheel drive control module
F10
(5A) Engine management
F11
(5A) Accident data recorder button, taximeter
F12
(10A) Door function control module, driver
F13
(10A) Datalink connector (DLC), light switch
F14
(5A) Steering column function control module
F15
(5A) Multifunction control module 1
F16
(10A) Ignition system
F17
(10A) Alarm system, auxiliary heater, wind screen wiper rain sensor
F18
–
F19
–
F20
–
F21
–
F22
(5A/10A) engine management
F23
(10A) engine management
F24
(5A/20A) Transmission control module(TCM), reverse gear position switch
F25
(10A) engine management
F26
(10A) Rear window blind
F27
(5A) Heater/air conditioning (AC)
F28
–
F29
(20A) Trailer control module
F30
(15A) Trailer control module
F31
(25A) Trailer control module
F32
(30A) Multifunction control module1
F33
(20A)Sunroof
F34
(15A) engine management
F35
(30A) Head lamp washers
F36
(20A) Auxiliary heater
F37
(30A) Heated seats
F38
–
F39
(40A) Heater/air conditioning (AC)
F40
(5A)Fog lamps
F41
(40A) Heater/air conditioning(AC)
F42
(15A) Windscreen washers, rear screen wiper motor
F43
(20A) Auxiliary heater
F44
(20A) Auxiliary heater
F45
(25A) Auxiliary power sockets
F46
F47
(5A) Two-way radio (police), crash control module(taxi/police), ignition switch circuits, tachograph (15A) Alarm system (taxi), auxiliary power sockets (glove box) – taxi, auxiliary power sockets(luggage compartment)-taxi, auxiliary power sockets(two-way radio)- police, interior lamps, luggage compartment lamp
F48
(20A) Auxiliary power sockets (police)
F49
–
Relay carrier on onboard power supply control unit, on left under dash Volkswagen at B6.
R1
Ignition main circuits relay
R2
–
R3
–
R4
Multifunction control module relay
R5
Heated rear window relay
R6
Horn relay
R7
Windscreen washer pump relay 1
R8
Windscreen washer pump relay 2
R9
Ignition auxiliary circuits relay
R11
Auxiliary heater relay
R12 R13
Heater blower motor relay
R14 R15
Fuel pump(FP) relay-Diesel
R16
Headlamp washer pump relay
R17
Starter motor relay
F1 F2
F3
(30A) Electric seats circuit breaker (enger)
F4
(15A) Electric seats circuit breaker (driver)
Tags: Fuse box diagram Volkswagen
Related Posts
Fuses and relay Volkswagen Vento 19921998
Fuses and relay Volkswagen Touran
Fuses and relay Volkswagen at B5
Fuses and relay Volkswagen Golf 4
Fuses and relay Volkswagen Jetta 6
Fuses and relay Volkswagen at B7
Fuse box diagram Copyright © 2019.
Back to Top ↑
FORD
MAZDA
PEUGEOT
AUDI
HONDA
BMW
HYUNDAI
MERCEDES
CHEVROLET
IVECO
MERCURY
RANGE ROVER
RENAULT
JEEP
MITSUBISHI
SUZUKI
CHRYSLER
KIA
CITROEN
DODGE
LAND ROVER
LEXUS
NISSAN
TOYOTA
Fuses and relay Volkswagen at B6
OPEL/VAUXHALL
VOLKSWAGEN
ADS SPONSORED SEARCHES
engine diagram breaker box fuse holder location box box tv
Search
For the Volkswagen at B6 (3C) 2005, 2006, 2007, 2008, 2009, 2010, 2011 model year. Fuse box location.
CATEGORIES Alfa Romeo Audi BMW Chevrolet Chrysler Citroen Dodge Fiat Ford Honda Hyundai Iveco Jeep Kia
FIAT
Land Rover Lexus Mazda Mercedes Mercury Mitsubishi Nissan Opel/Vauxhall Peugeot Range Rover Renault Suzuki Toyota Volkswagen Fuse box in engine compartment Volkswagen at B6. Fuse box location.
RECENT POSTS
The electronics box is mounted at the front right in the engine compartment.
