Remix Deck Layouts
Disclaimer
The information in this document is subject to change without notice and does not represent a commitment on the part of Native Instruments GmbH. The software described by this document is subject to a License Agreement and may not be copied to other media. No part of this publication may be copied, reproduced or otherwise transmitted or recorded, for any purpose, without prior written permission by Native Instruments GmbH, hereinafter referred to as Native Instruments. “Native Instruments”, “NI” and associated logos are (ed) trademarks of Native Instruments GmbH. Mac, Mac OS, GarageBand, Logic, iTunes and iPod are ed trademarks of Apple Inc., ed in the U.S. and other countries. Windows, Windows Vista and DirectSound are ed trademarks of Microsoft Corporation in the United States and/or other countries. All other trade marks are the property of their respective owners and use of them does not imply any affiliation with or endorsement by them. Document authored by: Native Instruments GmbH Software version: TRAKTOR 2.6.6 (12/2013) Hardware version: MASCHINE MK1, MASCHINE MK2, MASCHINE MIKRO MK1, MASCHINE MIKRO MK2 Special thanks to the Beta Test Team, who were invaluable not just in tracking down bugs, but in making this a better product.
Native Instruments GmbH Schlesische Str. 29-30 D-10997 Berlin www.native-instruments.de USA Native Instruments North America, Inc. 6725 Sunset Boulevard 5th Floor Los Angeles, CA 90028 USA www.native-instruments.com Japan Native Instruments KK YO Building 3F Jingumae 6-7-15, Shibuya-ku, Tokyo 150-0001 Japan www.native-instruments.co.jp
© Native Instruments GmbH, 2013. All rights reserved.
Table of Contents
Table of Contents 1
Introduction .............................................................................................................. 5
2
Installation ............................................................................................................... 6 2.1 2.2
3
Selecting a Remix Deck Layout for the MASCHINE Controller ...................................................... 6 Importing the TSI File into TRAKTOR ........................................................................................... 9
MASCHINE Remix Deck Layouts ................................................................................. 12 3.1 MASCHINE MK1 Controller Layout ............................................................................................... 13 3.2 MASCHINE MK2 Controller Layout ............................................................................................... 19 3.3 MASCHINE MIKRO MK1 Controller Layout .................................................................................... 25 3.4 MASCHINE MIKRO MK2 Controller Layout .................................................................................... 30
MASCHINE - Remix Deck Layouts - 4
Introduction
1
Introduction
Since the release of TRAKTOR 2.6.2, the ability to map numerous functions of the Remix Decks has been added to the Controller Manager. Using any MIDI-compatible controller, you can now trigger any of the 64 Sample Cells within a Remix Deck, load/capture/delete samples, and scroll through pages in the Remix Decks. With these new abilities, we've created a set of templates and mappings which allow for basic Remix Deck control from the MASCHINE family of controllers. As with KONTROL F1, you will have direct access to the full grid of samples using these mappings with your MASCHINE. Due to the limitations of MIDI and the complexity of the full Remix Deck, the MASCHINE control mappings are still not as extensive and integrated as the KONTROL F1 and this can mainly be seen in how visual differs between the two systems. While the F1 can show animations and a wide variety of colors to assist you during use, the MASCHINE mappings only show basic on/off states for parameters. For example, the colors of samples in the Remix Deck will not be mirrored on the MASCHINE hardware, but you will be able to see which cells are empty and which contain samples. The MASCHINE mappings do, however, include some features which are not available on F1. From the MASCHINE hardware, you will be able to control TRAKTOR's Loop Recorder in order to capture new samples on-the-fly and then copy them into cells of the Remix Decks. You also have transport controls such as Play and Auto Loop. And being that all of these functions are mapped via MIDI, you can change any of the behaviors in TRAKTOR's Controller Manager, and you can also change the preassigned colors for the MASCHINE pads in the Controller Editor.
MASCHINE - Remix Deck Layouts - 5
Installation Selecting a Remix Deck Layout for the MASCHINE Controller
2
Installation
In order to make use of these mappings, two components are required: A Controller Editor template for your MASCHINE controller and a corresponding TSI file for TRAKTOR. Templates and TSIs are available for the following four controllers in the MASCHINE family: ▪ MASCHINE MK1 ▪ MASCHINE MIKRO MK1 ▪ MASCHINE MK2 ▪ MASCHINE MIKRO MK2
2.1
Selecting a Remix Deck Layout for the MASCHINE Controller
Before you can add the Remix Deck Layout to your MASCHINE controller, you must connect your MASCHINE controller to your computer and launch the Controller Editor (this program was installed as part of your MASCHINE and TRAKTOR installations). On the right side of the Controller Editor screen is a list of the Templates that are stored in your Controller Editor. To select the new Remix Deck mapping template:
MASCHINE - Remix Deck Layouts - 6
Installation Selecting a Remix Deck Layout for the MASCHINE Controller
1.
Connect your MASCHINE controller and open up Controller Editor.
MASCHINE - Remix Deck Layouts - 7
Installation Selecting a Remix Deck Layout for the MASCHINE Controller
2.
Click Factory Templates on the right side of the screen and select Maschine Remix Decks from the drop-down menu.
The selected template appears at the bottom of the template list.
MASCHINE - Remix Deck Layouts - 8
Installation Importing the TSI File into TRAKTOR
3.
Click the template to activate it in your MASCHINE.
4.
Close Controller Editor.
2.2
Importing the TSI File into TRAKTOR
To finish setup, you must import the appropriate TSI file into TRAKTOR: 1. 2. 3. 4.
Launch TRAKTOR. In the top-right corner of TRAKTOR, click on the Preferences icon to open the Preferences dialog. Click on the Controller Manager tab. Click the Add… button to open the drop-down menu.
