ElectroLogIXS VLC and EC5

System Operation and Maintenance 100373-010 AR0

VOLUME ONE

© 2012 GE Transportation Systems Global Signaling, LLC. All rights reserved. The information contained in this publication is the property of GE Transportation Systems Global Signaling, LLC ("GETS") and is disclosed in confidence. This publication is intended for use by GETS customers solely for purposes of operating, training and performing routine maintenance of purchased or licensed GETS products, and it shall not be reproduced, redistributed, retransmitted, translated, abridged, adapted, condensed, revised or otherwise modified, in any form, in whole or in part, or used for any other purpose or disclosed to others, without the express written consent of GETS. However, if a GETS customer (“Customer”) requires additional copies of this document or portions thereof for internal use, GETS hereby grants to Customer a limited right to reproduce this publication, in whole or in part, and Customer agrees to use such authorized copies (“Copies”) solely for its intended purposes. Any Copies made under this limited reproduction right shall contain this notice and any other legal notices appearing in this publication. The Customer shall be responsible for complying with U.S. export control laws with respect of distribution of all Copies. GETS and Customer agree that the information contained herein does not purport to cover all details or variations in GETS products or to provide for every possible contingency with installation, operation or maintenance. Should further information be desired or should particular problems arise that are not covered sufficiently for the ’s purposes, the matter should be referred to GETS. Any applicable Federal, State or local regulations or company safety or operating rules must take precedence over any information or instructions given in the Technical Documentation. GETS has no obligation to keep the material up to date after the original publication. GE TRANSPORTATION SYSTEMS GLOBAL SIGNALING, LLC EXPLICITLY DISCLAIMS ALL WARRANTIES OF ACCURACY, MERCHANTABILITY OR FITNESS FOR ANY PURPOSE IN CONNECTION WITH THIS PUBLICATION AND USE THEREOF.

Reproduction and Use Restrictions Agreement The information contained in this Technical Manual (the “Document”) is the property of GE Transportation Global Signaling (“GETSGS”) and is protected by copyright and other intellectual property laws. Any unauthorized use or reproduction of this Document without the prior written consent of GETSGS, whether in hard copy or in an electronic form, is strictly prohibited [except as otherwise set forth below]. Notwithstanding the foregoing, GETSGS hereby grants to the purchaser of the GETSGS equipment, or licensee of the GETSGS software (such purchaser of licensee referred to herein as “You”), to which the Document pertains, the following limited reproduction rights. By reproducing any portion of the Document, You expressly agree to the following and conditions. You may make additional copies of the Document solely for use in connection with the GETSGS equipment or GETSGS software to which it pertains, provided that each copy is a complete copy and does not alter the content or meaning of the Document in any way, and provided further that each such copy preserves unaltered all trademark, copyright, patent designations and proprietary or confidentiality notices contained therein, including this Reproduction and Use Restrictions Agreement. Any other use or reproduction of any portion of the Document without the prior written authorization of GETSGS is expressly prohibited. Without limiting any other rights or remedies of GETSGS, in the event that You or any of Your employees, agents or contractors copies any portion of the Document in violation of this Reproduction and Use Restrictions Agreement, You agree to indemnify, defend and hold harmless GETSGS from and against any and all claims, damages, losses, liabilities and expenses (including reasonable attorney’s fees) that may be incurred or awarded by reason thereof.

Revision History This document supersedes all previously issued versions, providing new or revised information. The most recent publication can be determined by comparing the last three characters at the end of the part number and the date issued. ElectroLogIXS VLC and EC5 System Operation and Maintenance Part Number: 100373-010 AR0 Revision Level

Date Issued

AA0

02/28/03

Initial Release

AB0

02/01/05

Re-brand manual revise track circuit transmit and receive procedure.

AC0

02/01/06

Added new modules (VLD-R16S, VIO-44R, and VIO-86S)

AD0

01/16/07

Minor typographical errors fixed

AE0

07/02/07

Updated ElectrologIXS CIO key Pins to remove when CIO-2A and CIO-MDA are installed in the system and also updated as per the markup’s.

AF0

12/03/07

Incorporated VPM-3 module, CI-2 module and Web GUI information.

AG0

04/16/08

Added CI-2 Flash Memory application .

AH0

06/16/08

Incorporated 4-Slot Chassis.

AI0

09/08/08

Added BCS Protocol and description of CIO-2AB module.

