D009/D011/D012/ D013/D091/D092 PARTS CATALOG 003316MIU

D009/D011/D012/ D013/D091/D092 PARTS CATALOG

D009/D011/D012/D013/D091/D092 PARTS CATALOG

003316MIU

It is the reader's responsibility when discussing the information contained within this document to maintain a level of confidentiality that is in the best interest of Ricoh Americas Corporation and its member companies. NO PART OF THIS DOCUMENT MAY BE REPRODUCED IN ANY FASHION AND DISTRIBUTED WITHOUT THE PRIOR PERMISSION OF RICOH AMERICAS CORPORATION. All product names, domain names or product illustrations, including desktop images, used in this document are trademarks, ed trademarks or the property of their respective companies. They are used throughout this book in an informational or editorial fashion only and for the benefit of such companies. No such use, or the use of any trade name, or web site is intended to convey endorsement or other affiliation with Ricoh products.

© 2010 RICOH Americas Corporation. All rights reserved.

LEGEND (MAINFRAMES) PRODUCT CODE D009 D011 D012 D013 D091-17 D092-17 D091-57 D092-57

GESTETNER MP 4000B MP 4000 MP 5000B MP 5000 MP 4001SP MP 5001SP MP 4001G MP 5001G

LANIER LD040B LD040 LD050B LD050 LD140SP LD150SP LD140G LD150G

COMPANY RICOH Aficio MP 4000B Aficio MP 4000 Aficio MP 5000B Aficio MP 5000 Aficio MP 4001SP Aficio MP 5001SP Aficio MP 4001G Aficio MP 5001G

SAVIN 9040b 9040 9050b 9050 9240SP 9250SP 9240G 9250G

LEGEND (ACCESSORIES) B408 B679 B702 B802 B804 B805 B826 B829 B838 D346 D351 D352 D353 D381 D386 D389 G329 G381

1000-Sheet Finisher SR790 IEEE1284 Interface Unit Type A Punch Unit Type 3260 Auto Reverse Document Feeder DF3010 Booklet Finisher SR3020 Finisher SR3030 Bluetooth Interface Unit Type 3245 Copy Data Security Unit Type E Scanner Accessibility Option Type 4045 Fax Option Type 5000 Paper Feed Unit PB3040 LCIT PB3050 LCIT RT3000 Printer/Scanner Option Type 5000 Bridge Unit BU3030 1 Bin Tray BN3040 Platen Cover Type 3800C Gigabit Ethernet Type 7300

DOCUMENTATION HISTORY REV. NO. *

DATE 01/2010

COMMENTS Original Printing

D009/D011/D012/D013/D091/D092 TABLE OF CONTENTS D009/D011/D012/D013/D091/D092 PARTS LOCATION AND LIST Location of Unit ....................................................... 2 1.Exterior 1 (D009/D011/D012/D013/D091/D092) ....... 11 2.Exterior 2 (D009/D011/D012/D013/D091/D092) ....... 14 3.Operation (D009/D011/D012/D013/D091/D092) ....... 16 4.ARDF Exterior (D009/D011/D012/D013/D091/D092) ....... 18 5.Original Feed 1 (D009/D011/D012/D013/D091/D092) ....... 20 6.Original Feed 2 (D009/D011/D012/D013/D091/D092) ....... 22 7.Original Feed 3 (D009/D011/D012/D013/D091/D092) ....... 24 8.Original Transfer 1 (D009/D011/D012/D013/D091/D092) ....... 26 9.Original Transfer 2 (D009/D011/D012/D013/D091/D092) ....... 28 10.Original Transfer 3 (D009/D011/D012/D013/D091/D092) ....... 30

11.ARDF Drive Section 1 (D009/D011/D012/D013/D091/D092) ....... 32 12.ARDF Drive Section 2 (D009/D011/D012/D013/D091/D092) ....... 13.ARDF Electrical Section (D009/D011/D012/D013/D091/D092) ...... 14.ARDF Frame Section (D009/D011/D012/D013/D091/D092) ....... 15.Scanner Section 1 (D009/D011/D012/D013/D091/D092) ....... 16.Scanner Section 2 (D009/D011/D012/D013/D091/D092) ....... 17.Scanner Section 3 (D009/D011/D012/D013/D091/D092) ....... 18.Scanner Section 4 (D009/D011/D012/D013/D091/D092) ....... 19.LD Unit (D009/D011/D012/D013/D091/D092) ....... 20.Paper Tray (D009/D011/D012/D013/D091/D092) ....... 21.Paper Feed Section (D009/D011/D012/D013/D091/D092) ....... 22.By- Feed Section 1 (D009/D011/D012/D013/D091/D092) .......

34 36 38 40 42 44 46 48 50 52 54

23.By- Feed Section 2 (D009/D011/D012/D013/D091/D092) ....... 56 24.Paper Registration (D009/D011/D012/D013/D091/D092) ....... 58

35.Duplex Unit 3 (D009/D011/D012/D013/D091/D092) ....... 80 36.Duplex Unit 4 (D009/D011/D012/D013/D091/D092) ....... 82

25.Toner Supply Unit (D009/D011/D012/D013/D091/D092) ....... 26.PCDU 1 (D009/D011/D012/D013/D091/D092) ....... 27.PCDU 2 (D009/D011/D012/D013/D091/D092) ....... 28.Transfer Belt Unit 1 (D009/D011/D012/D013/D091/D092) ....... 29.Transfer Belt Unit 2 (D009/D011/D012/D013/D091/D092) ....... 30.Fusing Unit 1 (D009/D011/D012/D013/D091/D092) ....... 31.Fusing Unit 2 (D009/D011/D012/D013/D091/D092) ....... 32.Fusing Unit 3 (D009/D011/D012/D013/D091/D092) ....... 33.Duplex Unit 1 (D009/D011/D012/D013/D091/D092) ....... 34.Duplex Unit 2 (D009/D011/D012/D013/D091/D092) .......

37.Duplex Unit 5 (D009/D011/D012/D013/D091/D092) ....... 84 38.Paper Exit Section 1 (D009/D011/D012/D013/D091/D092) ....... 86 39.Paper Exit Section 2 (D009/D011/D012/D013/D091/D092) ....... 88 40.Drive Section 1 (D009/D011/D012/D013/D091/D092) ....... 90 41.Drive Section 2 (D009/D011/D012/D013/D091/D092) ....... 92 42.Drive Section 3 (D009/D011/D012/D013/D091/D092) ....... 94 43.Drive Section 4 (D009/D011/D012/D013/D091/D092) ....... 96 44.Electrical Section 1 (D009/D011/D012/D013/D091/D092) ....... 98 45.Electrical Section 2 (D009/D011/D012/D013/D091/D092) ...... 100 46.Electrical Section 3 (D009/D011/D012/D013/D091/D092) ...... 102

60 62 64 66 68 70 72 74 76 78

47.Electrical Section 4 (D009/D011/D012/D013/D091/D092) ....... 104 48.Electrical Section 5 (D009/D011/D012/D013/D091/D092) ....... 106 49.Frame Section (D009/D011/D012/D013/D091/D092) ....... 108 50.Controller Board (D009/D011/D012/D013/D091/D092) ....... 110 51.BICU Board (D009/D011/D012/D013/D091/D092) ....... 126 52.BICU Board MS (D009/D011/D012/D013/D091/D092) ....... 138 53.IO Board (D009/D011/D012/D013/D091/D092) ....... 150 54.Decals and Documents (D009/D011/D012/D013/D091/D092) ....... 158 55.Special Tools (D009/D011/D012/D013/D091/D092) ....... 162 D009/D011/D012/D013 PARTS INDEX PARTS INDEX .......................................................... 2 1000-SHEET FINISHER SR790 B408 PARTS LOCATION AND LIST 1.Exterior (B408) ..................................................... 2 2.Transport Section (B408) ..................................... 4

3.Paper Exit Section 1 (B408) ................................. 6 4.Paper Exit Section 2 (B408) ................................. 8 5.Vertical Transport (B408) .................................... 10 6.Staple Section 1 (B408) ...................................... 12 7.Staple Section 2 (B408) ...................................... 14 8.Staple Section 3 (B408) ...................................... 16 9.Shift Tray Drive (B408) ........................................ 18 10.Drive Section (B408) .......................................... 20 11.Electrical Section (B408) .................................... 22 12.Decals And Documents (B408) .......................... 24 1000-SHEET FINISHER SR790 B408 PARTS INDEX PARTS INDEX .......................................................... 2 IEEE1284 INTERFACE UNIT TYPE A B679 PARTS LOCATION AND LIST 1.IEEE1284 Interface Board (B679)........................ 2 IEEE1284 INTERFACE UNIT TYPE A B679 PARTS INDEX PARTS INDEX .......................................................... 2 PUNCH UNIT TYPE 3260 B702 PARTS LOCATION AND LIST 1.Punch Unit 1 (B702) ............................................. 2 2.Punch Unit 2 (B702) ............................................. 4 PUNCH UNIT TYPE 3260 B702 PARTS INDEX PARTS INDEX .......................................................... 2

AUTO REVERSE DOCUMENT FEEDER DF3010 B802 PARTS LOCATION AND LIST 1.Exterior (B802) ..................................................... 2 2.Original Feed 1 (B802) ......................................... 4 3.Original Feed 2 (B802) ......................................... 6 4.Original Feed 3 (B802) ......................................... 8 5.Original Transfer 1 (B802) ................................... 10 6.Original Transfer 2 (B802) ................................... 12 7.Original Transfer 3 (B802) ................................... 14 8.Drive Section 1 (B802) ........................................ 16 9.Drive Section 2 (B802) ........................................ 18 10.Electrical Section (B802) .................................... 20 11.Frame Section (B802) ........................................ 22 12.Decals and Documents (B802) .......................... 24 AUTO REVERSE DOCUMENT FEEDER DF3010 B802 PARTS INDEX PARTS INDEX .......................................................... 2 BOOKLET FINISHER SR3020 B804 PARTS LOCATION AND LIST 1.Exterior (B804) ..................................................... 2 2.Paper Transfer (B804).......................................... 4 3.Shift Transfer Section 1 (B804) ............................ 6 4.Shift Transfer Section 2 (B804) ............................ 8 5.Shift Transfer Section 3 (B804) ........................... 10

6.Paper Exit 1 (B804) ............................................ 7.Paper Exit 2 (B804) ............................................ 8.Staple Transfer Section 1 (B804) ....................... 9.Staple Transfer Section 2 (B804) ....................... 10.Staple Tray 1 (B804) ......................................... 11.Staple Tray 2 (B804) ......................................... 12.Staple Tray 3 (B804) ......................................... 13.Staple Tray 4 (B804) ......................................... 14.Staple Tray 5 (B804) ......................................... 15.Staple Tray 6 (B804) ......................................... 16.Paper fold Section 1 (B804) .............................. 17.Paper fold Section 2 (B804) .............................. 18.Paper fold Section 3 (B804) .............................. 19.Shift Tray (B804) ............................................... 20.Drive Section 1 (B804) ...................................... 21.Drive Section 2 (B804) ...................................... 22.Drive Section 3 (B804) ...................................... 23.Electrical Section (B804) ................................... 24.Frame Section (B804) ....................................... 25.Decals and Documents (B804) .........................

12 14 16 18 20 22 24 26 28 30 32 34 36 38 40 42 44 46 48 50

BOOKLET FINISHER SR3020 B804 PARTS INDEX PARTS INDEX ......................................................... 2

FINISHER SR3030 B805 PARTS LOCATION AND LIST 1.Exterior (B805) ..................................................... 2 2.Paper Transfer (B805) ......................................... 4 3.Shift Transfer Section 1 (B805) ............................ 6 4.Shift Transfer Section 2 (B805) ............................ 8 5.Shift Transfer Section 3 (B805) ........................... 10 6.Paper Exit 1 (B805) ............................................. 12 7.Paper Exit 2 (B805) ............................................. 14 8.Staple Transfer Section 1 (B805) ........................ 16 9.Staple Transfer Section 2 (B805) ........................ 18 10.Staple Tray 1 (B805) .......................................... 20 11.Staple Tray 2 (B805) .......................................... 22 12.Staple Tray 3 (B805) .......................................... 24 13.Staple Tray 4 (B805) .......................................... 26 14.Shift Tray (B805) ................................................ 28 15.Drive Section 1 (B805) ....................................... 30 16.Drive Section 2 (B805) ....................................... 32 17.Drive Section 3 (B805) ....................................... 34 18.Electrical Section (B805) .................................... 36 19.Frame Section (B805) ........................................ 38 20.Decals and Documents (B805) .......................... 40 FINISHER SR3030 B805 PARTS INDEX PARTS INDEX .......................................................... 2

BLUETOOTH INTERFACE UNIT TYPE 3245 B826 PARTS LOCATION AND LIST 1.Bluetooth Interface Unit (B826) ............................ 2 BLUETOOTH INTERFACE UNIT TYPE 3245 B826 PARTS INDEX PARTS INDEX .......................................................... 2 COPY DATA SECURITY UNIT TYPE E B829 PARTS LOCATION AND LIST 1.Copy Data Security Unit (B829) ........................... 2 COPY DATA SECURITY UNIT TYPE E B829 PARTS INDEX PARTS INDEX .......................................................... 2 SCANNER ACCESSIBILITY OPTION TYPE 4045 B838 PARTS LOCATION AND LIST 1.Scanner Accessibility Option (B838) ................... 2 SCANNER ACCESSIBILITY OPTION TYPE 4045 B838 PARTS INDEX PARTS INDEX .......................................................... 2 FAX OPTION TYPE 5000 D346 PARTS LOCATION AND LIST 1.Fax Option (D346) ................................................ 2 2.G3 Unit (D346) ..................................................... 4

FAX OPTION TYPE 5000 D346 PARTS INDEX PARTS INDEX .......................................................... 2

LCIT PB3050 D352 PARTS INDEX PARTS INDEX .......................................................... 2

PAPER FEED UNIT PB3040 D351 PARTS LOCATION AND LIST 1.Exterior (D351) ..................................................... 2 2.Frame Section (D351) .......................................... 4 3.Paper Tray (D351) ............................................... 6 4.Paper Feed Section (D351) ................................. 8 5.Electrical Section (D351)..................................... 10 6.Drive Section (D351) ........................................... 12

LCIT RT3000 D353 PARTS LOCATION AND LIST 1.Exterior (D353) ..................................................... 2 2.Paper Feed Section (D353) ................................. 4 3.Paper Tray (D353) ............................................... 6 4.Electrical Section (D353)...................................... 8 5.Frame (D353) ...................................................... 10 LCIT RT3000 D353 PARTS INDEX PARTS INDEX .......................................................... 2

PAPER FEED UNIT PB3040 D351 PARTS INDEX PARTS INDEX .......................................................... 2 LCIT PB3050 D352 PARTS LOCATION AND LIST 1.Exterior 1 (D352) .................................................. 2 2.Exterior 2 (D352) .................................................. 4 3.Right Tray 1 (D352).............................................. 6 4.Right Tray 2 (D352).............................................. 8 5.Left Tray (D352) .................................................. 10 6.Paper Feed Section (D352) ................................ 12 7.Electrical Section (D352)..................................... 14 8.Drive Section (D352) ........................................... 16

PRINTER/SCANNER OPTION TYPE 5000 D381 PARTS LOCATION AND LIST 1.Printer/Scanner Option 1 (D381) ......................... 2 2.Printer/Scanner Option 2 (B829/D362/D377/D381) ......................... 4 PRINTER/SCANNER OPTION TYPE 5000 D381 PARTS INDEX PARTS INDEX .......................................................... 2

BRIDGE UNIT BU3030 D386 PARTS LOCATION AND LIST 1.Bridge Unit 1 (D386) ............................................. 2 2.Bridge Unit 2 (D386) ............................................. 4 BRIDGE UNIT BU3030 D386 PARTS INDEX PARTS INDEX .......................................................... 2 1 BIN TRAY BN3040 D389 PARTS LOCATION AND LIST 1.1Bin Tray (D389) .................................................. 2 1 BIN TRAY BN3040 D389 PARTS INDEX PARTS INDEX .......................................................... 2 PLATEN COVER TYPE 3800C G329 PARTS LOCATION AND LIST 1.Platen Cover (G329)............................................. 2 PLATEN COVER TYPE 3800C G329 PARTS INDEX PARTS INDEX .......................................................... 2 GIGABIT ETHERNET TYPE 7300 G381 PARTS LOCATION AND LIST 1.Gigabit Ethernet Type 7300 (G381) ..................... 2 GIGABIT ETHERNET TYPE 7300 G381 PARTS INDEX PARTS INDEX .......................................................... 2

D009/D011/D012/D013/D091/D092 PARTS LOCATION AND LIST

This section shows you the part numbers and descriptions used on this machine.

LOCATIONS OF UNITS 1. Exterior 1 (D009/D011/D012/D013/D091/D092)

See Page 13 4. ARDF Exterior (D009/D011/D012/D013/D091/D092)

See Page 19

D009/D011/D012/D013/D091/D092

2. Exterior 2 (D009/D011/D012/D013/D091/D092)

See Page 15 5. Original Feed 1 (D009/D011/D012/D013/D091/D092)

See Page 21

2

3. Operation (D009/D011/D012/D013/D091/D092)

See Page 17 6. Original Feed 2 (D009/D011/D012/D013/D091/D092)

See Page 23

Parts Location and List

LOCATIONS OF UNITS 7. Original Feed 3 (D009/D011/D012/D013/D091/D092)

8. Original Transfer 1 (D009/D011/D012/D013/D091/D092)


See Page 25

See Page 27

See Page 29


11. ARDF Drive Section 1 (D009/D011/D012/D013/D091/D092)

12. ARDF Drive Section 2 (D009/D011/D012/D013/D091/D092)

See Page 31

See Page 33

See Page 35

D009/D011/D012/D013/D091/D092

3


LOCATIONS OF UNITS 13. ARDF Electrical Section (D009/D011/D012/D013/D091/D092)

See Page 37 16. Scanner Section 2 (D009/D011/D012/D013/D091/D092)

See Page 43

D009/D011/D012/D013/D091/D092

14. ARDF Frame Section (D009/D011/D012/D013/D091/D092)


See Page 45

4

15. Scanner Section 1 (D009/D011/D012/D013/D091/D092)


See Page 47


LOCATIONS OF UNITS 19. LD Unit (D009/D011/D012/D013/D091/D092)

See Page 49 22. By- Feed Section 1 (D009/D011/D012/D013/D091/D092)

See Page 55

D009/D011/D012/D013/D091/D092

20. Paper Tray (D009/D011/D012/D013/D091/D092)

See Page 51 23. By- Feed Section 2 (D009/D011/D012/D013/D091/D092)

See Page 57

5

21. Paper Feed Section (D009/D011/D012/D013/D091/D092)

See Page 53 24. Paper Registration (D009/D011/D012/D013/D091/D092)

See Page 59


LOCATIONS OF UNITS 25. Toner Supply Unit (D009/D011/D012/D013/D091/D092)

See Page 61 28. Transfer Belt Unit 1 (D009/D011/D012/D013/D091/D092)

See Page 67

D009/D011/D012/D013/D091/D092

26. PCDU 1 (D009/D011/D012/D013/D091/D092)

See Page 63 29. Transfer Belt Unit 2 (D009/D011/D012/D013/D091/D092)

See Page 69

6

27. PCDU 2 (D009/D011/D012/D013/D091/D092)

See Page 65 30. Fusing Unit 1 (D009/D011/D012/D013/D091/D092)

See Page 71


LOCATIONS OF UNITS 31. Fusing Unit 2 (D009/D011/D012/D013/D091/D092)

See Page 73 34. Duplex Unit 2 (D009/D011/D012/D013/D091/D092)

See Page 79

D009/D011/D012/D013/D091/D092

32. Fusing Unit 3 (D009/D011/D012/D013/D091/D092)


See Page 81

7

33. Duplex Unit 1 (D009/D011/D012/D013/D091/D092)


See Page 83


LOCATIONS OF UNITS 37. Duplex Unit 5 (D009/D011/D012/D013/D091/D092)

See Page 85 40. Drive Section 1 (D009/D011/D012/D013/D091/D092)

See Page 91

D009/D011/D012/D013/D091/D092

38. Paper Exit Section 1 (D009/D011/D012/D013/D091/D092)


See Page 93

8

39. Paper Exit Section 2 (D009/D011/D012/D013/D091/D092)


See Page 95


LOCATIONS OF UNITS 43. Drive Section 4 (D009/D011/D012/D013/D091/D092)

See Page 97 46. Electrical Section 3 (D009/D011/D012/D013/D091/D092)

See Page 103

D009/D011/D012/D013/D091/D092

44. Electrical Section 1 (D009/D011/D012/D013/D091/D092)


See Page 105

9

45. Electrical Section 2 (D009/D011/D012/D013/D091/D092)


See Page 107


LOCATIONS OF UNITS 49. Frame Section (D009/D011/D012/D013/D091/D092)

See Page 109

D009/D011/D012/D013/D091/D092

10


1.Exterior 1 (D009/D011/D012/D013/D091/D092)

101 29

101

30 31

27

33

3

32

24

25

103 101

20 28

105

102

1

101 101

2

101

10

4 5

26 21

102 16

6 15 11

102 102

7 17

12

104

22

101 23

101

18 101 19 8

13 9

14

D009/D011/D012/D013/D091/D092

102

13

11

101


1.Exterior 1 (D009/D011/D012/D013/D091/D092) Index No. 1 1 2 3 3 4 5 6 7 8 9 9 9 10 11 12 12 12 12 12 12 12 12 12 12 12 12 12 12 12 12 12 12 12

Part No. D009 1241 D012 1241 D009 1244 D012 1281 D013 1281 AG07 1012 D009 3268 D009 3269 B004 1325 B223 1255 B238 1372 D011 1250 D011 1251 D009 1242 B223 1253 D009 6192 D009 6193 D009 6194 D009 6195 D009 6492 D009 6493 D009 6494 D009 6495 D009 6692 D011 6192 D011 6193 D011 6194 D011 6195 D011 6492 D011 6493 D011 6494 D011 6495 D011 6692 D012 6192

Description Inner Cover: Upper: Left: DOM Inner Cover - Upper Left Inner Cover - Middle Left Cover Cover: Left: NA Magnet Catch: Ass'y Decal - Lock Toner Bottle Decal - Release Toner Bottle Cover - Shield Glass Cover - Main Switch Decal - Main Switch(On-Off) Decal: Main Switch: On-Off Decal: Main Switch: O-I Inner Cover - Left EMBLEM Cover Sheet: EMBLEM: RIC Sheet: EMBLEM: SVN Sheet: EMBLEM: GES: NA Sheet: EMBLEM: LAN: NA Sheet: EMBLEM: NSA Sheet: EMBLEM: REX Sheet: EMBLEM: GES: EU Sheet: EMBLEM: LAN: EU Sheet: EMBLEM: INF Sheet: EMBLEM: RIC Sheet: EMBLEM: SVN Sheet: EMBLEM: GES: NA Sheet: EMBLEM: LAN: NA Sheet: EMBLEM: NSA Sheet: EMBLEM: REX Sheet: EMBLEM: GES: EU Sheet: EMBLEM: LAN: EU Sheet: EMBLEM: INF Sheet: EMBLEM: RIC

D009/D011/D012/D013/D091/D092

Q’ty Per Assembly

Index No.

1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1

12

Part No.

12

D009 6292

12 12 12 12

D012 6193 D012 6194 D012 6195 D012 6292

12 12 12 12 12 12 12 12 12 12 12 12 12 12 12 12 12 12 12 12 13 13 13 13 13 13 13 13

D012 6492 D012 6493 D012 6494 D012 6495 D012 6692 D013 6192 D013 6193 D013 6194 D013 6195 D013 6492 D013 6493 D013 6494 D013 6495 D013 6692 D091 6192 D091 6193 D091 6194 D091 6195 D091 6492 D091 6493 D091 6494 D091 6495 D091 6692 D092 6192 D092 6193 D092 6194 D092 6195 D092 6492

Q’ty Per Assembly

Description Sheet: EMBLEM: RIC: 40SP Added MB10 Sheet: EMBLEM: SVN Sheet: EMBLEM: GES: NA Sheet: EMBLEM: LAN: NA Sheet: EMBLEM: RIC: 50SP Added MB10 Sheet: EMBLEM: NSA Sheet: EMBLEM: REX Sheet: EMBLEM: GES: EU Sheet: EMBLEM: LAN: EU Sheet: EMBLEM: INF Sheet: EMBLEM: RIC Sheet: EMBLEM: SVN Sheet: EMBLEM: GES: NA Sheet: EMBLEM: LAN: NA Sheet: EMBLEM: NSA Sheet: EMBLEM: REX Sheet: EMBLEM: GES: EU Sheet: EMBLEM: LAN: EU Sheet: EMBLEM: AL-C1CCS: INF Sheet: EMBLEM: 40: RIC (D091) Sheet: EMBLEM: 40: SVN (D091) Sheet: EMBLEM: 40: GES: NA (D091) Sheet: EMBLEM: 40: LAN: NA (D091) Sheet: EMBLEM: 40: NSA (D091) Sheet: EMBLEM: 40: REX (D091) Sheet: EMBLEM: 40: GES: EU (D091) Sheet: EMBLEM: 40: LAN: EU (D091) Sheet: EMBLEM: 40: INF (D091) Sheet: EMBLEM: 50: RIC (D092) Sheet: EMBLEM: 50: SVN (D092) Sheet: EMBLEM: 50: GES: NA (D092) Sheet: EMBLEM: 50: LAN: NA (D092) Sheet: EMBLEM: 50: NSA (D092)

1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1


Rev. 03/07/2011 Index No. 13 13 13 13 13 14 15 16 17 18 19 20 21 22 22 23 24 25 26 27 28 29 30 31 32 33

Part No. D092 6493 D092 6494 D092 6495 D092 6692 G020 1332 B132 1573 D012 1251 B223 1246 B024 1264 D009 1256 D012 1264 B237 1380 D009 1272 D012 1271 D013 1271 D009 2627 D012 1293 D012 1292 D012 1291 B223 1248 B652 2379 B065 1371 B065 1374 G038 1299 B238 2524 H511 5007

Description Sheet: EMBLEM: 50: REX (D092) Sheet: EMBLEM: 50: GES: EU (D092) Sheet: EMBLEM: 50: LAN: EU (D092) Sheet: EMBLEM: 50: INF (D092) Hinge - Front Cover Decal - Power Source: Off Front Cover Guide Plate: Scanner Magnet Catch Sheet - Misfeed Removal Front Right Cover Cover - Right Base EU Right Cover - Rear Right Cover - Front Cover: Right: Front: NA Decal - Misfeed Removal B1 Cap - Rear Cover EU Rear Cover - Upper Rear Cover Operating Instructions Holder Decal: Caution: Original: 5-Lang Cloth Holder Cloth - DF Exposure Glass Rivet - 5 Decal - Paper Size Stamp

D009/D011/D012/D013/D091/D092

Q’ty Per Assembly 1 1 1 1 2 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1

Index No. 101 102 103 104 105 105

13

Part No. 0451 3008N 0454 3008Q 0450 3012N 0450 3010N 1150 0438 1150 0377

Q’ty Per Assembly

Description Tapping Screw - M3x8 Tapping Screw: 3x8 Tapping Screw: 3x12 Tapping Screw - M3x10 Power Supply Code: AC125V 15A NA Power Supply Code: 250V: 10A: EU


2.Exterior 2 (D009/D011/D012/D013/D091/D092) 101

101

3

12

1 101

4

2 101 11 101

5

101

6

10 17 102

102 14

16

103

105

102

106

19 18

105 9

8

102

102

102 7

103

13 101 15

D009/D011/D012/D013/D091/D092

103

101

14


2.Exterior 2 (D009/D011/D012/D013/D091/D092) Index No. 1 1 2 2 3 4 5 6 7 8 9 10 11 11 12 12 13 14 15 16 17 18 19

Part No. B223 1818 B222 1818 D009 1282 D012 1282 B223 4487 B223 4486 D009 1260 B222 1262 B224 1263 B223 1261 B223 1266 B223 1273 B223 1819 B222 1819 B223 1820 B222 1820 D009 2247 D009 2254 D009 2249 D009 2248 D009 1243 D009 2616 D009 5515

Description Cover: Scanner: Left Cover: Scanner: Left: EU Cover: Left: Upper: DOM Left Cover - Upper Exit End Fence Exit Tray Upper Cover Cover: Inner Back: Upper: EU Cover: Inner Back: Middle: EU Cover: Inner Back Cover: Paper Exit Unit: Upper Cover: Right: Upper Middle Cover: Scanner: Right Cover: Scanner: Right: EU Cover: Scanner: Rear Cover: Scanner: Rear: EU Cover - Lock Lever Base - Lock Lever Spring Plate - Lock Lever Guide Plate - Lock Lever Inner Cover - Right Upper Paper Dust Case Harness - Operation

D009/D011/D012/D013/D091/D092

Q’ty Per Assembly

Index No.

Part No.

1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1

101 102 103 105 106

0451 3008N 0454 3008Q 0454 3006Q 0353 0030N 0353 0050N

15

Description

Q’ty Per Assembly

Tapping Screw - M3x8 Tapping Screw: 3x8 Tapping Screw - M3x6 Screw: M3x3 Screw-M3x5


Rev. 05/24/2011

3.Operation (D009/D011/D012/D013/D091/D092) D091/D092(EU) D009/D011/D012/D013

D091/D092(EU)

39 32

36

33

34 36

D091/D092(NA/AA)

35

D009/D011/D012/D013

3

32 36

34 33

D091/D092(NA/AA)

2

39

1

8

3 40 105

13 4

5

101

6

37 101 103

101

101

14 15 16 20 17

17 102

104

21

22

16

7

8

9

23 10

102

19 101

28 27 26

29

102

101

31 12

101 101

101 38

D009/D011/D012/D013/D091/D092

25

30

18

102 11

24

102

101

16

101


Rev. 3/2/2012

3.Operation (D009/D011/D012/D013/D091/D092) Index No. * * * * * * 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 21 21 22 23 24 25 26 27

Part No.

Description

Q’ty Per Assembly

D009 1441 D009 1452 D009 1443 D092 1411 D092 1412 D092 1443 B238 1547 B238 1511 B223 1518 B223 1497 D009 1480 D009 1481 B238 1527 B238 1540 D092 1481 D009 1486 D009 1484 B238 1548 B238 1519 D009 1504 D009 1488 B238 1534 B238 1535 D089 1498 D009 1487 B223 1520 R724 1521 R724 1540 R724 1541 B238 1583 B238 1504 B238 1506 B238 1509 B238 1552 B238 1550

Operation - NA Operation - EU Operation - AA Operation : NA (D091/D092) Operation : EU (D091/D092) Operation Sub-Unit: AA: Ass’y (D091/D092) Spacer - Keytop Keytop - Counter Keytop - Blank FB PCB: APC1: OP-L: Sub-Ass'y Harness: OP-R: 10 Harness: OP-R: 13 Operation Bracket Sheet: Data: Display: NA PCB - LCDC NA Inverter: TFT Harness: Inverter Operation Bracket - Right Lens - Front Shading Plate: Touch Touch : W-VGA: MA LCD Spacer A LCD Spacer B LCD: TFT: W-VGA: MV Cable: FFC: TFT: LCD Keytop - Clear/Stop Keytop: 10Key Keytop: 10Key: NA Keytop - 10Key AA Keytop - Clear Modes Keytop - Start Keytop - Try Print Keytop - Interrupt Keytop - Kantan Keytop -

1 1 1 1 1 1 1 1 2 1 1 1 1 1 1 1 1 1 1 1 1 2 2 1 1 1 1 1 1 1 1 1 1 1 1

D009/D011/D012/D013/D091/D092

Index No.

17

Part No.

Q’ty Per Assembly

Description

28 29 30 31 32 32 33 33 34 34 35 35 36 36 37 38 39 39 40

B238 1549 D009 1483 D009 1482 D009 1470 B223 1532 B223 1538 B223 1529 B223 1535 B223 1528 B223 1534 B223 1595 B222 1595 B223 1531 B223 1537 B223 1596 D009 1502 B223 1533 B223 1539 D009 1501

Keytop - Power Source Harness: OP-L: 13 Harness: OP-L: 12 PCB: OP-R Keytop: Scanner: NA Keytop: Scanner: EU Keytop - DOC NA Keytop: DOC: EU Keytop - Copy NA Keytop: Copy: EU Cover: Scanner: Front Cover: Scanner: Front: EU Keytop: Printer: NA Keytop: Printer: EU Cover: Front Right: Upper Cover: Lower Keytop: Function: NA (D091/D092) Keytop: Function: EU (D091/D092) Cover: Upper

101 102 103 104 105

0450 3010N 0353 0060N 1105 0511 1105 0032 0451 3008N

Tapping Screw - M3x10 Bind Screw - M3x6 Harness Clamp - LWS-0306ZC Clamp Tapping Screw - M3x8

1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1


4.ARDF Exterior (D009/D011/D012/D013/D091/D092)

1 12

11

13

101 8

2

101 14 15

7

16

7 101 9

17

22 23

20

18

21

23 24

10

4

5

19

102

3

19

102 25

26 6 102

D009/D011/D012/D013/D091/D092

18

102


Rev. 2/17/2011

4.ARDF Exterior (D009/D011/D012/D013/D091/D092) Index No. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26

Part No. B652 2379 A859 7211 D540 6121 B802 4411 B802 6013 5215 2621 B802 4712 B802 4511 B802 2551 B802 2581 B802 2526 B789 6031 B802 2522 B802 2536 B802 2532 B802 6011 B802 2571 A858 4676 A858 4671 GW01 0007 B802 2541 B802 5880 AW01 0129 B802 2562 B802 2512 AG07 0513

Description Decal: Caution: Original: 5-Lang Stepped Screw Full Dug Point Screw: Fix: Hinge Cover: Front Decal: Display: Misfeed Removal: P1 Snap Ring - M6 Sound Proofing Material: Cover: Rear Cover: Rear Stay: Original Table: Point Stopper: Original Table Side Fence Decal - Original Table Original Table: Face Front Slider: Side Fence Spring Plate: Side Fence Decal: Side Fence Spring Plate: 0.2T Spring Plate - Pressure Roller Roller Driven Photo Reflection Sensor: Exit Guide: Original Insert Harness: Sensor: Original Table Photo Reflection Sensor Plate: Point Original Table Magnet Catch

D009/D011/D012/D013/D091/D092

Q’ty Per Assembly

Index No.

1 2 2 1 1 1 3 1 1 1 1 1 1 1 1 1 3 1 4 1 1 1 3 1 1 2

101 102

19

Part No.

Description

Q’ty Per Assembly

0451 3006N Tapping Screw - 3x6 0450 3008N Tapping Screw - M3x8


5.Original Feed 1 (D009/D011/D012/D013/D091/D092)

104

1

15

101

2

16

103 102

103

16 3

17 4 18

18

18

17

101

20

20 21

7 19

5

102

22

12

11 8

9

6

10

13 23

14

D009/D011/D012/D013/D091/D092

20


Rev. 2/17/2011

5.Original Feed 1 (D009/D011/D012/D013/D091/D092) Index No. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23

Part No. B802 4121 B802 4152 B802 6012 D501 2609 B802 4711 B802 4154 B802 4155 B802 4158 AA06 2262 B802 4241 B802 4231 B802 4162 AA14 3789 AA14 3788 B802 4252 B802 5870 AW02 0154 AW02 0155 GW01 0007 AW01 0091 GW02 0020 B802 4263 GA14 3003

Description Cover: Paper Feed Grip: Cover Decal: Misfeed Removal: Original Decal: Size: Original Sound Proofing Material Hook: Grip: Cover: Front Hook: Grip: Cover: Inner Back Shaft: Grip: Cover Tension Spring Bracket: Cover: Front Bracket: Cover: Inner Back Stopper: Cover Shaft: Cleaner Pin: Guide Plate: Paper Feed Bracket: Paper Size Sensor Harness: Sensor: Paper Feed Photointerruptor: Entrance Photointerruptor: Paper Size Sensor Photo Reflection Sensor: Exit Photo Reflection Sensor Photointerruptor: LG248NL1 Feeler: Original Sensor Screw: MM5: 2.5mm

D009/D011/D012/D013/D091/D092

Q’ty Per Assembly

Index No.

