Microsoft Outlook 2007 Mail Box Management

Table of Contents 1. Offline Store Files (OST) .......................................................................................... 3 2. Personal Folders File ............................................................................................... 4 3. Managing your Offline Folders .................................................................................. 5 3a. Watch Out for Attachments!................................................................................ 6 3b. Your Mailbox Sent Items Folder........................................................... 7 3c.Empty Your Deleted Items Folder - Regularly! ........................................................ 7 3d.To compact PST or OST files on local machines ...................................................... 7 4. How to check space and Folder sizes occupied on the Email server. .............................. 9 5. Archiving ............................................................................................................. 10 5a.How to archive your personal folder messages ..................................................... 10 5b. How to archive Calendar Items ......................................................................... 13 6. Outlook Web Access.............................................................................................. 14 6a. Outlook Web Access Features............................................................................ 15 7. Parson’s Email File Attachment Blocking .................................................................. 15

1

Parsons Information Systems

Microsoft Outlook 2007 Mail Box Management

Pre-requisites Microsoft Outlook 2007 installed in PC/WS. Assumptions The s are familiar with the basic use of Windows & MS Office 2007. Objective

To manage your Outlook Mail Box.

Procedure

Identify the Outlook icon on your desktop 1. Click on the icon to start Microsoft Outlook. The Outlook logo should appear. After a short pause, the Outlook opening screen should display, showing a list of messages in the Inbox. If it does not, e.g. you see Outlook's Calendar or s, click the icon marked Inbox in the left-hand pane. The message 'Inbox' should show underneath Outlook's menu bar in the right hand pane.

2

Parsons Information Systems

Many Outlook s accumulate large volumes of email in their Exchange mailboxes. To remain within the mailbox quota, it is necessary for Outlook s to manage their files effectively by archiving out-of-date email and maintaining this information on their local file system. This document is intended to act as a guide in archiving Outlook files and their subsequent access. 1. Offline Store Files (OST) Offline Store File (OST) is your Exchange server primary store, meaning that your mail is delivered to the Inbox in that file and even the other default Outlook folders, such as Calendar, s, Deleted Items, Journal, Notes, Sent Items and Tasks reside there. When working offline, you work with the contents of an offline folder (OST) exactly as you do with a folder on a server. For example, you can change and move items in your offline Inbox, send messages that are placed in your offline Outbox, and read your offline public folders. You will continue to receive new messages in your Mailbox. However, you will not be aware of these changes on the server until you synchronize the offline folder with the server .The Synchronize command, connects to the server, copies the changes made, and then disconnects. Any item that you delete from either the offline folder or the corresponding server folder will be deleted from both after synchronization. The Offline folder (OST) is located on the ’s C: drive with a replica on the Exchange Server.

3

Parsons Information Systems

2. Personal Folders File Personal Folders are folders that you create to store mail messages on your hard disk. One or more .pst files can reside on each 's computer. A personal folder can be defined as a secondary store, meaning you can move items to it, either manually or with Inbox Rules, from your primary store (OST). Personal Folder file (PST) is located on the ’s C: drive without any replica on the Exchange Server.

o

o o

4

Personal Folder file is kept in your local hard disk “C:\...\My Documents\Outlook” & Archive files are kept in your hard disk “C:\...\My Documents\Outlook\Archives”. It is the 's responsibility to ensure that the Personal Folder files and Archive files are backed up appropriately. Please note as per the File Server Utilization policy these pst files cannot be stored on the file/print server. If the applies a to the Personal folder file OR Archive files, the must ensure that he/she re the . If the forgets the , then PARSONS IS has NO way to restore the Personal Folder and/or Archive files.

Parsons Information Systems

To backup the Personal Folder files OR Archive files, you need to quit Outlook. You can then copy the Personal Folder files (Your Lastname.pst) from C:\...\My Documents\Outlook to another location. The difference between an Offline Folder file and a Personal Folder file is that the Offline Folder file is a mirror image of your folders on the Microsoft Exchange Server and is updated by the server during synchronization process between the Server and the PC. A Personal Folder File, on the other hand, is simply a storage location on your hard disk that is used to move email-related data from your Offline Folder to free up the allocated space of 100MB for your Mail Box on the Exchange Server.

3. Managing your Offline Folders You will receive a warning when your mailbox reaches 90 MB. If the mailbox size increases to 100 MB, you may not be able to send new mail(s) until you reduce your offline mailbox size. As your mail storage grows you will need to manage your offline mailbox size. There are a number of things that you can do to assist in this maintenance. Listed below are current recommendations to help reduce the storage space. The reduction of used space can be accomplished by saving the email attachment(s) to a file location on a local or networked drive. Deleting items in various folders in your offline mailbox including the Sent Items folder and making sure that the Deleted Folder is purged or emptied. Finally you can create a Personal Folder (PST) file for long-term storage of your important email messages. If You Do Exceed Your Mailbox Limit: You will receive a notification messages until your mailbox size is reduced under the limit. It is a standard message that reads as follows: ----Original Message----From: System Sent: Monday, July 15, 2004 4:15 PM To: Last Name, First Name Subject: Your mailbox is over its size limit Importance: High

Your mailbox has exceeded one or more size limits set by your . Your mailbox size is 90831 KB. Mailbox size limits: You will receive a warning when your mailbox reaches 90000 KB. You may not be able to send new mail until you reduce your mailbox size. To make more space available, delete any items that you are no longer using or move them to your personal folder file (.PST). Items in all of your mailbox folders including the Deleted Items and Sent Items folders count against your size limit. You must empty the Deleted Items folder after deleting items or the space will not be freed.