Fuse box diagram Audi A4 (B7) Fuse box diagram Audi A2 Fuses and relay Audi A1 Fuses and relay Alfa Romeo Mito Fuses and relay Alfa Romeo GTV Fuses and relay Alfa Romeo GT Fuses and relay Alfa Romeo Giulietta Fuses and relay Alfa Romeo Crosswagon Fuses and relay Alfa Romeo Brera Fuses and relay Alfa Romeo 75
SPONSORED SEARCHES
fuse box
relay switch
ac and heater
power fuses
fuse box diagram (type 1 – pre 04.2005)
SPONSORED SEARCHES
power fuses
vw at
telephone systems
engine diagram
legend (type 1) R1
Ignition main circuits relay
R2 R3 R4 F1
(5A/15A) Transmission control module (TCM)
F2
(30A) Anti-lock brake system (ABS)
F3
(20A) Multifunction control module 2
F4
(5A) Multifunction control module 1
F5
(20A) Horn
F6
(20A) Engine management
F7
(5A) Clutch position potentiometer (AXX/BPY/BWA)
F8
(10A) Engine coolant blower motor control module, engine management
F9
(5A/10A) Engine management
F10
(5A/10A) Engine management
F11
(25A) Engine management-petrol
F12
(15A) Engine management
F13 F14 F15
(10A) Engine management
F16
(15A) Steering column function control module
F17
(10A) Instrumentation control module
F18
(30A) Audio unit output amplifier
F19
(15A) Audio system, navigation system
F20
(5A) Aerial module, telephone
F21
(10A) Audio unit, television tuner
F22
(7,5A) Telematics control module
F23 F24
(10A) CAN data bus gateway control module
F25 F26
(10A) Engine management
F27 F28
–
F29
–
F30
(20A) Auxiliary heater control module
F31
(30A) Windscreen wipers
F32
(10A) Engine management
F33
(15A) Engine management
F34
–
F35
–
F36
–
F37
–
F38
–
F39
–
F40
–
F41
–
F42
–
F43
–
F44
(10A) Engine management
F45
(10A) Engine management
F46
(10A) Engine management
F47
F48
(40A) LH headlamp, LH tail lamp, multifunction control module 1, RH front side lamp, RH tail lamp (40A) LH side lamp, LH tail lamp, multifunction control module 1, RH headlamp, RH tail lamp
F49
(50A) Multifunction control module 1
F50
(60A) Split charge relay
F51
–
F52
(60A) Heated rear window
F53
F54
(50A) Fascia fuse box/relay plate 1 (F40-F42), fascia fuse box/relayplate2(F39), multifunction control module 1 (50A) Glow plug control module
legend (type 2) – fuse box type 1 (pre 04.2005). 1
Ignition main circuits relay
2 3 4 F1
(5A/15A) Transmission control module (TCM)
F2
(30A) Anti-lock brake system (ABS)
F3
(20A) Multifunction control module 2
F4
(5A) Multifunction control module 1
F5
(20A) Horn
F6 F7 F8 F9 F10 F11 F12 F13 F14 F15 F16
(15A) Steering column function control module
F17
(10A) Instrumentation control module
F18
(30A) Audio unit output amplifier
F19
(15A) Audio system, navigation system
F20
(5A) Aerial module, telephone
F21 F22
(7,5A) Telematics control module
F23
(10A) Engine management
F24
(10A) CAN data bus gateway control module
F25 F26
(10A) Engine management
F27
(10A) Engine management-Diesel
F28
(25A/30A) Engine management
F29
(10A/15A) Engine management
F30
(20A) Auxiliary heater control module
F31
(30A) Windscreen wipers
F32
–
F33
–
F34
–
F35
–
F36
–
F37
–
F38
(10A) Engine coolant blower motor control module, engine management
F39
(10A) Engine management
F40
(10A/15A) Engine management
F41
–
F42
–
F43
–
F44
–
F45
–
F46
–
F47
F48
(40A) LH headlamp, LH tail lamp, multifunction control module 1, RH front side lamp, RH tail lamp (40A) LH side lamp, LH tail lamp, multifunction control module 1, RH
headlamp, RH tail lamp F49
(50A) Multifunction control module 1
F50
(60A) Split charge relay
F51
–
F52
(60A) Heated rear window
F53
F54
(50A) Fascia fuse box/relay plate 1 (F40-F42), fascia fuse box/relayplate2(F39), multifunction control module 1 (50A) Glow plug control module
fuse box diagram (type 2 – since 2005).