MASCHINE - Remix Deck Layouts - 9
Installation Importing the TSI File into TRAKTOR
5.
Go to Import TSI at the bottom of the list to open a submenu. Select Native Instruments from the submenu and then click the entry in the appearing sub-submenu that corresponds to your MASCHINE controller.
6.
Ensure that the In-Port and Out-Port menus are both set to Maschine. Do not use All Ports.
MASCHINE - Remix Deck Layouts - 10
Installation Importing the TSI File into TRAKTOR
7.
Close the Preferences dialog.
→
Your MASCHINE controller will now be ready to control the Remix Decks.
MASCHINE - Remix Deck Layouts - 11
MASCHINE Remix Deck Layouts
3
MASCHINE Remix Deck Layouts
This section covers all descriptions of Remix Deck layouts for the MASCHINE controllers. The following links lead you to the respective controller layout: ▪ ↑3.1, MASCHINE MK1 Controller Layout. ▪ ↑3.2, MASCHINE MK2 Controller Layout. ▪ ↑3.3, MASCHINE MIKRO MK1 Controller Layout. ▪ ↑3.4, MASCHINE MIKRO MK2 Controller Layout.
MASCHINE - Remix Deck Layouts - 12
MASCHINE Remix Deck Layouts MASCHINE MK1 Controller Layout
3.1
MASCHINE MK1 Controller Layout
Overview of sections on the MASCHINE MK1 controller.
(1) Control Section (2) Master Section
MASCHINE - Remix Deck Layouts - 13
MASCHINE Remix Deck Layouts MASCHINE MK1 Controller Layout
(3) Groups Section (6) Transport Section (5) Pad Section
Control Section
Overview of Knob sections 1 and 2 in the Control section on the MASCHINE MK1 controller.
Knob section 1 corresponds to Remix Deck C in TRAKTOR; Knob section 2 corresponds to Remix Deck D in TRAKTOR. Use the page buttons on the left of the displays to change between Knob page 1 and 2. Knob page 1 gives you control over volume and Knob page 2 control over filters.
Knob Page 1 Shortcut
Action
Press Button 1
Mute Remix Slot 1 (press while holding SAMPLING to Stop the Slot)
Press Button 2
Mute Remix Slot 2 (press while holding SAMPLING to Stop the Slot)
Press Button 3
Mute Remix Slot 3 (press while holding SAMPLING to Stop the Slot)
Press Button 4
Mute Remix Slot 4 (press while holding SAMPLING to Stop the Slot)
Turn Knob 1
Volume Remix Slot 1
MASCHINE - Remix Deck Layouts - 14
MASCHINE Remix Deck Layouts MASCHINE MK1 Controller Layout
Shortcut
Action
Turn Knob 2
Volume Remix Slot 2
Turn Knob 3
Volume Remix Slot 3
Turn Knob 4
Volume Remix Slot 4
Knob Page 2 Shortcut
Action
Press Button 5
FilterOn Remix Slot 1
Press Button 6
FilterOn Remix Slot 2
Press Button 7
FilterOn Remix Slot 3
Press Button 8
FilterOn Remix Slot 4
Turn Knob 5
Filter adjust Remix Slot 1
Turn Knob 6
Filter adjust Remix Slot 2
Turn Knob 7
Filter adjust Remix Slot 3
Turn Knob 8
Filter adjust Remix Slot 4
Master Section
Overview of the Master section on the MASCHINE MK1 controller.
Shortcut
Action
Turn VOLUME Knob
Browse
Turn TEMPO Knob
Capture Source
MASCHINE - Remix Deck Layouts - 15
MASCHINE Remix Deck Layouts MASCHINE MK1 Controller Layout
Shortcut
Action
Turn SWING Knob
Recorder Dry/Wet
Press NOTE REPEAT Button
Loop Recorder Record
Groups Section
Overview of the Groups section on the MASCHINE MK1 controller.
Shortcut
Action
Press Button A-D
Pads control Page 1-4 of Remix Deck C
Press Button E-H
Pads control Page 1-4 of Remix Deck D
MASCHINE - Remix Deck Layouts - 16
MASCHINE Remix Deck Layouts MASCHINE MK1 Controller Layout
Pads Section
Overview of the Pads Section on the MASCHINE MK1 controller.
Shortcut
Action
Press SCENE Button
Load Remix Deck from Browser
Hold PAD MODE Button + press Pads
Toggle Keylock, FX Enable, Monitor, and Punch Mode on Remix Slots
Hold SELECT Button + press Pad
Load sample from browser into Sample Cell.
Hold DUPLICATE Button + press Pad
Capture from Capture Source into Sample Cell.
Hold SOLO Button + press Pad
Reverse sample playback
Hold MUTE Button + press Pad
Delete sample from Sample Cell
MASCHINE - Remix Deck Layouts - 17
MASCHINE Remix Deck Layouts MASCHINE MK1 Controller Layout
Transport Section
Overview of the Transport section on the MASCHINE MK1 controller.
Shortcut
Action
Press PLAY Button
Play selected Remix Deck
Press CUE Button
Cue selected Remix Deck
Press ERASE Button
Cue Play selected Remix Deck
Press RESTART Button
Sync
Press ◄ STEP / STEP ► Button
Loop Size
Press GRID Button
Auto Loop
MASCHINE - Remix Deck Layouts - 18
MASCHINE Remix Deck Layouts MASCHINE MK2 Controller Layout
3.2
MASCHINE MK2 Controller Layout
Overview of sections on the MASCHINE MK2 controller.