5

Parsons Information Systems

3a. Watch Out for Attachments! Save Attachments to Your Hard Drive and then Delete Messages: Attachments consume a considerable amount of space in your mailbox if they aren't saved to your hard drive and removed from the server. Don't Send Large Attachments to Others, Especially to Groups Be aware of the size of the files you are attaching. Large attachments also fill up your mailboxes. If you have a large file to share, post it on Parshare and email a hyperlink to this location in your message - most common software such as Word and PowerPoint will convert into a web version and then you only need to email the hyperlinked web address to its location. Readers will be able to click on the link. This way we will save valuable mail server space and minimize network traffic. Save Attachments to another Location To save attachments to another location follow these guidelines:

6

Parsons Information Systems

•

Clearing/saving attachments: o In the message with an attachment, right mouse click on the attachment, choose 'Save As'. o Select the location where the attachment should be saved: local drive or your home directory in “S” drive. The attachment is now saved and can be cleared from the message by right clicking the attachment and selecting the ‘Remove’ option.

Select File menu, Close and click on Yes when prompted “Do you want to save changes?” 3b. Your Mailbox Sent Items Folder Periodically manage Your Sent Items Folder: It is easy to forget about managing the Sent Items folder. Messages quickly accumulate here. Periodically checking and deleting unwanted messages in your Sent Items folder will also help the storage space on the exchange server. You can move your sent item emails to Personal sent items folder. 3c.Empty Your Deleted Items Folder - Regularly! Messages in Deleted Items folder are still counted for the Information Store. Prompt purging of unwanted message in this folder will help alleviate the space shortage on the server How to Empty Your Deleted Items folder To empty your folder, right-click on the Deleted Items folder icon in your Outlook bar and choose “Empty Deleted Items Folder”. You can automatically empty your Deleted Items folder every time you close Outlook. To turn on or off this option, go to Tools - Options - Other Tab and check the "Empty the Deleted Items folder Upon Exiting." If you want a warning before it is emptied, go to Tools - Options - Other tab and click on Advanced Options button, then select or clear the "Warn before permanently deleting items" check box. You can also use Auto Archiving to automatically empty your Deleted Items periodically right click on the Deleted Items folder, choose Properties then choose the Auto Archive tab and select “Permanently Delete Old Items.” This is an excellent use of this feature, you can set it to whatever time interval you wish, and you never have to think about it. 3d.To compact PST or OST files on local machines To conserve space on your computer's hard disk, you can delete unwanted items from the various PST and/or OST folders and then compact the files to make them smaller. NOTE: Deleting the unwanted items from each folder only moves them to the Deleted Items folder, but not from the mailbox itself. You must delete the items from the Deleted Items folder to permanently delete them, so that Outlook can compact the file.

7

Parsons Information Systems

The compacting process does not remove all the free space from the file. It leaves either 16 kilobytes (KB) or 4 percent of the file size (before compacting) whichever is greater. To be compacted, a file must meet the following requirements: 1. The file must be 16 KB or larger. 2. The file must have at least 16 KB of space freed since the last time it was compacted. Personal folder compaction may be initiated either manually or it will happen automatically. Automatic compaction takes place as an idle task in the background while Outlook is running. To Manually Start PST Compaction 1. Right Click the Personal Folders, and then select Properties. 2. On the General tab, click the ‘Advanced’ button then click on ‘Compact Now’ button. 3. Click OK twice. To Manually Start OST Compaction 4. Right Click to select Mailbox - < >, < >, and then select Properties. 5. Click the Advanced button, on the Advanced tab, click "Offline Folder File Settings." 6. Click Compact Now. 7. Click OK three times.

8

Parsons Information Systems

4. How to check space and Folder sizes occupied on the Email server. 1. Right Click Mailbox - < >, < > as illustrated below and 2. select Properties for Mailbox….

3. Click Folder Size button from the subsequent window.

9

Parsons Information Systems

•

The Next window will tell you the sizes of all folders residing on the email server, one of them will be Calendar, see fig below.