Part No.

1 1 1 1 5 1 1 1 1 1 1 1 1 1 1 1 2 3 1 2 1 1 3

101 102 103 104

0451 3010N 0450 3008N 0451 3006N 1105 0516

21

Description

Q’ty Per Assembly

Tapping Screw: 3x10 Tapping Screw - M3x8 Tapping Screw - 3x6 Clamp


6.Original Feed 2 (D009/D011/D012/D013/D091/D092) 101

101

102 38 39

107

39

40 30

41

37 34

32

36 103 36 34

35

26 33

31

103

17

21

18

25

24

32

19

20

19

105 104

21

22

21

17 108

103

23 27 21

104

16 15

14

12

11

3

2

15

10 13

2

7

3

6 2

29 4

D009/D011/D012/D013/D091/D092

106

28

22

8

9

1

5


6.Original Feed 2 (D009/D011/D012/D013/D091/D092) Index No. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35

Part No. B802 4311 5447 2681 AA08 2101 B802 4357 B802 4358 B802 4361 B387 2163 B802 4372 AA04 3328 B802 4352 B802 4355 B802 4359 A859 2112 B387 2113 B386 3320 B802 4333 B802 4326 AA08 2104 AA13 2013 AA06 3435 A628 1225 B789 2114 A806 1295 B802 4322 AA06 6376 B802 4323 B802 4325 B802 4328 B802 4228 B802 4227 B802 4229 B802 4224 B802 4222 AA08 0288 B802 4295

Description Paper Feed: Unit Snap Ring Bushing - 6x10x6 Gear: Z19 Timing Pulley: Gear: T19/Z22 Roller: Pickup Pickup Collar Timing Pulley: T21 Timing Belt: 40S2M130 Shaft: Pickup Bracket: Pickup Cushion: Pickup Drive Shaft - Paper Feed Belt Roller - Paper Feed Belt Spring: Belt: Paper Feed: 8N Bracket: Paper Feed Belt Collar: Shaft Bushing - 8x12x7 Spacer Compression Spring: Paper Feed: t Bushing - 8mm Paper Feed Belt Roller Feed Belt Shaft: Drive Torsion Spring: Pickup: Pressure Holder Lever: Pickup: Release Gear: Z20 Drum Stay: Upper: Front Drum Stay: Upper: Inner Back Sheet: Guide: Upper Spring Plate: Upper Guide: Upper Bushing: DIA6 Driven Roller: Pull Out

D009/D011/D012/D013/D091/D092

Q’ty Per Assembly

Index No.

1 3 2 1 1 1 1 1 1 1 1 1 1 1 2 1 2 1 2 1 4 1 1 1 1 1 1 1 1 1 1 2 1 2 1

23

Part No.

Q’ty Per Assembly

Description

36 37 38 39 40 41

AA06 3441 B802 4282 B802 4292 G052 4892 B802 4265 B802 4225

Compression Spring Bracket: Driven Roller: Pull Out Ground Plate: Driven Roller: Pull Out Discharge Brush: Exit: Small Ground Plate Sheet: Driven Roller: Pull Out

101 102 103 104 105 106 107 108

0450 3008N 0451 3006N 0720 0040E 0720 0060E 0805 0088 0632 0100G 1105 0516 0741 3506

Tapping Screw - M3x8 Tapping Screw - 3x6 Retaining Ring - M4 Retaining Ring - M6 Retaining Ring - M6 Pin - 2x10mm Clamp Ball Bearing - 6x12x4 mm

2 1 1 2 1 1


7.Original Feed 3 (D009/D011/D012/D013/D091/D092) 15

14

10 105

18

13

12

27 104

11 8 10

17 27 21 105 24

106

16 28

19

20

105

26 25

103

5

22

23

2

106

1

27

101 102

101

3

4

6

8 7

D009/D011/D012/D013/D091/D092

9

24


Rev. 9/14/2012

7.Original Feed 3 (D009/D011/D012/D013/D091/D092) Index No. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28

Part No.

Description

Q’ty Per Assembly

Index No.

Part No.

B802 1773 B802 1777 B312 1615 B802 1774 AA14 3823 B802 5790 B802 3811 5447 2681 AA06 3919 AA08 2101 A859 2241 D541 2251 B802 2252 B802 2225 B802 2253 B802 2228 B802 6014 A422 1063 B802 2285 B802 2231 B802 2227 A458 2251 B802 2111 AA08 0265 AA06 0843 B802 2115 B802 2223 B802 2229

Bracket: Shaft: Side Plate: Front Knob: Misfeed Removal: T27 Tension Roller Timing Belt: 40S3M186 Tapping Screw Harness: Solenoid DC Solenoid: 24V Snap Ring Spring: Pressure Bushing - 6x10x6 Reverse Roller Torque Limiter Mechanical Clutch: Separator Shaft: Roller: Reverse Drum Stay: Guide: Reverse Gear: Z20 Guide: Reverse: Open and Close Decal: Display: Misfeed Removal: P2 Seal - 0.7x13x20 Roller: Reverse Exit: Driven Shaft: Reverse: Drive: Press Fit Guide: Reverse: Open and Close: Behind Cushion - Bin Solenoid Lever Stopper Pawl: Paper Feed Bushing: 6x8x5 Tension Spring Lever: Stopper Pawl Sheet: Guard Guide: Reverse: Open and Close: Sub-Ass'y

1 1 1 1 1 1 1 3 1 2 1 1 1 1 1 1 1 1 4 1 1 1 1 1 1 1 2 1

101 102 103 104 105 106

0451 3006N 0353 0040N 0450 3008N 0632 0120G 0720 0040E 0805 0089

D009/D011/D012/D013/D091/D092

25

Description

Q’ty Per Assembly

Tapping Screw - 3x6 Screw - M3x4 Tapping Screw - M3x8 Parallel Pin - 2x12 Retaining Ring - M4 Retaining Ring - M4


Rev. 08/20/2012

8.Original Transfer 1 (D009/D011/D012/D013/D091/D092)

16

26 18

20

19 2 17

3

1

101 16

27 4

102

104

25 4 24

6

22

7 8

23 101

22 28 4

9 5 4

10

101 16

11 21

103 101

12

13

101

14

101

15

D009/D011/D012/D013/D091/D092

26


Rev. 08/20/2012

8.Original Transfer 1 (D009/D011/D012/D013/D091/D092) Index No. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28

Part No. B802 3415 B802 3413 B802 3414 B802 3471 B802 3592 B802 3431 B802 3435 B802 3422 B802 3511 AA14 3569 B802 3553 B802 3566 B802 3567 B802 3569 B802 3561 A422 1063 B802 2291 GW01 0007 B802 3851 B802 3755 B802 3711 B789 3712 B789 3491 B714 5006 B802 3492 B802 3417 B802 3442 B802 9002

Description Guide: Scanning: Entrance: Lower Sheet: Roller: Scanning: Entrance Sheet: Scanning: Entrance Roller: Scanning: Driven Shaft: Driven: Exit Bracket: Entrance: Pressure: Ass'y Compression Spring: 3.3N Stay: Scanning: Entrance: Lower Guide Plate: Scanning Screw Guide: Scanning: Exit: Lower Plate: Exit: Pressure: Auxiliary Spring Plate: Scanning: Exit: Driven: Upper Spring Plate: Scanning: Exit: Driven: Lower Stay: Scanning: Exit: Lower Seal - 0.7x13x20 Stopper: Guide: Reverse Photo Reflection Sensor: Exit Bracket: Sensor: Scanning: Exit Discharge Brush: Reverse Spring Plate Exit Driven Roller Scanning Driven Shaft DC Solenoid: Transmitted Rubber Stamp Shaft: Driven: Entrance Sheet: Auxiliary: Scanning: Entrance Sensor Bracket Hook: Scanning: Exit [TSB#055]

D009/D011/D012/D013/D091/D092

Q’ty Per Assembly

Index No.

Part No.

1 4 1 8 2 2 6 1 1 1 1 2 2 2 1 1 1 1 1 1 2 4 2 1 2 5 1 1

101 102 103 104

0450 3008N 0453 3006N 0451 3006N 0452 3006N

27

Q’ty Per Assembly

Description Tapping Screw - M3x8 Tapping Screw - M3x6 Tapping Screw - 3x6 Binding Self-tapping Screw: 3x6


9.Original Transfer 2 (D009/D011/D012/D013/D091/D092) 101 1

108

4 2 4

9

5 7 8

10

101

108

101

102

101

105

14

103

101

6 5

105 101

3 102

101

101

11

104 106

101

12

D009/D011/D012/D013/D091/D092

104 106

107 13 4

28


9.Original Transfer 2 (D009/D011/D012/D013/D091/D092) Index No. 1 2 3 4 5 6 7 8 9 10 11 12 13 14

Part No. B802 5810 B802 3382 5447 2681 G052 4892 B802 3145 GW01 0007 B802 3833 B802 3834 B802 3231 B802 3251 B802 3235 B802 3252 A697 2102 B802 3233

Description Harness: Registration Sensor Bracket: Guide: Paper Feed: Lower Snap Ring Discharge Brush: Exit: Small Spring Plate Photo Reflection Sensor: Exit Shielding Plate: Sensor Bracket: Registration Sensor Roller: Scanning: Entrance Roller: Scanning: Exit Timing Pulley: T33-T24 Timing Pulley: T33 Damper - Junction Gate Solenoid Timing Pulley: T33

D009/D011/D012/D013/D091/D092

Q’ty Per Assembly 1 1 1 2 2 1 1 1 1 1 1 1 1 1

29

Index No.

Part No.

101 102 103 104 105 106 107 108

0451 3006N 0450 3008N 0720 0040E 0741 3506 0740 3506 0632 0100G 1105 0514 1105 0511

Q’ty Per Assembly

Description Tapping Screw - 3x6 Tapping Screw - M3x8 Retaining Ring - M4 Ball Bearing - 6x12x4 mm Ball Bearing - 6x12x4 mm Pin - 2x10mm Edge Saddle - EDS-0607l Harness Clamp - LWS-0306ZC


10.Original Transfer 3 (D009/D011/D012/D013/D091/D092) 101

15 14

28 16

16 20 19 21

18 17

22

23 13

103

6

101

105 14 18

101

1

106

2

25 16

3 102

6

4

7 104

5

9 10 6

8

24

6

26 27

106

11 12

13 101

D009/D011/D012/D013/D091/D092

30


Rev. 12/7/2012

10.Original Transfer 3 (D009/D011/D012/D013/D091/D092) Index No. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28

Part No. B238 4483 B802 1755 B802 1752 AA06 0842 AA04 3321 5447 2681 B802 1768 B802 3312 AA06 2260 B802 3631 B802 3615 G020 1160 AA08 2101 AA14 3790 D630 3351 A422 1063 B802 3211 5215 2621 B802 6016 B802 3653 B802 3311 B802 3612 B802 3611 B802 3332 B802 3756 B802 3751 D630 3331 B802 3655

Description Screw Bracket: Tension Timing Pulley: T31: Idler: Ass'y Tension Spring Timing Belt: 40S1.5M378 Snap Ring Pulley: Idler: DIA16: Ass'y Timing Pulley: T26 Tension Spring Link: Solenoid Lever: Exchange Pawl: Reverse Snap Ring Bushing - 6x10x6 Screw: Point Guide: Paper Feed: Lower Seal - 0.7x13x20 Roller: Pull Out Snap Ring - M6 Decal: Display: Misfeed Removal: P3 Guide: Exit: Upper Roller: Exit Cushion: Exchange Pawl Exchange Pawl: Reverse Timing Pulley: T23 Discharge Brush: Exit Stay: Reverse Roller: Reverse Guide: Exit: Upper: Sub-ass'y

D009/D011/D012/D013/D091/D092

Q’ty Per Assembly

Index No.

Part No.

1 1 1 1 1 2 1 1 1 1 1 1 2 2 1 2 1 1 1 1 1 1 1 1 1 1 1 1

101 102 103 104 105 106

0451 3006N 0720 0040E 0720 0060E 0720 0030E 0742 3808 0741 3506

31

Description

Q’ty Per Assembly

Tapping Screw - 3x6 Retaining Ring - M4 Retaining Ring - M6 Retaining Ring - M3 Ball Bearing - 8x16x5 Ball Bearing - 6x12x4 mm


11.ARDF Drive Section 1 (D009/D011/D012/D013/D091/D092)

103 8 101 101 4 104

22

5

102 101

12

3 2

15

6

1

7 12

14 13

16

8 104

17

13

12

10 101

9

103 101 101

D009/D011/D012/D013/D091/D092

11 18

19

20

21

21

101

32


11.ARDF Drive Section 1 (D009/D011/D012/D013/D091/D092) Index No. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22

Part No. B802 1812 AA10 1021 B802 1815 B044 1825 J503 3116 G570 1225 B802 1985 GW02 0020 AA04 3323 B802 1925 B700 5805 AA08 2101 5447 2681 B802 1951 B802 1956 B351 1781 B802 1931 B802 1942 5206 2686 B802 1943 B802 1946 B802 1941

Description Stepper Motor: DC4.08V 2.4W Rubber Bushing - 6 45HS Bracket: Reverse: Drive Collar Timing Belt: 40S2M128 Sensor Shielding Plate Bracket: Sensor: Pickup Photointerruptor: LG248NL1 Timing Belt: 40S2M120 Bracket: Pickup: Drive Stepper Motor: PM: S2M: T15: Ass'y Bushing - 6x10x6 Snap Ring Cam: Stopper Pawl Gear: Stopper: Original Insert: Z25 Gear - 18Z Timing Pulley: T33-Z17 Stopper: Cam: Pickup Snap Ring Feeler: Cam: Pickup Gear: Drive: Arm: Pickup Cam: Pickup

D009/D011/D012/D013/D091/D092

Q’ty Per Assembly

Index No.

Part No.

1 4 1 4 1 1 1 3 1 1 1 3 1 1 1 1 1 1 1 1 1 1

101 102 103 104

0451 3006N 0353 0060N 1105 0511 1105 0516

33

Q’ty Per Assembly

Description Tapping Screw - 3x6 Bind Screw - M3x6 Harness Clamp - LWS-0306ZC Clamp


12.ARDF Drive Section 2 (D009/D011/D012/D013/D091/D092)

1 105

2

21 3

5

104

4

103 103

7

8

104

103

6 13

101

12 104 101

10

15

102

103

14

101

16

17 101

104

103 102

101

9

18

11

20

103

12

101

D009/D011/D012/D013/D091/D092

19

34


12.ARDF Drive Section 2 (D009/D011/D012/D013/D091/D092) Index No. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21

Part No. B802 1671 B802 1661 B802 1642 B802 1643 B802 1651 B802 1631 B802 1632 B802 1633 AA04 3320 B802 1715 B802 1731 AA06 0842 B802 1736 B802 1721 B802 1681 B802 1741 AA04 3322 B802 1762 B238 4483 B802 1755 B802 1641

Description Gear: Z17 Gear: Z21/Z23 Gear: Z37 Gear: Z26 Gear: Z25 Timing Pulley: T31 Gear: Z18 Gear: Z19 Timing Belt: 40S1.5M150 Bracket: Stepper Motor Stay: Motor: Scanning Tension Spring Bracket: Protect: Drive Stepper Motor: DC1.76V 3.7W Gear: Z18 Timing Pulley: T31/T61 Timing Belt: 40S1.5M157.5 Timing Pulley: T31 Screw Bracket: Tension Gear: Z18

D009/D011/D012/D013/D091/D092

Q’ty Per Assembly

Index No.

Part No.

1 1 1 1 1 1 1 1 1 1 1 2 1 1 1 1 1 1 1 1 1

101 102 103 104 105

0451 3006N 0453 4006N 0720 0040E 0741 3506 1105 0511

35

Q’ty Per Assembly

Description Tapping Screw - 3x6 Binding Self Tapping Screw: 4x6 Retaining Ring - M4 Ball Bearing - 6x12x4 mm Harness Clamp - LWS-0306ZC


13.ARDF Electrical Section (D009/D011/D012/D013/D091/D092)

1

101

3

104

4 5

6

101

8

101

9

24

101 11

105

101

102 102

10

107

22

23

102

12

2

101

13 14

18 106

20 19

17

25

101 102

103

102 102 101

15

D009/D011/D012/D013/D091/D092

101

21 103

7

8 108

16

107

36


13.ARDF Electrical Section (D009/D011/D012/D013/D091/D092) Index No. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25

Part No. B802 5710 B802 1231 B802 5780 B802 5730 B802 5800 B802 5770 B802 1629 GX64 0028 B802 5760 B802 5820 B802 5501 B802 1246 GW02 0020 B802 1236 B703 1165 B802 1612 AA14 3802 B802 1624 B802 1616 AA06 0842 B802 1621 B387 1951 B802 1252 B802 1412 B802 5850

Description Harness: Interface Bracket: PCB: Right Harness: Lift Up Harness: Paper Feed Harness: Solenoid Harness: Motor: Reverse Cooling Fan Bracket Fan Motor DC24V 1.92W Harness: Motor: Paper Feed Harness: Motor: Pick Up ADF Main Board Bracket: On Off Detector Photointerruptor: LG248NL1 Bracket: PCB: Left Timing Belt: B40S2M390 Bracket: Motor Screw: 6x1.7 Bracket: Coupling Stay: Motor Tension Spring Stepper Motor: DC24V 4.8W Spring - Paper Size Sensor Feeler: Paper Size Sensor Plate: Harness: Guide Interface harness - Fan

D009/D011/D012/D013/D091/D092

Q’ty Per Assembly

Index No.

Part No.

1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1

101 102 103 104 105 106 107 108

0451 3006N 0450 3008N 0453 4006N 1105 0511 1105 0522 1105 0487 1105 0514 0451 3020N

37

Q’ty Per Assembly

Description Tapping Screw - 3x6 Tapping Screw - M3x8 Binding Self Tapping Screw: 4x6 Harness Clamp - LWS-0306ZC Edge Saddle - LES0510 Harness Clamp Edge Saddle - EDS-0607l Tapping Screw: 3x20


14.ARDF Frame Section (D009/D011/D012/D013/D091/D092) 101

101

8

2 101 1

101

102 10

101

9 101

4

7 11 5

16

6 14 15

103

3

13

D009/D011/D012/D013/D091/D092

38

12

13


Rev. 12/29/2011

14.ARDF Frame Section (D009/D011/D012/D013/D091/D092) Index No. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16

Part No. B802 1121 B802 1131 B802 4611 B802 4632 B802 4713 B802 4714 AA14 3790 B802 1321 B802 1361 A859 1841 AA14 3520 B802 4621 B477 2715 B802 1261 B802 1266 B802 1212

Description Positioning Plate: Front Positioning Plate: Rear Pressure Plate Cushion: Pressure Plate: Left Cushion: Left Cushion: Inner Back Screw: Point Hinge: Left: Ass'y Damper: Hinge: Right: Ass'y Filter - DF Open Sensor Shoulder Screw - M3 Drum Stay: Pressure Plate Pressure Plate Tape Grip: Lower Sponge: Base: 2mm Frame: Base

D009/D011/D012/D013/D091/D092

Q’ty Per Assembly

Index No.

1 1 1 3 1 1 2 1 1 1 1 1 2 1 1 1

101 102

39

Part No.

Description

Q’ty Per Assembly

0451 3006N Tapping Screw - 3x6 0454 3006Q Tapping Screw - M3x6


15.Scanner Section 1 (D009/D011/D012/D013/D091/D092) 104

101 106

105

104

16

23

17

107

12

18

106

104

1 2

3

12 11 4 5 6

101

20 14 10

15 20

101 108 104

22

104 8

13

101 9

21 7 10

102

21 104

109

101 103 101 19

102

108

102

D009/D011/D012/D013/D091/D092

40


15.Scanner Section 1 (D009/D011/D012/D013/D091/D092) Index No. 1 2 3 4 5 6 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23

Part No. D009 1731 D009 1732 B223 1773 BC01 2002 B223 1774 B223 1787 B223 1777 A250 1752 B051 1727 B223 1788 5442 1924 B132 1692 AA14 3520 A193 1793 AW02 0145 D029 5212 AW02 0146 B223 1808 D029 5213 B223 1116 B223 1833 B238 1845 B814 6053 D029 1774

Description

Q’ty Per Assembly

Index No.

Part No.

1 1 1 1 1 1 1 1 1 1 2 1 5 1 1 1 1 1 1 1 2 2 1 1

101 102 103 104 105 106 107 108 109

0451 3006N 0451 3008N 0451 3010N 0453 3006N 0314 0120N 0453 3008N 1105 0522 1105 0511 1105 0544

Bracket A - Left Scale Bracket B - Left Scale Scale: Machine Or Copier Exposure Glass: Sheet Through: 344x20 Seal: Sheet Through Scale: Left: NA Scale: Left Exposure Glass Frame: Scanner: Front Frame: Scanner: Rear Exposure Glass Cushion Scale: Rear: Printing Shoulder Screw - M3 Scanner Home Sensor Stopper Photointerruptor: Flat Harness: SIO: Sensor Photointerruptor: Flat: PICH2mm: M4 Document Feeder: Connector: Bracket Harness: SIO: ARDF Cam: Guide Plate: Scanner: Left Seal: Exposure Glass: Rear Seal: Exposure Glass Decal - Scale Seal: Guard: Exposure Glass: Document Feeder

D009/D011/D012/D013/D091/D092

41

Q’ty Per Assembly

Description Tapping Screw - 3x6 Tapping Screw - M3x8 Tapping Screw: 3x10 Tapping Screw - M3x6 Screw - M4x12 Binding Self Tapping Screw: 3x8 Edge Saddle - LES0510 Harness Clamp - LWS-0306ZC Edge Saddle: LES-2017


16.Scanner Section 2 (D009/D011/D012/D013/D091/D092) 2 103 8

7

3

14

102 12

11 104 102 13

9

1 8 5

8 11 104

6

10

8

15 16

5 4

15

16

105

101

19 17 103 18

101 17

20

17

19

101

103

20

D009/D011/D012/D013/D091/D092

42

18

17

101


Rev. 9/19/2011

16.Scanner Section 2 (D009/D011/D012/D013/D091/D092) Index No. 1 2 3 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20

Part No. A193 1766 A193 1769 D009 1840 B223 1840 D009 1715 M026 1815 AC03 0142 B223 1721 G404 2810 B223 1754 B223 1755 B238 1807 G570 2833 G570 2832 G570 2834 A193 1816 B180 1734 B238 1806 AA06 0980 B223 1782 B180 1704

Description

Q’ty Per Assembly

Wire Clamp 1 Clamp - Rear Wire 1 Xenon Lamp: MS model (D009/D012) 1 Xenon Lamp: CS model (D011/D013/D091/D092) 1 1st Carriage Ass'y 1 Clamp: Mirror: No. 1 2 1st Mirror 1 Carriage: No.2 1 Spring Plate - 2nd Mirror 4 Mirror: No.2: Concave 1 Mirror: No.2: Convex 1 Pulley 2 Pulley Holder 1 Guide - High Voltage Supply Cord 1 Pulley - High Voltage Supply Cord 1 1st Slide Rail 2 Slide Rail: No.2 2 Idler Pulley 4 Tension Spring: Tension: 11300mN 2 Drive Wire 2 Bracket: Tension 2

D009/D011/D012/D013/D091/D092

43

Index No.

Part No.

101 102 103 104 105

0451 3006N 0353 0050N 0802 5299 0720 0040E 1105 0534

Description

Q’ty Per Assembly

Tapping Screw - 3x6 Screw-M3x5 Tapping Screw - M3x8 Retaining Ring - M4 Clamp


17.Scanner Section 3 (D009/D011/D012/D013/D091/D092) 101 101

CS

101 3

104

101

8

MS

101 101

101

101

101 101

101

3

101

102 101

102

3

9

105

3 18

102

101 2 102

16

7

9

101

101

4

19

101 104

5 6

101

6 14 101

15

10 101

17

1

101 13 102

101 102

106

11 106 12 103

D009/D011/D012/D013/D091/D092

44


17.Scanner Section 3 (D009/D011/D012/D013/D091/D092) Index No. 1 2 3 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19

Part No. B051 1814 D009 1815 AW01 0133 AW01 0134 B223 1771 D011 5530 B154 5879 B180 1701 B223 1790 B223 1791 D009 1814 AX64 0164 D009 1742 D009 5380 D009 5540 B213 5544 D009 1681 D009 1832 D009 1779 B138 5801

Description Bracket: Original Sensor Original Sensor Bracket - Sub Scan Original Sensor - 66mm Original Sensor - 48mm Lens Unit Interface Cable - Scanner Color Plate: Cable Inner Cover Ground Plate: Stay: Lens Gasket: RFSG-030100: 75 Original Sensor Bracket - 48mm Fan Motor: 15mm: 24V Bracket - Printed Circuit Board Connector Board Interface Cable - Scanner BW Harness: FFC: SBU: 50Wick: 80mm Inner Cover - MS Lens Unit Gasket - 10x25 Gasket: Inner Cover

D009/D011/D012/D013/D091/D092

Q’ty Per Assembly

Index No.

Part No.

1 1 3 3 1 1 2 1 1 1 1 1 1 1 1 1 1 1 1 1

101 102 103 104 105 106

0451 3006N 0454 3006Q 0454 3020Q 1105 0534 1105 0511 1105 0516

45

Q’ty Per Assembly

Description Tapping Screw - 3x6 Tapping Screw - M3x6 Tapping Screw: 3x20 Clamp Harness Clamp - LWS-0306ZC Clamp


18.Scanner Section 4 (D009/D011/D012/D013/D091/D092) Option 109

104

29

108

104

8 104 31

113

105 27 105

26

104 104 106

CS

32 107

103

109 104

11

104 12 106 105

28

20

10

9

13

108

16 17

15 19

103

30 111 4

18

101

14

2

110

102 6

7

102 101

111

104

104

112 5

21 4

22

102

1

110

23 2

25 24

3

D009/D011/D012/D013/D091/D092

CS

46


18.Scanner Section 4 (D009/D011/D012/D013/D091/D092) Index No. 1 2 3 4 5 6 7 8 8 9 10 11 11 12 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 26 27 28 29 30 31

Part No. B180 1810 AA08 2144 B180 1814 G570 1160 B223 1824 B180 1812 G570 1133 AZ50 0070 AZ50 0074 D029 5214 B223 5223 D009 5555 D011 5550 D009 5370 D011 5350 B223 1779 B223 1807 B238 1792 B180 1713 D029 5215 B180 1803 D009 1816 AW01 0140 B223 1825 B223 1826 AX64 0164 B223 1827 B223 1828 B229 1687 B229 1688 D029 5218 H020 2318 B223 1786 AA06 0979 D009 1821

Description Pulley: Drive Were: Front: Sub-Ass'y Bushing - 8x12x7 Shaft: Scanner: Drive Spacer Bushing Seal: Scanner: Frame: Base Pulley: Drive Were: Rear: Sub-Ass'y Timing Pulley 73 Stabilizer - CS Stabilizer - MS Harness: SIO: Lamp Regulator Harness: SIO: Machine Or Copier Harness - Scanner Unit BW Harness - Scanner Unit Color Scanner I/O Board - BW Scanner I/O Board - Color Cover: Stepper Motor: Rear Bracket: Exterior: Rear Timing Belt - 157ST1.5-4.0 Stepper Motor: Ass'y Harness: SIO: STM Guide: High Voltage Supply Cord: Base Original Sensor Bracket Original Sensor - 76mm Duct: Scanner Sheet: Fan: Duct: Scanner Fan Motor: 15mm: 24V Seal: Duct: Front: Scanner Seal: Duct: Rear: Scanner Heater: Option: 120V: 9W Heater: Option: 230V: 9W Harness: Lamp: Connecting Rivet - NRP345 Holder: Connector Tension Spring: Tension: 14720mN Inverter Bracket

D009/D011/D012/D013/D091/D092

Q’ty Per Assembly

Index No.

1 2 1 2 1 1 1 1 1 1 1 1 1 1 1 1 2 1 1 1 1 1 2 1 1 1 1 1 1 1 1 1 1 1 1

47

Part No.

Q’ty Per Assembly

Description

32

D009 5560

Harness - Stabilizer BW

1

101 102 103 104 105 106 107 108 109 110 111 112 113

0451 3006N 0804 6123 0802 5299 0454 3006Q 1105 0516 1105 0518 1105 0488 1105 0517 1105 0460 0805 0088 1105 0508 1105 0511 1105 0195

Tapping Screw - 3x6 Hexagonal Bolt: W/Washer: M3x8 Tapping Screw - M3x8 Tapping Screw - M3x6 Clamp Edge Saddle - LES-1010 Harness Clamp Harness Clamp - LWS-2111Z Clamp Retaining Ring - M6 Harness Clamp - LWS-0711 Harness Clamp - LWS-0306ZC PCB Stud


19.LD Unit (D009/D011/D012/D013/D091/D092)

3

1

101 2

101

11 6

102

102

5

7

106

4

104 102

8 105

10 9

103 102 103

D009/D011/D012/D013/D091/D092

48


19.LD Unit (D009/D011/D012/D013/D091/D092) Index No. 1 2 3 4 5 6 7 8 9 10 11

Part No. D009 1860 D009 1861 G029 1980 AC01 5025 AX06 0353 D009 5570 D009 5325 D009 1870 D009 5571 AA06 3445 A232 1937

Description Imaging Unit Cover - Polygon Motor Decal - LD Shield Glass Polygon Mirror Motor - DC 16.8W Harness - Imaging Unit SYNC Detector Board Laser Diode Unit Harness: Laser Diode Control Spring - Laser Diode Unit Positioning Pin - Laser Unit Ass'y

D009/D011/D012/D013/D091/D092

Q’ty Per Assembly 1 1 1 1 1 1 1 1 1 1 1

49

Index No.

Part No.

101 102 103 104 105 106

0450 3010N 0450 3008N 0951 3008N 0951 3020N 0712 0030N 0454 3006Q

Q’ty Per Assembly

Description Tapping Screw - M3x10 Tapping Screw - M3x8 Screw: Polished Round: M3x8 Screw: Polished Round: M3x20 Hexagonal Nut: M3 Tapping Screw - M3x6


20.Paper Tray (D009/D011/D012/D013/D091/D092) 26

29

4

27 28

5 18 22 22 14

21 16

21

101

30

102

20 19

3

23

17

25 24

6 16

16 10

31

12 104

8 9

15

7 11

13

1

103

2 101

D009/D011/D012/D013/D091/D092

50


20.Paper Tray (D009/D011/D012/D013/D091/D092) Index No. * * 1 2 3 4 5 6 7 8 9 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31

Part No. B223 2901 D029 2900 B223 2910 B223 2911 B238 2523 B223 2940 AF01 3006 B223 2919 B223 2946 B223 2860 B238 2526 B238 2527 B223 2862 AA06 1014 D029 2863 B223 2861 AA06 1003 B223 2868 A232 2987 B223 2912 B223 2920 B223 2923 B004 2923 B223 2935 B223 2934 B223 2936 B223 2865 B223 2918 B223 2930 A267 2860 A267 2857 A267 2859 B223 2873 B180 2782

Description Paper Tray: No.2: Ass'y Paper Tray: No.2: Ass'y Link - Paper Size Sensor Spacer Decal - Paper Set Direction No.2 Tray Bottom Plate Bottom Plate Pad Ground Plate - Paper Tray No.2 Cover - Paper Tray No.2 Paper Tray Grip Decal - Grip Decal - Grip Lever - Release Inner Tension Spring: Grip Release Shaft Grip Holder Tension Spring: Side Fence: Rear Lever: Release: Paper Tray: Outer Roller - Paper Tray End Fence Front Side Fence Stopper Lever - Front Spring Plate - Release Lever Plate - Side Fence Right Plate - Side Fence Gear - 16Z Rise No.1 Shaft Rise Lever Rear Side Fence Rear Lever Stopper Spring Plate - Side Fence Side Fence Stopper Decal - Side Fence Rear Seal: Tray

D009/D011/D012/D013/D091/D092

Q’ty Per Assembly 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 4 1 1 1 1 2 2 1 1 1 1 1 1 1 1 1

51

Index No.

Part No.

101 102 103 104

0450 4008N 0453 3008N 0450 3012N 0720 0080E

Q’ty Per Assembly

Description Tapping Screw - M4x8 Binding Self Tapping Screw: 3x8 Tapping Screw: 3x12 Retaining Ring - M8


21.Paper Feed Section (D009/D011/D012/D013/D091/D092)

3

2

101

101 6

7

2

8

102 9 10

105 1

101

101

101

4 11

5

12

104

36

26 24

37

25

38

23 101 13

39

106

36

101

101

11

101 14

19

103

20

35

103

34

21

33 11

18

103

17 16 27

32 31

29 16

D009/D011/D012/D013/D091/D092

11

30

22 15

103

28

52


Rev. 6/6/2011

21.Paper Feed Section (D009/D011/D012/D013/D091/D092) Index No. * 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34

Part No. D009 2751 B223 2767 AW02 0145 D029 2773 D089 2778 AW01 0128 D089 2781 AW01 0122 B223 2780 B223 2776 D009 2757 AA08 2143 B223 2772 B223 2786 AF03 0090 AB01 1252 AA10 0014 B223 2829 AF03 1090 AB01 1218 GA08 2014 B223 2765 B223 2761 AA06 0691 G065 2767 B223 2764 B223 2762 AF03 2090 B004 2783 B223 2810 AB01 0157 AA06 0693 G065 2774 AB01 0156 B223 2815

Description Paper Feed Unit Paper End Feeler Photointerruptor: Flat Harness - Paper Feed Unit Bracket: Sensor: Feed Paper Feed Sensor Bracket: Sensor Paper Feed Sensor DC Solenoid 24V Stay Transport Roller: Drive: Ass'y Bushing - 6x10x6 Harness Sheet Ground Plate - Front Paper Feed Roller: Pickup Gear - 20Z Retaining Ring C - Separate Feed Guide Paper Feed Roller: Feed Gear - Roller Clutch Bushing – DIA6: DIA 10:9 [TSB#051] Ground Plate - Feed Pickup Arm Tension Spring Lever - Feed Gear-24Z Feed Shaft Paper Feed Roller: Separate Torque Limiter Separate Driven Shaft Gear: Separate: Drive Tension Spring Pressure Lever Gear: Separate: Drive Separate Drive Shaft

D009/D011/D012/D013/D091/D092

Q’ty Per Assembly

Index No.

2 1 2 1 1 1 1 1 1 1 1 4 1 1 1 1 2 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1

53

Part No.

Q’ty Per Assembly

Description

35 36 37 38 39

B223 2819 5206 2686 G065 2776 G065 2775 AA06 2259

Gear - 22Z Snap Ring Release Lever Link Lever Spring - Release

1 1 1 1 1

101 102 103 104 105 106

0451 3006N 0450 3008N 0805 0089 0720 0040E 1105 0511 0454 3008Q

Tapping Screw - 3x6 Tapping Screw - M3x8 Retaining Ring - M4 Retaining Ring - M4 Harness Clamp - LWS-0306ZC Tapping Screw: 3x8


22.By- Feed Section 1 (D009/D011/D012/D013/D091/D092)

1 101 3

4 2

5 14

101

101

8

6

12

9

11 10

11 102

102 7 13

D009/D011/D012/D013/D091/D092

54


22.By- Feed Section 1 (D009/D011/D012/D013/D091/D092) Index No. * 1 2 3 4 5 6 7 8 9 10 11 12 13 14 14

Part No.