(1) Control Section (2) Master Section
MASCHINE - Remix Deck Layouts - 19
MASCHINE Remix Deck Layouts MASCHINE MK2 Controller Layout
(3) Groups Section (6) Transport Section (5) Pads Section
Control Section
Overview of the Knob sections 1 and 2 in the Control section on the MASCHINE MK2 controller.
Knob section 1 corresponds to Remix Deck C in TRAKTOR; Knob section 2 corresponds to Remix Deck D in TRAKTOR. Use the page buttons on the left of the displays to change between Knob page 1 and 2. Knob page 1 gives you control over volume and Knob page 2 control over filters.
Knob Page 1 Shortcut
Action
Press Button 1
Mute Remix Slot 1 (press while holding SAMPLING to Stop the Slot)
Press Button 2
Mute Remix Slot 2 (press while holding SAMPLING to Stop the Slot)
Press Button 3
Mute Remix Slot 3 (press while holding SAMPLING to Stop the Slot)
Press Button 4
Mute Remix Slot 4 (press while holding SAMPLING to Stop the Slot)
MASCHINE - Remix Deck Layouts - 20
MASCHINE Remix Deck Layouts MASCHINE MK2 Controller Layout
Shortcut
Action
Turn Knob 1
Volume Remix Slot 1
Turn Knob 2
Volume Remix Slot 2
Turn Knob 3
Volume Remix Slot 3
Turn Knob 4
Volume Remix Slot 4
Knob Page 2 Shortcut
Action
Press Button 5
FilterOn Remix Slot 1
Press Button 6
FilterOn Remix Slot 2
Press Button 7
FilterOn Remix Slot 3
Press Button 8
FilterOn Remix Slot 4
Turn Knob 5
Filter adjust Remix Slot 1
Turn Knob 6
Filter adjust Remix Slot 2
Turn Knob 7
Filter adjust Remix Slot 3
Turn Knob 8
Filter adjust Remix Slot 4
Master Section
Overview of the Master section on the MASCHINE MK2 controller.
MASCHINE - Remix Deck Layouts - 21
MASCHINE Remix Deck Layouts MASCHINE MK2 Controller Layout
Shortcut
Action
Press NOTE REPEAT Button
Turn the encoder to scroll through the pages of the selected Remix deck. ◄ / ► and ENTER Buttons do nothing.
Press VOLUME Button
Turn the encoder to scroll through the Capture Source with . Buttons select direct Capture Source.
Press SWING Button
Browse mode. Press ◄ to scroll through the explorer (press the encoder to expand/collaps). Press ► to scroll through the favorites. Press ENTER to toggle browser mode. Without any mode selected (both arrow keys ◄ / ► off) press will load Remix Kit to Remix Deck.
Press TEMPO Button
Controls Loop Recorder. 1. Turn the encoder for Dry/Wet. 2. Press the encoder to Record. 3. Press ◄ / ► for Loop Size. 4. Press ENTER Button to Play.
Groups Section
Overview of the Groups section on the MASCHINE MK2 controller.
MASCHINE - Remix Deck Layouts - 22
MASCHINE Remix Deck Layouts MASCHINE MK2 Controller Layout
Shortcut
Action
Press Buttons A-D
Pads control Page 1-4 of Remix Deck C
Press Buttons E-H
Pads control Page 1-4 of Remix Deck D
Pads Section
Overview of the Pads Section on the MASCHINE MK2 controller.
Shortcut
Action
Hold PAD MODE Button + press Pads
Toggle Keylock, FX Enable, Monitor, and Punch Mode on Remix Slots
Hold DUPLICATE Button + press Pad
Capture from Capture Source into Sample Cell.
Hold SELECT Button + press Pad
Load sample from browser into Sample Cell.
MASCHINE - Remix Deck Layouts - 23
MASCHINE Remix Deck Layouts MASCHINE MK2 Controller Layout
Shortcut
Action
Hold SOLO Button + press Pad
Reverse sample playback
Hold MUTE Button + press Pad
Delete sample from Sample Cell
Transport Section
Overview of the Transport section on the MASCHINE MK2 controller.
Shortcut
Action
Press PLAY Button
Play selected Remix Deck
Press CUE Button
Cue selected Remix Deck
Press ERASE Button
Cue Play selected Remix Deck
Press RESTART Button
Sync
Press ◄ STEP / STEP ► Button
Loop Size
Press GRID Button
Auto loop
MASCHINE - Remix Deck Layouts - 24
MASCHINE Remix Deck Layouts MASCHINE MIKRO MK1 Controller Layout
3.3
MASCHINE MIKRO MK1 Controller Layout
Overview of the MASCHINE MIKRO MK1 controller.
(1) Master Section (2) Transport Section (3) Pads Section
MASCHINE - Remix Deck Layouts - 25
MASCHINE Remix Deck Layouts MASCHINE MIKRO MK1 Controller Layout
Master section
Overview of the Master section on the MASCHINE MIKRO MK1 controller.
Shortcut
Action
Press BROWSE
When this button is on, the encoder is used for browsing. 1. Rotate the encoder to scroll through the list and push the encoder to load the selected item into the current Remix Deck. 2. If you also turn on F1, then you will browse the Tree. 3. With F2 on, you'll browse the Favorites. 3. Pressing F3 toggles Browser View.
Press SAPMLING
When this button is on, the encoder will select the Capture Source for the Remix Deck. Shortcuts are also available with the F-buttons: 1. Press F1 to select Remix Deck A. 2. Press F2 to select Remix Deck B. 3. Press F3 to select the Loop Recorder for the Capture Source.