5. Archiving If you want to remove items from your Personal folders but not delete them, use the archive utility. Periodically moving items from your main Personal folder into an archive file keeps your main file small and speeds up some operations, such as Find. It is recommended to do archiving of your Personal Folders every six months. When you archive, the original items are copied to the archive file, and then removed from the current folder. Since archived messages are saved on the hard drive and not on the server, messages will not be accessible remotely using Web mail or Outlook from another computer. Please ensure that you backup your personal folder messages (pst) before proceeding to step 4a. 5a.How to archive your personal folder messages For Example, if you want to archive your personal folder messages on a six month basis (from 1st of Jan, 2010 till the end of June 2010) then follow the procedure as given below: •

In Outlook 2007:

1. Click on File – Archive; you get an Archive window

10

Parsons Information Systems

2. Highlight your Personal Folder. 3. Change the Archive date under Archive items older than to 7/1/2010 (1st July, 2002) 4. Click Browse for the Archive file, wherein an Open Personal Folders window pops up.

11

Parsons Information Systems

Enter the file name as: 2010-01 to 2010-06.pst (The file archived will be from 1st of Jan, 2010 till the end of June 2010). Archive file: C:\...\My Documents\Outlook\Archives\2010-01to 2010-06.pst Click OK. The message archiving process starts and then it stays as a file in your local Hard Drive (C:\...\My Documents\Outlook\Archives\2010-01 to 2010 -06.pst)

Archives that are imported back into your offline folder mailbox take up their original space on the Exchange server. This may result in you exceeding your space quota. Archives that are imported into your Personal folders only take up space on your disks, not on the Exchange server. s folder cannot be archived but Calendar Items can be archived.

12

Parsons Information Systems

5b. How to archive Calendar Items Change the Outlook view by click on the Calendar icon as shown below. Follow the above steps explained in 5a for archiving Calendar items for a period.

Once the archiving is complete the archived calendar will look similar to the graphic below. Select the archived Calendars that you would like to view or uncheck them to remove them from view.

13

Parsons Information Systems

6. Outlook Web Access Outlook Web Access is a service provided to all the PARSONS employees to increase email availability wherever you go. Please note that the Web Access performance is slower than using the outlook e-mail client software. Outlook Web Access can be accessed by two methods: 1. Through Parsons Web (PWEB) - http://pweb.parsons.com & clicking on the E-Mail icon on the right side top corner, which will take you to Outlook Web access logon screen.

Microsoft (R) Outlook (TM) Web Access is a Microsoft Exchange Active Server Application that gives you private access to your Microsoft Outlook or Microsoft Exchange personal email so that you can view your Inbox from any Web Browser. For more information about this Outlook product, click here. Log on to the Exchange server Type your Domain\ name: Parsons\p00<5 digit Parsons employee number : Your Current computer/Pweb

Don't forget to log off.

14

Parsons Information Systems

Once you've finished your online Exchange session, don't forget to log off. If anyone else will be using this computer after you, you should then completely exit your browser to keep your private. You can directly go to the Web site and logon to the Parsons Mail Server https://webmail03.parsons.com/exchange/ 6a. Outlook Web Access Features Feature Outlook 2007

Outlook Web Access 2003

Basic features E-mail

Yes

Yes

Calendaring

Yes

Yes

s

Yes

Yes

Tasks

Yes

Yes

Access to embedded objects

Yes

Yes

Rich text

Yes

Yes

HTML

Yes

No

Offline use

Yes

No

Journal

Yes

No

Printing templates

Yes

No

Delegate access to mailbox

Yes

Yes (read-only)

Timed delivery

Yes

No

Expiration

Yes

No

Spelling checker

Yes

No

Reminders

Yes

No

Outlook rules

Yes

No

Advanced features

7. Parson’s Email File Attachment Blocking To proactively protect the Parsons Corporation from computer viruses delivered via email file attachments, the following file extensions are being blocked on the Parsons Internet Email gateway as well as all MS Exchange Servers. The list includes, .COM, .BAT, .EXE, .HTR, .HTA, .JS, .JSE, .PIF, .OCX, .REG, .SHS, .SCR, .VBS, .VBE, .VBX, .WSF, .WSH, .LNK, .EML. .RAR Any message coming in or going out of the Parsons Internet Email gateway or MS Exchange servers that contain one of the above named file attachments will not be delivered to its intended recipient. A notification message will be delivered to the sender informing them that the file attachment was blocked from the system. If there is a business reason to send or receive these types of files the options listed below can be used.

15

Parsons Information Systems

1. The first option is to compress the .EXE file. This changes the extension to .ZIP and will allow the message to be delivered. As a general rule it is recommended that any attachment greater than 1MB in size be compressed. Compression is built into the Windows operating system and can achieved by Right clicking the concerned file and selecting “Send To”Compressed (zipped) folder. NOTE: "Self Extracting" Zip files use the .EXE extension and will not be delivered. 2. The second option is to use an FTP (File Transfer Protocol) service. Parsons IS provides a secure FTP server for the purpose of external file sharing and can be accessed both internally and across the Internet by partners, clients, and customers. 3. The third option is to use the ParShare. ParShare provides a central file repository that is accessible both internally and externally.