Description

Q’ty Per Assembly

B223 2700 Manual Feed Table: Exp: Ass'y B223 2674 Side Fence: Front B223 2673 Side Fence: Rear B223 2726 Grip: Side Fence: Manual Feed B223 2668 Spring Plate: Stopper B223 2645 Decal: Side Fence B223 2729 Decal: Paper Set Direction: Manual Feed: EXP B223 2661 Cover: Manual Feed B223 2644 Decal: Scale B223 2669 Harness: Paper Size Sensor AW50 0031 Paper Size Sensor B223 2713 Rack: Manual Feed B223 2666 Gear: 16Z B223 2663 Extension Tray B223 2662 Manual Feed Table D029 2662 Manual Feed Table

D009/D011/D012/D013/D091/D092

Index No. 101 102

1 1 1 1 1 1 1 1 1 1 1 2 1 1 1 1

55

Part No.

Description

Q’ty Per Assembly

0450 3008N Tapping Screw - M3x8 0805 0089 Retaining Ring - M4


23.By- Feed Section 2 (D009/D011/D012/D013/D091/D092) 1

43

101

103

44 45

108 46

2 103

113

101

3

104

47

102

4

112

9

108 5

7

109 7 102 108

16

12

14

108

8

48 31

15 13

10

6

21

28

29

108 108 30

11 18

20

105

7 108

19

102

7

17

26

108

32

110

27

50

105

49

108 33

101 102 34

38

36 111 42

23 108 37 107

22 102

D009/D011/D012/D013/D091/D092

25 24

106

108 5

56

41

35 40 39


Rev. 2/17/2011

23.By- Feed Section 2 (D009/D011/D012/D013/D091/D092) Index No. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35

Part No. B223 2623 AW01 0107 B223 2622 B223 2621 AA10 0014 AF03 1046 AA08 2101 AA14 0777 B223 2629 AB01 1387 AF03 0049 AA06 3568 G060 2932 B223 2632 B223 2633 B223 2659 D009 2552 D009 2555 B223 2634 B223 2636 AW50 0035 B223 2651 AA08 2102 B223 2657 B223 2607 D009 2609 AF01 3016 G080 2682 B223 2606 AA08 3014 AX20 2007 B223 2637 B223 2652 B223 2658 A259 6754

Description Cover: Guide Plate: Exit Paper Feed Sensor Guide Plate: Exit Cover: Manual Feed Unit Retaining Ring C - Separate Feed Roller - Manual Feed Bushing - 6x10x6 Shaft: Feed Stay: Feed Gear - 23Z Pick-up Roller Pressure Spring Pick-up Arm - Manual Feed DC Solenoid: Pickup Spring: Release: Pickup Harness: Manual Feed Guide Sheet - Manual Feed Transport Roller - Duplex Exit Stay: Arm Torsion Spring: 27N Paper End Sensor Arm: Manual Feed: Front Bushing - 6x10x6 Arm: Manual Feed: Short: Front Ground Plate: Reverse Guide Plate: Separator Bottom Plate Pad Bushing: Feed Ground Plate: Rear One-way Clutch Magnetic Clutch Bracket: Arm: Manual Feed: Rear Arm: Manual Feed: Rear Arm: Manual Feed: Short: Rear Bushing - 6 6mm

D009/D011/D012/D013/D091/D092

Q’ty Per Assembly

Index No.

1 1 1 1 2 1 4 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1

57

Part No.

Q’ty Per Assembly

Description

36 37 38 39 40 41 42 43 44 45 46 47 48 49 50

AB01 1416 B223 2608 AA14 0778 AF03 2046 G080 2900 B180 2871 AA06 3499 AA06 0872 B223 2681 AB01 1223 B223 2686 B223 2683 B223 2689 B223 2696 B223 2620

Gear - 20Z Gear: Z16 Shaft: Separator: Drive Separation Roller - Manual Feed Torque Limiter Shaft: Separator: Driven: Ass'y Pressure Spring Spring Arm: Tightener Idler Gear - 25Z Gear: Z31 Gear: 25Z Gear: Z28 Drum Stay: Drive Housing: Manual Feed

101 102 103 104 105 106 107 108 109 110 111 112 113

0451 3006N 0450 3008N 0452 3008N 0353 0040N 0454 3008Q 0451 3008N 0360 3006N 0805 0089 0805 0088 1105 0522 1102 6248 1105 0551 1105 0511

Tapping Screw - 3x6 Tapping Screw - M3x8 Tapping Screw - M3x8 Screw - M3x4 Tapping Screw: 3x8 Tapping Screw - M3x8 Screw - M3x6 Retaining Ring - M4 Retaining Ring - M6 Edge Saddle - LES0510 Connector - 5P Clamp: LES-0505 Harness Clamp - LWS-0306ZC

1 1 1 1 1 1 1 1 1 1 1 1 1 1 1


24.Paper Registration (D009/D011/D012/D013/D091/D092)

104

27

24

25

102

23

9

18

104

10

103 103

32

28

104

102 24 102

26 30

31

7

103

16

8

6 14 29 104

102

103

15

17

13 19

103

103

102

102

21

D009/D011/D012/D013/D091/D092

3

102 2

22

12 102

8

4

101

10

7

5 101

105

20

102

101 105

4

1

11

58


24.Paper Registration (D009/D011/D012/D013/D091/D092) Index No.

Part No.

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 101 102 103

D009 2841 D009 2836 D009 2617 D009 2650 D009 2638 D009 2618 D009 2607 D009 2636 D009 2603 AA08 2074 D009 2612 D009 2624 D009 2606 D009 2600 B238 2655 D009 2602 D009 2604 D009 2623 D009 2626 AW01 0107 D009 2614 D009 2622 D009 2240 AA08 2078 D009 2243 D009 2245 D009 2244 D009 2241 D009 2242 D009 3858 D009 3107 D009 3108 0450 3006N 0454 3006Q 0805 0089

Description Guide Plate - No.2 Guide Plate Upper Guide Plate - Registration Torsion Spring - Registration Stay - Paper Dust Removal Cover - Paper Dust Removal Bushing - Driven Registration Tension Spring Gear - 28Z Bushing - M8 Case er - Remove Paper Dust Lower Guide Plate - Registration Registration Roller - Driven Registration Roller - Drive Gear - 16Z Gear - 18Z Knob - Registration Roller Rear Positioning Guide Harness - Registration Sensor Paper Feed Sensor Bracket - Registration Sensor Front Positioning Guide Rear Flange - Lock Bushing - 8mm Shaft - Lock Stopper Cover - Stopper Stopper - Lock Front Flange - Lock Spring Plate - Lock Entrance Guide Plate - Transfer Seal: Shielding Plate Seal: Guide Plate Tapping Screw - M3x6 Tapping Screw - M3x6 Retaining Ring - M4

D009/D011/D012/D013/D091/D092

Q’ty Per Assembly

Index No.

1 1 1 2 1 1 2 2 1 2 1 1 1 1 1 1 1 1 1 1 1 1 1 2 1 1 1 1 1 1 1 1

104 105

59

Part No.

Description

Q’ty Per Assembly

0453 3006N Tapping Screw - M3x6 1105 0568 Clamp: LWSS-0504


25.Toner Supply Unit (D009/D011/D012/D013/D091/D092)

4

1

101 9 8

7

5 12

6

14

103 13

11 102

2

10 3 3

16 15

17 103 104 105

D009/D011/D012/D013/D091/D092

60


25.Toner Supply Unit (D009/D011/D012/D013/D091/D092) Index No. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 15 16 17 17

101

Part No. D009 3209 B077 3262 A232 3266 A232 3240 A134 3180 A232 3252 A232 3251 AA06 3566 AA15 3083 A232 3263 D009 3265 A232 3264 D009 5892 D009 3264 D011 5841 D011 5842 D009 5611 D011 1252 D011 1253

Description Toner Supply Unit Slide Rail: Toner Supply Unit Seal - Slide Rail Cover - Toner Bottle Ass'y Bottle Chuck Slider Ass'y Chuck Shaft Pressure Spring Seal - Toner Supply Unit Cover Spring Plate - Toner Bottle Shaft - Slide Stopper - Slide Rail Heater Stopper Cam: Handle Heater: PCD: NA: Sub-ass'y Heater: PCD: EU: Sub-ass'y Harness: AC: Heater Decal: Main Switch: On-standby Decal: Main Switch: On-standby: EU

Q’ty Per Assembly

Index No.

Part No.

1 1 2 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1

102 103 104 105

0456 3008N 0454 3006Q 1105 0487 1105 0516

Description

Q’ty Per Assembly

Tapping Screw - M3x8 Tapping Screw - M3x6 Harness Clamp Clamp

0452 3010N Binding Self-tapping Screw: 3x10

D009/D011/D012/D013/D091/D092

61


Rev. 8/15/2011

26.PCDU 1 (D009/D011/D012/D013/D091/D092) 32

1

31 30 41

32

31 28 101

102

2

26

29 40 33

102

23

22

25

3

20

102 39

18

15

104

19

24

5 17

18

19

102 36 34 21 36 38

4

16 13 14

35

6

103

7

8

104

102

9 37

102 12

11

102 10

D009/D011/D012/D013/D091/D092

62


Rev. 12/27/2011

26.PCDU 1 (D009/D011/D012/D013/D091/D092) Index No. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 28 29 30 31 32 33 34 35 36

Part No.

Description

Q’ty Per Assembly

D009 2110 D009 2389 G065 2681 D009 2301 B296 9640 A232 3155 AB01 4061 A232 3077 AB01 4060 AB01 4062 D009 3068 D009 3069 A232 3067 B213 3065 D009 3078 D009 3066 D009 3205 AA15 3095 B082 3123 D009 3206 D009 3072 D009 3053 D009 3070 D009 3204 D009 3086 D009 3162 B082 3122 B082 3121 D009 3152 5206 2686 D009 2480 D009 3203 D009 3102 AA08 0281 D009 3101

PCU Rear Side Plate - Coupling Snap Ring - M6 Development Unit Developer - Black Front Cover - Development Unit Gear - 13Z Spacer - M5 Gear - 21Z Gear - 17Z/25Z Front Bias Terminal Rear Bias Terminal Tape - TD Sensor Density Sensor: Development: C4 t- Paddle Entrance Seal - Toner Supply Seal: Side Plate: Front Shield - Development - Center Shield: Case: Development: Front Rear: C3 Seal: Side Plate: Rear Seal - Density Sensor Harness Upper Case Seal Upper Cover - Development Unit Front Seal - Upper Cover Development Filter Ground Plate: Doctor Blade Shield: Development Sleeve: Rear: C3 Shield: Development Sleeve: Front: C3 Entrance Seal Ass'y Snap Ring Screw - M3x10 Rear Seal - Upper Cover Upper Cap - Development Case Bushing - 12x18x5.5 Seal: Development

1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 2 2 1 1 1 1 1 1 1 1 1 1 2 2 1 3 1 2

D009/D011/D012/D013/D091/D092

Index No. 37 38 39 40 41

101 102 103 104

63

Part No.

Description

D009 3106 D009 3178 D009 3084 D009 3085 D009 3124

Sponge Seal: Slide Development Filter: Front Development Filter: Rear t: Development Sleeve

0454 3006Q 0456 3008N 0720 0030E 0725 0110E

Tapping Screw - M3x6 Tapping Screw - M3x8 Retaining Ring - M3 C Ring - M11

Q’ty Per Assembly 1 1 1 1 1


Rev. 04/04/2012

27.PCDU 2 (D009/D011/D012/D013/D091/D092) 1 102

4

6 8

2 101

5 10

7

15

11

103

13 49 10428 25

11

10

34

3

14

23 27

12

30

26

24

101 48

20

33

13

103

29

102

31

32

102

21

20 105

9

46 105 102 19

104 21

22

17 102

16

102 45

18 41 38 105

37

D009/D011/D012/D013/D091/D092

64

40 39

42

43

44


Rev. 5/9/2012

27.PCDU 2 (D009/D011/D012/D013/D091/D092) Index No. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 37

Part No. D129 2212 D009 2389 D009 2392 D009 2317 D009 2445 D009 2380 D009 2279 D009 3267 D009 2633 A232 2399 D009 2205 D009 2201 D009 2203 D009 2202 D009 2204 B213 2316 G065 2354 G065 2681 D009 2331 AA06 3648 A232 2421 A232 2315 B213 2312 D009 2351 D009 2318 AA06 2348 AA06 2300 AB01 1380 AB01 1379 D009 2336 G065 2308 B082 2333 A232 2318 D009 2426 AD02 7012

Description Frame: PCU: Upper: C2: Ass'y Rear Side Plate - Coupling Side Plate: Idler Ass’y Electrode Plate - Charge Handle - PCU Front Side Plate - Coupling Seal: Toner Supply: Entrance: Upper Seal: Toner Supply: Entrance: Front Cap - Toner Supply Seal - Blade 13x9.5x3 Seal: Blade: Upper Rear: Small Seal: Drum: Front Seal: Drum: Entrance Seal: Drum: Rear Seal: Blade: Upper: Case Stud: Point: Cleaning Electrode Plate: Charge: Front Snap Ring - M6 Front Arm - Pressure/Charge Pressure Spring Bushing - 6x10x3 Front Bushing - Cleaning Bracket Bracket: Cleaning Blade Cleaning Blade Spring Plate - Electrode Pressure Spring Tension Spring Cam - Cleaning Blade Gear - 19Z Rear Arm - Pressure/Charge Electrode Plate: Charge: Rear Terminal: Brush Roller Collar - Cleaning Seal - 24.5x68.5 Roller: Charge: Apply

D009/D011/D012/D013/D091/D092

Q’ty Per Assembly

Index No.

1 1 1 1 1 1 1 1 1 2 2 1 2 1 1 1 1 2 1 2 2 1 1 1 1 1 1 1 1 1 1 1 1 1 1

Q’ty Per Assembly

Description

38 39 40 41 42 43 44 45 46

D009 2303 AA14 3549 A232 3553 D009 9510 AA06 2310 A232 2340 AD02 5021 A232 2339 G790 2329

48 49

D009 3104 D009 2214

Drum Hold Plate Screw: DIA10: M3x8 Ball Bearing - 8x16x5 OPC Drum Pressure Spring Holder - Pick-Off Pawl Pick-Off Pawl Spur Brush Roller: Cleaner: Charge: AMABUKI: Ass'y Seal: Level Separation Plate: Case: Blade: Upper

0454 3006Q 0456 3008N 0457 3008N 0720 0040E 0360 3006N

Tapping Screw - M3x6 Tapping Screw - M3x8 Tapping Screw - M3x8 Retaining Ring - M4 Screw - M3x6

101 102 103 104 105

65

Part No.

1 1 1 1 1 1 1 1 1 1 1


28.Transfer Belt Unit 1 (D009/D011/D012/D013/D091/D092) 1

2

3 6 7

5 101

4

17

102

16 5 101

10

13

14

9 9 7

15 8

11 12

D009/D011/D012/D013/D091/D092

102

17

66


Rev. 3/2/2012

28.Transfer Belt Unit 1 (D009/D011/D012/D013/D091/D092) Index No. * 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17

Part No. D009 3806 A232 3885 B213 3889 AA08 2054 D009 3935 D009 3937 D009 3934 AA06 1020 D009 3890 A232 3926 D009 3894 D009 3954 D009 3948 G024 1314 AB01 1282 A232 3880 D009 3883 D009 3893

Description Transfer Unit Driven Roller - Transfer Unit Roller: Bias Bushing - M4 Earth Terminal - Transfer Belt Terminal - Transfer Belt Bias Terminal - Transfer Belt Spring: Release: Transfer Belt Front Bushing - Bias Roller Transfer Belt Roller Drive Roller - Transfer Belt Sheet: Prevent fence: Transfer Belt Scraper - Drive Roller Pulley Pin Gear - 31Z Transfer Belt Frame - Transfer Belt Arm - Transfer Belt

D009/D011/D012/D013/D091/D092

Q’ty Per Assembly

Index No.

1 1 1 1 1 1 1 2 1 2 1 1 1 1 1 1 1 2

101 102

67

Part No.

Q’ty Per Assembly

Description

0452 3006N Binding Self-tapping Screw: 3x6 0451 3006N Tapping Screw - 3x6


29.Transfer Belt Unit 2 (D009/D011/D012/D013/D091/D092)

101 17

101

101 29

5

20

18 3

1

13 7

2

8 28

4

101

103

10 9

101

21 19

103

22

11

24

9

6

25

101 23

26

27

102

12

D009/D011/D012/D013/D091/D092

16 20

15 14

102

68


Rev. 10/03/2012

29.Transfer Belt Unit 2 (D009/D011/D012/D013/D091/D092) Index No. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30

Part No. AD04 1135 D009 3943 AA06 1100 D009 3919 805 0106 D009 3920 D009 3921 D009 3916 AA06 3447 D009 3917 G102 3837 D009 3899 D009 3918 GW23 0001 D009 3872 D009 3803 D009 3992 AA06 6380 D009 3876 AA06 6381 D009 3875 D009 3907 D009 3953 D009 3952 D009 3906 B082 3867 AA15 0423 A232 3909 A232 3908 B234 3177

Description Cleaning Blade - Transfer Belt Bracket: Cleaning Blade: Transfer Belt Spring: Pressure: Cleaning Blade Release Lever Shaft Retaining Rings-E: Silencer: Dia6 Front Release Plate Rear Release Plate Front Lever - Transfer Belt Spring - Transfer Belt Rear Lever - Transfer Belt Stopper: Blade Set Lever - Transfer Unit Release Lever Toner End Sensor Harness - Used Toner Sensor Case - Transfer Unit Receptacle Housing - Transfer Unit Spring Earth Harness - Transfer Unit Spring Harness - Transfer Unit Bias Seal - Transfer Belt Exit Front Seal - Cleaning Blade Rear Seal - Cleaning Blade Seal - Rear Transfer Exit Shield: Remove Paper Dust Seal - Cleaning Pressure Seal - Front Case Seal - Rear Case Decal: Positioning Display: Development

D009/D011/D012/D013/D091/D092

Q’ty Per Assembly

Index No.

1 1 1 1 1 1 1 1 2 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1

101 102 103

69

Part No.

Description

Q’ty Per Assembly

0451 3006N Tapping Screw - 3x6 0456 3008N Tapping Screw - M3x8 0452 3008N Tapping Screw - M3x8


30.Fusing Unit 1 (D009/D011/D012/D013/D091/D092) 101

23

102

8 1

101

10

9

101

101 11

101

2

5

12

10

3

101

4 101

101

11

101 13

101

101

14

101

7

101

101

15 16 101

101

15

101

16

6 22

19

17

21

20

18 101

101

D009/D011/D012/D013/D091/D092

70


Rev. 12/7/2012

30.Fusing Unit 1 (D009/D011/D012/D013/D091/D092) Index No. * * 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23

Part No. D130 4002 D011 4003 D009 4244 D009 4243 D009 4248 AA06 1023 D129 4059 D129 4055 B223 1317 D129 4062 D009 4057 AA06 1022 AA08 0352 D009 4664 D009 4238 D009 4225 AA06 1099 AA08 0351 AE04 2098 D009 4066 AA14 3520 D009 4069 AA14 3520 D009 4053 D129 4242

Description Fusing Unit: NA: Service: Ass’y Fusing Unit - 230V Knob Exit Guide - Pressure Roller Unit Knob Bracket Compression Spring - Knob Fusing Cover - Upper Front Fusing Cover - Lower Front Screw Fusing Cover - Upper Rear Fusing Cover - Lower Rear Spring - Driven Roller Bushing - Driven Roller Driven Roller Bracket - Driven Roller Stay - Pressure Roller Unit Compression Spring: Cleaning Roller Bushing - Cleaning Roller Cleaning Roller: Ass'y Fusing Cover - Duplex Guide Shoulder Screw - M3 Entrance Guide Plate - Fusing Shoulder Screw - M3 Fusing Cover - Lower Middle Decal: H-Temp Warning

D009/D011/D012/D013/D091/D092

Q’ty Per Assembly

Index No.

1 1 2 1 1 1 1 1 1 1 1 2 2 1 1 1 2 2 1 1 1 1 1 1 1

101 102

71

Part No.

Description

Q’ty Per Assembly

0360 3006N Screw - M3x6 0353 0050N Screw-M3x5


31.Fusing Unit 2 (D009/D011/D012/D013/D091/D092) 26 104

45 101

102

18

101

102

29

101 104 20 101

19 101 20

101

21 22

103

102

36

101

23 22

24

101

101

101 24

101

101

25 103 101

27 28 101 33 34

32 31 30

101

8

106

7

102 10

5

35

15

107 38

101 101

102

12

16

14

101 105 101

37

9 102

2 3

104

39

17

13 4

101 101

1 2

101 101

108

5

6

D009/D011/D012/D013/D091/D092

3

108

4

8 106 7 10 9107

102

41

42

45

40 43 44

11

101

72


31.Fusing Unit 2 (D009/D011/D012/D013/D091/D092) Index No. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 27 28 29 30 31 32 33 34

Part No. D009 4126 D009 4156 AE03 0099 AE03 0098 B238 4166 D009 4271 B238 4194 AA14 3792 D009 4274 AA06 1024 D009 4275 D009 4196 D009 4143 D009 4135 D009 4152 AA06 0948 AE04 4099 D009 4165 D009 4197 D009 4193 AW11 0098 D009 4195 AW11 0099 D009 4178 D009 4177 D009 4099 D009 4097 D009 4098 D009 4125 D009 4132 D009 4131 D009 4142 D009 4141 D009 4124 AB01 0172

Description Front Heater Bracket Retaining Rings-C - Hot Roller Ball Bearing - 30x42x7 Ball Bearing - 8x22x7 End Ring: Spring: DIA4 Front Lever - Pressure Release Roller: Lever: Pressure Screw: Drawer Pressure Lock Lever Tension Spring - Pressure Front Pressure Lever Harness 1 - Thermostat Electrode Plate 3 Terminal - AC Stay: Fusing Sub-unit: Fusing Exit: Peen Tension Spring: Stripper Pawls: 50mN Stripper Pawls Fusing Unit Cover Harness 2 - Thermostat Housing - Thermostat Thermostat - 220C Spacer - Thermostat Thermostat - 219C Thermistor Bracket Thermistor Harness - Fusing Unit Harness - Set Sensor NA Set Sensor Harness - 230V Connector Bracket 2 Terminal Cover Terminal - AC/DC Electrode Plate 2 Electrode Plate 1 Connector Bracket 1 Gear - 24Z/25Z

D009/D011/D012/D013/D091/D092

Q’ty Per Assembly

Index No.

1 2 2 2 2 1 2 2 2 2 1 1 1 1 1 7 7 1 1 2 1 2 1 2 1 1 1 1 1 1 1 1 1 1 1

73

Part No.

Q’ty Per Assembly

Description

35 36 37 38 39 40 41 41 42 42 43 44 45

D009 4123 D009 4127 D009 4291 D009 4295 AB01 0171 AE01 0099 AX43 0112 AX43 0113 AX44 0252 AX44 0253 AE02 0199 D009 4163 AA14 3520

Bracket: Side Plate: Auxiliary Rear Heater Bracket Rear Lever - Pressure Release Front Pressure Lever Gear - 40Z Hot Roller Heater - 120V 550W Heater - 230V 550W Heater - 120V 750W Heater - 230V 750W Pressure Roller Exit Guide - Hot Roller Unit Shoulder Screw - M3

101 102 103 104 105 106 107 108

0360 3006N 0804 6123 0954 3010N 0957 4008N 0454 3006Q 0733 0408 0720 0030E 0720 0080E

Screw - M3x6 Hexagonal Bolt: W/Washer: M3x8 Screw: Polished Round/Spring: M3x10 Screw: Small Round/Spring: M4x8 Tapping Screw - M3x6 Bushing: 4x8 Retaining Ring - M3 Retaining Ring - M8

1 1 1 1 1 1 1 1 1 1 1 1 2


32.Fusing Unit 3 (D009/D011/D012/D013/D091/D092) 1

12

11

2

10

1

104

102

101

17

102

103

13 14

16

103 102

101

13 102

102

17

102

101

15

103

103 7 23

102 4 7

5 102

102

3

8

9

6

103 19

102

20

21 18

102 103 19

D009/D011/D012/D013/D091/D092

17

22

74


Rev. 06/06/2012

32.Fusing Unit 3 (D009/D011/D012/D013/D091/D092) Index No. * 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23

Part No. D129 4305 AA14 3812 D129 4307 D009 4369 B065 4247 AB01 0174 AB01 0175 AA06 3886 D009 4355 AE04 0099 D009 4393 B065 4221 D009 4378 AA08 0355 D009 4377 AB01 0178 AB01 0177 AA08 0356 AE04 5099 AA08 0354 AB01 0173 D009 4388 AB01 0176 AA08 0353

Description Cleaning Unit: Ass'y Screw - Scale Cover: Cleaning Unit Bracket - Cleaning Unit Drive Brake Pad Gear - 20Z/50Z Gear - 24Z Spring Roller Clutch Holder Roller Feeler - Web Feeler Spring Worm Gear Shaft Bushing - 7mm Worm Gear Bracket Worm Gear Gear - 32Z Bushing - 6mm Cleaning Web Bushing - 6mm Gear - 60Z Roller Clutch Gear - 24Z Bushing - 4mm

D009/D011/D012/D013/D091/D092

Q’ty Per Assembly

Index No.

Part No.

1 2 1 1 1 1 1 2 2 1 1 1 1 2 1 1 1 3 1 2 1 1 1 1

101 102 103 104

0353 0050N 0360 3006N 0720 0030E 0573 0030E

75

Q’ty Per Assembly

Description Screw-M3x5 Screw - M3x6 Retaining Ring - M3 Hexagonal Set Screw - M3x3


33.Duplex Unit 1 (D009/D011/D012/D013/D091/D092)

7

4 103

103

2

101

5 102

6

8 9

11 10

12

9 10 13

101

3 103

101

101 17 103

101

1

16 14 14 15

D009/D011/D012/D013/D091/D092

76


33.Duplex Unit 1 (D009/D011/D012/D013/D091/D092) Index No. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17

Part No. D009 4534 D009 4533 B223 4579 D009 4590 D009 4532 D009 4537 D009 4538 D009 4664 AA08 0254 B223 4538 AG07 0514 B223 4531 D009 4540 B223 2665 B223 2664 B223 4539 B223 4525

Description Front Inner Cover - Duplex Rear Inner Cover - Duplex Grip: Open And Close: Duplex Unit Stopper Hook - Duplex Unit Tension Spring - Stopper Hook Front Release Arm Rear Release Arm Driven Roller Bushing - M4 Compression Spring Magnet Catch Guide Plate: Cover Cover - Duplex Unit Spring: Cover: Manual Feed Cover: Manual Feed: Entrance Sheet: Cover: Duplex Tension Spring: Wire: 180N

D009/D011/D012/D013/D091/D092

Q’ty Per Assembly

Index No.

1 1 1 1 1 1 1 1 2 2 1 1 1 2 1 1 1

101 102 103

77

Part No.

Description

Q’ty Per Assembly

0451 3006N Tapping Screw - 3x6 0720 0030E Retaining Ring - M3 0451 3008N Tapping Screw - M3x8



101

2

104 104

1

102 3

4

5 11

4 6

10

5 7

12

9 101

8 10

103 14

13

D009/D011/D012/D013/D091/D092

78


34.Duplex Unit 2 (D009/D011/D012/D013/D091/D092) Index No. 1 2 3 4 5 6 7 8 9 10 11 12 13 14

Part No. D009 4483 D009 4481 D009 4489 D009 4485 D009 4543 D009 4486 D009 4409 B223 4494 B223 4479 D009 4488 D009 4482 D009 4577 D009 4522 D009 4503

Description Upper Gate Grip - Upper Gate Driven Roller Bushing - Gate Tension Spring - Duplex Gate Lever - Upper Gate Sheet - Gate Stopper - Upper gate Pawl Tension Spring: Gate Pawl: 1.6N Right Spring - Guide Plate Right Guide Plate - Open/Close Duplex Gate Tension Spring - Duplex Gate Guide Plate - Left Upper

D009/D011/D012/D013/D091/D092

Q’ty Per Assembly 1 1 1 2 2 1 1 1 1 2 1 1 1 1

79

Index No.

Part No.

101 102 103 104

0450 3008N 0805 0092 0805 0097 1105 0511

Q’ty Per Assembly

Description Tapping Screw - M3x8 Retaining Ring - 3M Ring Separator Harness Clamp - LWS-0306ZC


35.Duplex Unit 3 (D009/D011/D012/D013/D091/D092) 12 101

25

13

107

7

2

101 14

102

8 106

1 106

1

9

6 101

4 5

101

3

3

11

16 105

15 105

16

10 27 102

101 24 105

10

3 108 17

18

19

20 22

104

21

103

101

108

3

23

26

101

D009/D011/D012/D013/D091/D092

80


35.Duplex Unit 3 (D009/D011/D012/D013/D091/D092) Index No. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27

Part No. AA14 3807 D009 4504 AA08 2104 B223 4566 AW01 0107 D009 4664 B223 4560 B223 4552 AW02 0145 D009 4661 AB01 4161 B223 4562 B044 1847 B223 4564 B223 4526 B223 4586 B223 4572 AA10 1021 B223 4575 B223 4571 B223 4573 B044 1825 B223 4501 D009 4521 D009 4497 D009 4652 B223 4567

Description Screw: A Upper Guide Plate - Gate Bushing - 8x12x7 Bracket: Sensor: Entrance Paper Feed Sensor Driven Roller Tension Spring: Driven Roller Bushing: DIA4 Photointerruptor: Flat Reverse Roller - Feed Reverse Roller Gear Tightener Shoulder Screw Spring: Tightener Timing Belt: 30S2M268 Pulley: T30 Stepper Motor: DC4.29V 1.7W Rubber Bushing - 6 45HS Bracket: Stepper Motor Gear: Pulley: Z24/T40 Timing Belt: 30S2M128 Collar Guide Plate: Right Harness Bracket Decal - Right Guide Motor Harness Stay: Transport: Upper: Peen

D009/D011/D012/D013/D091/D092

Q’ty Per Assembly

Index No.

Part No.

2 1 4 1 1 1 2 2 1 2 1 1 1 1 1 2 1 4 1 1 1 4 1 1 1 1 1

101 102 103 104 105 106 107 108

0451 3006N 0454 3006Q 0353 0100N 0720 0040E 1105 0511 0720 0030E 1105 0551 0805 0088

81

Q’ty Per Assembly

Description Tapping Screw - 3x6 Tapping Screw - M3x6 Screw-M3x10 Retaining Ring - M4 Harness Clamp - LWS-0306ZC Retaining Ring - M3 Clamp: LES-0505 Retaining Ring - M6


36.Duplex Unit 4 (D009/D011/D012/D013/D091/D092) 13

19

14

101

15

10 104

11

102

20

103 26 16

22

17

18

10 102

15

6 103 102 3 102

7

101

1

24 25

21

101

23

2 101

10

12

101

101

4

5

10 8 101 9 102 10

D009/D011/D012/D013/D091/D092

82


36.Duplex Unit 4 (D009/D011/D012/D013/D091/D092) Index No. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26

Part No. D009 4662 D009 4663 B223 4512 B223 4536 B223 4511 B223 4529 B223 4544 B223 4527 B223 4535 AA08 2101 B223 4514 B223 4502 B223 4553 B223 4552 D009 4664 D009 3860 AA06 3448 D009 4551 D009 3861 D009 3884 D009 4541 AA10 0014 D009 4545 AA06 3303 AA08 0254 B234 3177

Description Transport Roller 1 Transport Roller 2 Timing Belt: 30S2M182 Timing Belt: 30S2M234 Timing Belt: 30S2M312 Roller Clutch: T24 Pulley: T35/T33 Pulley: T26/T24 Roller Clutch: T26 Bushing - 6x10x6 Roller Clutch: T24 Guide Plate: Left Lower Tension Spring: Driven Roller Bushing: DIA4 Driven Roller Spring Cover - Transfer Unit Pressure Spring - Transfer Unit Guide Plate - Holder Terminal Holder - Transfer Unit Sensor Harness Front Torsion Spring Retaining Ring C - Separate Holder Shaft - Transfer Unit Pressure Spring Bushing - M4 Decal: Positioning Display: Development

D009/D011/D012/D013/D091/D092

Q’ty Per Assembly 1 1 1 1 1 1 1 1 1 5 1 1 2 2 2 2 2 1 1 1 1 1 1 2 2 1

83

Index No.

Part No.

101 102 103 104

0450 3008N 0805 0089 0720 0030E 1105 0623

Description

Q’ty Per Assembly

Tapping Screw - M3x8 Retaining Ring - M4 Retaining Ring - M3 Clamp - LBWS-0206S-V0



1

16

8

3

9

7

4 106

10 6

2

3

5 11

26

13

4

102 3

14

15

102

104 105 20 101

101

19

101

3 12 21

17

27 24

25 103

104

28 101 23 22

18

107

15 101

D009/D011/D012/D013/D091/D092

84


Rev. 01/19/2011

37.Duplex Unit 5 (D009/D011/D012/D013/D091/D092) Index No. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28

Part No. D009 2554 D009 2563 G060 2652 B223 2676 D009 2571 D009 2572 D009 2574 D009 2573 D009 2576 D009 2575 D009 2511 B223 4524 B223 2648 D009 2560 B223 2649 D009 4535 D009 4651 B223 4595 D009 4597 B223 4594 D009 4599 D009 4598 D009 4589 D009 4588 AA14 3183 D009 4593 D009 4587 B223 4522

Description Guide Sheet - Vertical Transport Guide Plate - Vertical Transport Bushing - M4 Spring - 11N Holder - Vertical Transport Transport Belt Pulley - Idler Pulley - Vertical Transport Shaft - Vertical Transport Shaft - Idler Guide Plate: Feed Paper Again: Exit: A Wire: Stopper: DIA1.5 Guide Plate: Transport Unit: Exit Driven Roller Spring: Pressure: 5N Harness Guide Harness - Duplex Unit Pulley: DIA13 Bracket - Wire Pulley Shaft Shaft: Pulley: Wire Shaft - Duplex Unit Spring - Set Shaft Guide - Set Shaft Stopper Bracket - Spring Stepped Screw Stepped Screw - M3 Tension Spring - Release Bracket Spacer: Wire: Stopper

D009/D011/D012/D013/D091/D092

Q’ty Per Assembly

Index No.

Part No.

1 1 6 4 1 1 1 1 1 1 1 1 1 1 2 1 1 1 1 1 1 1 1 1 1 1 1 1

101 102 103 104 105 106 107

0451 3006N 0450 3008N 0450 3010N 0954 3008N 1105 0487 1105 0511 0720 0040E

85

Q’ty Per Assembly

Description Tapping Screw - 3x6 Tapping Screw - M3x8 Tapping Screw - M3x10 Screw - M3x8 Harness Clamp Harness Clamp - LWS-0306ZC Retaining Ring - M4


38.Paper Exit Section 1 (D009/D011/D012/D013/D091/D092)

107 108 22

16 109

105

24

105 101 102

15

101

19 6

23

101

20 106

18

21

107

17 102 4 103

6

8

14

9

1

10 102

101

5 2

25

103

7

8

11 107

11

4

11

3

12

104 13

D009/D011/D012/D013/D091/D092

86

101 101


38.Paper Exit Section 1 (D009/D011/D012/D013/D091/D092) Index No. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25

Part No. D009 4430 D009 4457 D009 4438 D009 4439 D009 4455 AW01 0107 D009 4436 H053 2208 D009 4445 D009 4441 D009 4418 D009 4408 AW01 0127 D009 4464 D009 4447 D009 4499 D009 4407 B223 4497 AW02 0145 D009 4461 D009 4469 D009 4471 D009 4490 D009 4547 D009 4448

Description DC Solenoid - Exit Tension Spring Release Lever - Entrance Gate Bushing - 4mm Cushion - DC Solenoid Paper Feed Sensor Entrance Gate Bushing - M4 Transport Roller Exit Guide Plate - Upper Right Stepped Tapping Screw - M3 Bracket - Fusing Exit Sensor Paper Feed Sensor Gear - 22Z Exit Sensor Bracket Harness - Paper Exit Unit Feeler - Overflow Shaft: Feeler: Overflow Photointerruptor: Flat Gear - 17Z Gear - 17Z Stepper Motor Bracket Exit Motor Cover Stepper Motor - DC 5.79W Tension Spring - Gate Pawl

D009/D011/D012/D013/D091/D092

Q’ty Per Assembly 1 1 1 2 1 2 1 2 1 1 3 1 1 1 1 1 1 1 1 1 1 1 1 1 1

87

Index No.