MASCHINE - Remix Deck Layouts - 26
MASCHINE Remix Deck Layouts MASCHINE MIKRO MK1 Controller Layout
Shortcut
Action
Press NOTE REPEAT
With this button on, the encoder controls the Loop Recorder Dry/Wet mix. 1. Push the encoder to toggle Record on and off. 2. Press F1 to decrease the Loop Size 3. Press F2 to increase the Loop Size. 4. Push F3 to toggle Playback on and off.
Press MAIN
This button selects which Remix Deck is controlled by the MASCHINE hardware. When the button is off, Remix Deck C is controlled. When the button is on, Remix Deck D is controlled.
Press GROUP
When this button is on, the Encoder scrolls the Sample Pages of the selected Remix Deck.
MASCHINE - Remix Deck Layouts - 27
MASCHINE Remix Deck Layouts MASCHINE MIKRO MK1 Controller Layout
Pads Section
Overview of Pads section on the MASCHINE MIKRO MK1 controller.
Most of these actions require to press a Pad. For example, holding SELECT and then pressing a Pad loads the sample selected in the Browser into the Pad. Shortcut
Action
Hold PAD MODE Button + press Pads
Toggle Keylock, FX Enable, Monitor, and Punch Mode on Remix Slots
Hold DUPLICATE Button + press Pad
Capture from Capture Source into Sample Cell.
Hold SELECT Button + press Pad
Load sample from browser into Sample Cell.
Hold SOLO Button + press Pad
Reverse sample playback
Hold MUTE Button + press Pad
Delete sample from Sample Cell
MASCHINE - Remix Deck Layouts - 28
MASCHINE Remix Deck Layouts MASCHINE MIKRO MK1 Controller Layout
Transport
Overview of the Transport section on the MASCHINE MIKRO MK1 controller.
Shortcut
Action
Press PLAY button
Play selected Remix deck
Press CUE button
Cue selected Remix Deck
Press ERASE button
Cue Play selected Remix deck
Press RESTART button
Sync
Press ◄ STEP / STEP ► button
Loop Siz
Press GRID button
Auto loop
MASCHINE - Remix Deck Layouts - 29
MASCHINE Remix Deck Layouts MASCHINE MIKRO MK2 Controller Layout
3.4
MASCHINE MIKRO MK2 Controller Layout
Overview of sections on the MASCHINE MIKRO MK2 controller.
(1) Master Section (2) Transport Section (3) Pads Section
MASCHINE - Remix Deck Layouts - 30
MASCHINE Remix Deck Layouts MASCHINE MIKRO MK2 Controller Layout
Master Section
Overview of the Master section on the MASCHINE MIKRO MK2 controller.
Shortcut
Action
Press BROWSE
When this button is on, the Encoder is used for browsing. 1. Rotate the Encoder to scroll through the list and push the Encoder to load the selected item into the current Remix Deck. 2. If you also turn on F1, then you will browse the Tree. 3. With F2 on, you'll browse the Favorites. 3. Pressing F3 toggles Browser View.
Press SAPMLING
When this button is on, the encoder will select the Capture Source for the Remix Deck. Shortcuts are also available with the F-buttons: 1. Press F1 to select Remix Deck A. 2. Press F2 to select Remix Deck B. 3. Press F3 to select the Loop Recorder for the Capture Source.
MASCHINE - Remix Deck Layouts - 31
MASCHINE Remix Deck Layouts MASCHINE MIKRO MK2 Controller Layout
Shortcut
Action
Press NOTE REPEAT
With this button on, the encoder controls the Loop Recorder Dry/ Wet mix. 1. Push the encoder to toggle Record on and off. 2. Press F1 to decrease the Loop Size 3. Press F2 to increase the Loop Size. 4. Push F3 to toggle Playback on and off.
Press CONTROL
This button selects which Remix Deck is controlled by the MASCHINE hardware. When the button is off, Remix Deck C is controlled. When the button is on, Remix Deck D is controlled.
Press GROUP
When this button is on, the Encoder scrolls the Sample Pages of the selected Remix Deck.
MASCHINE - Remix Deck Layouts - 32
MASCHINE Remix Deck Layouts MASCHINE MIKRO MK2 Controller Layout
Pads Section
Overview of the Pads section on the MASCHINE MIKRO MK2 controller.
Most of these actions require to press a Pad. For example, holding SELECT and then pressing a Pad loads the sample selected in the Browser into the Pad. Shortcut
Action
Hold PAD MODE Button + press Pads
Toggle Keylock, FX Enable, Monitor, and Punch Mode on Remix Slots
Hold DUPLICATE Button + press Pad
Capture from Capture Source into Sample Cell.
Hold SELECT Button + press Pad
Load sample from browser into Sample Cell.
Hold SOLO Button + press Pad
Reverse sample playback
Hold MUTE Button + press Pad
Delete sample from Sample Cell
MASCHINE - Remix Deck Layouts - 33
MASCHINE Remix Deck Layouts MASCHINE MIKRO MK2 Controller Layout
Transport Section
Overview of the Transport section on the MASCHINE MIKRO MK2 controller.