AJ0

12/03/08

Incorporated Connector Probing and 1-Slot Chassis.

AK0

12/15/08

Incorporated Connector Probing and 4-Slot Chassis.

AL0

06/01/09

Update for EDVP release of ElectroLogIXS.

AM0

08/26/09

Update for EDVP 2 release of ElectroLogIXS.

AN0

03/08/10

Added DH Server Details.

AO0

05/19/10

Added EC5 Details.

AP0

09/07/10

Add PTC Functionality.

AQ0

07/01/11

Added PTC2, 100373-U001, 100373-U002, and 100373-U003 Updates.

AR0

11/05/12

Added PTC3 Updates.

General Description of Changes

© 2012 GE Transportation Systems Global Signaling, LLC. All rights reserved. Subject to restrictions on the cover or first page.

,

UCI-3 UCI-3

100373-010 AR0


Update (Boot) Mode GUI (Recommended Method) The Update (Boot) Mode GUI is the recommended method for updating software on the VPM-3. Executive Software, Boot Software, PTC Config Files and PTC Mapping Files can all be updated from the Update (Boot) Mode GUI. For directions in using the Update (Boot) Mode GUI, please see the Update (Boot) Mode Web GUI instructions below. Web GUI

1. 2. 3.

Connect to Web GUI diagnostic interface

5.

Connect to VPM3 with RJ45 cable (Crossover or Straight) Open 'Local Area Network Properties', Select Internet Protocol (T/IP) and click 'Properties'. Enter IP address of 192.168.1.100 and a SubNet Mask of 255.255.255.0 if using default ELX port address. Open a Browser and Enter 192.168.1.12 for Port 2 or 192.168.0.11 for Port 1 access. Default name is '', Default is ''

*

VPM3 GE Connect Software tool automates this. P/N: 203630-000

4.

Executive Software Update udate (Boot) Mode GUI 1.

Prior to ing the new VPM-3 Executive Software, ensure the values for all configurable parameters are available from the site documentation or have been recorded from the values shown on the CDU or Web GUI.

2.

Place the VPM-3 in Update (Boot) Mode as follows: a. Turn off the power switch on the ElectroLogIXS/EC5 b. Press and hold the PROG button on the VPM-3 c. Turn on the power switch on the ElectroLogIXS/EC5 d. Release the PROG button

3.

Connect the computer Ethernet RJ45 port to one of the VPM-3 Ethernet RJ45 ports, using an Ethernet cable. Note:

4.

The default VPM-3 IP addresses are 192.168.0.11 for the ENET1 (upper) RJ45 port and 192.168.1.12 for the ENET2 (lower) RJ45 port. These default IP address values are the typical values used in Update (Boot) Mode. Changing the ElectroLogIXS/EC5 IP addresses from the CDU or Web GUI during normal operation does not change the IP addresses used in Update Mode. If values other than the default IP address values must be set / used in Update (Boot) mode, they may be changed using the Update Mode command line. However, the IP address used in Update (Boot) mode is not visible on the CDU, so use of the default values whenever possible is recommended.

Using a Web Browser, navigate to the IP address of the ElectroLogIXS/EC5 unit.


100373-010 AR0

UCI-3 UCI-3

100373-010 AR0



100373-010 AR0

SO F T W A R E

A C TI V A TI O N

Software Activation -- Activate Executive and PTC Mapping files

100373-010 AR0


*(76*6+20(0(18

65[!7[ 7[5[

67,&.

) )

775$&.&85,17 6/27

6<67(0 &21) , * 85$7 , 21

75$&.6

/$036

SNMP Traps

/$030$,17(1$1&(

/,*+728767$786

/$03'5,9(567$786

75$&.

75$&.

)/$6+67$786

$/7)/$6+67$786

9,7$/672367$786

75$&.75$160,77(5

75$&.5(&(,9(5

7(6702'(

$/7(51$7,1*&2'(

;0,79 9 , $ 75$&.5(6 2+0

5(&(,9(, $ 5()(5(1&(

75$160,77(6702'( 7;7(6702'( 2))

$/7(51$7,1*&2'( &2'( 121$/7

6&$%2)) &$%&$%B5

/$03$63(&766 ))))))))))))))))

SNMP Traps - Enable/Disable Traps

/$03'(7(&7,216 ))))))))))))))))

69,7,1 7)

6&2'(6(/(&7

69,7287 7))7

6'(&2'(52876 0

$33,'


100373-010 AR0