Part No.

101 102 103 104 105 106 107 108 109

0451 3006N 0454 3006Q 0805 0092 0353 0100N 0453 3006N 0720 0040E 1105 0511 1105 0516 0450 3006N

Q’ty Per Assembly

Description Tapping Screw - 3x6 Tapping Screw - M3x6 Retaining Ring - 3M Screw-M3x10 Tapping Screw - M3x6 Retaining Ring - M4 Harness Clamp - LWS-0306ZC Clamp Tapping Screw - M3x6


39.Paper Exit Section 2 (D009/D011/D012/D013/D091/D092) 108 2

1

30

101

6

32

31

33

3 5

106

34 6

7

101

13

14

102

12

9 106

10

6

8

26

104

8

27

28 102

102

24

107 16 103

101

102

101

4

102 29

101

25 21 20 18 17 21 103

104 23 22

15 19

101

102

18

17

16 103

103

11

D009/D011/D012/D013/D091/D092

105

88


39.Paper Exit Section 2 (D009/D011/D012/D013/D091/D092) Index No. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34

Part No. D009 4444 D009 4428 D009 4445 H053 2208 D009 4443 AA08 2101 D009 4442 AF04 0575 5206 2684 D009 4434 D009 4406 D009 4412 AF04 0571 B223 4428 D009 4422 B223 4435 D009 4419 D009 4498 D009 4413 D009 4477 B213 4460 D009 4491 D009 4476 AF04 0601 D009 4492 AF04 0599 D009 4493 D009 4496 D009 4478 D009 4431 D009 4466 D009 4465 D009 4462 D009 4463

Description Exit Roller Upper Stay Transport Roller Bushing - M4 Discharge Brush - Exit Bushing - 6x10x6 Exit Guide Plate - Upper Driven Roller Shoulder Screw - M3 Front Side Plate Separation Plate - Paper Exit Lower Guide Plate - Exit Guide Roller Roller: Guide: PFA Driven Roller Shaft Roller: Auxiliary: Driven: DIA16: PFA Spring - Lower Guide Plate Bushing - Lower Guide Plate Lower Stay - Exit Spring - Exit Pressure Shaft: Pressure Roller Entrance Arm Spring - Entrance Pressure Pressure Roller: Entrance Exit Arm Pressure Roller: 15 Bracket - Point Spring Plate - Exit Roller Lower ing Plate Rear Side Plate Timing Belt - 30S2M172 Timing Pulley - 22T Gear - 22Z Gear/Pulley - 22Z/22T

D009/D011/D012/D013/D091/D092

Q’ty Per Assembly

Index No.

Part No.

1 1 1 1 1 3 1 3 3 1 1 1 1 1 1 1 2 2 1 1 2 1 1 1 1 1 1 1 1 1 1 1 1 1

101 102 103 104 105 106 107 108

0451 3006N 0353 0040N 0720 0025E 0720 0030E 0450 3008P 0805 0092 1105 0551 1105 0511

89

Q’ty Per Assembly

Description Tapping Screw - 3x6 Screw - M3x4 Retaining Ring - M2.5 Retaining Ring - M3 Tapping Screw 3x8 Retaining Ring - 3M Clamp: LES-0505 Harness Clamp - LWS-0306ZC


40.Drive Section 1 (D009/D011/D012/D013/D091/D092) 7

101

6

101 12

1

2

3

102

4 5

13 101 10 101

9

103

101

15

11

14

101

10

101

104

18

8

105 25 101 106

101 16

19

106 20 17

101

106

106

22

23

105

21

22

107 30 29 101

24

31

102

29

34

108 26

101

28

101 32

27 101 33

101

109

101 101

D009/D011/D012/D013/D091/D092

90


40.Drive Section 1 (D009/D011/D012/D013/D091/D092) Index No. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34

Part No. D009 1182 D009 1183 AA13 2208 AB01 4284 AB01 4283 AB01 4280 AB01 4281 D009 1090 D009 5620 AA14 3744 AB01 4282 D009 1171 AX06 0356 AW02 0150 D009 5500 D009 1193 D009 1187 AB01 1523 AB01 1524 AB01 1526 AB01 1525 AB01 1527 AB01 1528 D009 1194 D009 1195 AX04 0167 AX06 0355 D009 1161 AA08 0347 AB03 0815 AA04 3656 AB01 7743 D009 1158 D009 1164

Description t Cover t - Cleaning Spacer - M6 Gear - 24Z Gear - 24Z Gear - 26Z/90Z Gear - 40Z Connector Bracket - Fusing AC Harness - Fusing Stepped Screw Gear - 26Z/30Z Bracket - Fusing Drive Sub-Unit Brushless Motor: DC24V 18W Photointerruptor: Flat: 7mm Interface Harness - Web Sensor Sensor Bracket Bracket - Fusing Cleaning Drive Gear - 24Z Gear - 36Z Gear - 24Z Gear - 32Z Gear - 14Z/32Z Gear - 14Z/32Z Motor Holder Motor Bracket Motor: DC5V 0.71W Brushless Motor - DC 11W Bracket - Paddle Roller Drive Bushing - 8mm Timing Pulley - 24T Timing Belt - 60S3M177 Gear - 20Z Holder - Paddle Roller Drive Shaft - Paddle Roller Drive

D009/D011/D012/D013/D091/D092

Q’ty Per Assembly

Index No.

Part No.

1 1 1 1 1 1 1 1 1 2 1 1 1 1 1 1 1 1 1 1 1 2 1 1 1 1 1 1 2 1 1 1 1 1

101 102 103 104 105 106 107 108 109

0454 3006Q 0720 0060E 0957 4008N 0454 3008Q 0805 0089 1105 0511 1105 0522 1105 0487 1105 0613

91

Q’ty Per Assembly

Description Tapping Screw - M3x6 Retaining Ring - M6 Screw: Small Round/Spring: M4x8 Tapping Screw: 3x8 Retaining Ring - M4 Harness Clamp - LWS-0306ZC Edge Saddle - LES0510 Harness Clamp Clamp: EDS-1010L-V0


41.Drive Section 2 (D009/D011/D012/D013/D091/D092) 101 101

101

110

3

2

1

33 34

101 103 10 102

9

104

101 103

7 101

101

101

4

109

101

101

24

11 12

101

32 101

13

28 106

23

8

14 101

15

18

108 101

6 101

108

D009/D011/D012/D013/D091/D092

5

22

30

19 29

101 101

20

101

21

106 28

16 104

17

105

27

101 26

27

107

29

31

107

25

92


Rev. 03/23/2010

41.Drive Section 2 (D009/D011/D012/D013/D091/D092) Index No. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34

Part No. D009 5420 AZ32 0145 D009 5854 AX06 0354 AX06 0355 D009 1120 B242 1161 D009 1121 AB01 0379 D009 1113 D009 1123 AB01 7752 D009 1148 AB03 0821 AB01 0141 AB03 0820 AA14 5294 D009 1141 D009 1145 D009 1155 D009 1147 AA06 3432 D009 1111 D009 1139 AB01 0140 D009 1142 AA04 3658 D009 1127 D009 1128 D009 1135 D009 1125 B004 1936 D009 3831 D009 3832

Description Harness - High Voltage Cable Power Pack: CBT Bracket - Power Pack Brushless Motor - DC 6W Brushless Motor - DC 11W Rear Drive Bracket - Engine Ball Bearing - 8x22x7 Ground Plate - Drum Gear: Drum Drive Unit- Transfer On-Off Drive Bracket - Transfer Gear - 27TZ/42Z Collar - 6x18.8mm Pulley - 31T Gear - 46Z Pulley - 31T Parallel Pin - 2x12mm Ground Plate - Drum Drum Shaft Holder t - Development Sleeve: Ass’y Terminal - Development Roller Spring - Intermediate Drawer Drum Shaft Front Drive Bracket - Engine Gear - 90Z Pulley - 48T/90T Timing Belt - 60S2M300 Roller - Tightener Spring - Tightener Tightener Bracket - Development Tightener Bracket - Transfer Plate - Optical Housing Unit Receptacle Housing - Transfer Receptacle Terminal - Transfer

D009/D011/D012/D013/D091/D092

Q’ty Per Assembly

Index No.

Part No.

1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 2 2 2 1 1 2 1 2

101 102 103 104 105 106 107 108 109 110

0454 3006Q 1105 0367 0454 3020Q 0805 0088 0740 3808 0805 0089 0954 3010N 1105 0534 1105 0623 0451 3008N

93

Q’ty Per Assembly

Description Tapping Screw - M3x6 Spacer Tapping Screw: 3x20 Retaining Ring - M6 Ball Bearing - 8x16x5mm Retaining Ring - M4 Screw: Polished Round/Spring: M3x10 Clamp Clamp - LBWS-0206S-V0 Tapping Screw - M3x8


42.Drive Section 3 (D009/D011/D012/D013/D091/D092)

5

3 2

101

101

4

1

102 101

13 15

101

15 14

6 101 7

102 8 9 101

11 10

101 102 102 102

D009/D011/D012/D013/D091/D092

94

12


42.Drive Section 3 (D009/D011/D012/D013/D091/D092) Index No. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

Part No.

Description

B223 1350 Stepper Motor DC5.06V A232 4666 Cushion - Stepper Motor D009 1151 Bracket - Registration Drive Unit AB03 0744 Timing Pulley - 27Z/40T AA04 3601 Timing Belt - B40S2M118 B238 1089 Cover - Positioning Pin B238 2541 Tray Cover - Right AX04 0154 DC Motor 24V D009 5851 Bracket - IO Board B223 2721 Bracket: Push Switch AW50 0038 Push Switch: Paper Size Sensor B238 2543 Cover - Tray Left B238 1066 Rubber Foot Cover D009 5440 Harness - Development Drawer AA14 3579 Screw - M3

D009/D011/D012/D013/D091/D092

Q’ty Per Assembly

Index No.

1 1 1 1 1 1 2 2 1 1 1 1 1 1 2

101 102

95

Part No.

Description

Q’ty Per Assembly

0454 3006Q Tapping Screw - M3x6 0454 3008Q Tapping Screw: 3x8


43.Drive Section 4 (D009/D011/D012/D013/D091/D092) 26 17 18

1

108

3 107

102

24

20 102

101

2

4

102

23

3 101 107

102

25

101 19

101 9 7 8

21

102

22

10

6

102

5

11

6

12

5 13

14

102

102 13

105

101

104

102 15

106 103

D009/D011/D012/D013/D091/D092

96

16


43.Drive Section 4 (D009/D011/D012/D013/D091/D092) Index No. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26

Part No. B223 1189 B223 1183 B223 1186 B223 1354 AB01 7699 AB01 1258 AA04 3585 AB03 0781 AB01 1259 B223 1180 AX20 0289 B223 1187 AA08 0346 5447 2681 AA16 1164 B223 1188 B700 2649 AB01 7493 B223 2694 B044 1825 B223 2691 B223 2745 AA10 1021 AX31 0045 D009 1088 B223 5846

Description Feed Drive Shaft Grip Shaft Drive t Drum Stay: Drive Unit Gear - 33Z/44Z Gear - 38Z Timing Belt: 40S3M162 Timing Pulley - 28Z/30T Gear - 32Z Bracket: Paper Feed Magnetic Clutch - 32Z Magnetic Clutch Bracket Bushing: Flange Type: DIA6 Snap Ring Cushion: Stepper Motor Stepper Motor DC24V Timing Belt: 40S2M144 Gear Pulley Guide: Gear Collar Bracket: Stepper Motor Stepper Motor: Ass'y Rubber Bushing - 6 45HS Total Counter: 7FIG: 24V Grip Bracket - Right Rear Bracket: Total Counter

D009/D011/D012/D013/D091/D092

Q’ty Per Assembly 1 1 2 1 2 2 1 1 1 1 2 2 2 2 1 1 1 1 1 4 1 1 4 1 1 1

97

Index No.

Part No.

101 102 103 104 105 106 107 108

0451 3006N 0454 3006Q 0451 4008N 0805 0089 1105 0488 0434 0100N 0720 0040E 0353 0080N

Description

Q’ty Per Assembly

Tapping Screw - 3x6 Tapping Screw - M3x6 Tapping Screw: 4x8 Retaining Ring - M4 Harness Clamp Tapping Screw - 4x10 Retaining Ring - M4 Screw: M3x8


44.Electrical Section 1 (D009/D011/D012/D013/D091/D092) 3

1

102

6

4

22

5

2

105

102

102

101 7

101

102

8

101

19

9

20 101

12

101

101

11

103 21 101

16

12

18

12 12 14

102 102

D009/D011/D012/D013/D091/D092

105

13

17

12

10 11 104

11

15

22 102

98


Rev. 12/09/2011

44.Electrical Section 1 (D009/D011/D012/D013/D091/D092) Index No. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22

Part No. D009 5505 AX05 0329 B004 7667 D009 3210 A096 2065 D009 5481 AW50 0023 D009 4351 D009 3865 D009 2367 AA14 3579 B004 2310 A232 1284 D009 3866 D009 4350 B238 1119 B213 2362 D009 5510 AW01 0199 D009 3856 D009 3857 D009 4356

Description Harness - Toner Supply Motor DC Motor: Toner Bottle: Ass'y Holder: Toner Bottle: EU Guide - Toner Supply Slider Ring Interface Harness - IOB-Switch Push Switch Rear Lock Lever Holder - Density Sensor Density Sensor Screw - M3 Spur Spring Holder Guide - Separation/Transport Front Lock Lever Lever - Front Upper LED Array QL Ass'y Harness - Quenching Lamp Entrance Sensor Guide: Standard: Transfer Unit: Rear Guide: Standard: Transfer Unit: Front Washer: DIA3.5

D009/D011/D012/D013/D091/D092

Q’ty Per Assembly

Index No.

Part No.

1 1 1 1 1 1 1 1 1 1 4 4 1 1 1 1 1 1 1 1 1 2

101 102 103 104 105

0454 3008Q 0454 3008Q 0450 3010N 0451 3008N 0802 5299

99

Description

Q’ty Per Assembly

Tapping Screw: 3x8 Tapping Screw: 3x8 Tapping Screw - M3x10 Tapping Screw - M3x8 Tapping Screw - M3x8



107

101

1

101 3 101 2

5 4

105 16

106

108

17 15

102

18

104

104

102 14 12 104

101 11

12 13

7 6

10 8 9

102 7 102

D009/D011/D012/D013/D091/D092

103

20

102 19

103

100


45.Electrical Section 2 (D009/D011/D012/D013/D091/D092) Index No. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20

Part No. D009 1366 D009 1367 D009 1368 D009 1369 B223 1332 D009 5898 D009 5866 D009 5869 D009 5867 D009 5896 D009 5868 D009 5857 D009 5864 D009 5865 D009 5858 D009 5863 D009 5895 D009 5840 AX64 0194 D009 1371

Description Middle Exhaust Duct - Upper Middle Exhaust Duct - Lower Front Upper Duct Front Lower Duct Fan Motor - MM60 DC24V Harness Guide - Safety Switch Base - Right Safety Switch Right Lower Lever - Safety Switch Guide Plate - Safety Switch Spring - Right Safety Switch Right Lever - Safety Switch Shaft - Safety Switch Middle Lever - Safety Switch Cam - Safety Switch Left/Right Lever - Safety Switch Left Lever - Safety Switch Tension Spring: Safety Switch: Left Base - Left Safety Switch Fan Motor - DC 2.16W Exit Duct - MM60

D009/D011/D012/D013/D091/D092

Q’ty Per Assembly

Index No.

Part No.

1 1 1 1 1 1 1 1 1 1 1 2 1 1 1 1 1 1 1 1

101 102 103 104 105 106 107 108

0454 3008Q 0454 3006Q 0450 3008N 0805 0092 0451 3025N 1204 2521 1105 0487 1105 0534

101

Description

Q’ty Per Assembly

Tapping Screw: 3x8 Tapping Screw - M3x6 Tapping Screw - M3x8 Retaining Ring - 3M Tapping Screw: M3x25 Micro Switch Harness Clamp Clamp


46.Electrical Section 3 (D009/D011/D012/D013/D091/D092)

101

2

104 4 108

101

101 104 7

101

101

1 103

3

8

101 101

103

101

106 105

101 101

6

11 102

101

13 105

107

10

1

9

5

102

14

5

D009/D011/D012/D013/D091/D092

101 102

13

12 102

102


Rev. 12/2/2011

46.Electrical Section 3 (D009/D011/D012/D013/D091/D092) Index No. 1 2 3 4 5 5 6 7 8 9 10 11 12 13 14

Part No. AX64 0159 D009 1351 D009 1352 D009 5852 D009 1358 D009 1359 D009 5876 B238 1088 B223 1065 D009 5615 D009 5856 D009 1355 B223 5848 D009 2527 D009 1354

Description Fan Motor MM80 Upper Fusing Duct Lower Fusing Duct Connector Bracket Sponge: Duct: Exhaust: 1 Sponge: Duct: Exhaust: 2 Small Bracket - BICU Cover - Connector Connector Bracket AC Harness - Heater Bracket - Heater Connector Rear Exhaust Duct - Left Bracket: Base: Connector Cover - Electrical Components Rear Exhaust Duct - Right

D009/D011/D012/D013/D091/D092

Q’ty Per Assembly

Index No.

Part No.

2 1 1 1 2 2 1 1 1 1 1 1 1 2 1

101 102 103 104 105 106 107 108

0454 3006Q 0454 3008Q 1105 0488 1105 0489 1105 0487 1102 8534 1105 0522 1102 9782

103

Description

Q’ty Per Assembly

Tapping Screw - M3x6 Tapping Screw: 3x8 Harness Clamp Harness Clamp - LWS 1316 Harness Clamp Connector - QR/P17-14S-B Edge Saddle - LES0510 Connector: 51405-1819


Rev. 7/18/2011


101 8

101

108

101 1

24

3

101

101 4

101 5

101

101

101

101

110 21 101

101

101

6 7 101 104

23

25 15 105 101

107 109

109 101

22 104

11 9

10

101

101

106

111 112

111: 1st Paper Feed 112: 2nd Paper Feed

12

20 101

13 14 101

D009/D011/D012/D013/D091/D092

19

103

101

17 105

104

102

18

16


Rev. 7/18/2011

47.Electrical Section 4 (D009/D011/D012/D013/D091/D092) Index No. 1 1 2 3 4 5 6 6 6 6 6 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 21 22 23 24 25

Part No.

Description

Q’ty Per Assembly

Index No.

Part No.

D009 5540 D011 5530 B154 5879 D009 5465 D009 5470 D009 5877 D009 5166 D009 5167 D011 5166 D011 5167 D091 5156 D091 5157 D009 5461 D009 5875 D009 5480 D009 5495 D009 5486 D009 5521 D009 5490 D009 5155 D009 5851 D009 5602 D009 5855 D009 5431 D009 5425 D009 5435 AZ24 0139 AZ24 0141 D009 5605 D009 5610 D009 5853 D009 5842

Interface Cable - Scanner BW Interface Cable - Scanner Color Plate: Cable Harness - BICU-SIO Harness - BICU-IDB Guide - Mother Board BICU - MS - 50M (D012) PCB: BICU - MS - 40M (D009) PCB: BICU: FCS: 50 M (D013) [TSB#045] PCB: BICU: FCS: 40 M (D011) [TSB#045] PCB: BICU: FCS 50M (D092) PCB: BICU: FCS 40M (D091) DC Harness - BICU-IOB Bracket - BICU Harness - IOB Upper Harness - IOB-Lift Motor DC Harness-IOB Lower DC Harness - IOB-Motor Harness - IOB Lower Behind IO Board Bracket - IO Board Harness: AC: Inlet Bracket - Inlet DC Harness-DC Power Supply-IOB Harness - Safety Switch Harness - PSU-SIO Power Supply Unit - 120V Power Supply Unit - 230V AC Harness - Switch AC Harness - Heater Bracket - Main Switch Grounding Plate - BICU

1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1

101 102 103 104 105 106 107 108 109 110 111 112

0454 3006Q 0451 3006N 0957 4008N 1105 0487 1105 0489 1105 0367 1102 8502 1204 2608 0451 3008N 1407 6362 1102 6257 1102 6271

D009/D011/D012/D013/D091/D092

105

Q’ty Per Assembly

Description Tapping Screw - M3x6 Tapping Screw - 3x6 Screw: Small Round/Spring: M4x8 Harness Clamp Harness Clamp - LWS 1316 Spacer Connector - 54679-1615 Rocker Switch: SDDJE33900 Tapping Screw - M3x8 EEPROM: BR24I64-W Relay Connector – 14P Connector: 53358-1442

1 1


48.Electrical Section 5 (D009/D011/D012/D013/D091/D092)

104 104 104

1

107

4

28 3

101

102

104 104

104

2 103 9

102 101

104

10 104

23

104

7

15 108

19 104

101

101

101

101

20 21

101

25

18

26 27

24 12

106 106 11 101

16

101

17 16

101

17 14

105

6 5 101

22

29

101

101 101

101 104

CS

D009/D011/D012/D013/D091/D092

8

13

106

101


Rev. 12/09/2011

48.Electrical Section 5 (D009/D011/D012/D013/D091/D092) Index No. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 19 19 19 19 19 20 21 22 23 24 25 26 27 28 29

Part No. D009 5879 D009 5182 D009 5881 D009 5880 B154 5869 D011 5884 D009 5872 D009 5874 D009 5844 D009 5870 M080 5320 D362 1140 D362 5131 D362 5132 D009 5480 AA16 1167 AA14 3848 D362 5170 D012 5733 D012 5734 D013 5733 D013 5734 D092 5714 D092 5724 D009 5899 D009 5891 B585 5140 D009 9593 B154 5861 AX64 0195 B154 5865 B129 5008 D009 5886 D092 5830

Description Bracket - Mother Board Mother Board Guide - Fax Control Unit Bracket - Control Board : Interface: SECC Cover - SD-Card Large Cover - Fax Control Unit Grip - C/T Box Fixing Plate - Controller Board Upper grip - Controller Box HDD: 160GB: MK1676GSX HDD Bracket Cable - HDD Power Harness - HDD Harness - IOB Upper Rubber Cushion Stepped Screw - M3 PCB - HDD Controller: PCB for D012 [TSB#050] Controller: PCB for D009 [TSB#050] Controller: PCB for D013 [TSB#050] Controller: PCB for D011 [TSB#050] PCB: CTL: 50 (D092) PCB: CTL: 40 (D091) Right Rail - Small Left Rail - Fax Control Unit PCB: DDR1-DIMM-32D: 512MB: Ass'y NVRAM Guard: Fan Fan Motor - DC 2.16W Cap: Connector: USB Cap - LAN Connector Ground Plate- C/T Box SD-Card: VM: EXP: Ass'y

D009/D011/D012/D013/D091/D092

Q’ty Per Assembly 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 2 2 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1

107

Index No.

Part No.

101 102 103 104 105 106 107 108

0360 3006N 0451 3006N 0452 3008N 0454 3006Q 0353 0060N 0360 3030N 1105 0487 1102 6246

Description

Q’ty Per Assembly

Screw - M3x6 Tapping Screw - 3x6 Tapping Screw - M3x8 Tapping Screw - M3x6 Bind Screw - M3x6 Screw: M3x30 Harness Clamp Relay Connector - 4P


49.Frame Section (D009/D011/D012/D013/D091/D092)

1

5

101 2

101 3 4

101

101

101

103

101

101

101

101

101 16

18

101

7

101 15

6

101

104 101

19

103

7 20

19

13 11

105

7

14

17 101 106

15

12

101

101 102

Optin

D009/D011/D012/D013/D091/D092

10

9

108

8

102


49.Frame Section (D009/D011/D012/D013/D091/D092) Index No. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 17 18 18 19 20

Part No. B223 2710 D009 5475 B223 2715 B223 2714 AA16 1163 B223 4524 B101 1097 D009 4595 D009 4594 AA14 3404 D009 4512 B223 1120 B223 1245 B223 1101 B223 1102 D009 1093 B223 2702 B223 2703 B237 1355 B237 1372 D009 4513 D009 4511

Description er - Left No.2 Interface Harness - BICU-LDB er - Right Positioning Cap - Short Cushion Wire: Stopper: DIA1.5 Rubber Foot: H5 Rear Guide - Duplex Unit Set Front Guide - Duplex Unit Set Stepped Screw - M4 Link: Stopper Bracket: Paper Feed Unit Cap: Grip Grip: Front Bracket: Grip: Right Front Stopper Bracket - Grip Heat Sink: Heater: NA Heat Sink: Heater: EU Decal - Main Switch EU OP Decal - Main Switch On-Standby Compression Spring: Earth: Duplex Unit Spacer: DIA8.0: 1.5mm

D009/D011/D012/D013/D091/D092

Q’ty Per Assembly

Index No.

Part No.

1 1 1 1 1 1 6 1 1 1 1 1 1 1 1 1 1 1 1 1 2 1

101 102 103 104 105 106

0454 3006Q 0451 3008N 0805 0088 0802 5305 1105 0522 0802 5299

109

Description

Q’ty Per Assembly

Tapping Screw - M3x6 Tapping Screw - M3x8 Retaining Ring - M6 Tapping Screw - M3x6 Edge Saddle - LES0510 Tapping Screw - M3x8


50.Controller Board (D009/D011/D012/D013/D091/D092)

BAT SYMBOL NO. BAT1

CAPACITOR INDEX NO. 114

SYMBOL NO. ------C4 C5

INDEX NO. ------195 193

SYMBOL NO. C11 C12 C13 C14 ---

INDEX NO. 195 198 182 218 ---

SYMBOL NO. C21 --C23 C24 C25

INDEX NO. 195 --195 182 193

SYMBOL NO. C31 C32 C33 -----

INDEX NO. 193 180 212 -----

SYMBOL NO. C41 C42 C43 C44 C45

INDEX NO. 186 188 209 194 186

SYMBOL NO.

INDEX NO.

C51 C52 --C54 C55

195 195 --195 195

C6 C7 C8 C9 C10

186 189 183 186 212

--C17 --C19 C20

--195 --195 198

--C27 C28 C29 C30

--181 181 193 218

------C39 ---

------180 ---

C46 C47 C48 C49 C50

195 213 192 218 182

C56 C57 C58 C59 C60

182 195 195 195 195

CAPACITOR SYMBOL NO. C61 C62 C63 C64 ---

INDEX NO. 192 208 208 189 ---


INDEX NO. 188 197 189 195 195

SYMBOL NO. C81 ----C84 C85

INDEX NO. 185 ----192 205


INDEX NO. 189 193 195 189 189

SYMBOL NO. --C102 C103 C104 ---

INDEX NO. --186 189 184 ---

SYMBOL NO. C111 C112 C113 C114 C115

INDEX NO. 183 205 205 195 189

SYMBOL NO. C121 C122 C123 C124 C125

INDEX NO. 182 211 195 179 195

C66 C67 C68 C69 C70

195 205 195 205 200

C76 C77 C78 C79 C80

215 195 189 195 192

C86 C87 C88 C89 C90

192 192 200 198 192

C96 C97 C98 C99 ---

195 189 182 195 ---

--C107 C108 C109 C110

--182 189 192 205

C116 C117 C118 C119 C120

195 210 188 218 189

C126 C127 C128 C129 C130

195 195 195 183 201

D009/D011/D012/D013/D091/D092

110



CAPACITOR SYMBOL NO. C131 C132 C133 C134 ---

INDEX NO. 189 192 198 182 ---

SYMBOL NO. C141 C142 C143 C144 C145

INDEX NO. 201 201 189 193 189

SYMBOL NO. C151 C152 --C154 ---

INDEX NO. 179 189 --192 ---

SYMBOL NO. C161 C162 C163 C164 C165

INDEX NO. 195 195 208 189 212

SYMBOL NO. C171 C172 C173 --C175

INDEX NO. 195 195 207 --189

SYMBOL NO. C181 C182 C183 C184 C185

INDEX NO. 195 207 189 189 195

SYMBOL NO.

INDEX NO.

C191 C192 C193 C194 C195

198 198 189 205 193

C136 C137 C138 C139 C140

192 201 218 201 201

C146 C147 C148 --C150

189 193 179 --189

C156 C157 --C159 C160

207 189 --195 195

--C167 --C169 C170

--212 --195 205

C176 C177 C178 C179 C180

195 195 187 195 195

C186 C187 C188 C189 C190

192 192 189 195 195

C196 C197 C198 C199 C200

189 187 195 193 188

CAPACITOR SYMBOL NO. C201 C202 C203 C204 C205

INDEX NO. 187 189 193 189 208

SYMBOL NO. C211 C212 C213 C214 C215

INDEX NO. 208 195 198 193 193

SYMBOL NO. C221 C222 C223 C224 C225

INDEX NO. 205 193 187 189 205

SYMBOL NO. C231 C232 C233 C234 C235

INDEX NO. 193 187 203 195 189

SYMBOL NO. C241 C242 C243 C244 C245

INDEX NO. 195 192 195 195 189

SYMBOL NO. C251 C252 C253 C254 C255

INDEX NO. 188 195 195 192 189

SYMBOL NO. C261 C262 C263 C264 C265

INDEX NO. 189 192 192 192 189

C206 C207 C208 C209 C210

189 192 205 187 187

C216 C217 C218 C219 C220

187 208 213 189 195

C226 C227 C228 C229 C230

193 189 206 193 193

C236 C237 C238 C239 C240

187 192 211 195 195

--C247 C248 C249 C250

--314 195 195 205

C256 C257 C258 C259 C260

195 195 187 189 189

C266 --C268 C269 C270

195 --192 192 189

D009/D011/D012/D013/D091/D092

111




INDEX NO. 192 189 189 189 192

SYMBOL NO. C281 C282 C283 --C285

INDEX NO. 195 195 205 --213

SYMBOL NO. C291 C292 C293 C294 C295

INDEX NO. 192 195 205 184 189

SYMBOL NO. C301 C302 C303 C304 C305

INDEX NO. 189 199 189 199 189

SYMBOL NO. C311 C312 C313 C314 C315

INDEX NO. 192 192 192 192 192

SYMBOL NO. C321 C322 C323 C324 C325

INDEX NO. 205 189 192 192 205

SYMBOL NO.

INDEX NO.

C331 C332 C333 C334 C335

195 189 205 205 193

C276 C276 C277 C279 C280

189 195 189 189 192

C286 C287 C288 C289 C290

195 189 192 189 192

C296 C297 C298 C299 C300

192 189 199 189 199

C306 C307 C308 C309 C310

189 189 189 192 213

C316 C317 C318 C319 C320

192 189 211 195 189

C326 C327 C328 C329 C330

192 208 213 193 195

C336 C337 C338 C339 C340

189 187 187 193 198


INDEX NO. 189 195 189 189 192

SYMBOL NO. C351 --C353 C354 C355

INDEX NO. 203 --189 189 192

SYMBOL NO. C361 C362 C363 C364 C365

INDEX NO. 195 189 192 192 195

SYMBOL NO. C371 C372 C373 C374 C375

INDEX NO. 195 195 195 189 192

SYMBOL NO. C381 C382 C383 C384 C385

INDEX NO. 189 192 192 192 189

SYMBOL NO. C391 C392 C393 C394 C395

INDEX NO. 192 212 189 192 192

SYMBOL NO. C401 C402 C403 -----

INDEX NO. 212 212 212 -----

C346 C347 C348 C349 C350

205 192 213 195 189

C356 C357 C358 C359 C360

189 188 208 192 195

C366 C367 C368 C369 C370

195 213 213 205 189

C376 C377 C378 C379 C380

192 192 189 213 189

C386 C387 C388 C389 C390

192 189 192 189 189

C396 C397 -------

187 187 -------

C406 C407 C408 C409 C410

195 189 192 192 212

D009/D011/D012/D013/D091/D092

112




INDEX NO. 198 212 198 212 214

SYMBOL NO. C421 C422 C423 C424 C425

INDEX NO. 189 187 213 212 192

SYMBOL NO. C431 C432 C433 C434 C435

INDEX NO. 205 212 212 212 212

SYMBOL NO. C441 C442 C443 C444 C445

INDEX NO. 195 189 187 195 189

SYMBOL NO. C451 C452 C453 C454 C455

INDEX NO. 195 195 195 192 188

SYMBOL NO. C461 C462 C463 C464 ---

INDEX NO. 189 195 189 192 ---

SYMBOL NO.

INDEX NO.

C471 C472 C473 C474 C475

192 192 195 195 192

C416 C417 C418 C419 C420

205 198 195 195 195

C426 C427 C428 C429 C430

198 189 198 212 212

C436 C437 C438 C439 C440

212 195 195 195 189

C446 C447 C448 C449 C450

195 195 205 195 204

C456 C457 C458 C459 C460

189 189 195 189 195

C466 C467 --C469 C470

195 189 --205 213

C476 C477 C478 C479 ---

189 192 189 191 ---

CAPACITOR SYMBOL NO. C481 C482 --C484 C485

INDEX NO. 195 201 --213 192

SYMBOL NO. C491 C492 C493 C494 C495

INDEX NO. 192 198 195 188 189

SYMBOL NO. C501 C502 C503 C504 C505

INDEX NO. 203 189 192 195 189

SYMBOL NO. C511 C512 C513 C514 C515

INDEX NO. 195 192 216 211 314

SYMBOL NO. C521 C522 C523 C524 C525

INDEX NO. 211 192 189 190 189

SYMBOL NO. C531 C532 C533 C534 C535

INDEX NO. 186 186 189 189 192

SYMBOL NO. C541 C542 C543 C544 C545

INDEX NO. 310 310 309 308 189

C486 C487 C488 C489 C490

189 195 192 201 189

C496 C497 C498 C499 C500

212 188 189 192 178

C506 C507 C508 C509 C510

192 185 201 189 192

C516 C517 C518 C519 C520

314 189 195 195 189

C526 C527 C528 C529 C530

216 192 192 192 186

C536 C537 C538 C539 C540

192 192 201 308 309

C546 C547 C548 C549 C550

192 213 182 183 308

D009/D011/D012/D013/D091/D092

113




INDEX NO. 309 310 310 309 308

SYMBOL NO. C561 --C563 C564 C565

INDEX NO. 310 --211 310 309

SYMBOL NO. C571 C572 C573 C574 C575

INDEX NO. 308 309 310 310 309

SYMBOL NO. ----C583 C584 C585

INDEX NO. ----202 179 201

SYMBOL NO. C591 C592 C593 C594 C595

INDEX NO. 196 205 195 189 194

SYMBOL NO. C601 --C603 C604 C605

INDEX NO. 314 --213 217 189

SYMBOL NO.

INDEX NO.

C611 C612 C613 C614 C615

189 189 189 212 189

C556 C557 C558 C559 C560

183 213 183 308 309

C566 C567 C568 C569 C570

308 201 201 201 195

C576 C577 C578 -----

308 179 195 -----

C586 C587 C588 C589 C590

195 195 195 195 195

C596 C597 C598 C599 C600

192 189 205 205 203

C606 C607 C608 C609 C610

198 192 205 208 195

C616 C617 C618 C619 C620

189 195 195 195 217

SYMBOL NO. FIL1 FIL2 FIL3 FIL4 FIL5

INDEX NO. 220 220 221 226 226


INDEX NO. 222 222 219 219 219

FIL6 FIL7 FIL8 FIL9 FIL10

225 219 221 221 221

FIL16 FIL17

222 225

CAPACITOR SYMBOL NO. C621 C622 --C624

INDEX NO. 192 203 --192

CONNECTOR SYMBOL NO. CN701 CN702 CN703 --CN705

INDEX NO. 101 109 105 --106

CN706 CN707 CN708 CN709 CN710

106 107 104 108 103

D009/D011/D012/D013/D091/D092

FIL

DIODE SYMBOL NO. CN711

INDEX NO. 102

SYMBOL NO. D1 D2 D3 D4 D5

INDEX NO. 124 124 124 123 122

--D7 D8 D9 D10

--122 125 122 122

114

SYMBOL NO. D11

INDEX NO. 122



FUSE SYMBOL NO. FU1 FU2 FU3

IC INDEX NO. 112 110 111

SYMBOL NO. IC1 IC2 IC3 IC4 IC5

INDEX NO. 148 156 313 143 161

SYMBOL NO. ----IC13 IC14 ---

INDEX NO. ----141 133 ---


INDEX NO. 144 163 152 130 147

SYMBOL NO. IC31 --IC33 IC34 IC35

INDEX NO. 317 --135 135 313


INDEX NO. 313 134 137 135 312

SYMBOL NO.