Shortcut
Action
Press PLAY button
Play selected Remix Deck
Press CUE button
Cue selected Remix Deck
Press ERASE button
Cue Play selected Remix Deck
Press RESTART button
Sync
Press ◄ STEP / STEP ► button
Loop Siz
Press GRID button
Auto loop
MASCHINE - Remix Deck Layouts - 34
Disclaimer
The information in this document is subject to change without notice and does not represent a commitment on the part of Native Instruments GmbH. The software described by this document is subject to a License Agreement and may not be copied to other media. No part of this publication may be copied, reproduced or otherwise transmitted or recorded, for any purpose, without prior written permission by Native Instruments GmbH, hereinafter referred to as Native Instruments. “Native Instruments”, “NI” and associated logos are (ed) trademarks of Native Instruments GmbH. Mac, Mac OS, GarageBand, Logic, iTunes and iPod are ed trademarks of Apple Inc., ed in the U.S. and other countries. Windows, Windows Vista and DirectSound are ed trademarks of Microsoft Corporation in the United States and/or other countries. All other trade marks are the property of their respective owners and use of them does not imply any affiliation with or endorsement by them. Document authored by: Native Instruments GmbH Software version: TRAKTOR 2.6.6 (12/2013) Hardware version: MASCHINE MK1, MASCHINE MK2, MASCHINE MIKRO MK1, MASCHINE MIKRO MK2 Special thanks to the Beta Test Team, who were invaluable not just in tracking down bugs, but in making this a better product.
Native Instruments GmbH Schlesische Str. 29-30 D-10997 Berlin www.native-instruments.de USA Native Instruments North America, Inc. 6725 Sunset Boulevard 5th Floor Los Angeles, CA 90028 USA www.native-instruments.com Japan Native Instruments KK YO Building 3F Jingumae 6-7-15, Shibuya-ku, Tokyo 150-0001 Japan www.native-instruments.co.jp
© Native Instruments GmbH, 2013. All rights reserved.
Table of Contents
Table of Contents 1
Introduction .............................................................................................................. 5
2
Installation ............................................................................................................... 6 2.1 2.2
3
Selecting a Remix Deck Layout for the MASCHINE Controller ...................................................... 6 Importing the TSI File into TRAKTOR ........................................................................................... 9
MASCHINE Remix Deck Layouts ................................................................................. 12 3.1 MASCHINE MK1 Controller Layout ............................................................................................... 13 3.2 MASCHINE MK2 Controller Layout ............................................................................................... 19 3.3 MASCHINE MIKRO MK1 Controller Layout .................................................................................... 25 3.4 MASCHINE MIKRO MK2 Controller Layout .................................................................................... 30
MASCHINE - Remix Deck Layouts - 4
Introduction
1
Introduction
Since the release of TRAKTOR 2.6.2, the ability to map numerous functions of the Remix Decks has been added to the Controller Manager. Using any MIDI-compatible controller, you can now trigger any of the 64 Sample Cells within a Remix Deck, load/capture/delete samples, and scroll through pages in the Remix Decks. With these new abilities, we've created a set of templates and mappings which allow for basic Remix Deck control from the MASCHINE family of controllers. As with KONTROL F1, you will have direct access to the full grid of samples using these mappings with your MASCHINE. Due to the limitations of MIDI and the complexity of the full Remix Deck, the MASCHINE control mappings are still not as extensive and integrated as the KONTROL F1 and this can mainly be seen in how visual differs between the two systems. While the F1 can show animations and a wide variety of colors to assist you during use, the MASCHINE mappings only show basic on/off states for parameters. For example, the colors of samples in the Remix Deck will not be mirrored on the MASCHINE hardware, but you will be able to see which cells are empty and which contain samples. The MASCHINE mappings do, however, include some features which are not available on F1. From the MASCHINE hardware, you will be able to control TRAKTOR's Loop Recorder in order to capture new samples on-the-fly and then copy them into cells of the Remix Decks. You also have transport controls such as Play and Auto Loop. And being that all of these functions are mapped via MIDI, you can change any of the behaviors in TRAKTOR's Controller Manager, and you can also change the preassigned colors for the MASCHINE pads in the Controller Editor.
MASCHINE - Remix Deck Layouts - 5
Installation Selecting a Remix Deck Layout for the MASCHINE Controller
2
Installation
In order to make use of these mappings, two components are required: A Controller Editor template for your MASCHINE controller and a corresponding TSI file for TRAKTOR. Templates and TSIs are available for the following four controllers in the MASCHINE family: ▪ MASCHINE MK1 ▪ MASCHINE MIKRO MK1 ▪ MASCHINE MK2 ▪ MASCHINE MIKRO MK2
2.1
Selecting a Remix Deck Layout for the MASCHINE Controller
Before you can add the Remix Deck Layout to your MASCHINE controller, you must connect your MASCHINE controller to your computer and launch the Controller Editor (this program was installed as part of your MASCHINE and TRAKTOR installations). On the right side of the Controller Editor screen is a list of the Templates that are stored in your Controller Editor. To select the new Remix Deck mapping template:
MASCHINE - Remix Deck Layouts - 6
Installation Selecting a Remix Deck Layout for the MASCHINE Controller
1.
Connect your MASCHINE controller and open up Controller Editor.
MASCHINE - Remix Deck Layouts - 7
Installation Selecting a Remix Deck Layout for the MASCHINE Controller
2.
Click Factory Templates on the right side of the screen and select Maschine Remix Decks from the drop-down menu.
The selected template appears at the bottom of the template list.
MASCHINE - Remix Deck Layouts - 8
Installation Importing the TSI File into TRAKTOR
3.
Click the template to activate it in your MASCHINE.
4.
Close Controller Editor.
2.2
Importing the TSI File into TRAKTOR
To finish setup, you must import the appropriate TSI file into TRAKTOR: 1. 2. 3. 4.
Launch TRAKTOR. In the top-right corner of TRAKTOR, click on the Preferences icon to open the Preferences dialog. Click on the Controller Manager tab. Click the Add… button to open the drop-down menu.
MASCHINE - Remix Deck Layouts - 9
Installation Importing the TSI File into TRAKTOR
5.
Go to Import TSI at the bottom of the list to open a submenu. Select Native Instruments from the submenu and then click the entry in the appearing sub-submenu that corresponds to your MASCHINE controller.