legend. R1
Secondary air injection (AIR) pump relay
R2
Ignition main circuits relay
F1
(7,5A) Telematics control module
F2
(30A) Anti-lock brake system (ABS)
F3
(20A) Multifunction control module 1
F4
(20A) Multifunction control module 2
F5
(5A) Multifunction control module 1
F6
(5A/15A) Transmission control module (TCM)
F7
(15A) Audio system, navigation system
F8
–
F9
(15A) Steering column function control module
F10
(20A) Engine management
F11
(5A) Instrumentation control module
F12
(5A) Telephone control module
F13
(10A) Engine management
F14
(30A) Engine management
F15
(10A) CAN data bus gateway control module
F16
(10A/15A) Engine management
F17
–
F18
–
F19
(30A) Audio unit output amplifier
F20
(5A/15A) Clutch position potentiometer engine management
F21
(20A) Auxiliary heater control module
F22
(30A) Windscreen wipers
F23
(10A) Engine coolant blower motor control module, engine management
F24
(10A/15A) Engine management
F25
(40A) Multifunction control module 1
F26
(40A) Multifunction control module 1
F27
(60A) Heated rear window
F28
(40A) Engine management-petrol
F29
(50A) Multifunction control module 1
F30
(50A) Multifunction control module 1
Back-up fuse box Volkswagen at B6.
fuse box pre 04.2005.
F1
(150A/180A) Alternator
F2
(80A) Power steering
F3
(50A/80A) Engine coolant blower motor control module
F4
(100A) Fascia fuse box/relay plate 1 (F32-F37),fascia fuse box/relay plate2(F32-F37), fascia fuse box/relay plate 3 (F44/F46)
F5
(80A) Fascia fuse box/relay plate 2 (F22-F27)
F6
(50A) Fascia fuse box/relay plate 1 (F12-F17/F20/F22-F27/F43-F45)
F7
–
fuse box since 05.2005.
F1
(150A) Altemator
F2
(80A) Power steering
F3
(50A/80A) Engine coolant blower motor control module
F4
(100A) Fascia fuse box/relay plate 1 (F32-F37), fascia fuse box/relay plate 2 (F32-F37), fascia fuse box/relay plate 3 (F44/F46)
F5
(80A) Fascia fuse box/relay plate 2 (F22-F27)
F6
(50A) Fascia fuse box/relay plate 1 (F12-F17/F29-F31)
F7
(60A) Split charge relay
F8
(40A) Anti-lock brake system (ABS)
Fuse box in enger compartment Volkswagen at B6. Fuse box, in right-hand side of dash .
fuse box diagram. left hand drive
right hand drive
F1
–
F2
(5A) Anti-lock brake system (ABS), parking brake control module
F3
(5A) Parking aid control module, navigation system
F4
(5A) Cruise control
F5
(10A) RH gas discharge headlamp
F6
(5A) Transmission mode selection switch
F7
(5A) Headlamp level control module
F8
(5A) Engine management
F9
(10A) Supplementary restraint system (SRS)
F10
(5A) Engine management (BLF/BLR/B LY/AXX/B PY/B LX/BVX/BVY/BVZ/BWA)
F12
(10A) Door function control module, left front
F13
(10A) Parking aid control module
F14
(10A) Assisted door closing control module relay
F15
(5A) Heater/air conditioning (AC)
F16
(5A) Transmission mode selection switch
F17
(10A) Anti-lock brake system (ABS), parking brake control module
F18
–
F19
–
F20
–
F21
–
F22
(30A) Accessories connector
F23
(30A) Door function control module, left rear, door function control module, right rear
F24
(30A) Assisted door closing control module, left rear
F25
(30A) Assisted door closing control module, right rear
F26
–
F27
(25A) Heated seats
F28
(15A) Engine management
F29
F30
(30A) Door function control module, driver, door function control module, left front (20A) Parking brake control module
F31
(20A) Parking brake control module
F32
–
F33
(20A) Accessories connector
F34
(15A) Engine management (AXX/BLF/BLR/BLX/BLY/BPY/BVX/BVY/BVZ/BWA)
F35
(20A) Cigarette lighter
F36
–
F37
–
F38
–
F39
(10A) Heater/air conditioning (AC), heated seats, heated wind screen waterjets, split charge relay
F40
(5A) Crash control module (taxi/police)
F41
auxiliary power sockets(luggage compartment)-taxi, interior lamps-taxi,
(15A) Alarm system (taxi), auxiliary power sockets (glove box) – taxi, roof sign lamp-taxi, taximeter F42
(20A) Auxiliary power sockets(glove box)-taxi (5A) Alarm system (taxi), auxiliary power sockets (police), auxiliary
F43
F44
power sockets (glove box) – taxi, auxiliary power sockets (luggage com partment) -taxi (20A) Alarm system (taxi), auxiliary power sockets- taxi, auxiliary power sockets (police)
Fuse box, on left in dash pane Volkswagen at B6. fuse box location.
fuse box diagram.