INDEX NO.

IC51 IC52 --IC54 IC55

154 151 --135 152

IC6 IC7 IC8 IC9 IC10

146 145 313 154 164

--IC17 IC18 IC19 IC20

--165 149 142 153

IC26 IC27 -------

147 136 -------

--IC37 ----IC40

--150 ----140

IC46 ----IC49 IC50

155 ----159 151

IC56 IC57 --IC59 IC60

152 157 --151 152

SYMBOL NO. Q1 Q2 Q3 Q4 Q5

INDEX NO. 118 118 121 120 121

Q6 --Q8 Q9 Q10

120 --116 117 121

IC

L


INDEX NO. 139 158 132 131 157

SYMBOL NO. IC71 IC72 IC73 IC74 ---

INDEX NO. 151 157 136 157 ---


152 138 137 162 160

IC76 ---------

133 ---------

D009/D011/D012/D013/D091/D092

SYMBOL NO. --------IC135

INDEX NO. --------311

LED

SYMBOL NO. L1 L2 L3 L4 L5

INDEX NO. 227 227 224 228 228

L6 L7

229 223

115

SYMBOL NO. LED1 LED2 LED3 LED58

OSC INDEX NO. 128 127 126 129

SYMBOL NO. OSC1 OSC2 OSC3 OSC4 OSC5

Q INDEX NO. 167 166 169 168 170



Q

RESISTOR

SYMBOL NO. Q11 Q12 --Q14 Q15

INDEX NO. 115 115 --119 119

SYMBOL NO. R1 R2 R3 R4 R5

INDEX NO. 242 242 289 242 242

SYMBOL NO. R11 R12 R13 --R15

INDEX NO. 274 242 299 --277


INDEX NO. 288 300 277 300 298


INDEX NO. 277 261 267 273 289


INDEX NO. 294 294 261 249 249

SYMBOL NO.

INDEX NO.

R51 R52 R53 R54 R55

278 270 249 261 303

R6 R7 R8 R9 R10

242 289 274 293 269

R16 R17 R18 R19 R20

272 242 259 288 300

R26 R27 R28 R29 R30

277 290 298 300 259

R36 R37 R38 -----

278 278 284 -----

R46 R47 R48 R49 R50

278 293 278 259 293

R56 R57 R58 R59 R60

298 270 249 290 278

RESISTOR SYMBOL NO. R61 R62 R62 R64 R65

INDEX NO. 270 249 278 259 270

SYMBOL NO. R71 R72 R73 R74 ---

INDEX NO. 270 277 298 274 ---


INDEX NO. 261 261 259 298 278

SYMBOL NO. R91 --R93 R94 R95

INDEX NO. 279 --290 278 305

SYMBOL NO. R101 R102 R103 R104 ---

INDEX NO. 256 285 290 259 ---

SYMBOL NO. R111 R112 R113 -----

INDEX NO. 290 274 277 -----

SYMBOL NO. R121 --R123 R124 R125

INDEX NO. 298 --279 278 247

R66 R67 R68 R69 R70

243 270 259 290 243

R76 R77 R78 R79 R80

298 289 289 278 305

R86 R87 R88 R89 R90

290 278 290 278 290

R96 R97 R98 R99 R100

292 278 291 290 278

R106 --R108 R109 R110

305 --261 298 290

R116 R117 R118 R119 R120

298 298 279 248 286

R126 R127 R128 R129 R130

259 253 298 290 278

D009/D011/D012/D013/D091/D092

116




INDEX NO. 248 277 277 277 306

SYMBOL NO. R141 R142 --R144 R145

INDEX NO. 248 249 --274 248

SYMBOL NO. R151 --R153 R154 R155

INDEX NO. 278 --278 277 277

SYMBOL NO. R161 --R163 R164 R165

INDEX NO. 259 --290 297 259

SYMBOL NO. R171 R172 R173 R174 ---

INDEX NO. 290 290 290 290 ---

SYMBOL NO. R181 R182 R183 R184 R185

INDEX NO. 259 249 249 290 259

SYMBOL NO.

INDEX NO.

R191 ----R194 ---

242 ----249 ---

R136 R137 R138 --R140

306 290 255 --255

--R147 R148 R149 R150

--249 295 261 290

R156 R157 R158 R159 R160

277 255 255 304 248

R166 R167 R168 R169 R170

258 259 259 274 290

R176 R177 R178 R179 R180

252 296 248 249 290

R186 ----R189 R190

248 ----248 296

--R197 R198 -----

--280 249 -----

RESISTOR SYMBOL NO. R201 --R203 R204 ---

INDEX NO. 248 --258 259 ---

SYMBOL NO. R211 R212 R213 R214 ---

INDEX NO. 249 250 238 238 ---

SYMBOL NO. --R222 R223 -----

INDEX NO. --315 249 -----

SYMBOL NO. R231 R232 R233 R234 R235

INDEX NO. 315 248 248 301 243

SYMBOL NO. R241 R242 R243 R244 R245

INDEX NO. 259 242 316 315 315

SYMBOL NO. R251 R252 R253 R254 R255

INDEX NO. 249 249 250 248 259

SYMBOL NO. R261 R262 R263 --R265

INDEX NO. 259 268 275 --259

--R207 R208 R209 R210

--248 285 249 247

R216 --R218 -----

250 --250 -----

R226 R227 R228 --R230

248 302 315 --315

R236 R237 R238 R239 R240

315 315 249 259 259

R246 R247 R248 -----

243 315 259 -----

R256 R257 R258 R259 R260

318 249 259 274 274

R266 R267 R268 --R270

249 259 249 --249

D009/D011/D012/D013/D091/D092

117




INDEX NO. 249 275 274 259 249

SYMBOL NO. --R282 R283 R284 R285

INDEX NO. --243 268 249 248

SYMBOL NO. R291 R292 R293 R294 R295

INDEX NO. 252 242 247 252 249

SYMBOL NO. R301 R302 R303 R304 R305

INDEX NO. 249 259 259 259 259

SYMBOL NO. R311 R312 --R314 ---

INDEX NO. 259 242 --249 ---

SYMBOL NO. R321 R322 R323 R324 R325

INDEX NO. 242 247 259 259 249

SYMBOL NO.

INDEX NO.

R331 --R333 --R335

242 --289 --284

R276 R277 --R279 ---

268 249 --259 ---

--R287 R288 R289 R290

--274 274 248 242

--R297 R298 -----

--249 249 -----

R306 R307 R308 R309 R310

259 249 249 259 259

--R317 R318 R319 R320

--249 263 242 242

--R327 R328 R329 ---

--249 249 249 ---

--R337 --R339 ---

--242 --289 ---

RESISTOR SYMBOL NO. --R342 -------

INDEX NO. --247 -------

SYMBOL NO. -----------

INDEX NO. -----------

SYMBOL NO. R361 --R363 R364 R365

INDEX NO. 249 --261 242 242

SYMBOL NO. R371 R372 R373 R374 R375

INDEX NO. 257 289 259 259 290

SYMBOL NO. R381 R382 R383 --R385

INDEX NO. 259 279 279 --296

SYMBOL NO. R391 R392 R393 R394 R395

INDEX NO. 296 243 278 283 305

SYMBOL NO. R401 R402 R403 R404 R405

INDEX NO. 298 243 298 278 278

R346 --R348 -----

277 --298 -----

--R357 R358 R359 ---

--261 261 290 ---

----R368 R369 ---

----247 249 ---

R376 R377 R378 R379 R380

281 289 289 289 289

R386 R387 R388 R389 R390

279 279 278 305 296

R396 R397 R398 R399 ---

305 243 278 278 ---

R406 --R408 R409 R410

251 --243 278 278

D009/D011/D012/D013/D091/D092

118




INDEX NO. 251 240 239 278 247

SYMBOL NO. R421 --R423 R424 ---

INDEX NO. 290 --296 305 ---

SYMBOL NO. --R432 R433 R434 R435

INDEX NO. --290 278 290 278

SYMBOL NO. R441 R442 --R444 R445

INDEX NO. 278 274 --278 278

SYMBOL NO. R451 R452 R453 -----

INDEX NO. 248 259 305 -----

SYMBOL NO. R461 R462 R463 R464 ---

INDEX NO. 278 290 249 249 ---

SYMBOL NO.

--R417 R418 R419 R420

--278 296 305 278

R426 R427 R428 R429 R430

290 305 260 274 274

R436 R437 R438 R439 R440

260 278 282 259 278

R446 R447 R448 --R450

290 277 240 --278

--R457 R458 --R460

--248 241 --278

----R468 R469 R470

----278 259 249

--R477 R478 R479 R480

--278 259 259 248

-----------

INDEX NO. -----------

RESISTOR SYMBOL NO. R481 R482 R483 R484 ---

INDEX NO. 249 248 249 277 ---

SYMBOL NO. R491 R492 R493 --R495

INDEX NO. 287 274 274 --278

SYMBOL NO. R501 R502 --R504 ---

INDEX NO. 296 296 --249 ---

SYMBOL NO. ----R513 R514 ---

INDEX NO. ----248 242 ---

SYMBOL NO. R521 --R523 R524 ---

INDEX NO. 255 --248 249 ---

SYMBOL NO. R531 R532 R533 R534 R535

INDEX NO. 279 248 277 277 279

SYMBOL NO. R541 R542 R543 R544 R545

INDEX NO. 290 290 255 255 248

--R487 R488 R489 R490

--259 278 249 259

R496 R497 R498 R499 R500

296 259 274 278 279

R506 --R508 R509 R510

249 --242 278 279

--R517 R518 R519 ---

--249 296 255 ---

R526 R527 R528 R529 ---

247 255 249 248 ---

R536 R537 R538 R539 R540

259 290 277 259 290

R546 R547 R548 R549 R550

290 290 255 247 259

D009/D011/D012/D013/D091/D092

119




INDEX NO. 259 259 290 259 254

SYMBOL NO. --R562 R563 --R565

INDEX NO. --290 259 --290

SYMBOL NO. R571 R572 R573 -----

INDEX NO. 247 260 261 -----

SYMBOL NO. R581 R582 R583 --R585

INDEX NO. 265 265 265 --260

SYMBOL NO. R591 R592 R593 R594 R595

INDEX NO. 261 261 249 261 244

SYMBOL NO. R601 R602 R603 R604 ---

INDEX NO. 259 289 289 289 ---

SYMBOL NO.

INDEX NO.

--R612 R613 R614 ---

--259 262 262 ---

R556 --R558 R559 R560

249 --255 254 254

R566 R567 --R569 R570

252 252 --249 290

R576 R577 R578 R579 R580

248 248 265 265 265

R586 R587 R588 R589 ---

260 289 262 274 ---

R596 R597 --R599 R600

246 246 --245 258

R606 ----R609 ---

249 ----307 ---

R616 --R618 R619 R620

259 --262 289 262


INDEX NO. 289 248 248 248 249

SYMBOL NO. R631 --R633 R634 ---

INDEX NO. 249 --259 260 ---

SYMBOL NO. R641 R642 R643 R644 R645

INDEX NO. 259 261 279 264 262

SYMBOL NO. R651 R652 -------

INDEX NO. 274 261 -------

SYMBOL NO. R661 R662 --R664 R665

INDEX NO. 259 293 --261 274

SYMBOL NO. R671 R672 ----R675

INDEX NO. 259 259 ----290

SYMBOL NO. R681 --R683 R684 ---

INDEX NO. 242 --243 243 ---

----R628 R629 R630

----278 249 249

R636 R637 R638 --R640

259 259 259 --259

R646 R647 --R649 R650

293 289 --274 274

R656 R657 ----R660

249 276 ----259

--R667 R668 R669 R670

--278 259 259 259

R676 R677 R678 R679 ---

290 277 249 290 ---

--R687 R688 R689 R690

--259 259 243 243

D009/D011/D012/D013/D091/D092

120



RESISTOR SYMBOL NO.

INDEX NO.

R771

293

INDEX NO. 174 231 237 237 230

SYMBOL NO. --RN62 --RN64 RN65

INDEX NO. --171 --237 236

234 --171 --234

RN66 RN67 RN68 RN69 RN70

230 237 177 231 230

SYMBOL NO. R691 R692 R693 R694 R695

INDEX NO. 243 266 242 243 242

SYMBOL NO. ------R704 R705

INDEX NO. ------271 274

SYMBOL NO. R711 ----R714 ---

INDEX NO. 255 ----242 ---

SYMBOL NO. R721 R722 ----R725

INDEX NO. 255 255 ----255

SYMBOL NO. ------R734 ---

INDEX NO. ------274 ---

SYMBOL NO. --------R765

INDEX NO. --------259

--R697 R698 R699 R700

--243 243 255 242

----R708 R709 R710

----277 274 249

--R717 ----R720

--242 ----255

R726 ---------

274 ---------

------R739 ---

------242 ---

R766 ------R770

259 ------293

SYMBOL NO. RN1 RN2 RN3 RN4 RN5

INDEX NO. 173 232 171 175 230


INDEX NO. 234 232 234 236 174


INDEX NO. 173 231 176 235 173


INDEX NO. 230 230 230 233 231


INDEX NO. 233 232 231 175 171



171 173 235 235 234


172 236 232 235 231


233 231 173 233 230


171 233 233 171 231

RN46 RN47 RN48 --RN50

171 171 231 --233

RN56 --RN58 --RN60

RN

D009/D011/D012/D013/D091/D092

121



RN

SW


INDEX NO. 236 233 230 177 173

RN76 --RN78 RN79 RN80

236 --236 231 230

SYMBOL NO. RN81

D009/D011/D012/D013/D091/D092

INDEX NO. 176

SYMBOL NO. --SW2

INDEX NO. --113

122


Rev. 02/02/2011

50.Controller Board (D009/D011/D012/D013/D091/D092) Index No. * * * * * *

Part No. D012 5733 D012 5734 D013 5733 D013 5734 D092 5714 D092 5724

Description Controller: PCB for D012 [TSB#050] Controller: PCB for D009 [TSB#050] Controller: PCB for D013 [TSB#050] Controller: PCB for D011 [TSB#050] PCB: CTL: 50 (D092) PCB: CTL: 40 (D091)

D009/D011/D012/D013/D091/D092

Q’ty Per Assembly

Index No.

Part No.

1 1 1 1 1 1

101 102 103 104 105 106 107 108 109 110 111 112 113 114 115 116 117 118 119 120 121 122 123 124 125 126 127 128 129 130 131 132 133 134 135

1102 6790 1102 7615 1102 8212 1102 8329 1103 4234 1102 9336 1102 9890 1102 9956 1103 4043 1107 1083 1107 1099 1109 0009 1204 2791 1206 0124 1401 1318 1401 1414 1401 1415 1401 1448 1401 1457 1401 1466 1401 1475 1402 1336 1402 1365 1402 1929 1402 2039 1403 0953 1403 0978 1403 1131 1407 4919 1407 5009 1407 5010 1407 5190 1407 5192 1407 5300 1407 5351

123

Q’ty Per Assembly

Description Connector - 100R-LT-N1 Connector - B8B-XH-A Connector: TX24-50R-10ST-H1E Connector - USB - UBB-4R-D14C RHM-176P-SDK11-UH1L1C(LF)(SN) Connector: FPS009-2300-0 Connector: 5-1605706-2 Connector: UBA-4R-D14T-4D(LF)(SN) Connector: 87825-1001 Fuse: SST 4 Fuse SST 5 IC - MINISMDC075-02 DIP Switch: DM-04-V Lithium Cell: CR2032VO4H/Z FET - HAT2198R FET: Si3433BDV-E3 FET: SI3434DV-E3 FET: SI3447BDV-E3 FET: TP8102 FET: SI4800BDY-E3 FET: SI3867DV-E3 Diode - 1SS355 Diode-RB751V-40 Diode: RB160M-30 Diode: RSX301LA-30 LED - SML-310MT LED - SML-310DT LED: SML-311UT IC - 74VHCT244 TSSOP CMOS Logic: TC7SET04FU IC - TC7SET08FU CMOS Logic: TC7SZ08FU CMOS Logic: TC7SZ04FU CMOS Logic - 74LVC16244A TSSOP IC - SN74LV14APW


Rev. 09/07/2010 Index No.

Part No.

136 137 138 139 140 141 142 143 144 145 146 147 148 149 150 151 152 153 154 155 156 157 158 159 160 161 162 163 164 165 166 167 168 169 170

1407 5482 1407 5520 1407 5523 1407 5528 1407 5604 1407 6145 1407 6265 1407 6386 1407 6400 1407 6671 1407 6723 1104 0821 1407 6741 1407 6751 1407 6801 1407 6803 1407 6853 1407 6863 1407 6898 1407 6899 1407 6944 1407 6951 1408 1826 1408 2053 1408 2062 1408 2087 1408 2180 1408 2449 1408 2463 1408 2484 1503 1138 1503 1355 1503 1362 1503 1363 1503 1379

Description

Q’ty Per Assembly

IC - SN74LVC07APW CMOS Logic: SN74LVC125APW ROM - I2C SOP 3V IC - SN74LVC126APW CMOS Logic: SN74LVC16245ADGG IC: SN74LVC373APW Real Time Clock: R2025S U: RM7035C-533L-REV1.1 Clock Generator - ICS960013BFLF USB Controller: UPD720102GC-YEB-A Custom IC: Cornet IC Socket: 16008-B0A0020N LAN Controller LSI: DP83848JSQ/NOPB CMOS Logic: HD74LV1GW07ACM CMOS Logic: TC7PA17FU CMOS Logic: TC7SZ07FU CMOS Logic: HD74LV1GW17ACM Controller: ST19WP18FT28PVGI CMOS Logic: TC7WH126FK CMOS Logic: TC7WH125FK USB Controller IC: ST72681/R21 CMOS Logic: TC7MBL3245SFK IC - R3112Q421A IC: R3112Q291A-FA IC: R3112Q221A-FA IC: LTC3736EUF#TRPBF IC - BD3531F DC/DC Converter: BD9104FVM DDR Terminator - TPS51116PWPG4 IC: LTC3808EDE#PBF Crystal Oscillator - 48MHz Crystal Oscillator: 25MHz Crystal Oscillator: 30MHz Crystal Oscillator: 12MHz Crystal Oscillator: 14.31818MHz

D009/D011/D012/D013/D091/D092

124

Index No.

Part No.

171 172 173 174 175 176 177 178 179 180 181 182 183 184 185 186 187 188 189 190 191 192 193 194 195 196 197 198 199 200 201 202 203 204 205

1601 7887 1601 7896 1601 7898 1601 7913 1601 7914 1601 7959 1601 7981 1604 5724 1605 1124 1605 1197 1605 1199 1605 1200 1605 1204 1605 1206 1605 1207 1605 1208 1605 1211 1605 1212 1605 1214 1605 1216 1605 1218 1605 1221 1605 1240 1605 1284 1605 1289 1605 1291 1605 1293 1605 1295 1605 1296 1605 1301 1605 1306 1605 1307 1605 1358 1605 1376 1605 1406

Q’ty Per Assembly

Description Resistor Array - 10K Ω ±5% 1/32W Resistor Array - 56 Ω ±5% 1/32W Resistor Array Resistor 22 Ω ±5% 1/32W Resistor Array - 47 Ω ±5% Resistor Resistor Array - 100K Ω±5%1/16W Capacitor: 100μF: ±20%: 2V Capacitor - 4.7μF+80 -20% 10V Capacitor - 6pF ±0.5pF 50V Capacitor - 8pF ±0.5pF 50V Capacitor - 10pF ±0.5pF 50V Capacitor-pF50V Capacitor - 47pF ±5% 50V Capacitor - 68pF ±5% 50V Capacitor: 100pF: ±5%: 50V Capacitor - 220pF ±10% 50V Capacitor - 470pF ±10% 50V Capacitor - 1000pF ±10% 50V Capacitor - 2200pF±10%50V Capacitor: 4700pF: ±10%: 25V Capacitor - 0.1 μF+80-20%16V Capacitor - 0.01μF±10% 25V Capacitor: 1500pF: ±10%: 50V Capacitor - 0.1μF±10% 10V Capacitor: 2.2μF: ±10%: 10V Capacitor - 27pF±5%50V Capacitor: 10μF: +80-20%: 10V Capacitor - 330pF ±10% 50V Capacitor-6800pF ±10% 50V Capacitor - 1μF±10% 10V Capacitor - 2.2μF+80-20% 11V Capacitor - 10μF±10% 10V Capacitor - 0.033μF- ±10%: 25V Capacitor - 10μF±10% 6.3V



Part No.

206 207 208 209 210 211 212 213 214 215 216 217 218 219 220 221 222 223 224 225 226 227 228 229 230 231 232 233 234 235 236 237 238 239 240

1605 1451 1605 1452 1605 1474 1605 1475 1605 1544 1605 1563 1605 1583 1605 1587 1605 1602 1605 1605 1605 1607 1605 1689 1606 2319 1607 1014 1607 1051 1607 1061 1607 1199 1607 1477 1607 1556 1607 1567 1607 1572 1607 1637 1607 1827 1607 1946 1609 0005 1609 0006 1609 0007 1609 0011 1609 0016 1609 0020 1609 0026 1609 0027 1610 1900 1610 2045 1610 2046

Description

Q’ty Per Assembly

Capacitor: 0.47μF: ±10%: 6.3V Capacitor - 1μF±10% 6.3V Capacitor - 47μF±20% 6.3V Resistor - 1μF±10% 16V Resistor - 330pF ±5% 50V Capacitor: 10μF: ±10%: 10V Capacitor - 0.1μF: ±10%: 16V Capacitor: 22μF: ±20%: 6.3V Capacitor: 3.3μF: ±10%: 6.3V Capacitor - 4.7μF±10% 10V Capacitor: 22μF: +80-20%: 6.3V Capacitor: 100μF: ±20%: 6.3V Capacitor: 100μF: ±20%: 6.3V EMI Filter - BLM11P600SPB Filter - FBMJ2125HS420 Filter - BLM11P300SPB Filter - BLM21PG600SN1B Inductor - RLF7030-4R7M3R4 Inductor: RLF7030-1R5N6R1 Filter: MPZ2012S101A Filter: MPZ1608S101A Coil: ACM2012-900-2P Inductor: RLF7030-2R2M5R4 Inductor: VLF10040-2R2N7R1 Resistor: 33 Ω: ±5%: 1/16W Resistor: 10K Ω: ±5%: 1/16W Resistor - 68Ω ±5% 1/16W Resistor: 22Ω: ±5%: 1/16W Resistor: 56 Ω: ±5%: 1/16W Resistor: 10 Ω: ±5%: 1/16W Resistor - 47Ω ±5% 1/16W Resistor - 100KΩ±5% 1/16W Resistor: 56K Ω: ±0.5%: 1/16W 1005 Resistor: 115KΩ: ±0.1%: 1/10W: 2125 Resistor: 25.5KΩ: ±0.1%: 1/10W: 2125

D009/D011/D012/D013/D091/D092

125

Index No.

Part No.

241 242 243 244 245 246 247 248 249 250 251 252 253 254 255 256 257 258 259 260 261 262 263 264 265 266 267 268 269 270 271 272 273 274 275

1610 2047 1633 0000 1634 0000 1650 4101 1650 4470 1650 4472 1650 5101 1650 5102 1650 5103 1650 5104 1650 5109 1650 5122 1650 5152 1650 5203 1650 5220 1650 5221 1650 5222 1650 5272 1650 5330 1650 5470 1650 5472 1650 5560 1650 5621 1650 5683 1650 5822 1654 1002 1654 1004 1654 1009 1654 1502 1654 1509 1654 2200 1654 3002 1654 6800 1655 0000 1655 1000

Q’ty Per Assembly

Description Resistor: 30.1KΩ: ±0.1%: 1/10W: 2125 Resistor - 0 Ω 1/10W Resistor - 0 Ω 1/16W Resistor - 100Ω±5%1/10W Resistor - 47Ω±5%1/10W Resistor - 4.7KΩ ±5% 1/10W Chip Resistor - 100 Ω±5%1/16W Chip Resistor - 1KΩ±5%1/16W Chip Resistor - 10KΩ±5%1/16W Chip Resistor - 100KΩ±5%1/16W Chip Resistor 1Ω ±5% 1/16W Chip Resistor - 1.2KΩ±5%1/16W Chip Resistor: 1.5KΩ: ±5%: 1/16W Resistor - 20KΩ ±5% 1/16W Resistor - 22Ω ±5% 1/16W Chip Resistor - 220Ω±5%1/16W Resistor - 2.2KΩ ±5% 1/16W Chip Resistor: 2.7KΩ: ±5%: 1/16W Chip Resistor - 33Ω±5%1/16W Chip Resistor 47Ω ±5% 1/16W Chip Resistor: 4.7KΩ: ±5%: 1/16W Chip Resistor 56Ω ±5% 1/16W Chip Resistor 620Ω ±5% 1/16W Chip Resistor 68KΩ ±5% 1/16W Chip Resistor: 8.2KΩ: ±5%: 1/16W Resistor - 10KΩ±5%1/10W Chip Resistor - 1MΩ ±1% 1/10W Resistor - 10Ω±1% 1/10W Resistor - 15KΩ±1% 1/10W Chip Resistor: 15Ω: ±1%: 1/10W Resistor: 220Ω: ±1%: 1/10W: 1608 Resistor - 30KΩ±1%1/10W Resistor - 680 Ω ±1% 1/10W Chip Resistor - 0Ω±0%1/16W Chip Resistor: 100Ω: ±1%: 1/16W



Part No.

276 277 278 279 280 281 282 283 284 285 286 287 288 289 290 291 292 293 294 295 296 297 298 299 300 301 302 303 304 305 306 307 308 309 310

1655 1001 1655 1002 1655 1003 1655 1009 1655 1109 1655 1132 1655 1200 1655 1242 1655 1501 1655 1502 1655 1601 1655 1651 1655 2200 1655 2201 1655 2209 1655 2552 1655 3012 1655 3309 1655 3909 1655 4700 1655 4701 1655 4702 1655 4709 1655 4871 1655 4999 1655 5102 1655 5103 1655 5600 1655 5601 1655 5609 1655 6809 1655 9101 1660 2101 1660 2471 1660 4103

Description

Q’ty Per Assembly

Chip Resistor - 1KΩ ±1% 1/16W Chip Resistor - 10KΩ±1%1/16W Chip Resistor - 100KΩ±1%1/16W Resistor - 10Ω ±1% 1/16W Resistor: 11 Ω: ±1%: 1/16W: 1005 Resistor: 11.3K Ω: ±1%: 1/16W: 1005 Resistor - 120 Ω ±1% 1/16W Resistor: 12.4K Ω: ±1%: 1/16W: 1005 Chip Resistor 1.5KΩ ±1% 1/16W Resistor - 15KΩ ±1% 1/16W Resistor: 1.6K Ω: ±1%: 1/16W: 1005 Resistor: 1.65K Ω: ±1%: 1/16W: 1005 Resistor - 220Ω ±1% 1/16W Resistor: 2.2K Ω: ±1%: 1/16W: 1005 Resistor - 22Ω ±1% 1/16W Resistor: 25.5K Ω: ±1%: 1/16W: 1005 Resistor: 30.1K Ω: ±1%: 1/16W: 1005 Resistor - 33Ω ±1% 1/16W Resistor 39Ω ±1% 1/16W Resistor - 470Ω ±1% 1/16W Chip Resistor - 4.7KΩ±1%1/16W Chip Resistor: 47KΩ: ±1%: 1/16W: 1005 Resistor - 47Ω ±1% 1/16W Resistor: 4.87K Ω: ±1%: 1/16W: 1005 Resistor - 49.9Ω ±1% 1/16W Resistor: 51K Ω: ±1%: 1/16W: 1005 Resistor: 510K Ω: ±1%: 1/16W: 1005 Resistor - 560Ω ±1% 1/16W Resistor - 5.6KΩ ±1% 1/16W Resistor - 56Ω ±1% 1/16W Chip Resistor - 68Ω±1%1/16w Resistor - 9.1K Ω ±1% 1/16W Capacitor - 100pF - ±10% - 50V Capacitor - 470pF - ±5% - 50V Capacitor - 10000pF - ±10% - 50V

D009/D011/D012/D013/D091/D092

126

Index No.

Part No.

311 312 313 314 315 316 317 318

1660 8104 1906 0117 1907 0077 1605 1681 1654 2209 1654 3309 1906 0120 1654 1809

Q’ty Per Assembly

Description Capacitor - 0.1μF+80-20% 25V Flash Memory: S29GL032A90TFIR20 DDR512M: 8Mx16x4: 333MHZ: CL2.5G3 Capacitor: 22μF: ±20%: 10V Resistor - 22Ω±1% 1/10W Resistor - 33Ω±1% 1/10W NAND Flash: 1G: x8: 30NS: 3.3V: 2KB Resistor: 18 Ω: ±1%: 1/10W: 1608


51.BICU Board (D009/D011/D012/D013/D091/D092)

CAPACITOR SYMBOL NO. C1 C2 ----C5

INDEX NO. 167 167 ----174


INDEX NO. 168 174 164 168 168


INDEX NO. 167 170 167 167 170


INDEX NO. 170 167 170 167 167


INDEX NO. 170 167 170 170 171


INDEX NO. 175 170 180 173 167

SYMBOL NO.

INDEX NO.

C61 C62 C63 C64 C65

170 168 170 175 167

C6 C7 C8 C9 C10

168 168 168 168 174

C16 C17 C18 C19 C20

174 167 170 170 170

C26 C27 C28 C29 C30

170 167 170 167 170

C36 C37 C38 C39 C40

167 170 170 168 167

C46 C47 C48 C49 C50

168 171 170 168 175

C56 C57 C58 C59 C60

175 175 170 175 170

C66 C67 C68 C69 C70

180 167 164 177 177

CAPACITOR SYMBOL NO. C71 C72 --C74 ---

INDEX NO. 177 177 --171 ---


INDEX NO. 170 167 167 167 167


INDEX NO. 160 174 167 171 167

SYMBOL NO. C101 C102 C103 C104 C105

INDEX NO. 172 184 170 178 170

SYMBOL NO. C111 C112 C113 --C115

INDEX NO. 170 175 170 --160

SYMBOL NO. C121 C122 --C124 C125

INDEX NO. 170 165 --170 174

SYMBOL NO. C131 C132 C133 C134 C135

INDEX NO. 170 170 170 170 170

C76 C77 C78 C79 C80

174 164 164 170 174

C86 C87 C88 C89 C90

167 174 167 162 159

C96 C97 C98 C99 C100

167 170 170 154 182

C106 ---------

169 ---------

C116 --C118 C119 C120

160 --161 170 155

C126 C127 C128 C129 C130

156 156 170 170 171

C136 C137 --C139 C140

167 170 --174 167

D009/D011/D012/D013/D091/D092

127




INDEX NO. 170 162 162 174 163

SYMBOL NO. C151 C152 C153 C154 C155

INDEX NO. 167 170 170 178 178

SYMBOL NO. C161 C162 --C164 C165

INDEX NO. 178 170 --164 167

SYMBOL NO. C171 C172 C173 C174 C175

INDEX NO. 167 170 174 153 170

SYMBOL NO. C181 C182 C183 C184 C185

INDEX NO. 170 170 170 170 153

SYMBOL NO. C191 ----C194 C195

INDEX NO. 170 ----170 176

SYMBOL NO.

INDEX NO.

C201 ----C204 C205

175 ----174 166

C146 ------C150

174 ------167

--C157 C158 C159 C160

--156 178 170 156

C166 C167 --C169 C170

170 178 --170 174

C176 C177 C178 C179 C180

167 170 167 169 157

------C189 C190

------167 167

C196 C197 C198 C199 C200

166 168 168 174 181

C206 C207 C208 C209 C210

166 168 168 162 181


INDEX NO. 175 162 170 167 167

SYMBOL NO. C221 C222 C223 C224 C225

INDEX NO. 172 164 164 172 172

SYMBOL NO. C231 C232 C233 C234 C235

INDEX NO. 164 174 167 167 170

SYMBOL NO. C241 C242 C243 C244 C245

INDEX NO. 170 167 170 156 170

SYMBOL NO. C251 C252 C253 C254 C255

INDEX NO. 170 167 171 170 167

SYMBOL NO. C261 C262 C263 C264 C265

INDEX NO. 167 171 170 167 178

SYMBOL NO. C271 C272 C273 C274 C275

INDEX NO. 179 179 170 167 170

C216 C217 C218 C219 C220

170 172 172 172 172

C226 C227 C228 C229 C230

172 172 172 183 164

C236 C237 C238 C239 C240

167 170 167 170 167

C246 C247 C248 C249 C250

178 170 156 170 178

C256 C257 C258 C259 C260

171 170 167 171 170

C266 C267 C268 C269 C270

170 167 178 170 167

C276 C277 C278 C279 C280

171 171 178 170 156

D009/D011/D012/D013/D091/D092

128




INDEX NO. 167 170 167 170 167

SYMBOL NO. C291 C292 C293 C294 C295

INDEX NO. 170 170 167 170 167

SYMBOL NO. C301 C302 C303 C304 C305

INDEX NO. 167 170 167 170 179

SYMBOL NO. C311 C312 C313 C314 C315

INDEX NO. 167 170 171 167 170

SYMBOL NO. C321 C322 C323 C324 C325

INDEX NO. 167 170 167 170 167

SYMBOL NO. C331 C332 C333 C334 C335

INDEX NO. 170 174 170 241 168

SYMBOL NO.

INDEX NO.

C341 C342 C343 C344 C345

168 168 178 170 168

C286 C287 C288 C289 C290

171 171 170 167 167

C296 C297 C298 C299 C300

170 178 171 171 167

C306 C307 C308 C309 C310

170 171 167 170 171

C316 C317 C318 C319 C320

171 167 179 170 167

C326 C327 C328 C329 C330

170 167 170 174 162

C336 C337 C338 C339 C340

178 170 156 158 178

C346 C347 C348 C349 C350

156 178 158 158 178


INDEX NO. 156 168 170 178 168

SYMBOL NO. C361 C362 C363 C364 C365

INDEX NO. 178 168 168 168 168

SYMBOL NO. C371 C372 C373 C374 C375

INDEX NO. 168 168 168 162 164

SYMBOL NO. C381 C382 C383 C384 C385

INDEX NO. 170 160 171 160 160

SYMBOL NO. C391 C392 C393 C394 C395

INDEX NO. 180 167 180 180 167

SYMBOL NO. C401 C402 C403 C404 C405

INDEX NO. 180 167 167 167 162

SYMBOL NO. C411 C412 C413 C414 C415

INDEX NO. 167 167 167 167 167

C356 C357 C358 C359 C360

168 178 158 156 170

C366 C367 C368 C369 C370

168 168 168 168 168

C376 C377 C378 C379 C380

162 162 162 162 160

C386 C387 C388 C389 C390

160 160 160 167 167

C396 C397 C398 C399 C400

167 180 164 171 180

C406 C407 C408 C409 C410

162 162 162 167 167

C416 C417 C418 C419 C420

167 167 167 167 167

D009/D011/D012/D013/D091/D092

129



CAPACITOR

CA

SYMBOL NO. C421 C422 C423 C424 C425

INDEX NO. 167 167 167 167 167

SYMBOL NO. C431 C432 C433 C434 C435

INDEX NO. 170 170 170 170 170

C426 C427 C428 C429 C430

170 170 170 170 170

C436 C437 C438 C439 C440

170 170 170 170 170

DIODE SYMBOL NO. --D2 D3 D4 D5

SYMBOL NO. C441 C442 ----C445

INDEX NO. 170 170 ----170

SYMBOL NO. -----------

INDEX NO. -----------

------C999

------244

FIL INDEX NO. --120 120 120 120

INDEX NO. 185 185 185 185 185

SYMBOL NO. CN101 CN102 CN103 CN104 CN105

INDEX NO. 112 102 105 108 101

SYMBOL NO.