6.
Ensure that the In-Port and Out-Port menus are both set to Maschine. Do not use All Ports.
MASCHINE - Remix Deck Layouts - 10
Installation Importing the TSI File into TRAKTOR
7.
Close the Preferences dialog.
→
Your MASCHINE controller will now be ready to control the Remix Decks.
MASCHINE - Remix Deck Layouts - 11
MASCHINE Remix Deck Layouts
3
MASCHINE Remix Deck Layouts
This section covers all descriptions of Remix Deck layouts for the MASCHINE controllers. The following links lead you to the respective controller layout: ▪ ↑3.1, MASCHINE MK1 Controller Layout. ▪ ↑3.2, MASCHINE MK2 Controller Layout. ▪ ↑3.3, MASCHINE MIKRO MK1 Controller Layout. ▪ ↑3.4, MASCHINE MIKRO MK2 Controller Layout.
MASCHINE - Remix Deck Layouts - 12
MASCHINE Remix Deck Layouts MASCHINE MK1 Controller Layout
3.1
MASCHINE MK1 Controller Layout
Overview of sections on the MASCHINE MK1 controller.
(1) Control Section (2) Master Section
MASCHINE - Remix Deck Layouts - 13
MASCHINE Remix Deck Layouts MASCHINE MK1 Controller Layout
(3) Groups Section (6) Transport Section (5) Pad Section
Control Section
Overview of Knob sections 1 and 2 in the Control section on the MASCHINE MK1 controller.
Knob section 1 corresponds to Remix Deck C in TRAKTOR; Knob section 2 corresponds to Remix Deck D in TRAKTOR. Use the page buttons on the left of the displays to change between Knob page 1 and 2. Knob page 1 gives you control over volume and Knob page 2 control over filters.
Knob Page 1 Shortcut
Action
Press Button 1
Mute Remix Slot 1 (press while holding SAMPLING to Stop the Slot)
Press Button 2
Mute Remix Slot 2 (press while holding SAMPLING to Stop the Slot)
Press Button 3
Mute Remix Slot 3 (press while holding SAMPLING to Stop the Slot)
Press Button 4
Mute Remix Slot 4 (press while holding SAMPLING to Stop the Slot)
Turn Knob 1
Volume Remix Slot 1
MASCHINE - Remix Deck Layouts - 14
MASCHINE Remix Deck Layouts MASCHINE MK1 Controller Layout
Shortcut
Action
Turn Knob 2
Volume Remix Slot 2
Turn Knob 3
Volume Remix Slot 3
Turn Knob 4
Volume Remix Slot 4
Knob Page 2 Shortcut
Action
Press Button 5
FilterOn Remix Slot 1
Press Button 6
FilterOn Remix Slot 2
Press Button 7
FilterOn Remix Slot 3
Press Button 8
FilterOn Remix Slot 4
Turn Knob 5
Filter adjust Remix Slot 1
Turn Knob 6
Filter adjust Remix Slot 2
Turn Knob 7
Filter adjust Remix Slot 3
Turn Knob 8
Filter adjust Remix Slot 4
Master Section
Overview of the Master section on the MASCHINE MK1 controller.
Shortcut
Action
Turn VOLUME Knob
Browse
Turn TEMPO Knob
Capture Source
MASCHINE - Remix Deck Layouts - 15
MASCHINE Remix Deck Layouts MASCHINE MK1 Controller Layout
Shortcut
Action
Turn SWING Knob
Recorder Dry/Wet
Press NOTE REPEAT Button
Loop Recorder Record
Groups Section
Overview of the Groups section on the MASCHINE MK1 controller.
Shortcut
Action
Press Button A-D
Pads control Page 1-4 of Remix Deck C
Press Button E-H
Pads control Page 1-4 of Remix Deck D
MASCHINE - Remix Deck Layouts - 16
MASCHINE Remix Deck Layouts MASCHINE MK1 Controller Layout
Pads Section
Overview of the Pads Section on the MASCHINE MK1 controller.
Shortcut
Action
Press SCENE Button
Load Remix Deck from Browser
Hold PAD MODE Button + press Pads
Toggle Keylock, FX Enable, Monitor, and Punch Mode on Remix Slots
Hold SELECT Button + press Pad
Load sample from browser into Sample Cell.
Hold DUPLICATE Button + press Pad
Capture from Capture Source into Sample Cell.
Hold SOLO Button + press Pad
Reverse sample playback
Hold MUTE Button + press Pad
Delete sample from Sample Cell
MASCHINE - Remix Deck Layouts - 17
MASCHINE Remix Deck Layouts MASCHINE MK1 Controller Layout
Transport Section
Overview of the Transport section on the MASCHINE MK1 controller.
Shortcut
Action
Press PLAY Button
Play selected Remix Deck
Press CUE Button
Cue selected Remix Deck
Press ERASE Button
Cue Play selected Remix Deck
Press RESTART Button
Sync
Press ◄ STEP / STEP ► Button
Loop Size
Press GRID Button
Auto Loop
MASCHINE - Remix Deck Layouts - 18
MASCHINE Remix Deck Layouts MASCHINE MK2 Controller Layout
3.2
MASCHINE MK2 Controller Layout
Overview of sections on the MASCHINE MK2 controller.
(1) Control Section (2) Master Section
MASCHINE - Remix Deck Layouts - 19
MASCHINE Remix Deck Layouts MASCHINE MK2 Controller Layout
(3) Groups Section (6) Transport Section (5) Pads Section
Control Section
Overview of the Knob sections 1 and 2 in the Control section on the MASCHINE MK2 controller.