F1
(10A) Datalink connector (DLC)
F2
(5A) Anti-lock brake system (ABS)
F3
(5A) Power steering
F4
(5A) Brake pedal position (BPP)switch
F5
(10A) LH gas discharge head lamp, head lamp level control module, head lamp adjustment motor, left or single, head lamp adjustment motor, right
F6
(5A) Trailer control module
F7
(5A)Databusconnection,enginemanagement,instrumentationcontrolmodule
F8
(5A) Garage door opener, interior rearview mirror, rear window blind
F9
(5A) Four-wheel drive control module
F10
(5A) Engine management
F11
(5A) Accident data recorder button, taximeter
F12
(10A) Door function control module, driver
F13
(10A) Datalink connector (DLC), light switch
F14
(5A) Steering column function control module
F15
(5A) Multifunction control module 1
F16
(10A) Ignition system
F17
(10A) Alarm system, auxiliary heater, wind screen wiper rain sensor
F18
–
F19
–
F20
–
F21
–
F22
(5A/10A) engine management
F23
(10A) engine management
F24
(5A/20A) Transmission control module(TCM), reverse gear position switch
F25
(10A) engine management
F26
(10A) Rear window blind
F27
(5A) Heater/air conditioning (AC)
F28
–
F29
(20A) Trailer control module
F30
(15A) Trailer control module
F31
(25A) Trailer control module
F32
(30A) Multifunction control module1
F33
(20A)Sunroof
F34
(15A) engine management
F35
(30A) Head lamp washers
F36
(20A) Auxiliary heater
F37
(30A) Heated seats
F38
–
F39
(40A) Heater/air conditioning (AC)
F40
(5A)Fog lamps
F41
(40A) Heater/air conditioning(AC)
F42
(15A) Windscreen washers, rear screen wiper motor
F43
(20A) Auxiliary heater
F44
(20A) Auxiliary heater
F45
(25A) Auxiliary power sockets
F46
F47
(5A) Two-way radio (police), crash control module(taxi/police), ignition switch circuits, tachograph (15A) Alarm system (taxi), auxiliary power sockets (glove box) – taxi, auxiliary power sockets(luggage compartment)-taxi, auxiliary power sockets(two-way radio)- police, interior lamps, luggage compartment lamp
F48
(20A) Auxiliary power sockets (police)
F49
–
Relay carrier on onboard power supply control unit, on left under dash Volkswagen at B6.
R1
Ignition main circuits relay
R2
–
R3
–
R4
Multifunction control module relay
R5
Heated rear window relay
R6
Horn relay
R7
Windscreen washer pump relay 1
R8
Windscreen washer pump relay 2
R9
Ignition auxiliary circuits relay
R11
Auxiliary heater relay
R12 R13
Heater blower motor relay
R14 R15
Fuel pump(FP) relay-Diesel
R16
Headlamp washer pump relay
R17
Starter motor relay
F1 F2
F3
(30A) Electric seats circuit breaker (enger)
F4
(15A) Electric seats circuit breaker (driver)
Tags: Fuse box diagram Volkswagen
Related Posts
Fuses and relay Volkswagen Vento 19921998
Fuses and relay Volkswagen Touran
Fuses and relay Volkswagen at B5
Fuses and relay Volkswagen Golf 4
Fuses and relay Volkswagen Jetta 6
Fuses and relay Volkswagen at B7
Fuse box diagram Copyright © 2019.
Back to Top ↑
Related Documents 3h463d
Fuse Box at B6 3jj28
March 2023 0
Fuse Box Volkswagen at B6 35153
July 2021 0
Volkswagen at B7 Fuse Box Diagram 34132b
December 2019 192
Vw at B6 - Climatronic Manual 535q4w
October 2022 0
Reparat Motoras Climatizare at B6 5y6s5i
March 2023 0
at Fuse And Relay Locations i2341
April 2023 0More Documents from "Ionut Albuica" 6z1b6o
Fuse Box at B6 3jj28
March 2023 0
Opencv With Java 3el21
December 2019 98
Esp Wroom 32 Datasheet En 6j702h
April 2023 0
Produc Specification Irb 2600 164q30
August 2021 0
Kuhn Thomas S Structura Revolutiilor Stiintifice Pdf f4w4
November 2021 0