INDEX NO.

CN111 --CN113 CN114 CN115

107 --103 111 109

CN106 CN107 CN108 -----

106 104 113 -----

--CN117

--110

IC


INDEX NO. 186 186 186 186 186


INDEX NO. 187 186 186 186 186


186 186 188 186 191


186 186 186 186 191

D009/D011/D012/D013/D091/D092

SYMBOL NO. CA1 CA2 CA3 CA4 CA5

CONNECTOR

SYMBOL NO. FIL21

130

INDEX NO. 188

SYMBOL NO. ------IC4 IC5

INDEX NO. ------131 126

SYMBOL NO. IC11 IC12 IC13 --IC15

INDEX NO. 133 134 142 --132


INDEX NO. 144 143 129 128 129


131 126 135 135 131


141 138 136 146 138

IC26 IC27 IC28 --IC30

129 129 242 --243



IC

ICS

SYMBOL NO. --IC32 IC33 --IC35

INDEX NO. --147 137 --140

SYMBOL NO. IC41 ---------

INDEX NO. 140 ---------


INDEX NO. 148 129 139 140 127


123 126 124 140 143


138 125 148 128 128

IC56 IC57 IC58 -----

130 130 123 -----

OSC SYMBOL NO. OSC1 OSC2

Q INDEX NO. 151 150

SYMBOL NO. IC61

INDEX NO. 123

SYMBOL NO. ICS1

L INDEX NO. 114

LED

SYMBOL NO. L1 ----L4 L5

INDEX NO. 192 ----189 193

L6 L7

190 194

SYMBOL NO.

INDEX NO.

LED1 LED2

122 121

RESISTOR


INDEX NO. 118 116 116 116 115


INDEX NO. 119 117 117 117 117


INDEX NO. 234 215 214 215 214


INDEX NO. 220 214 214 220 214


INDEX NO. 220 220 214 213 215


INDEX NO. 213 213 213 213 213

Q6 Q7 Q8 Q9 Q10

116 116 119 119 119

Q16 Q17 Q18

117 117 116

R6 R7 R8 R9 R10

215 215 215 230 215

R16 R17 R18 R19 R20

220 213 220 214 214

R26 R27 R28 R29 R30

213 215 220 214 213

R36 R37 R38 R39 R40

213 213 213 215 220

D009/D011/D012/D013/D091/D092

131




INDEX NO. 230 214 229 230 230


INDEX NO. 230 215 230 230 222


INDEX NO. 210 213 213 213 210


INDEX NO. 232 232 232 232 215


INDEX NO. 226 --215 215 230


INDEX NO. 230 217 214 214 230

SYMBOL NO.

INDEX NO.

R101 R102 R103 R104 R105

213 230 230 215 215

R46 R47 R48 R49 R50

230 219 219 226 216

R56 R57 R58 R59 R60

214 214 215 210 213

R66 R67 R68 R69 R70

214 215 215 215 218

------R79 ---

------215 ---

R86 R87 R88 R89 R90

215 215 215 215 215

R96 R97 R98 R99 R100

230 230 230 214 215

R106 R107 R108 R109 R110

215 215 215 215 215


INDEX NO. 215 215 234 215 215

SYMBOL NO. ----R123 R124 R125

INDEX NO. ----214 214 215

SYMBOL NO. -----------

INDEX NO. -----------

SYMBOL NO. R141 R142 R143 R144 R145

INDEX NO. 210 210 230 222 215

SYMBOL NO. R151 R152 R153 R154 R155

INDEX NO. 230 230 222 215 215

SYMBOL NO. R161 R162 R163 R164 R165

INDEX NO. 210 210 215 215 230

SYMBOL NO. R171 R172 R173 R174 R175

INDEX NO. 213 220 220 213 215

----R118 --R120

----234 --236

R126 ------R130

230 ------210

R136 R137 R138 R139 ---

230 222 222 222 ---

R146 R147 R148 R149 R150

230 215 211 210 215

R156 R157 R158 R159 R160

229 227 215 210 210

R166 R167 R168 R169 R170

230 230 230 230 213

R176 R177 R178 R179 R180

215 215 209 210 230

D009/D011/D012/D013/D091/D092

132



RESISTOR SYMBOL NO. --R182 --R184 R185

INDEX NO. --222 --210 212

SYMBOL NO. R191 --R193 R194 R195

INDEX NO. 210 --210 215 210

SYMBOL NO. R201 --R203 R204 R205

INDEX NO. 210 --210 209 209

SYMBOL NO. R211 --R213 --R215

INDEX NO. 230 --215 --210

SYMBOL NO. R221 R222 --R224 R225

INDEX NO. 210 215 --215 224

SYMBOL NO. R231 R232 R233 R234 R235

INDEX NO. 221 223 223 214 215

SYMBOL NO.

INDEX NO.

R241 R242 R243 R244 R245

230 230 228 228 207

R186 R187 R188 R189 R190

210 210 210 210 210

R196 R197 --R199 R200

210 222 --210 230

------R209 R210

------215 230

R216 R217 R218 R219 R220

222 210 230 224 220

R226 R227 R228 R229 R230

220 230 222 216 224

R236 R237 R238 R239 R240

215 214 213 214 214

R246 R247 R248 R249 R250

206 212 215 215 152


INDEX NO. 208 212 215 214 230

SYMBOL NO. R261 R262 R263 R264 R265

INDEX NO. 234 234 235 235 238

SYMBOL NO. R271 R272 R273 R274 R275

INDEX NO. 234 235 235 238 237

SYMBOL NO. R281 R282 R283 R284 R285

INDEX NO. 215 215 215 215 215

SYMBOL NO. --R292 ----R295

INDEX NO. --219 ----215

SYMBOL NO. R301 R302 R303 R304 R305

INDEX NO. 210 214 214 210 209

SYMBOL NO. R311 R312 R313 R314 R315

INDEX NO. 210 215 215 215 215

R256 R257 R258 R259 R260

215 214 230 222 215

R266 R267 R268 R269 R270

237 215 225 231 234

R276 R277 R278 R279 R280

215 225 215 226 215

R286 R287 R288 R289 ---

215 215 230 230 ---

R296 R297 R298 R299 R300

230 210 210 210 210

R306 R307 R308 R309 R310

210 209 210 230 215

--R317 R318 R319 R320

--215 215 215 215

D009/D011/D012/D013/D091/D092

133



RESISTOR SYMBOL NO.

INDEX NO.

R381 R382 R383 R384

230 230 230 230

INDEX NO. 202 197 197 197 ---

SYMBOL NO. ----RN43 RN44 RN45

INDEX NO. ----196 196 201

----197 196 201


198 198 198 198 197

SYMBOL NO. R321 R322 ----R325

INDEX NO. 210 210 ----210

SYMBOL NO. R331 R332 R333 R334 R335

INDEX NO. 222 230 215 210 210

SYMBOL NO. -----------

INDEX NO. -----------

SYMBOL NO. R351 R352 R353 R354 R355

INDEX NO. 233 233 233 233 230

SYMBOL NO. R361 R362 R363 R364 R365

INDEX NO. 233 233 233 233 233

SYMBOL NO. R371 --R373 --R375

INDEX NO. 240 --234 --234

--R327 R328 R329 R330

--215 215 222 222

R336 R337 R338 -----

215 230 230 -----

R346 --R348 R349 R350

230 --230 215 231

R356 R357 R358 R359 R360

233 233 230 233 233

R366 R367 R368 R369 R370

233 214 215 214 239

R376 --R378 R379 R380

215 --210 230 215

SYMBOL NO. RN1 --RN3 RN4 ---

INDEX NO. 201 --201 201 ---

SYMBOL NO. --RN12 RN13 RN14 RN15

INDEX NO. --204 197 204 197

SYMBOL NO. RN21 RN22 RN23 RN24 ---

INDEX NO. 201 203 204 197 ---



198 198 198 197 197

RN16 ------RN20

197 ------201

RN26 ------RN30

201 ------201

----RN38 RN39 RN40

RESISTOR SYMBOL NO. -----------

INDEX NO. -----------

----R998 R999

----245 246

REG SYMBOL NO. REG1 REG2

D009/D011/D012/D013/D091/D092

RN INDEX NO. 145 149

134



RN SYMBOL NO. RN51 RN52 RN53 RN54 RN55

INDEX NO. 201 197 201 197 197


INDEX NO. 196 196 196 196 199

SYMBOL NO. -----------

INDEX NO. -----------


INDEX NO. 200 200 200 200 200

SYMBOL NO. RN91 ---------

INDEX NO. 196 ---------


INDEX NO. 197 196 196 204 196

SYMBOL NO.

INDEX NO.

RN111 RN112 RN113 RN114 RN115

195 203 195 195 197


197 197 201 197 197

RN66 RN67 RN68 RN69 ---

199 199 199 199 ---

----RN78 RN79 RN80

----200 200 200


197 197 197 197 196


204 197 204 196 197

RN106 RN107 RN108 RN109 RN110

201 197 195 195 203

RN116 RN117 RN118 RN119 ---

205 197 197 204 ---

RN SYMBOL NO. RN121 RN122 RN123

INDEX NO. 203 197 197

D009/D011/D012/D013/D091/D092

135


Rev. 01/19/2011

51.BICU Board (D009/D011/D012/D013/D091/D092) Index No. * * * *

Part No.

Description

Q’ty Per Assembly

Index No.

Part No.

D011 5166 D011 5167 D091 5156 D091 5157

PCB: BICU: FCS: 50 M (D013) [TSB#045] PCB: BICU: FCS: 40 M (D011) [TSB#045] PCB: BICU: FCS: 50 M (D092) PCB: BICU: FCS: 40 M (D091)

1 1 1 1

101 102 103 104 105 106 107 108 109 110 111 112 113 114 115 116 117 118 119 120 121 122 123 124 125 126 127 128 129 130 131 132 133 134 135

1102 4203 1102 4204 1102 4645 1102 6893 1102 7358 1102 8489 1102 8560 1102 9116 1103 3158 1103 3167 1103 3175 1103 3188 1103 3736 1104 0821 1400 1240 1400 1241 1400 1243 1400 1244 1401 1414 1402 1798 1403 0978 1403 0996 1407 4840 1407 5346 1407 5347 1407 5351 1407 5353 1407 5392 1407 5463 1407 5633 1407 5713 1407 6166 1407 6232 1407 6430 1407 6466

D009/D011/D012/D013/D091/D092

136

Q’ty Per Assembly

Description CT Header - 4P CT Header - 5P CT Connector - 4P Connector: 53314-3065 (Color Only) Connector - 80P Connector - 55451-3010 Connector - KX14-60K5D1E Connector - 353297-5 Connector - FH12-10S-0.5SV(89) Connector: FH12-28S-0.5SH(89) Connector - FH12-40S-0.5SV(89) Connector: FH12S-50S-0.5SH(89) Connector: FH12S-45S-0.5SH(89) IC Socket: 16008-B0A0020N Transistor: SRC1202UF Transistor: SRC1206UF Transistor: SRC1210UF Transistor: SRA2206UF FET: Si3433BDV-E3 Diode - RSX30 LED - SML-310DT LED - SML-310VT IC - TC7SH04FU IC - SN74LS74ANS IC - SN74LV08APW IC - SN74LV14APW IC - SN74LV244APW IC: SN74LV541APW IC - SN74LV245APW IC - SN74LV574APW IC: SN74LV06APW IC - ESOC LVDS: THC63LVD104A (Color Only) IC - GAVD Type-R Field Memory: 3M: x12: 3.3V (Color Only)


Index No.

Part No.

136 137 138 139 140 141 142 143 144 145 146 147 148 149 150 151 152 153 154 155 156 157 158 159 160 161 162 163 164 165 166 167 168 169 170

1407 6613 1407 6641 1407 6787 1407 6801 1407 6803 1407 7190 1408 1779 1408 1826 1408 1829 1408 1850 1408 1907 1408 2024 1408 2088 1408 2524 1503 1110 1503 1215 1600 1880 1604 4728 1604 4968 1604 5186 1605 1124 1605 1148 1605 1176 1605 1201 1605 1202 1605 1205 1605 1206 1605 1207 1605 1208 1605 1210 1605 1211 1605 1212 1605 1214 1605 1216 1605 1221

Description

Q’ty Per Assembly

Clock Generator: ICS7152M-01LF Custom IC: LEO CMOS Logic: TC7SH125FU CMOS Logic: TC7PA17FU CMOS Logic: TC7SZ07FU Controller: RB5V871A IC - R3112Q281A IC - R3112Q421A Op Amp - LM358PW Regulator - R1170H181B IC: R3112Q451A-FA IC: R3112Q261A-FA IC: LTC3701EGN#TRPBF Series Regulator: R1171S181B-F Crystal Oscillator: 28.7MHz Crystal Oscillator - 17.5MHz Resistor - 25M Ω±1% 1W Capacitor - 100μF±20% 16V Capacitor: 330μF: ±20%: 6.3V Capacitor: 220μF: ±20%: 10V Capacitor - 4.7μF+80 -20% 10V Capacitor - 0.1μF+80-20% 50V Ceramic Capacitor 0.47μF+80-20%16V Capacitor - 12pF ±5% 50V Capacitor - 15pF ±5% 50V Capacitor - 33pF ±5% 50V Capacitor - 47pF ±5% 50V Capacitor - 68pF ±5% 50V Capacitor: 100pF: ±5%: 50V Capacitor: 180pF: ±5%: 50V Capacitor - 220pF ±10% 50V Capacitor - 470pF ±10% 50V Capacitor - 1000pF ±10% 50V Capacitor - 2200pF±10%50V Capacitor - 0.1 μF+80-20%16V

D009/D011/D012/D013/D091/D092

137

Index No.

Part No.

171 172 173 174 175 176 177 178 179 180 181 182 183 184 185 186 187 188 189 190 191 192 193 194 195 196 197 198 199 200 201 202 203 204 205

1605 1240 1605 1282 1605 1285 1605 1289 1605 1295 1605 1296 1605 1299 1605 1303 1605 1305 1605 1347 1605 1387 1605 1391 1605 1474 1605 1544 1605 1692 1607 0861 1607 1002 1607 1108 1607 1222 1607 1340 1607 1351 1607 1546 1607 1680 1607 1827 1609 0005 1609 0006 1609 0007 1609 0019 1609 0027 1609 0061 1609 0062 1609 0063 1609 0064 1609 0065 1609 0067

Description

Q’ty Per Assembly

Capacitor - 0.01μF±10% 25V Capacitor: 22μF: +80-20%: 10V Capacitor - 3300pF ±10% 50V Capacitor - 0.1μF±10% 10V Capacitor: 10μF: +80-20%: 10V Capacitor - 330pF ±10% 50V Resistor - 56pF ±5% 50V Capacitor - 0.01μF+80-20% 50V Capacitor - 1μF+80-20% 6.3V Capacitor - 1μF: +80-20%: 16V Capacitor - 0.68μF±10% 10V Capacitor - 22μF: ±20%: 6.3V Capacitor - 47μF±20% 6.3V Resistor - 330pF ±5% 50V Capacitor: 47pF: ±10%: 50V Filter - BK2125HS101 IC - NFM60R30T222 Filter - BLM21PG220SN1B Inductor - 3.3UH ±20% 2.5A Inductor: SLF7045-220MR90-PF Filter BLM21PG221SN1B Inductor - SLF6028-220MR77-PF Inductor: SLF6028-6R8M1R5-PF Inductor: RLF7030-2R2M5R4 Resistor: 33 Ω: ±5%: 1/16W Resistor: 10K Ω: ±5%: 1/16W Resistor - 68Ω ±5% 1/16W Resistor: 0 Ω: 1608 Resistor - 100KΩ±5% 1/16W Resistor Array: 4.7K Ω: ±5%: 1/1Ww: 4Number Resistor Array: 10K Ω: ±5%: 1/16W: 4Number Resistor Array: 100 Ω: ±5%: 1/16W: 4Number Resistor Array: 33 Ω: ±5%: 1/16W: 4Number Resistor Array: 68 Ω: ±5%: 1/16W: 4Number Resistor Array: 100K Ω: ±5%: 1/16W: 4Number


Index No.

Part No.

206 207 208 209 210 211 212 213 214 215 216 217 218 219 220 221 222 223 224 225 226 227 228 229 230 231 232 233 234 235 236 237 238 239 240

1610 1420 1610 1735 1610 1877 1633 0000 1634 0000 1650 4681 1650 5100 1650 5101 1650 5102 1650 5103 1650 5104 1650 5105 1650 5122 1650 5220 1650 5222 1650 5244 1650 5330 1650 5331 1650 5332 1650 5333 1650 5472 1650 5511 1650 5513 1650 5561 1650 5680 1650 5682 1654 4709 1654 5109 1655 0000 1655 1202 1655 2400 1655 2402 1655 3742 1655 4701 1655 5600

Description

Q’ty Per Assembly

Resistor - 0.075Ω ±1% 0.5W Resistor: 0.05 Ω: ±1%: 1W Resistor: 0.24 Ω: ±1%: 2W Resistor - 0 Ω 1/10W Resistor - 0 Ω 1/16W Resistor - 680Ω ±5% 1/10W Chip Resistor - 10 Ω±5%1/16W Chip Resistor - 100 Ω±5%1/16W Chip Resistor - 1KΩ±5%1/16W Chip Resistor - 10KΩ±5%1/16W Chip Resistor - 100KΩ±5%1/16W Chip Resistor - 1MΩ±5%1/16W Chip Resistor - 1.2KΩ±5%1/16W Resistor - 22Ω ±5% 1/16W Resistor - 2.2KΩ ±5% 1/16W Resistor: 240K Ω: ±5%: 1/16W: 1005 Chip Resistor - 33Ω±5%1/16W Resistor - 330Ω ±5% 1/16W Resistor - 3.3KΩ ±5% 1/16W Resistor: 33K Ω: ±5%: 1/16W: 1005 Chip Resistor: 4.7KΩ: ±5%: 1/16W Resistor - 510Ω ±5% 1/16W Chip Resistor: 51KΩ: ±5%: 1/1W Chip Resistor 560Ω ±5% 1/16W Resistor - 68Ω ±5% 1/16W Chip Resistor: 6.8KΩ: ±5%: 1/16W: 1005 Resistor - 47Ω±1% 1/10W Resistor: 51Ω: ±1%: 1/10W Chip Resistor - 0Ω±0%1/16W Resistor: 12K Ω: ±1%: 1/16W: 1005 Resistor: 240 Ω: ±1%: 1/16W: 1005 Resistor - 24KΩ ±1% 1/16W Resistor: 37.4K Ω: ±1%: 1/16W: 1005 Chip Resistor - 4.7KΩ±1%1/16W Resistor - 560Ω ±1% 1/16W

D009/D011/D012/D013/D091/D092

138

Index No.

Part No.

241 242 243 244 245 246

1660 4332 1902 0084 1906 0101 1605 1221 1650 4472 1623 1003

Q’ty Per Assembly

Description Capacitor - 3300pF - ±10% - 50V SRAM: 4M: x16: TSOP44Type2: 3.3V Flash Memory: S29GL032A90TFIR40 Capacitor - 0.1 μF+80-20%16V Resistor - 4.7KΩ ±5% 1/10W Resistor: 100K Ω: ±1%: 1/4W


52.BICU Board MS (D009/D011/D012/D013/D091/D092)

CAPACITOR SYMBOL NO. C1 C2 ----C5

INDEX NO. 169 169 ----177


INDEX NO. 170 177 166 170 170

SYMBOL NO. --C22 C23 C24 ---

C6 C7 C8 C9 C10

170 170 170 170 177

C16 C17 C18 C19 C20

177 187 172 176 184

-----------

INDEX NO. --177 177 172 -------------

SYMBOL NO. -----------

INDEX NO. -----------

SYMBOL NO. ----C43 -----

INDEX NO. ----172 -----

SYMBOL NO. C51 --C53 C54 C55

INDEX NO. 178 --183 176 169

SYMBOL NO.

INDEX NO.

C61 C62 C63 C64 C65

172 170 172 178 169

------C39 ---

------170 ---

--------C50

--------178

C56 C57 C58 C59 C60

178 178 172 178 172

C66 C67 C68 C69 C70

183 169 166 180 180

CAPACITOR SYMBOL NO. C71 C72 --C74 ---

INDEX NO. 180 180 --174 ---


INDEX NO. 172 169 169 169 169


INDEX NO. 162 177 169 174 169

SYMBOL NO. C101 C102 C103 C104 C105

INDEX NO. 175 189 172 181 172

SYMBOL NO. C111 C112 C113 --C115

INDEX NO. 172 178 172 --162

SYMBOL NO. C121 C122 --C124 C125

INDEX NO. 172 167 --172 177

SYMBOL NO. C131 C132 C133 C134 C135

INDEX NO. 172 172 172 172 172

C76 C77 C78 --C80

177 166 166 --177

C86 C87 C88 C89 C90

169 177 169 164 161

C96 C97 C98 C99 C100

169 172 172 156 186

C106 ---------

171 ---------

C116 --C118 C119 C120

162 --163 172 157

C126 C127 ----C130

158 158 ----174

C136 C137 --C139 C140

169 172 --177 169

D009/D011/D012/D013/D091/D092

139




INDEX NO. 172 164 164 177 165

SYMBOL NO. C151 C152 C153 C154 C155

INDEX NO. 169 172 172 181 181

SYMBOL NO. C161 C162 C163 C164 C165

INDEX NO. 181 172 172 166 169

SYMBOL NO. C171 C172 C173 C174 C175

INDEX NO. 169 172 177 155 172

SYMBOL NO. C181 C182 C183 C184 C185

INDEX NO. 172 172 172 172 155

SYMBOL NO. C191 ----C194 C195

INDEX NO. 172 ----172 179

SYMBOL NO.

INDEX NO.

C201 ----C204 C205

178 ----177 168

C146 ------C150

177 ------169

--C157 C158 C159 C160

--158 181 172 158

C166 C167 --C169 C170

172 181 --172 177

C176 C177 C178 C179 C180

169 172 169 171 159

------C189 C190

------169 169

C196 C197 C198 C199 C200

168 170 170 177 185

C206 C207 C208 C209 C210

168 170 170 164 185


INDEX NO. 178 164 172 169 169

SYMBOL NO. C221 C222 C223 C224 C225

INDEX NO. 175 166 166 175 175

SYMBOL NO. C231 C232 C233 C234 C235

INDEX NO. 166 177 169 169 172

SYMBOL NO. C241 C242 C243 C244 C245

INDEX NO. 172 169 172 158 172

SYMBOL NO. C251 C252 C253 C254 C255

INDEX NO. 172 169 174 172 169

SYMBOL NO. C261 C262 C263 C264 C265

INDEX NO. 169 174 172 169 181

SYMBOL NO. C271 C272 C273 C274 C275

INDEX NO. 182 182 172 169 172

C216 C217 C218 C219 C220

172 175 175 175 175

C226 C227 C228 C229 C230

175 175 175 188 166

C236 C237 C238 C239 C240

169 172 169 172 169

C246 C247 C248 C249 C250

181 172 158 172 181

C256 C257 C258 C259 C260

174 172 169 174 172

C266 C267 C268 C269 C270

172 169 181 172 169

C276 C277 C278 C279 C280

174 174 181 172 158

D009/D011/D012/D013/D091/D092

140




INDEX NO. 169 172 169 172 169

SYMBOL NO. C291 C292 C293 C294 C295

INDEX NO. 172 172 169 172 169

SYMBOL NO. C301 C302 C303 C304 C305

INDEX NO. 169 172 169 172 182

SYMBOL NO. C311 C312 C313 C314 C315

INDEX NO. 169 172 174 169 172

SYMBOL NO. C321 C322 C323 C324 C325

INDEX NO. 169 172 169 172 169

SYMBOL NO. C331 C332 C333 C334 C335

INDEX NO. 172 177 172 249 170

SYMBOL NO.

INDEX NO.

C341 C342 C343 C344 C345

170 170 181 172 170

C286 C287 C288 C289 C290

174 174 172 169 169

C296 C297 C298 C299 C300

172 181 174 174 169

C306 C307 C308 C309 C310

172 174 169 172 174

C316 C317 C318 C319 C320

174 169 182 172 169

C326 C327 C328 C329 C330

172 169 172 177 164

C336 C337 C338 C339 C340

181 172 158 160 181

C346 C347 C348 C349 C350

158 181 160 160 181


INDEX NO. 158 170 172 181 170

SYMBOL NO. C361 C362 C363 C364 C365

INDEX NO. 181 170 170 170 170

SYMBOL NO. C371 C372 C373 C374 C375

INDEX NO. 170 170 170 172 166

SYMBOL NO. C381 --C383 -----

INDEX NO. 174 --172 -----

SYMBOL NO. C391 C392 C393 C394 C395

INDEX NO. 183 169 183 183 169

SYMBOL NO. C401 C402 C403 C404 C405

INDEX NO. 183 169 169 169 164

SYMBOL NO. C411 C412 C413 C414 C415

INDEX NO. 169 169 169 169 169

C356 C357 C358 C359 C360

170 181 160 158 172

C366 C367 C368 C369 C370

170 170 170 170 170

C376 C377 --C379 ---

174 173 --172 ---

C386 C387 C388 C389 C390

174 248 172 169 169

C396 C397 C398 C399 C400

169 183 166 174 183

C406 C407 C408 C409 C410

164 164 164 169 169

C416 C417 C418 C419 C420

169 169 169 169 169

D009/D011/D012/D013/D091/D092

141



CAPACITOR

CA

SYMBOL NO. C421 C422 C423 C424 C425

INDEX NO. 169 169 169 169 169

SYMBOL NO. C431 C432 C433 C434 C435

INDEX NO. 172 172 172 172 172

SYMBOL NO. C441 C442 C443 C444 C445

INDEX NO. 172 172 174 172 169

C426 C427 C428 C429 C430

172 172 172 172 172

C436 C437 C438 C439 C440

172 172 172 172 172

C446 C447 C448 C449 C450

172 169 172 169 172

DIODE SYMBOL NO. --D2 D3 D4 D5

FIL INDEX NO. --120 120 120 120

SYMBOL NO. C451 C452 C453 C454 C455

INDEX NO. 169 172 169 172 169

SYMBOL NO. CA1 CA2 CA3 CA4 CA5

CONNECTOR INDEX NO. 190 190 190 190 190


INDEX NO. 112 102 104 108 101

SYMBOL NO.

INDEX NO.

CN111 --CN113 CN114 CN115

107 --103 111 109

CN106 CN107 CN108 -----

106 105 113 -----

--CN117

--110

IC

SYMBOL NO. FIL1 FIL2 -------

INDEX NO. 196 193 -------


INDEX NO. 192 191 191 191 191

SYMBOL NO. --IC2 --IC4 IC5

INDEX NO. --139 --133 127

SYMBOL NO. IC11 IC12 IC13 --IC15

INDEX NO. 124 136 144 --135


INDEX NO. 146 145 129 134 129

SYMBOL NO. --IC32 IC33 --IC35

INDEX NO. --149 138 --141

----FIL8 FIL9 FIL10

----193 191 196

FIL16 FIL17 FIL18 FIL19

191 191 191 191


133 127 142 132 132


143 139 137 148 139

IC26 IC27 IC28 --IC30

129 129 250 --251


124 127 125 141 145

D009/D011/D012/D013/D091/D092

142



IC

ICS

SYMBOL NO. IC41 ---------

INDEX NO. 141 ---------


INDEX NO. 150 131 140 141 128


124 126 150 130 130

IC56

123

Q

SYMBOL NO. ICS1

L INDEX NO. 114

LED

SYMBOL NO. L1 ----L4 L5

INDEX NO. 197 ----194 198

L6 L7

195 199

SYMBOL NO. LED1 LED2

OSC INDEX NO. 122 121

SYMBOL NO. OSC1 OSC2

Q INDEX NO. 153 152

SYMBOL NO.

INDEX NO.

Q1 Q2 Q3 Q4 Q5

118 116 116 116 115

Q6 Q7 Q8 Q9 Q10

116 116 119 119 119

RESISTOR


INDEX NO. 119 117 117 117 117


INDEX NO. 239 221 220 221 220


INDEX NO. 225 220 220 225 220


INDEX NO. 225 225 220 219 221


INDEX NO. 219 219 219 219 219


INDEX NO. 221 220 234 235 214

SYMBOL NO. R51 R52 --R54 R55

INDEX NO. 215 235 --221 227

Q16 Q17 Q18 Q19

117 117 116 116

R6 R7 R8 R9 R10

221 221 221 235 221

R16 R17 R18 R19 R20

225 219 225 220 220

R26 R27 R28 R29 R30

219 221 225 220 219

R36 R37 R38 R39 R40

219 219 219 221 225

R46 R47 R48 R49 R50

214 216 214 221 215

R56 R57 R58 R59 R60

220 220 221 215 219

D009/D011/D012/D013/D091/D092

143




INDEX NO. 215 219 219 219 215


INDEX NO. 237 237 237 237 221


INDEX NO. 231 --221 221 235


INDEX NO. 235 223 220 220 235

SYMBOL NO. R101 R102 R103 R104 R105

INDEX NO. 219 235 235 221 221

SYMBOL NO. R111 R112 R113 R114 R115

INDEX NO. 221 221 239 221 221

SYMBOL NO.

INDEX NO.

----R123 R124 R125

----220 220 221

R66 R67 R68 R69 R70

220 221 221 221 224

------R79 ---

------221 ---

R86 R87 R88 R89 R90

221 221 221 221 221

R96 R97 R98 R99 R100

235 235 235 220 221

R106 R107 R108 R109 R110

221 221 221 221 221

----R118 --R120

----239 --242

R126 ------R130

235 ------215


INDEX NO. -----------

SYMBOL NO. R141 R142 R143 R144 R145

INDEX NO. 215 215 235 227 221

SYMBOL NO. R151 R152 R153 R154 R155

INDEX NO. 235 235 227 221 221

SYMBOL NO. R161 R162 R163 R164 R165

INDEX NO. 215 215 221 221 235

SYMBOL NO. R171 R172 R173 R174 R175

INDEX NO. 219 225 225 219 221

SYMBOL NO. R181 R182 --R184 R185

INDEX NO. 235 227 --215 218

SYMBOL NO. R191 R192 R193 --R195

INDEX NO. 215 215 215 --215

R136 R137 R138 R139 ---

235 227 227 227 ---

R146 R147 R148 R149 R150

235 221 217 215 221

R156 R157 R158 R159 R160

234 232 221 215 215

R166 R167 R168 R169 R170

235 235 235 235 219

R176 R177 R178 R179 R180

221 221 214 215 235

R186 R187 R188 R189 R190

215 215 215 215 215

R196 R197 R198 R199 R200

215 227 221 215 235

D009/D011/D012/D013/D091/D092

144



RESISTOR SYMBOL NO. R201 --R203 R204 R205

INDEX NO. 215 --215 214 214

SYMBOL NO. R211 --R213 --R215

INDEX NO. 235 --221 --215

SYMBOL NO. R221 R222 R223 R224 R225

INDEX NO. 215 221 221 221 229

SYMBOL NO. R231 R232 R233 R234 R235

INDEX NO. 226 228 228 220 221

SYMBOL NO. R241 R242 R243 R244 R245

INDEX NO. 235 235 233 233 212

SYMBOL NO. R251 R252 R253 R254 R255

INDEX NO. 213 218 221 220 235

SYMBOL NO.

INDEX NO.

R261 R262 R263 R264 R265

239 239 240 240 244

------R209 R210

------221 235

R216 R217 R218 R219 R220

227 215 235 229 225

R226 R227 R228 R229 R230

225 235 227 222 229

R236 R237 R238 R239 R240

221 220 219 220 220

R246 R247 R248 R249 R250

211 218 221 221 154

R256 R257 R258 R259 R260

221 220 235 227 221

R266 R267 R268 R269 R270

243 221 230 236 239


INDEX NO. 239 240 240 244 243

SYMBOL NO. R281 R282 R283 R284 R285

INDEX NO. 221 221 221 221 221

SYMBOL NO. --------R295

INDEX NO. --------221

SYMBOL NO. R301 R302 R303 R304 R305

INDEX NO. 215 220 220 215 214

SYMBOL NO. R311 R312 R313 R314 R315

INDEX NO. 215 221 221 221 221

SYMBOL NO. --R322 ----R325

INDEX NO. --215 ----215

SYMBOL NO. R331 R332 R333 R334 R335

INDEX NO. 227 235 221 215 215

R276 R277 R278 R279 R280

221 230 221 231 221

R286 R287 R288 R289 ---

221 221 235 235 ---

--R297 R298 R299 R300

--215 215 215 215

R306 R307 R308 R309 R310

215 214 215 235 221

--R317 R318 R319 R320

--221 221 221 221

--R327 R328 R329 R330

--221 221 227 227

R336 ---------

221 ---------

D009/D011/D012/D013/D091/D092

145




INDEX NO. -----------

SYMBOL NO. R351 R352 R353 R354 ---

INDEX NO. 238 238 238 238 ---

SYMBOL NO. R361 R362 -------

INDEX NO. 235 221 -------

SYMBOL NO. R371 --R373 --R375

------R349 R350

------221 236

R356 R357 --R359 R360

238 238 --238 238

--R367 R368 R369 R370

--220 221 220 245

-----------

SYMBOL NO. RN1 RN2 RN3 -----

INDEX NO. 206 206 206 -----

SYMBOL NO. --RN12 ----RN15

INDEX NO. --209 ----202



203 203 203 202 202

RN16 ------RN20

202 ------206

RN26 ------RN30

INDEX NO. 215 215 215 215 215

SYMBOL NO. R391 R392 -------

INDEX NO. 221 215 -------

SYMBOL NO.

INDEX NO.

R401 --R403 R404 R405

241 --235 235 241

R386 R387 R388 R389 R390

215 215 215 215 215

R396 R397 ----R400

220 220 ----243

R406 R407

247 215

INDEX NO. 206 208 209 202 ---

SYMBOL NO. RN31 RN32 -------

INDEX NO. 207 202 -------

SYMBOL NO. ----RN43 RN44 RN45

INDEX NO. ----201 201 206


INDEX NO. 206 202 206 202 202

206 ------206

----RN38 RN39 RN40

----202 201 206


203 203 203 203 202


202 202 206 202 202

-----------

RN

REG SYMBOL NO. REG1 REG2

SYMBOL NO. R381 R382 R383 R384 R385

INDEX NO. 246 --239 --239

INDEX NO. 147 151

D009/D011/D012/D013/D091/D092

146




INDEX NO. 201 201 201 201 204

SYMBOL NO. -----------

INDEX NO. -----------


INDEX NO. 205 205 205 205 205

SYMBOL NO. RN91 ------RN95

INDEX NO. 201 ------202


INDEX NO. 202 201 201 209 201


INDEX NO. 200 208 200 200 202

RN66 RN67 RN68 RN69 ---

204 204 204 204 ---

----RN78 RN79 RN80

----205 205 205


202 202 202 202 201


202 202 209 201 202

RN106 RN107 RN108 RN109 RN110

206 202 200 200 208

RN116 RN117 RN118 RN119 ---

210 202 202 209 ---

D009/D011/D012/D013/D091/D092

147

SYMBOL NO.

INDEX NO.

RN121

208


Rev. 09/07/2010

52.BICU Board MS (D009/D011/D012/D013/D091/D092) Index No. * *

Part No. D009 5146 D009 5167

Description BICU - MS - 50M PCB: BICU: MS: 40M

D009/D011/D012/D013/D091/D092

Q’ty Per Assembly

Index No.

Part No.