Knob section 1 corresponds to Remix Deck C in TRAKTOR; Knob section 2 corresponds to Remix Deck D in TRAKTOR. Use the page buttons on the left of the displays to change between Knob page 1 and 2. Knob page 1 gives you control over volume and Knob page 2 control over filters.
Knob Page 1 Shortcut
Action
Press Button 1
Mute Remix Slot 1 (press while holding SAMPLING to Stop the Slot)
Press Button 2
Mute Remix Slot 2 (press while holding SAMPLING to Stop the Slot)
Press Button 3
Mute Remix Slot 3 (press while holding SAMPLING to Stop the Slot)
Press Button 4
Mute Remix Slot 4 (press while holding SAMPLING to Stop the Slot)
MASCHINE - Remix Deck Layouts - 20
MASCHINE Remix Deck Layouts MASCHINE MK2 Controller Layout
Shortcut
Action
Turn Knob 1
Volume Remix Slot 1
Turn Knob 2
Volume Remix Slot 2
Turn Knob 3
Volume Remix Slot 3
Turn Knob 4
Volume Remix Slot 4
Knob Page 2 Shortcut
Action
Press Button 5
FilterOn Remix Slot 1
Press Button 6
FilterOn Remix Slot 2
Press Button 7
FilterOn Remix Slot 3
Press Button 8
FilterOn Remix Slot 4
Turn Knob 5
Filter adjust Remix Slot 1
Turn Knob 6
Filter adjust Remix Slot 2
Turn Knob 7
Filter adjust Remix Slot 3
Turn Knob 8
Filter adjust Remix Slot 4
Master Section
Overview of the Master section on the MASCHINE MK2 controller.
MASCHINE - Remix Deck Layouts - 21
MASCHINE Remix Deck Layouts MASCHINE MK2 Controller Layout
Shortcut
Action
Press NOTE REPEAT Button
Turn the encoder to scroll through the pages of the selected Remix deck. ◄ / ► and ENTER Buttons do nothing.
Press VOLUME Button
Turn the encoder to scroll through the Capture Source with . Buttons select direct Capture Source.
Press SWING Button
Browse mode. Press ◄ to scroll through the explorer (press the encoder to expand/collaps). Press ► to scroll through the favorites. Press ENTER to toggle browser mode. Without any mode selected (both arrow keys ◄ / ► off) press will load Remix Kit to Remix Deck.
Press TEMPO Button
Controls Loop Recorder. 1. Turn the encoder for Dry/Wet. 2. Press the encoder to Record. 3. Press ◄ / ► for Loop Size. 4. Press ENTER Button to Play.
Groups Section
Overview of the Groups section on the MASCHINE MK2 controller.
MASCHINE - Remix Deck Layouts - 22
MASCHINE Remix Deck Layouts MASCHINE MK2 Controller Layout
Shortcut
Action
Press Buttons A-D
Pads control Page 1-4 of Remix Deck C
Press Buttons E-H
Pads control Page 1-4 of Remix Deck D
Pads Section
Overview of the Pads Section on the MASCHINE MK2 controller.
Shortcut
Action
Hold PAD MODE Button + press Pads
Toggle Keylock, FX Enable, Monitor, and Punch Mode on Remix Slots
Hold DUPLICATE Button + press Pad
Capture from Capture Source into Sample Cell.
Hold SELECT Button + press Pad
Load sample from browser into Sample Cell.
MASCHINE - Remix Deck Layouts - 23
MASCHINE Remix Deck Layouts MASCHINE MK2 Controller Layout
Shortcut
Action
Hold SOLO Button + press Pad
Reverse sample playback
Hold MUTE Button + press Pad
Delete sample from Sample Cell
Transport Section
Overview of the Transport section on the MASCHINE MK2 controller.
Shortcut
Action
Press PLAY Button
Play selected Remix Deck
Press CUE Button
Cue selected Remix Deck
Press ERASE Button
Cue Play selected Remix Deck
Press RESTART Button
Sync
Press ◄ STEP / STEP ► Button
Loop Size
Press GRID Button
Auto loop
MASCHINE - Remix Deck Layouts - 24
MASCHINE Remix Deck Layouts MASCHINE MIKRO MK1 Controller Layout
3.3
MASCHINE MIKRO MK1 Controller Layout
Overview of the MASCHINE MIKRO MK1 controller.
(1) Master Section (2) Transport Section (3) Pads Section
MASCHINE - Remix Deck Layouts - 25
MASCHINE Remix Deck Layouts MASCHINE MIKRO MK1 Controller Layout
Master section
Overview of the Master section on the MASCHINE MIKRO MK1 controller.
Shortcut
Action
Press BROWSE
When this button is on, the encoder is used for browsing. 1. Rotate the encoder to scroll through the list and push the encoder to load the selected item into the current Remix Deck. 2. If you also turn on F1, then you will browse the Tree. 3. With F2 on, you'll browse the Favorites. 3. Pressing F3 toggles Browser View.
Press SAPMLING
When this button is on, the encoder will select the Capture Source for the Remix Deck. Shortcuts are also available with the F-buttons: 1. Press F1 to select Remix Deck A. 2. Press F2 to select Remix Deck B. 3. Press F3 to select the Loop Recorder for the Capture Source.
MASCHINE - Remix Deck Layouts - 26
MASCHINE Remix Deck Layouts MASCHINE MIKRO MK1 Controller Layout
Shortcut
Action
Press NOTE REPEAT
With this button on, the encoder controls the Loop Recorder Dry/Wet mix. 1. Push the encoder to toggle Record on and off. 2. Press F1 to decrease the Loop Size 3. Press F2 to increase the Loop Size. 4. Push F3 to toggle Playback on and off.