1 1

101 102 103 104 105 106 107 108 109 110 111 112 113 114 115 116 117 118 119 120 121 122 123 124 125 126 127 128 129 130 131 132 133 134 135

1102 4203 1102 4204 1102 4645 1102 7358 1102 8484 1102 8489 1102 8560 1102 9116 1103 3158 1103 3167 1103 3175 1103 3188 1103 3736 1104 0821 1400 1240 1400 1241 1400 1243 1400 1244 1401 1414 1402 1798 1403 0978 1403 0996 1407 2187 1407 4840 1407 5346 1407 5347 1407 5351 1407 5353 1407 5368 1407 5392 1407 5463 1407 5633 1407 5713 1407 5773 1407 6166

148

Q’ty Per Assembly

Description CT Header - 4P CT Header - 5P CT Connector - 4P Connector - 80P Connector: 55447-2080 Connector - 55451-3010 Connector - KX14-60K5D1E Connector - 353297-5 Connector - FH12-10S-0.5SV(89) Connector: FH12-28S-0.5SH(89) Connector - FH12-40S-0.5SV(89) Connector: FH12S-50S-0.5SH(89) Connector: FH12S-45S-0.5SH(89) IC Socket: 16008-B0A0020N Transistor: SRC1202UF Transistor: SRC1206UF Transistor: SRC1210UF Transistor: SRA2206UF FET: Si3433BDV-E3 Diode - RSX30 LED - SML-310DT LED - SML-310VT TTLIC - SN74LS07NS IC - TC7SH04FU IC - SN74LS74ANS IC - SN74LV08APW IC - SN74LV14APW IC - SN74LV244APW IC - 74LVC245A TSSOP IC: SN74LV541APW IC - SN74LV245APW IC - SN74LV574APW IC: SN74LV06APW CMOS Logic: SN74LVC541APW IC - ESOC



Part No.

136 137 138 139 140 141 142 143 144 145 146 147 148 149 150 151 152 153 154 155 156 157 158 159 160 161 162 163 164 165 166 167 168 169 170

1407 6430 1407 6613 1407 6641 1407 6787 1407 6801 1407 6803 1407 6823 1407 7190 1408 1779 1408 1826 1408 1829 1408 1850 1408 1907 1408 2024 1408 2088 1408 2524 1503 1110 1503 1215 1600 1880 1604 4728 1604 4968 1604 5186 1605 1124 1605 1148 1605 1176 1605 1201 1605 1202 1605 1205 1605 1206 1605 1207 1605 1208 1605 1210 1605 1211 1605 1212 1605 1214

Description

Q’ty Per Assembly

IC - GAVD Type-R Clock Generator: ICS7152M-01LF Custom IC: LEO CMOS Logic: TC7SH125FU CMOS Logic: TC7PA17FU CMOS Logic: TC7SZ07FU Custom IC: GASIU Controller: RB5V871A IC - R3112Q281A IC - R3112Q421A Op Amp - LM358PW Regulator - R1170H181B IC: R3112Q451A-FA IC: R3112Q261A-FA IC: LTC3701EGN#TRPBF Series Regulator: R1171S181B-F Crystal Oscillator: 28.7MHz Crystal Oscillator - 17.5MHz Resistor - 25M Ω±1% 1W Capacitor - 100μF±20% 16V Capacitor: 330μF: ±20%: 6.3V Capacitor: 220μF: ±20%: 10V Capacitor - 4.7μF+80 -20% 10V Capacitor - 0.1μF+80-20% 50V Ceramic Capacitor 0.47μF+80-20%16V Capacitor - 12pF ±5% 50V Capacitor - 15pF ±5% 50V Capacitor - 33pF ±5% 50V Capacitor - 47pF ±5% 50V Capacitor - 68pF ±5% 50V Capacitor: 100pF: ±5%: 50V Capacitor: 180pF: ±5%: 50V Capacitor - 220pF ±10% 50V Capacitor - 470pF ±10% 50V Capacitor - 1000pF ±10% 50V

D009/D011/D012/D013/D091/D092

149

Index No.

Part No.

171 172 173 174 175 176 177 178 179 180 181 182 183 184 185 186 187 188 189 190 191 192 193 194 195 196 197 198 199 200 201 202 203 204 205

1605 1216 1605 1221 1605 1234 1605 1240 1605 1282 1605 1285 1605 1289 1605 1295 1605 1296 1605 1299 1605 1303 1605 1305 1605 1347 1605 1367 1605 1387 1605 1391 1605 1453 1605 1474 1605 1544 1605 1692 1607 0861 1607 1002 1607 1108 1607 1222 1607 1340 1607 1351 1607 1546 1607 1680 1607 1827 1609 0005 1609 0006 1609 0007 1609 0019 1609 0027 1609 0061

Description

Q’ty Per Assembly

Capacitor - 2200pF±10%50V Capacitor - 0.1 μF+80-20%16V Capacitor: 4700pF: ±10%: 50V Capacitor - 0.01μF±10% 25V Capacitor: 22μF: +80-20%: 10V Capacitor - 3300pF ±10% 50V Capacitor - 0.1μF±10% 10V Capacitor: 10μF: +80-20%: 10V Capacitor - 330pF ±10% 50V Resistor - 56pF ±5% 50V Capacitor - 0.01μF+80-20% 50V Capacitor - 1μF+80-20% 6.3V Capacitor - 1μF: +80-20%: 16V Capacitor - 0.033μF±10% 16V Capacitor - 0.68μF±10% 10V Capacitor - 22μF: ±20%: 6.3V Capacitor: 0.022μF: ±10%: 16V Capacitor - 47μF±20% 6.3V Resistor - 330pF ±5% 50V Capacitor: 47pF: ±10%: 50V Filter - BK2125HS101 IC - NFM60R30T222 Filter - BLM21PG220SN1B Inductor - 3.3UH ±20% 2.5A Inductor: SLF7045-220MR90-PF Filter BLM21PG221SN1B Inductor - SLF6028-220MR77-PF Inductor: SLF6028-6R8M1R5-PF Inductor: RLF7030-2R2M5R4 Resistor: 33 Ω: ±5%: 1/16W Resistor: 10K Ω: ±5%: 1/16W Resistor - 68Ω ±5% 1/16W Resistor: 0 Ω: 1608 Resistor - 100KΩ±5% 1/16W Resistor Array: 4.7K Ω: ±5%: 1/1Ww: 4Number



Part No.

206 207 208 209 210 211 212 213 214 215 216 217 218 219 220 221 222 223 224 225 226 227 228 229 230 231 232 233 234 235 236 237 238 239 240

1609 0062 1609 0063 1609 0064 1609 0065 1609 0067 1610 1420 1610 1735 1610 1877 1633 0000 1634 0000 1650 3470 1650 4681 1650 5100 1650 5101 1650 5102 1650 5103 1650 5104 1650 5105 1650 5122 1650 5222 1650 5244 1650 5330 1650 5331 1650 5332 1650 5333 1650 5472 1650 5511 1650 5513 1650 5561 1650 5680 1650 5682 1654 4709 1654 5109 1655 0000 1655 1202

Description

Q’ty Per Assembly

Resistor Array: 10K Ω: ±5%: 1/16W: 4Number Resistor Array: 100 Ω: ±5%: 1/16W: 4Number Resistor Array: 33 Ω: ±5%: 1/16W: 4Number Resistor Array: 68 Ω: ±5%: 1/16W: 4Number Resistor Array: 100K Ω: ±5%: 1/16W: 4Number Resistor - 0.075Ω ±1% 0.5W Resistor: 0.05 Ω: ±1%: 1W Resistor: 0.24 Ω: ±1%: 2W Resistor - 0 Ω 1/10W Resistor - 0 Ω 1/16W Resistor: 47 Ω: ±5%: 1/8W: 2125 Resistor - 680Ω ±5% 1/10W Chip Resistor - 10 Ω±5%1/16W Chip Resistor - 100 Ω±5%1/16W Chip Resistor - 1KΩ±5%1/16W Chip Resistor - 10KΩ±5%1/16W Chip Resistor - 100KΩ±5%1/16W Chip Resistor - 1MΩ±5%1/16W Chip Resistor - 1.2KΩ±5%1/16W Resistor - 2.2KΩ ±5% 1/16W Resistor: 240K Ω: ±5%: 1/16W: 1005 Chip Resistor - 33Ω±5%1/16W Resistor - 330Ω ±5% 1/16W Resistor - 3.3KΩ ±5% 1/16W Resistor: 33K Ω: ±5%: 1/16W: 1005 Chip Resistor: 4.7KΩ: ±5%: 1/16W Resistor - 510Ω ±5% 1/16W Chip Resistor: 51KΩ: ±5%: 1/1W Chip Resistor 560Ω ±5% 1/16W Resistor - 68Ω ±5% 1/16W Chip Resistor: 6.8KΩ: ±5%: 1/16W: 1005 Resistor - 47Ω±1% 1/10W Resistor: 51Ω: ±1%: 1/10W Chip Resistor - 0Ω±0%1/16W Resistor: 12K Ω: ±1%: 1/16W: 1005

D009/D011/D012/D013/D091/D092

150

Index No.

Part No.

241 242 243 244 245 246 247 248 249 250 251

1655 2001 1655 2400 1655 2402 1655 3742 1655 4701 1655 5600 1655 5609 1660 4222 1660 4332 1902 0084 1906 0101

Q’ty Per Assembly

Description Resistor - 2KΩ ±1% 1/16W Resistor: 240 Ω: ±1%: 1/16W: 1005 Resistor - 24KΩ ±1% 1/16W Resistor: 37.4K Ω: ±1%: 1/16W: 1005 Chip Resistor - 4.7KΩ±1%1/16W Resistor - 560Ω ±1% 1/16W Resistor - 56Ω ±1% 1/16W Capacitor - 2200pF - ±10% - 50V Capacitor - 3300pF - ±10% - 50V SRAM: 4M: x16: TSOP44Type2: 3.3V Flash Memory: S29GL032A90TFIR40


53.IO Board (D009/D011/D012/D013/D091/D092)


INDEX NO. 181 181 180 180 180


INDEX NO. 180 185 180 185 185


INDEX NO. 180 179 178 180 195


INDEX NO. 185 185 185 185 185


INDEX NO. 266 185 185 185 185


INDEX NO. 185 266 183 183 184

SYMBOL NO.

INDEX NO.

C61 C62 C63 C64 C65

266 188 180 180 180

C6 C7 C8 C9 C10

190 187 180 180 180

C16 C17 C18 C19 C20

180 266 185 180 180

C26 C27 C28 C29 C30

176 180 179 185 185

C36 C37 C38 C39 C40

185 185 185 174 179

C46 C47 C48 C49 C50

185 185 185 185 185

C56 C57 C58 C59 C60

180 195 195 173 266

C66 C67 C68 C69 C70

257 180 180 180 262


INDEX NO. 180 266 258 256 266


INDEX NO. 180 266 266 266 182


INDEX NO. 259 191 266 266 182

SYMBOL NO. C101 C102 C103 C104 C105

INDEX NO. 191 187 186 180 191

SYMBOL NO. C111 C112 C113 C114 C115

INDEX NO. 266 266 193 266 174

SYMBOL NO. C121 C122 C123 C124 C125

INDEX NO. 171 180 180 265 180

SYMBOL NO. C131 C132 C133 --C135

INDEX NO. 172 172 172 --180

C76 C77 C78 C79 C80

180 266 191 266 186

C86 C87 C88 C89 C90

191 266 182 187 180

C96 C97 C98 C99 C100

266 188 266 175 266

C106 C107 C108 C109 C110

260 191 182 188 266

C116 C117 C118 C119 C120

182 180 266 266 207

C126 C127 C128 C129 C130

174 180 180 266 266

C136 C137 C138 C139 C140

187 178 187 177 177

D009/D011/D012/D013/D091/D092

151


53.IO Board (D009/D011/D012/D013/D091/D092)

CA

CAPACITOR SYMBOL NO. C1

INDEX NO. 181

INDEX NO. 180 189 264 189 266

SYMBOL NO. C151 C152 C153 C154 C155

INDEX NO. 265 265 266 266 263

SYMBOL NO. C161 C162 C163 C164 C165

INDEX NO. 263 266 188 188 178

SYMBOL NO. C171 C172 C173 C174 C175

INDEX NO. 266 266 178 266 266

C146 C147 C148 C149 C150

264 264 266 266 261

C156 C157 C158 C159 C160

266 266 186 266 266

C166 C167 C168 C169 C170

266 263 266 266 261

C176 C177 C178 C179 C180

266 178 189 189 265

CONNECTOR

CA SYMBOL NO. CA11 CA12 CA13 CA14

SYMBOL NO. C141 C142 C143 C144 C145

INDEX NO. 194 194 194 194

SYMBOL NO. C181 C182 C183

INDEX NO. 177 180 180

SYMBOL NO.

INDEX NO.

CA1 CA2 CA3 CA4 CA5

194 194 194 194 192

CA6 CA7 CA8 CA9 CA10

192 192 194 194 194

INDEX NO. 142 144 --144 144

DIODE


INDEX NO. 104 107 106 125 113

SYMBOL NO. CN211 --CN213 CN214 CN215

INDEX NO. 105 --115 114 121

SYMBOL NO. CN221 CN222 -------

INDEX NO. 117 126 -------

SYMBOL NO. --CN232 CN233 CN234 ---

INDEX NO. --120 109 108 ---

SYMBOL NO. D1 D2 D3 D4 D5

INDEX NO. 144 144 144 144 144

SYMBOL NO. D11 D12 --D14 D15

CN206 CN207 CN208 CN209 CN210

124 108 116 114 115

CN216 CN217 CN218 CN219 CN220

118 119 123 110 111

CN226 CN227 ----CN230

112 122 ----110

------CN299

------103

D6 D7 D8 D9 D10

144 144 144 142 142

-----------

D009/D011/D012/D013/D091/D092

152

-----------


53.IO Board (D009/D011/D012/D013/D091/D092)

FUSE

DIODE SYMBOL NO. D21 D22

INDEX NO. 144 144

SYMBOL NO. FU1

IC INDEX NO. 127

OSC


INDEX NO. 158 157 169 154 152


INDEX NO. 166 160 167 2 151


INDEX NO. 148 148 146 158 167


153 159 152 156 149


162 155 161 161 150


164 165 147 147 147

SYMBOL NO. IC31

INDEX NO. 147

SYMBOL NO.

INDEX NO.

OSC1

170

RESISTOR

Q SYMBOL NO. Q1 Q2 Q3 Q4 Q5

INDEX NO. 129 131 131 139 136


INDEX NO. 131 139 132 133 137


INDEX NO. 225 226 225 226 225


INDEX NO. 226 225 225 225 225

SYMBOL NO. --R22 R23 --R25

INDEX NO. --230 225 --226


INDEX NO. 224 226 226 230 234


INDEX NO. 225 204 204 226 226

Q6 Q7 Q8 Q9 Q10

133 134 134 134 131

Q16 Q17 Q18 Q19

138 135 130 135

R6 R7 R8 R9 R10

226 226 226 225 226

R16 R17 R18 R19 R20

225 226 225 226 226

R26 R27 R28 R29 R30

225 225 230 224 230

R36 R37 R38 R39 R40

222 226 229 230 226

R46 R47 R48 R49 R50

226 226 226 226 224

D009/D011/D012/D013/D091/D092

153


53.IO Board (D009/D011/D012/D013/D091/D092)


INDEX NO. 226 226 234 234 226

SYMBOL NO. R61 R62 --R64 R65

INDEX NO. 226 230 --227 233


INDEX NO. 220 223 225 226 226


INDEX NO. 251 251 231 231 225


INDEX NO. 226 226 234 230 226

SYMBOL NO. R101 R102 R103 R104 R105

INDEX NO. 230 225 226 252 211

SYMBOL NO.

INDEX NO.

R111 R112 R113 R114 R115

252 221 225 225 225

R56 R57 R58 R59 R60

226 226 226 226 226

R66 R67 R68 --R70

226 226 230 --202

R76 --R78 R79 R80

226 --226 203 226

R86 R87 --R89 R90

225 231 --230 225

R96 R97 R98 R99 R100

234 226 203 230 226

R106 R107 R108 R109 R110

211 221 234 226 226

R116 R117 R118 R119 R120

255 226 249 250 225


INDEX NO. 226 228 206 226 226

SYMBOL NO. R131 R132 R133 R134 R135

INDEX NO. 226 225 232 225 218

SYMBOL NO. R141 R142 R143 R144 R145

INDEX NO. 232 254 225 226 226

SYMBOL NO. R151 R152 R153 R154 R155

INDEX NO. 226 226 226 226 226

SYMBOL NO. R161 R162 R163 R164 R165

INDEX NO. 226 254 253 226 226

SYMBOL NO. R171 R172 R173 R174 R175

INDEX NO. 225 226 226 226 212

SYMBOL NO. R181 R182 R183 R184 R185

INDEX NO. 217 202 225 233 226

R126 R127 R128 R129 R130

230 232 226 231 228

R136 R137 R138 R139 R140

231 230 218 226 232

R146 R147 R148 R149 R150

226 208 253 226 226

R156 R157 R158 R159 R160

226 226 225 226 226

R166 R167 R168 R169 R170

225 226 233 227 226

R176 R177 R178 R179 R180

219 226 225 226 226

R186 R187 R188 R189 R190

226 226 226 210 205

D009/D011/D012/D013/D091/D092

154


53.IO Board (D009/D011/D012/D013/D091/D092)

RESISTOR SYMBOL NO. R191 R192 R193 --R195

INDEX NO. 205 233 226 --226

SYMBOL NO. R201 R202 R203 R204 R205

INDEX NO. 227 226 212 213 213

SYMBOL NO. R211 R212 R213 R214 R215

INDEX NO. 237 212 236 244 236

SYMBOL NO. R221 R222 R223 R224 R225

INDEX NO. 214 248 236 212 237

SYMBOL NO. R231 R232 R233 R234 R235

INDEX NO. 213 213 241 241 240

SYMBOL NO. R241 R242 R243 R244 ---

INDEX NO. 213 215 216 206 ---

SYMBOL NO.

INDEX NO.

R251 R252 R253 R254 R255

211 243 247 245 246

R196 R197 R198 R199 R200

225 209 226 225 226

R206 --R208 R209 ---

212 --213 225 ---

R216 R217 R218 R219 R220

236 236 242 212 236

R226 R227 R228 R229 R230

237 213 206 206 213

R236 R237 R238 --R240

240 213 226 --226

R246 --R248 R249 ---

213 --213 213 ---

R256 R257 R258 R259 R260

246 238 213 241 246


INDEX NO. 198 200 198 198 197


INDEX NO. 199 196 201 198 198


INDEX NO. 196 198 198 198 199


197 200 199 198 196


200 198 199 199 199


199 199 196 199 198

REG


INDEX NO. 213 239 213 213 206

SYMBOL NO. R271 R272 R273 R274 R275

INDEX NO. 244 235 242 213 212

SYMBOL NO. R281 R282 R283 R284 ---

INDEX NO. 225 225 226 226 ---

--------R270

--------213

R276 R277 R278 R279 R280

212 213 226 226 226

R286 R287 R288 R289

226 226 203 234

D009/D011/D012/D013/D091/D092

RN

SYMBOL NO. REG1 REG2

155

INDEX NO. 163 168


53.IO Board (D009/D011/D012/D013/D091/D092)

SW


INDEX NO. 200 198 198 198 198


INDEX NO. 198 201 201 198 198

--RN37 RN38 RN39 RN40

--198 198 197 197


200 200 197 200 200


INDEX NO. 200 200 197 197 198

TH

SYMBOL NO. SW1

INDEX NO. 128

SYMBOL NO. TH1

TP INDEX NO. 145

SYMBOL NO. TP1 TP2 TP3 TP4 TP5

INDEX NO. 101 101 101 101 101

SYMBOL NO.

INDEX NO.

TP11 TP12 TP13 TP14 TP15

101 101 101 101 101


101 101 101 101 101


101 101 101 101 101

ZD

TP SYMBOL NO. TP21 TP22 TP23 TP24 TP25

INDEX NO. 101 101 101 101 101

SYMBOL NO. TP31 ----TP34 TP35

INDEX NO. 101 ----102 101

SYMBOL NO. TP41 TP42 TP43 TP44 TP45

INDEX NO. 101 101 101 102 101


101 101 102 101 102

TP36 --TP38 TP39 TP40

101 --101 102 101


101 101 101 101 101

D009/D011/D012/D013/D091/D092

SYMBOL NO. TP51 TP52 TP53

156

INDEX NO. 101 101 101

SYMBOL NO. ZD1 ZD2 ZD3 ZD4 ZD5

INDEX NO. 143 143 140 141 141

ZD6 ZD7

141 143


Rev. 09/12/2011

53.IO Board (D009/D011/D012/D013/D091/D092) Index No. * 1

Part No. D009 5155 B238 5503

Description IO Board IC: TRIO2

D009/D011/D012/D013/D091/D092

Q’ty Per Assembly

Index No.

Part No.

1 1

101 102 103 104 105 106 107 108 109 110 111 112 113 114 115 116 117 118 119 120 121 122 123 124 125 126 127 128 129 130 131 132 133 134 135

1100 1475 1101 0328 1102 4203 1102 6300 1102 6297 1102 6397 1102 6594 1102 8466 1102 8467 1102 8470 1102 8471 1102 8474 1102 8475 1102 8477 1102 8480 1102 8481 1102 8485 1102 8488 1102 8492 1102 9108 1102 9109 1102 9114 1102 9117 1102 9120 1102 9121 1103 3188 1109 0082 1204 2768 1400 0728 1400 0902 1400 1209 1400 1212 1400 1214 1400 1240 1400 1241

157

Q’ty Per Assembly

Description Test Pin Connector Pin CT Header - 4P Connector - 7P Connector - 4P Box Header Connector - 10P Connector: 55447-0210 Connector - 55447-0370 Connector - 55447-0610 Connector - 55447-071 Connector - 5 P Connector - 11P Connector - 13P Connector - 55447-1610 Connector - 55447-1760 Connector - 55451-2210 Connector - 5451-2810 Connector - 55451-3610 Connector - 353297-3 Connector - 353297-4 Connector - 353297-1 Connector - 353297-8 Connector - 2-292208-2 Connector: 2-353308-4 Connector: FH12S-50S-0.5SH(89) Fuse: SMD1812P110TF Dip Switch: NDIR-08HT-V Transistor - 2SD2170 Transistor - DTA113ZUA Transistor: 2SA1980UF Transistor: 2SA1980UF-Y Transistor: 2SC5343UF-G Transistor: SRC1202UF Transistor: SRC1206UF


Index No.

Part No.

136 137 138 139 140 141 142 143 144 145 146 147 148 149 150 151 152 153 154 155 156 157 158 159 160 161 162 163 164 165 166 167 168 169 170

1400 1246 1400 1258 1400 1259 1401 0972 1402 1662 1402 1663 1402 1932 1402 1952 1402 1996 1404 0360 1407 1535 1407 2187 1407 2219 1407 4840 1407 5344 1407 5347 1407 5351 1407 5392 1407 5469 1407 6196 1407 6197 1407 6314 1407 6320 1407 6492 1407 6759 1407 6847 1408 1204 1408 1383 1408 1779 1408 1826 1408 2029 1408 2030 1408 2122 1408 2468 1503 1004

Description

Q’ty Per Assembly

Transistor: SRC1205UF Transistor: 2SA1980UF-G Transistor: 2SC5343UF-L Transistor-2SB1260 Diode: PTZ6.2B Diode - ZTP12B Diode: SDS142WMF Diode - TDZ12 Diode: SDS511Q Thermistor - 103HT IC - TD62308AP TTLIC - SN74LS07NS IC - TD62003AP IC - TC7SH04FU IC - SN74LV02APW IC - SN74LV08APW IC - SN74LV14APW IC: SN74LV541APW IC - SN74LV07APW Motor Control IC: STK672-610 Driver: M54563P Motor Control IC: TB6561NG Motor Control IC: MTD1501S-7101 Clock Generator - ICS180M-51LF Custom IC: EIO Motor Control IC: STK672-600B-E IC - TA8083P Regulator - TA7812F IC - R3112Q281A IC - R3112Q421A Comparator: LM2901PW Operational Amplifier - LM224D Series Regulator - R1130H331A-FB IC: R1250V401A-F Oscillator - 19.6608MHz

D009/D011/D012/D013/D091/D092

158

Index No.

Part No.

Description

Q’ty Per Assembly

171 172 173 174 175 176 177 178 179 180 181 182 183 184 185 186 187 188 189 190 191 192 193 194 195 196 197 198 199 200 201 202 203 204 205

1604 4661 1604 4825 1604 5452 1604 5524 1604 5669 1604 5670 1605 1137 1605 1148 1605 1206 1605 1212 1605 1214 1605 1216 1605 1234 1605 1281 1605 1293 1605 1294 1605 1303 1605 1353 1605 1354 1605 1396 1605 1447 1605 1481 1605 1489 1605 1531 1605 1605 1609 0005 1609 0006 1609 0096 1609 0098 1609 0111 1609 0114 1610 1409 1610 1947 1610 1997 1610 2049

Capacitor - 100μF±20% 50V Capacitor - 220μF±20% 35V Capacitor: 47μF: ±20%: 10V Capacitor - 100μF±20% 50V Capacitor: 470μF: ±20%: 25V Capacitor: 10μF: ±20%: 25V Capacitor - 470pF ±10% 50V Capacitor - 0.1μF+80-20% 50V Capacitor - 47pF ±5% 50V Capacitor - 470pF ±10% 50V Capacitor - 1000pF ±10% 50V Capacitor - 2200pF±10%50V Capacitor: 4700pF: ±10%: 50V Capacitor - 0.22μF±10% 16V Capacitor - 27pF±5%50V Resistor - 1000pF ±5% 50V Capacitor - 0.01μF+80-20% 50V Capacitor - 0.1μF±10% 25V Capacitor: 1200pF: ±5%: 50V Capacitor - 0.33μF±10% 50V Resistor - 470pF ±5% 50V Capacitor: 1000pF: ±20%: 50V Resistor - 2.2μF±10% 25V Capacitor: 470pF: ±20%: 50V Capacitor - 4.7μF±10% 10V Resistor: 33 Ω: ±5%: 1/16W Resistor: 10K Ω: ±5%: 1/16W Resistor Array: 10KΩ: ±5%: 1/16W: 4Number Resistor Array: 33Ω: ±5%: 1/16W: 4Number Resistor Array: 1KΩ: ±5%: 1/16W: 4Number Resistor Array: 68Ω: ±5%: 1/16W: 4Number Chip Resistor - 6.8Ω ±5% Resistor: 220 Ω: ±5%: 1W: 6332 Resistor: 1.5 Ω: ±1%: 1W: 6332 Resistor: 1.8 Ω: ±1%: 1W: 6332 Parts Location and List

Index No.

Part No.

206 207 208 209 210 211 212 213 214 215 216 217 218 219 220 221 222 223 224 225 226 227 228 229 230 231 232 233 234 235 236 237 238 239 240

1634 0000 1640 5100 1650 2101 1650 2682 1650 3153 1650 4101 1650 4102 1650 4103 1650 4104 1650 4105 1650 4222 1650 4223 1650 4330 1650 4472 1650 4510 1650 4560 1650 4621 1650 4681 1650 5100 1650 5102 1650 5103 1650 5104 1650 5204 1650 5220 1650 5222 1650 5330 1650 5472 1650 5473 1650 5680 1654 1001 1654 1003 1654 1403 1654 1601 1654 2001 1654 2002

Description

Q’ty Per Assembly

Resistor - 0 Ω 1/16W Capacitor - 10μF+20% 50 Resistor - 100Ω ±5% 1/4W Resistor - 6.8KΩ ±5% 1/4W Resistor: 15KΩ: ±5%: 1/8W Resistor - 100Ω±5%1/10W Resistor - 1KΩ ±5% 1/10W Resistor - 10KΩ ±5% 1/10W Resistor - 100KΩ±5%1/10W Resistor - 1MΩ ±5% 1/10W Resistor - 2.2KΩ±5%1/10W Resistor - 22KΩ±5%1/10W Chip Resistor - 33Ω ±5% 1/10W Resistor - 4.7KΩ ±5% 1/10W Resistor - 51Ω±5%1/10W Chip Resistor - 56Ω ±5% 1/10W Resistor - 620Ω ±5% 1/10W 1608 Resistor - 680Ω ±5% 1/10W Chip Resistor - 10 Ω±5%1/16W Chip Resistor - 1KΩ±5%1/16W Chip Resistor - 10KΩ±5%1/16W Chip Resistor - 100KΩ±5%1/16W Chip Resistor - 200KΩ±5%1/16W Resistor - 22Ω ±5% 1/16W Resistor - 2.2KΩ ±5% 1/16W Chip Resistor - 33Ω±5%1/16W Chip Resistor: 4.7KΩ: ±5%: 1/16W Chip Resistor - 47KΩ ±5% 1/16W Resistor - 68Ω ±5% 1/16W Resistor - 1KΩ±1%1/10W Resistor - 100KΩ±1%1/10W Resistor: 140KΩ: ±1%: 1/10W Chip Resistor - 1.6KΩ±1% 1/10W Chip Resistor - 2KΩ ±1% 1/10W Resistor - 20KΩ±1%1/10W

D009/D011/D012/D013/D091/D092

159

Index No.

Part No.

241 242 243 244 245 246 247 248 249 250 251 252 253 254 255 256 257 258 259 260 261 262 263 264 265 266

1654 2401 1654 3301 1654 3601 1654 5601 1654 6201 1654 6801 1654 7501 1654 9100 1655 1001 1655 1002 1655 2002 1655 2402 1655 3902 1655 4701 1655 5621 1660 2120 1660 2150 1660 2330 1660 2470 1660 2471 1660 4102 1660 4103 1660 4222 1660 4472 1660 6103 1660 8104

Q’ty Per Assembly

Description Resistor - 2.4KΩ ±1% 1/10W Resistor - 3.3KΩ ±1% 1/10W Resistor - 3.6KΩ ±1% 1/10W Resistor - 5.6KΩ±1% 1/10W Resistor - 6.2KΩ ±1% 1/10W Resistor - 6.8KΩ±1% 1/10W Resistor - 7.5KΩ±1%1/10W-1608 Resistor: 910 Ω: ±1%: 1/10W: 1608 Chip Resistor - 1KΩ ±1% 1/16W Chip Resistor - 10KΩ±1%1/16W Chip Resistor - 20KΩ±1%1/16W Resistor - 24KΩ ±1% 1/16W Resistor: 39K Ω: ±1%: 1/16W: 1005 Chip Resistor - 4.7KΩ±1%1/16W Resistor - 5.62KΩ ±1% 1/16W Capacitor - 12 pF ±5% 50V Capacitor - 15pF ±5% 50V Capacitor - 33pF - ±5% - 50V Capacitor - 47pF ±5% 50V Capacitor - 470pF - ±5% - 50V Capacitor - 1000pF ±10% 50V Capacitor - 10000pF - ±10% - 50V Capacitor - 2200pF - ±10% - 50V Capacitor - 4700pF±10% 50V Capacitor - 10000pF - +80%-20%50V Capacitor - 0.1μF+80-20% 25V


54.Decals and Documents (D009/D011/D012/D013/D091/D092)

D009/D011/D012/D013/D091/D092

160



12

17 P 1 2

1 2

3

1

2

P1

1

3 P1

2 4 >ABS<

>ABS<

>ABS<

>ABS<

>ABS<

P3 5

14

13

6

P3

>ABS<

>ABS<

R

Face up Face haut Bild oben Faccia in su Boca arriba

7

18

>ABS<

16

15

P2

P1 >ABS<

>ABS<

D009/D011/D012/D013/D091/D092

161



D009/D011/D012/D013/D091/D092

162


Rev. 08/06/2012

54.Decals and Documents (D009/D011/D012/D013/D091/D092) Index No. 1 2 3 4 5 6 6 7 7 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 26 27

Part No. B132 1573 B223 2644 B223 2645 B223 2729 B223 2873 B237 1355 B237 1372 B238 1372 D011 1250 D011 1251 B238 2523 B238 2526 B238 2527 D501 4406 B652 2379 B789 6031 B802 6011 B802 6013 B802 6014 B802 6012 B802 6016 D009 2627 D009 3268 D009 4497 D009 3269 G029 1980 B238 2524 D129 4242 D011 1252 D011 1253 B814 6053

Description

Q’ty Per Assembly

Decal - Power Source: Off Decal: Scale Decal: Side Fence Decal: Paper Set Direction: Manual Feed: EXP Decal - Side Fence Rear Decal - Main Switch EU OP Decal - Main Switch On-Standby Decal - Main Switch(On-Off) Decal: Main Switch: On-Off Decal: Main Switch: O-I Decal - Paper Set Direction No.2 Decal - Grip Decal - Grip Decal: Size: Original Decal: Caution: Original: 5-Lang Decal - Original Table Decal: Side Fence Decal: Display: Misfeed Removal: P1 Decal: Display: Misfeed Removal: P2 Decal: Misfeed Removal: Original Decal: Display: Misfeed Removal: P3 Decal - Misfeed Removal B1 Decal - Lock Toner Bottle Decal - Right Guide Decal - Release Toner Bottle Decal - LD Decal - Paper Size Decal: H-Temp Warning Decal: Main Switch: On-standby Decal: Main Switch: On-standby: EU Decal - Scale

D009/D011/D012/D013/D091/D092

Index No.

Part No.

Description

Q’ty Per Assembly

1 1 1 1 1 1 1 1 1 1 1 1 1 2 2 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1

163


Rev. 05/23/2012

55.Special Tools (D009/D011/D012/D013/D091/D092)

1

2

3

4

5

6

7

9

11

12

8 10

D009/D011/D012/D013/D091/D092

164


Rev. 05/23/2012

55.Special Tools (D009/D011/D012/D013/D091/D092) Index No. 1 2 3 4 5 6 7 8 9 10 11 12

Part No. A006 9104 A292 9500 VSSM 9000 A230 9003 A230 9004 B645 5010 B645 6820 A257 9300 5203 9502 G021 9350 D091 1361 D091 1362

Description

Q’ty Per Assembly

Scanner Positioning Pin (4PCS/Set) Test Chart - S5S (10PCS/Set) Digital Multimeter - FLUKE 187 Adjustment Cam - Laser Unit Positioning Pin - Laser Unit SD Card SD-Card: USB: Writer: BN-SDCGTY Grease Barrierta - S552R Silicon Grease G-501 Loop Back Connector Duct: Right Rr Sideways: Alex: Ass’y [TSB#054] Duct: Rear: Alex: Ass’y [TSB#054]

D009/D011/D012/D013/D091/D092

Index No.

Part No.

Description

Q’ty Per Assembly

1 1 1 1 1 1 1 1 1 1 1 1

165


D009/D011/D012/D013/D091/D092 PARTS INDEX

This section shows you the part numbers and descriptions used on this machine.

PM Parts Index Section Name PCDU 1 (D009/D011/D012/D013/D091/D092) PCDU 1 (D009/D011/D012/D013/D091/D092) PCDU 1 (D009/D011/D012/D013/D091/D092) PCDU 1 (D009/D011/D012/D013/D091/D092) Paper Registration (D009/D011/D012/D013/D091/D092) Paper Registration (D009/D011/D012/D013/D091/D092) Paper Registration (D009/D011/D012/D013/D091/D092) Paper Registration (D009/D011/D012/D013/D091/D092) Paper Registration (D009/D011/D012/D013/D091/D092) Transfer Belt Unit 1 (D009/D011/D012/D013/D091/D092) Transfer Belt Unit 2 (D009/D011/D012/D013/D091/D092) Fusing Unit 2 (D009/D011/D012/D013/D091/D092) Fusing Unit 2 (D009/D011/D012/D013/D091/D092) Fusing Unit 2 (D009/D011/D012/D013/D091/D092) Fusing Unit 2 (D009/D011/D012/D013/D091/D092) Fusing Unit 3 (D009/D011/D012/D013/D091/D092) Fusing Unit 3 (D009/D011/D012/D013/D091/D092)

D009/D011/D012/D013/D091/D092

Part No.

Description in Service Manual

Description in Parts Catalog

Q’ty Per Assembly

Page and Index No.