Press MAIN
This button selects which Remix Deck is controlled by the MASCHINE hardware. When the button is off, Remix Deck C is controlled. When the button is on, Remix Deck D is controlled.
Press GROUP
When this button is on, the Encoder scrolls the Sample Pages of the selected Remix Deck.
MASCHINE - Remix Deck Layouts - 27
MASCHINE Remix Deck Layouts MASCHINE MIKRO MK1 Controller Layout
Pads Section
Overview of Pads section on the MASCHINE MIKRO MK1 controller.
Most of these actions require to press a Pad. For example, holding SELECT and then pressing a Pad loads the sample selected in the Browser into the Pad. Shortcut
Action
Hold PAD MODE Button + press Pads
Toggle Keylock, FX Enable, Monitor, and Punch Mode on Remix Slots
Hold DUPLICATE Button + press Pad
Capture from Capture Source into Sample Cell.
Hold SELECT Button + press Pad
Load sample from browser into Sample Cell.
Hold SOLO Button + press Pad
Reverse sample playback
Hold MUTE Button + press Pad
Delete sample from Sample Cell
MASCHINE - Remix Deck Layouts - 28
MASCHINE Remix Deck Layouts MASCHINE MIKRO MK1 Controller Layout
Transport
Overview of the Transport section on the MASCHINE MIKRO MK1 controller.
Shortcut
Action
Press PLAY button
Play selected Remix deck
Press CUE button
Cue selected Remix Deck
Press ERASE button
Cue Play selected Remix deck
Press RESTART button
Sync
Press ◄ STEP / STEP ► button
Loop Siz
Press GRID button
Auto loop
MASCHINE - Remix Deck Layouts - 29
MASCHINE Remix Deck Layouts MASCHINE MIKRO MK2 Controller Layout
3.4
MASCHINE MIKRO MK2 Controller Layout
Overview of sections on the MASCHINE MIKRO MK2 controller.
(1) Master Section (2) Transport Section (3) Pads Section
MASCHINE - Remix Deck Layouts - 30
MASCHINE Remix Deck Layouts MASCHINE MIKRO MK2 Controller Layout
Master Section
Overview of the Master section on the MASCHINE MIKRO MK2 controller.
Shortcut
Action
Press BROWSE
When this button is on, the Encoder is used for browsing. 1. Rotate the Encoder to scroll through the list and push the Encoder to load the selected item into the current Remix Deck. 2. If you also turn on F1, then you will browse the Tree. 3. With F2 on, you'll browse the Favorites. 3. Pressing F3 toggles Browser View.
Press SAPMLING
When this button is on, the encoder will select the Capture Source for the Remix Deck. Shortcuts are also available with the F-buttons: 1. Press F1 to select Remix Deck A. 2. Press F2 to select Remix Deck B. 3. Press F3 to select the Loop Recorder for the Capture Source.
MASCHINE - Remix Deck Layouts - 31
MASCHINE Remix Deck Layouts MASCHINE MIKRO MK2 Controller Layout
Shortcut
Action
Press NOTE REPEAT
With this button on, the encoder controls the Loop Recorder Dry/ Wet mix. 1. Push the encoder to toggle Record on and off. 2. Press F1 to decrease the Loop Size 3. Press F2 to increase the Loop Size. 4. Push F3 to toggle Playback on and off.
Press CONTROL
This button selects which Remix Deck is controlled by the MASCHINE hardware. When the button is off, Remix Deck C is controlled. When the button is on, Remix Deck D is controlled.
Press GROUP
When this button is on, the Encoder scrolls the Sample Pages of the selected Remix Deck.
MASCHINE - Remix Deck Layouts - 32
MASCHINE Remix Deck Layouts MASCHINE MIKRO MK2 Controller Layout
Pads Section
Overview of the Pads section on the MASCHINE MIKRO MK2 controller.
Most of these actions require to press a Pad. For example, holding SELECT and then pressing a Pad loads the sample selected in the Browser into the Pad. Shortcut
Action
Hold PAD MODE Button + press Pads
Toggle Keylock, FX Enable, Monitor, and Punch Mode on Remix Slots
Hold DUPLICATE Button + press Pad
Capture from Capture Source into Sample Cell.
Hold SELECT Button + press Pad
Load sample from browser into Sample Cell.
Hold SOLO Button + press Pad
Reverse sample playback
Hold MUTE Button + press Pad
Delete sample from Sample Cell
MASCHINE - Remix Deck Layouts - 33
MASCHINE Remix Deck Layouts MASCHINE MIKRO MK2 Controller Layout
Transport Section
Overview of the Transport section on the MASCHINE MIKRO MK2 controller.
Shortcut
Action
Press PLAY button
Play selected Remix Deck
Press CUE button
Cue selected Remix Deck
Press ERASE button
Cue Play selected Remix Deck
Press RESTART button
Sync
Press ◄ STEP / STEP ► button
Loop Siz
Press GRID button
Auto loop
MASCHINE - Remix Deck Layouts - 34
Related Documents 3h463d
Maschine Remix Deck Layout.pdf 622e5x
March 2023 0
Plakito Remix 1a2id
June 2022 0
Maschine Manual 76l50
November 2019 29
Deck 6evs
October 2020 0
Remix (1) 12165b
October 2022 0
Nuevos Remix 5h6350
June 2022 0More Documents from "marc" 3nt4r
Maschine Remix Deck Layout.pdf 622e5x
March 2023 0
The Aesthetics Of St Augustine 726q5o
April 2022 0
Grade 10 History Book Sri Lanka 4x5l3u
November 2019 2,255
4p345f
December 2020 0
Beauty And The Beast 2x15 - The Watcher 3h6m50
August 2022 0