B296 9640

Developer - Black

Developer - Black

1

13 - 5

D009 3086

Development Filter

Development Filter

1

13 - 25

D009 3084

Development Filter:Front

Development Filter:Front

1

13 - 39

D009 3085

Development Filter:Rear

Development Filter:Rear

1

13 - 40

D009 2351

Cleaning Blade

Cleaning Blade

1

13 - 24

AD02 7012

Roller:Charge:Apply

Roller:Charge:Apply

1

25 - 37

D009 9510

OPC Drum

OPC Drum

1

25 - 41

AD02 5021

Pick-Off Pawl

Pick-Off Pawl

1

27 - 44

G790 2329

Brush Roller:Cleaner:Charge:Amabuki

Brush Roller:Cleaner:Charge:Amabuki:Ass'y

1

55 - 46

A232 3880

Transfer Belt

Transfer Belt

1

55 - 15

AD04 1135

Cleaning Blade - Transfer Belt

Cleaning Blade - Transfer Belt

1

55 - 1

AE04 4099

Stripper Pawls

Stripper Pawls

1

61 - 17

D009 4177

Thermistor

Thermistor

1

61 - 25

AE01 0099

Hot Roller

Hot Roller

1

61 - 40

AE02 0199

Pressure Roller

Pressure Roller

1

61 - 43

B065 4247

Brake Pad

Brake Pad

1

61 - 4

AE04 0099

Holder Roller

Holder Roller

1

67 - 9

2

PM Parts Index

Section Name Fusing Unit 3 (D009/D011/D012/D013/D091/D092)

D009/D011/D012/D013/D091/D092

Part No. AE04 5099

Description in Service Manual Cleaning Web

Description in Parts Catalog Cleaning Web

3

Q’ty Per Assembly 1

Page and Index No. 71 - 18

PM Parts Index

Parts Index Part No. D009 1088 D009 1090 D009 1093 D009 1111 D009 1113 D009 1120 D009 1121 D009 1123 D009 1125 D009 1127 D009 1128 D009 1131 D009 1135 D009 1139 D009 1141 D009 1142 D009 1145 D009 1147 D009 1148 D009 1151 D009 1158 D009 1161 D009 1164 D009 1171 D009 1182 D009 1183 D009 1187 D009 1193 D009 1194 D009 1195 D009 1241 D009 1242 D009 1243 D009 1244 D009 1256

Description Grip Bracket - Right Rear Connector Bracket - Fusing Stopper Bracket - Grip Drum Shaft Drive Unit- Transfer On-Off Rear Drive Bracket - Engine Ground Plate - Drum Drive Bracket - Transfer Tightener Bracket - Transfer Roller - Tightener Spring - Tightener t - Development Roller Tightener Bracket - Development Front Drive Bracket - Engine Ground Plate - Drum Pulley - 48T/90T Drum Shaft Holder Terminal - Development Roller Collar - 6x18.8mm Bracket - Registration Drive Unit Holder - Paddle Roller Drive Bracket - Paddle Roller Drive Shaft - Paddle Roller Drive Bracket - Fusing Drive Sub-Unit t Cover t - Cleaning Bracket - Fusing Cleaning Drive Sensor Bracket Motor Holder Motor Bracket Inner Cover: Upper: Left: DOM Inner Cover - Left Inner Cover - Right Upper Inner Cover - Middle Sheet - Misfeed Removal

D009/D011/D012/D013/D091/D092

Page and Index No.

Part No.

Description

97 - 25 91 - 8 109 - 16M 93 - 23 93 - 10 93 - 6 93 - 8 93 - 11 93 - 31 93 - 28 93 - 29 93 - 20 93 - 30 93 - 24 93 - 18 93 - 26 93 - 19 93 - 21 93 - 13 95 - 3 91 - 33 91 - 28 91 - 34 91 - 12 91 - 1 91 - 2 91 - 17 91 - 16 91 - 24 91 - 25 13 - 1 13 - 10 15 - 17 13 - 2 13 - 18

D009 1260 D009 1272 D009 1282 D009 1351 D009 1352 D009 1354 D009 1355 D009 1356 D009 1366 D009 1367 D009 1368 D009 1369 D009 1371 D009 1411 D009 1412 D009 1413 D009 1415 D009 1461 D009 1462 D009 1463 D009 1466 D009 1480 D009 1481 D009 1482 D009 1483 D009 1484 D009 1486 D009 1487 D009 1488 D009 1498 D009 1502 D009 1504 D009 1681 D009 1715 D009 1731

Upper Cover Right Cover - Rear Cover: Left: Upper: DOM Upper Fusing Duct Lower Fusing Duct Rear Exhaust Duct - Right Rear Exhaust Duct - Left Sponge: Duct: Exhaust Middle Exhaust Duct - Upper Middle Exhaust Duct - Lower Front Upper Duct Front Lower Duct Exit Duct - MM60 Operation - NA Operation - EU Operation - AA Operation : TWN PCB - LCDC NA PCB - LCDC EU PCB - LCDC AA PCB: ALC1: OP-R: Sub-ass'y Harness: OP-R: 10 Harness: OP-R: 13 Harness: OP-L: 12 Harness: OP-L: 13 Harness: Inverter Inverter: TFT Cable: FFC: TFT: LCD Touch : W-VGA: MA LCD: TFT: W-VGA: MV Cover: Lower Shading Plate: Touch Inner Cover - MS 1st Carriage Ass'y Bracket A - Left Scale

4

Page and Index No. 15 - 5 13 - 21 15 - 2 103 - 2 103 - 3 103 - 14 103 - 11 103 - 5 101 - 1 101 - 2 101 - 3 101 - 4 101 - 20 17 - * 17 - * 17 - * 17 - * 17 - 9 17 - 9 17 - 9 17 - 31 17 - 5 17 - 6 17 - 30 17 - 29 17 - 11 17 - 10 17 - 19 17 - 15 17 - 18 17 - 38 17 - 14 45 - 16 43 - 4 41 - 1

Parts Index

Part No. D009 1732 D009 1742 D009 1779 D009 1814 D009 1815 D009 1816 D009 1821 D009 1832 D009 1840 D009 1860 D009 1861 D009 1870 D009 2105 D009 2201 D009 2202 D009 2203 D009 2204 D009 2205 D009 2211 D009 2240 D009 2241 D009 2242 D009 2243 D009 2244 D009 2245 D009 2247 D009 2248 D009 2249 D009 2254 D009 2279 D009 2301 D009 2303 D009 2317 D009 2318 D009 2331

Description Bracket B - Left Scale Bracket - Printed Circuit Board Gasket - 10x25 Original Sensor Bracket - 48mm Original Sensor Bracket - Sub Scan Original Sensor Bracket Inverter Bracket Lens Unit Xenon Lamp - MS model Imaging Unit Cover - Polygon Motor Laser Diode Unit PCU Seal: Drum: Front Seal: Drum: Rear Seal: Drum: Entrance Seal: Blade: Upper: Case Seal: Blade: Upper Rear: Small Frame: PCU: Upper: Ass'y Rear Flange - Lock Front Flange - Lock Spring Plate - Lock Shaft - Lock Stopper - Lock Stopper Cover - Stopper Cover - Lock Lever Guide Plate - Lock Lever Spring Plate - Lock Lever Base - Lock Lever Seal: Toner Supply: Entrance: Upper Development Unit Drum Hold Plate Electrode Plate - Charge Spring Plate - Electrode Front Arm - Pressure/Charge

D009/D011/D012/D013/D091/D092

Page and Index No. 41 45 45 45 45 47 47 45 43 49 49 49 63 65 65 65 65 65 65 59 59 59 59 59 59 15 15 15 15 65 63 65 65 65 65 -


2 12 18 10 2 19 31 17 3 1 2 8 1 12 14 13 15 11 1 23 28 29 25 27 26 13 16 15 14 7 4 38 4 25 19

5

Description Rear Arm - Pressure/Charge Cleaning Blade Density Sensor Front Side Plate - Coupling Rear Side Plate - Coupling Rear Side Plate - Coupling Idler Bracket Seal - 24.5x68.5 Handle - PCU Screw - M3x10 Guide Plate - Exit Cover - Electrical Components Guide Sheet - Manual Feed Guide Sheet - Vertical Transport Transport Roller - Duplex Exit Driven Roller Guide Plate - Vertical Transport Holder - Vertical Transport Transport Belt Pulley - Vertical Transport Pulley - Idler Shaft - Idler Shaft - Vertical Transport Registration Roller - Drive Gear - 18Z Gear - 28Z Knob - Registration Roller Registration Roller - Driven Bushing - Driven Registration Case er - Remove Paper Dust Bracket - Registration Sensor Paper Dust Case Upper Guide Plate - Registration Cover - Paper Dust Removal Front Positioning Guide

Page and Index No. 65 - 30 65 - 24 99 - 10 65 - 6 65 - 2 63 - 2 65 - 3 65 - 34 65 - 5 63 - 32 85 - 11 103 - 13 57 - 17 85 - 1 57 - 18 85 - 14 85 - 2 85 - 5 85 - 6 85 - 8 85 - 7 85 - 10 85 - 9 59 - 14 59 - 16 59 - 9 59 - 17 59 - 13 59 - 7 59 - 11 59 - 21 15 - 18 59 - 3 59 - 6 59 - 22

Parts Index


Description Rear Positioning Guide Lower Guide Plate - Registration Harness - Registration Sensor Decal - Misfeed Removal B1 Decal - Misfeed Removal B1 Cap - Toner Supply Tension Spring Stay - Paper Dust Removal Torsion Spring - Registration Transport Roller: Drive: Ass'y Guide Plate Guide Plate - No.2 Upper Case Seal Entrance Seal - Toner Supply Front Bias Terminal Rear Bias Terminal Upper Cover - Development Unit Seal - Density Sensor Harness t- Paddle Development Filter: Front Development Filter: Rear Development Filter Development Sleeve: Alex: Ass'y Seal: Development Upper Cap - Development Case Seal: Level Sponge Seal: Shielding Plate Seal: Guide Plate t: Development Sleeve Entrance Seal Ass'y Ground Plate: Doctor Blade Seal: Slide Rear Seal - Upper Cover Front Seal - Upper Cover

D009/D011/D012/D013/D091/D092

Page and Index No.


59 - 18 59 - 12 59 - 19 13 - 23 151 - 19 65 - 9 59 - 8 59 - 5 59 - 4 53 - 10 59 - 2 59 - 1 63 - 22 63 - 16 63 - 11 63 - 12 63 - 23 63 - 21 63 - 15 63 - 39 63 - 40 63 - 25 63 - 27 63 - 36 63 - 34 65 - 48 63 - 37 59 - 31 59 - 32 63 - 41 63 - 30 63 - 26 63 - 38 63 - 33 63 - 24

6

Description Seal: Side Plate: Front Seal: Side Plate: Rear Toner Supply Unit Guide - Toner Supply Cam: Handle Shaft - Slide Seal: Toner Supply: Entrance: Front Decal - Lock Toner Bottle Decal - Lock Toner Bottle Decal - Release Toner Bottle Decal - Release Toner Bottle Case - Transfer Unit Transfer Unit Receptacle Housing - Transfer Receptacle Terminal - Transfer Guide: Standard: Transfer Unit: Rear Guide: Standard: Transfer Unit: Front Entrance Guide Plate - Transfer Spring Cover - Transfer Unit Terminal Holder - Transfer Unit Holder - Density Sensor Guide - Separation/Transport Harness - Used Toner Sensor Harness - Transfer Unit Bias Earth Harness - Transfer Unit Frame - Transfer Belt Sensor Harness Front Bushing - Bias Roller Arm - Transfer Belt Drive Roller - Transfer Belt Set Lever - Transfer Unit Seal - Rear Transfer Exit Seal - Transfer Belt Exit Front Lever - Transfer Belt Rear Lever - Transfer Belt

Page and Index No. 63 - 17 63 - 20 61 - 1 99 - 4 61 - 14 61 - 11 65 - 8 151 - 20 13 - 5 13 - 6 151 - 22 69 - 16 67 - * 93 - 33 93 - 34 99 - 20 99 - 21 59 - 30 83 - 16 83 - 19 99 - 9 99 - 14 69 - 15 69 - 21 69 - 19 67 - 16 83 - 20 67 - 8 67 - 17 67 - 10 69 - 12 69 - 25 69 - 22 69 - 8 69 - 10

Parts Index


Description Release Lever Release Lever Shaft Front Release Plate Rear Release Plate Bias Terminal - Transfer Belt Earth Terminal - Transfer Belt Terminal - Transfer Belt Bracket: Cleaning Blade: Transfer Belt Scraper - Drive Roller Rear Seal - Cleaning Blade Front Seal - Cleaning Blade Sheet: Prevent fence: Transfer Belt Receptacle Housing - Transfer Unit Fusing Cover - Lower Middle Fusing Cover - Lower Front Fusing Cover - Lower Rear Fusing Cover - Upper Front Fusing Cover - Upper Rear Fusing Cover - Duplex Guide Entrance Guide Plate - Fusing Harness - Set Sensor NA Set Sensor Harness - 230V Harness - Fusing Unit Bracket: Side Plate: Auxiliary Connector Bracket 1 Connector Bracket 2 Front Heater Bracket Rear Heater Bracket Terminal - AC/DC Terminal Cover Terminal - AC Electrode Plate 1 Electrode Plate 2 Electrode Plate 3 Stay: Fusing Sub-unit: Fusing Exit: Peen

D009/D011/D012/D013/D091/D092

Page and Index No. 69 69 69 69 67 67 67 69 67 69 69 67 69 71 71 71 71 71 71 71 73 73 73 73 73 73 73 73 73 73 73 73 73 73 73 -


13 4 6 7 6 4 5 2 12 24 23 11 17 22 6 9 5 8 18 20 27 27 26 35 33 28 1 36 30 29 14 32 31 13 15

7

Description Retaining Rings-C - Hot Roller Exit Guide - Hot Roller Unit Fusing Unit Cover Thermistor Thermistor Bracket Housing - Thermostat Spacer - Thermostat Harness 1 - Thermostat Harness 2 - Thermostat Stay - Pressure Roller Unit Bracket - Driven Roller Decal: High Temperature Decal: High Temperature Exit Guide - Pressure Roller Unit Knob Knob Bracket Front Lever - Pressure Release Pressure Lock Lever Front Pressure Lever Rear Lever - Pressure Release Front Pressure Lever Cleaning Web Ass'y Cleaning Unit Cover - Fusing Front Lock Lever Rear Lock Lever Roller Clutch Washer: DIA3.5 Bracket - Cleaning Unit Drive Worm Gear Bracket Worm Gear Shaft Roller Clutch Feeler - Web Separation Plate - Paper Exit Feeler - Overflow Bracket - Fusing Exit Sensor

Page and Index No. 73 - 2 73 - 44 73 - 18 73 - 25 73 - 24 73 - 20 73 - 22 73 - 12 73 - 19 71 - 14 71 - 13 71 - 23 151 - 25 71 - 2 71 - 1 71 - 3 73 - 6 73 - 9 73 - 11 73 - 37 73 - 38 75 - * 75 - 2 99 - 15 99 - 8 75 - 8 99 - 22 75 - 3 75 - 14 75 - 12 75 - 21 75 - 10 89 - 11 87 - 17 87 - 12

Parts Index


Description Sheet - Gate Lower Guide Plate - Exit Lower Stay - Exit Stepped Tapping Screw - M3 Spring - Lower Guide Plate Driven Roller Shaft Upper Stay DC Solenoid - Exit Rear Side Plate Front Side Plate Entrance Gate Lever - Entrance Gate Bushing - 4mm Exit Guide Plate - Upper Right Exit Guide Plate - Upper Discharge Brush - Exit Exit Roller Transport Roller Transport Roller Exit Sensor Bracket Tension Spring - Gate Pawl Cushion - DC Solenoid Tension Spring Release Gear - 17Z Gear - 22Z Gear/Pulley - 22Z/22T Gear - 22Z Timing Pulley - 22T Timing Belt - 30S2M172 Gear - 17Z Stepper Motor Bracket Spring - Entrance Pressure Spring - Exit Pressure Lower ing Plate Grip - Upper Gate

D009/D011/D012/D013/D091/D092

Page and Index No. 79 89 89 87 89 89 89 87 89 89 87 87 87 87 89 89 89 87 89 87 87 87 87 87 89 89 87 89 89 87 87 89 89 89 79 -


7 12 19 11 17 15 2 1 30 10 7 3 4 10 7 5 1 9 3 15 25 5 2 20 33 34 14 32 31 21 22 23 20 29 2

8

Description Right Guide Plate - Open/Close Upper Gate Bushing - Gate Lever - Upper Gate Right Spring - Guide Plate Driven Roller Exit Motor Cover Entrance Arm Exit Arm Bracket - Point Spring Plate - Exit Roller Decal - Right Guide Decal - Right Guide Bushing - Lower Guide Plate Harness - Paper Exit Unit Guide Plate - Left Upper Upper Guide Plate - Gate Spacer: DIA8.0: 1.5mm Link: Stopper Compression Spring: Earth: Duplex Unit Harness Bracket Tension Spring - Duplex Gate Tension Spring - Stopper Hook Rear Inner Cover - Duplex Front Inner Cover - Duplex Harness Guide Front Release Arm Rear Release Arm Cover - Duplex Unit Front Torsion Spring Tension Spring - Duplex Gate Holder Shaft - Transfer Unit Stepper Motor - DC 5.79W Guide Plate - Holder Duplex Gate

Page and Index No. 79 - 11 79 - 1 79 - 4 79 - 6 79 - 10 79 - 3 87 - 23 89 - 22 89 - 25 89 - 27 89 - 28 151 - 21 81 - 25 89 - 18 87 - 16 79 - 14 81 - 2 109 - 20 109 - 11 109 - 19 81 - 24 79 - 13 77 - 5 77 - 2 77 - 1 85 - 16 77 - 6 77 - 7 77 - 13 83 - 21 79 - 5 83 - 23 87 - 24 83 - 18 79 - 12

Parts Index


Description Tension Spring - Release Bracket Stopper Bracket - Spring Guide - Set Shaft Stopper Hook - Duplex Unit Stepped Screw - M3 Front Guide - Duplex Unit Set Rear Guide - Duplex Unit Set Bracket - Wire Pulley Shaft Spring - Set Shaft Shaft - Duplex Unit Harness - Duplex Unit Motor Harness Reverse Roller - Feed Transport Roller 1 Transport Roller 2 Driven Roller Driven Roller Driven Roller Driven Roller BICU - MS - 50M BICU - MS - 50M BICU - MS - 40M BICU - MS - 40M IO Board IO Board Mother Board SYNC Detector Board Scanner I/O Board - BW Connector Board Harness - High Voltage Cable Harness - Safety Switch DC Harness-DC Power Supply-IOB Harness - PSU-SIO Harness - Development Drawer DC Harness - BICU-IOB

D009/D011/D012/D013/D091/D092

Page and Index No.


85 - 27 85 - 24 85 - 23 77 - 4 85 - 26 109 - 9 109 - 8 85 - 19 85 - 22 85 - 21 85 - 17 81 - 26 81 - 10 83 - 1 83 - 2 83 - 15 77 - 8 71 - 12 81 - 6 105 - 6 139 - * 139 - * 105 - 6 105 - 14 145 - * 107 - 2 49 - 7 47 - 12 45 - 13 93 - 1 105 - 19 105 - 18 105 - 20 95 - 14 105 - 7

9

Description Harness - BICU-SIO Harness - BICU-IDB Interface Harness - BICU-LDB Harness - IOB Upper Harness - IOB Upper Interface Harness - IOB-Switch DC Harness-IOB Lower Harness - IOB Lower Behind Harness - IOB-Lift Motor Interface Harness - Web Sensor Harness - Toner Supply Motor Harness - Quenching Lamp Harness - Operation DC Harness - IOB-Motor Interface Cable - Scanner BW Interface Cable - Scanner BW Harness - Scanner Unit BW Harness - Stabilizer BW Harness - Imaging Unit Harness: Laser Diode Control Harness: AC: Inlet AC Harness - Switch AC Harness - Heater Harness: AC: Heater AC Harness - Heater AC Harness - Fusing Base - Left Safety Switch Grounding Plate - BICU Fixing Plate - Controller Board Bracket - IO Board Bracket - IO Board Connector Bracket Bracket - Main Switch Bracket - Power Pack Bracket - Inlet

Page and Index No. 105 - 3 105 - 4 109 - 2 107 - 15 105 - 9 99 - 6 105 - 11 105 - 13 105 - 10 91 - 15 99 - 1 99 - 18 15 - 19 105 - 12 45 - 14 105 - 1 47 - 11 47 - 32 49 - 6 49 - 9 105 - 16 105 - 22 105 - 23 61 - 16 103 - 9 91 - 9 101 - 18 105 - 25 107 - 9 105 - 15 95 - 9 103 - 4 105 - 24 93 - 3 105 - 17

Parts Index


Description Bracket - Heater Connector Shaft - Safety Switch Left/Right Lever - Safety Switch Left Lever - Safety Switch Middle Lever - Safety Switch Cam - Safety Switch Base - Right Safety Switch Guide Plate - Safety Switch Right Lever - Safety Switch Right Lower Lever - Safety Switch Upper grip - Controller Box Large Cover - Fax Control Unit Grip - C/T Box Bracket - BICU Small Bracket - BICU Guide - Mother Board Bracket - Mother Board Bracket - Control Board Guide - Fax Control Unit Ground Plate- C/T Box Left Rail - Fax Control Unit Heater Stopper Tension Spring: Safety Switch: Left Spring - Right Safety Switch Harness Guide - Safety Switch Right Rail - Small Sheet: EMBLEM: RIC Sheet: EMBLEM: SVN Sheet: EMBLEM: GES: NA Sheet: EMBLEM: LAN: NA Sheet: EMBLEM: RIC: 40SP Sheet: EMBLEM: NSA Sheet: EMBLEM: REX Sheet: EMBLEM: GES: EU Sheet: EMBLEM: LAN: EU

D009/D011/D012/D013/D091/D092

Page and Index No.


103 - 10 101 - 12 101 - 15 101 - 16 101 - 13 101 - 14 101 - 7 101 - 9 101 - 11 101 - 8 107 - 10 107 - 7 107 - 8 105 - 8 103 - 6 105 - 5 107 - 1 107 - 4 107 - 3 107 - 28 107 - 21 61 - 13 101 - 17 101 - 10 101 - 6 107 - 20 13 - 12 13 - 12 13 - 12 13 - 12 13 - 12 13 - 12 13 - 12 13 - 12 13 - 12

10

Description Sheet: EMBLEM: INF OPC Drum NVRAM Decal: Main Switch: On-Off Decal: Main Switch: On-Off Decal: Main Switch: O-I Decal: Main Switch: O-I Decal: Main Switch: On-standby Decal: Main Switch: On-standby Decal: Main Switch: On-standby: EU Decal: Main Switch: On-standby: EU Fusing Unit - 120V Fusing Unit - 230V BICU - CS - 50M BICU - CS - 50M BICU - CS - 40M BICU - CS - 40M Scanner I/O Board - Color Interface Cable - Scanner Color Interface Cable - Scanner Color Harness - Scanner Unit Color Heater: PCD: NA: Sub-ass'y Heater: PCD: EU: Sub-ass'y Cover - SD-Card Sheet: EMBLEM: RIC Sheet: EMBLEM: SVN Sheet: EMBLEM: GES: NA Sheet: EMBLEM: LAN: NA Sheet: EMBLEM: NSA Sheet: EMBLEM: REX Sheet: EMBLEM: GES: EU Sheet: EMBLEM: LAN: EU Sheet: EMBLEM: INF Inner Cover - Upper Left Front Cover

Page and Index No. 13 - 12 65 - 41 107 - 23 13 - 9 151 - 7 13 - 9 151 - 7 151 - 26 61 - 17 61 - 17 151 - 26 71 - * 71 - * 105 - 6 135 - * 135 - * 105 - 6 47 - 12 105 - 1 45 - 5 47 - 11 61 - 15 61 - 15 107 - 6 13 - 12 13 - 12 13 - 12 13 - 12 13 - 12 13 - 12 13 - 12 13 - 12 13 - 12 13 - 1 13 - 15

Parts Index


Description Front Right Cover Right Cover - Front Left Cover Left Cover - Upper Rear Cover Rear Cover - Upper Cap - Rear Cover EU Controller Board - MS - 40M Controller Board - MS - 40M Controller Board - MS - 50M Controller Board - MS - 50M Sheet: EMBLEM: RIC Sheet: EMBLEM: SVN Sheet: EMBLEM: GES: NA Sheet: EMBLEM: LAN: NA Sheet: EMBLEM: RIC: 50SP Sheet: EMBLEM: NSA Sheet: EMBLEM: REX Sheet: EMBLEM: GES: EU Sheet: EMBLEM: LAN: EU Sheet: EMBLEM: INF Cover: Right: Front: NA Cover: Left: NA Controller Board - CS - 50M Controller Board - CS - 50M Controller Board - CS - 40M Controller Board - CS - 40M Sheet: EMBLEM: RIC Sheet: EMBLEM: SVN Sheet: EMBLEM: GES: NA Sheet: EMBLEM: LAN: NA Sheet: EMBLEM: NSA Sheet: EMBLEM: REX Sheet: EMBLEM: GES: EU Sheet: EMBLEM: LAN: EU

D009/D011/D012/D013/D091/D092

Page and Index No.

Part No. D013 6692 D091 5146 D091 5146 D091 5147 D091 5147 D091 6192 D091 6193 D091 6194 D091 6195 D091 6492 D091 6493 D091 6494 D091 6495 D091 6692 D092 1411 D092 1412 D092 1413 D092 1415 D092 5714 D092 5714 D092 5724 D092 5724 D092 5910 D092 6192 D092 6193 D092 6194 D092 6195 D092 6492 D092 6493 D092 6494 D092 6495 D092 6692 A006 9104 A096 2065 A134 3180

13 - 19 13 - 22 13 - 3 15 - 2 13 - 26 13 - 25 13 - 24 107 - 19 123 - * 107 - 19 123 - * 13 - 12 13 - 12 13 - 12 13 - 12 13 - 12 13 - 12 13 - 12 13 - 12 13 - 12 13 - 12 13 - 22 13 - 3 123 - * 107 - 19 123 - * 107 - 19 13 - 12 13 - 12 13 - 12 13 - 12 13 - 12 13 - 12 13 - 12 13 - 12

11

Description Sheet: EMBLEM: AL-C1CCS: INF PCB: BICU: 50 (D092) PCB: BICU: 50 (D092) PCB: BICU: 40 (D091) PCB: BICU: 40 (D091) Sheet: EMBLEM: 40: RIC (D091) Sheet: EMBLEM: 40: SVN (D091) Sheet: EMBLEM: 40: GES: NA (D091) Sheet: EMBLEM: 40: LAN: NA (D091) Sheet: EMBLEM: 40: NSA (D091) Sheet: EMBLEM: 40: REX (D091) Sheet: EMBLEM: 40: GES: EU (D091) Sheet: EMBLEM: 40: LAN: EU (D091) Sheet: EMBLEM: 40: INF (D091) Operation : NA (D091/D092) Operation : EU (D091/D092) Operation : AA (D091/D092) Operation : TWN (D091/D092) PCB: CTL: 50 (D092) PCB: CTL: 50 (D092) PCB: CTL: 40 (D091) PCB: CTL: 40 (D091) SD-Card: VM: EXP: Ass'y Sheet: EMBLEM: 50: RIC (D092) Sheet: EMBLEM: 50: SVN (D092) Sheet: EMBLEM: 50: GES: NA (D092) Sheet: EMBLEM: 50: LAN: NA (D092) Sheet: EMBLEM: 50: NSA (D092) Sheet: EMBLEM: 50: REX (D092) Sheet: EMBLEM: 50: GES: EU (D092) Sheet: EMBLEM: 50: LAN: EU (D092) Sheet: EMBLEM: 50: INF (D092) Scanner Positioning Pin (4PCS/Set) Slider Ring Bottle Chuck

Page and Index No. 13 - 12 105 - 6 135 - * 135 - * 105 - 6 13 - 12 13 - 12 13 - 12 13 - 12 13 - 12 13 - 12 13 - 13 13 - 13 13 - 13 17 - * 17 - * 17 - * 17 - * 107 - 19 123 - * 107 - 19 123 - * 107 - 29 13 - 13 13 - 13 13 - 13 13 - 13 13 - 13 13 - 13 13 - 13 13 - 13 13 - 13 153 - 1 99 - 5 61 - 5

Parts Index

Part No. A193 1766 A193 1767 A193 1769 A193 1793 A193 1816 A230 9003 A230 9004 A232 1284 A232 1937 A232 2315 A232 2318 A232 2339 A232 2340 A232 2399 A232 2421 A232 2987 A232 3067 A232 3077 A232 3155 A232 3240 A232 3251 A232 3252 A232 3263 A232 3264 A232 3266 A232 3553 A232 3880 A232 3885 A232 3908 A232 3909 A232 3926 A232 4666 A250 1752 A257 9300 A259 6754

Description Wire Clamp 1st Mirror Holder Clamp - Rear Wire Scanner Home Sensor Stopper 1st Slide Rail Adjustment Cam - Laser Unit Positioning Pin - Laser Unit Spring Holder Positioning Pin - Laser Unit Ass'y Front Bushing - Cleaning Bracket Collar - Cleaning Spur Holder - Pick-Off Pawl Seal - Blade 13x9.5x3 Bushing - 6x10x3 Roller - Paper Tray Tape - TD Sensor Spacer - M5 Front Cover - Development Unit Cover - Toner Bottle Ass'y Chuck Shaft Slider Ass'y Spring Plate - Toner Bottle Stopper - Slide Rail Seal - Slide Rail Ball Bearing - 8x16x5 Transfer Belt Driven Roller - Transfer Unit Seal - Rear Case Seal - Front Case Transfer Belt Roller Cushion - Stepper Motor Exposure Glass Grease Barrierta - S552R Bushing - 6 6mm

D009/D011/D012/D013/D091/D092

Page and Index No.

Part No. A267 2857 A267 2859 A267 2860 A292 9500 A422 1063 A422 1063 A422 1063 A458 2251 A628 1225 A697 2102 A806 1295 A858 4671 A858 4676 A859 1841 A859 2112 A859 2241 A859 7211 B004 1325 B004 1936 B004 2310 B004 2783 B004 2923 B004 7667 B024 1264 B044 1825 B044 1825 B044 1825 B044 1847 B051 1727 B051 1814 B065 1371 B065 1374 B065 4221 B065 4247 B077 3262

43 - 1 43 - 5 43 - 2 41 - 13 43 - 15 153 - 4 153 - 5 99 - 13 49 - 11 65 - 22 65 - 33 65 - 45 65 - 43 65 - 10 65 - 21 51 - 16 63 - 13 63 - 8 63 - 6 61 - 4 61 - 7 61 - 6 61 - 10 61 - 12 61 - 3 65 - 40 67 - 15 67 - 1 69 - 29 69 - 28 67 - 9 95 - 2 41 - 7 153 - 8 57 - 35

12

Description Spring Plate - Side Fence Side Fence Stopper Rear Lever Stopper Test Chart - S5S (10PCS/Set) Seal - 0.7x13x20 Seal - 0.7x13x20 Seal - 0.7x13x20 Cushion - Bin Solenoid Lever Bushing - 8mm Damper - Junction Gate Solenoid Feed Belt Roller Driven Spring Plate - Pressure Roller Filter - DF Open Sensor Drive Shaft - Paper Feed Belt Reverse Roller Stepped Screw Cover - Shield Glass Plate - Optical Housing Unit Spur Torque Limiter Spring Plate - Release Lever Holder: Toner Bottle: EU Magnet Catch Collar Collar Collar Shoulder Screw Frame: Scanner: Front Bracket: Original Sensor Cloth Holder Cloth - DF Exposure Glass Feeler Spring Brake Pad Slide Rail: Toner Supply Unit

Page and Index No. 51 - 28 51 - 29 51 - 27 153 - 2 25 - 18 27 - 16 31 - 16 25 - 22 23 - 21 29 - 13 23 - 23 19 - 19 19 - 18 39 - 10 23 - 13 25 - 11 19 - 2 13 - 7 93 - 32 99 - 12 53 - 28 51 - 20 99 - 3 13 - 17 97 - 20 81 - 22 33 - 4 81 - 13 41 - 8 45 - 1 13 - 29 13 - 30 75 - 11 75 - 4 61 - 2

Parts Index

Part No. B082 2333 B082 2781 B082 3121 B082 3122 B082 3123 B082 3867 B101 1097 B129 5008 B132 1573 B132 1573 B132 1692 B138 5801 B154 5861 B154 5865 B154 5869 B154 5879 B154 5879 B180 1701 B180 1704 B180 1713 B180 1734 B180 1803 B180 1810 B180 1812 B180 1814 B180 2782 B180 2871 B213 2312 B213 2316 B213 2362 B213 3065 B213 3889 B213 4460 B213 5544 B222 1262

Description Terminal: Brush Roller Bracket: Sensor Shield: Development Sleeve: Front: C3 Shield: Development Sleeve: Rear: C3 Shield: Case: Development: Front Rear: C3 Shield: Remove Paper Dust Rubber Foot: H5 Cap - LAN Connector Decal - Power Source: Off Decal - Power Source: Off Scale: Rear: Printing Gasket: Inner Cover Guard: Fan Cap: Connector: USB : Interface: SECC Plate: Cable Plate: Cable Inner Cover Bracket: Tension Stepper Motor: Ass'y Slide Rail: No.2 Guide: High Voltage Supply Cord: Base Pulley: Drive Wire: Front: Sub-Ass'y Pulley: Drive Wire: Rear: Sub-Ass'y Shaft: Scanner: Drive Seal: Tray Shaft: Separator: Driven: Ass'y Bracket: Cleaning Blade Stud: Point: Cleaning LED Array QL Ass'y Density Sensor: Development: C4 Roller: Bias Shaft: Pressure Roller Harness: FFC: SBU: 50Wick: 80mm Cover: Inner Back: Upper: EU

D009/D011/D012/D013/D091/D092

Page and Index No.


65 - 32 53 - 6 63 - 29 63 - 28 63 - 19 69 - 26 109 - 7 107 - 27 13 - 14 151 - 1 41 - 11 45 - 19 107 - 24 107 - 26 107 - 5 105 - 2 45 - 6 45 - 7 43 - 20 47 - 16 43 - 16 47 - 18 47 - 1 47 - 6 47 - 3 51 - 31 57 - 41 65 - 23 65 - 16 99 - 17 63 - 14 67 - 2 89 - 21 45 - 15 15 - 6

13

Description Cover: Scanner: Front: EU Cover: Scanner: Left: EU Cover: Scanner: Right: EU Cover: Scanner: Rear: EU Connector Bracket Grip: Front Bracket: Grip: Right Front Cam: Guide Plate: Scanner: Left Bracket: Paper Feed Unit Bracket: Paper Feed Grip Shaft Drive t Magnetic Clutch Bracket Stepper Motor DC24V Feed Drive Shaft Cap: Grip Guide Plate: Scanner Operating Instructions Holder EMBLEM Cover Cover - Main Switch Cover: Inner Back Cover: Paper Exit Unit: Upper Cover: Right: Upper Middle Screw Fan Motor - MM60 DC24V Stepper Motor DC5.06V Drum Stay: Drive Unit PCB: APC1: OP-L: Sub-ass'y Keytop - Blank FB Keytop - Clear/Stop Keytop: 10Key Keytop - Copy NA Keytop - DOC NA Keytop: Printer: NA Keytop: Scanner: NA

Page and Index No. 17 - 35 15 - 1 15 - 11 15 - 12 103 - 8 109 - 14 109 - 15 41 - 19 109 - 12 97 - 10 97 - 2 97 - 3 97 - 12 97 - 16 97 - 1 109 - 13 13 - 16 13 - 27 13 - 11 13 - 8 15 - 8 15 - 9 15 - 10 71 - 7 101 - 5 95 - 1 97 - 4 17 - 4 17 - 3 17 - 20 17 - 21 17 - 34 17 - 33 17 - 36 17 - 32

Parts Index


Description Keytop: Function: NA (D091/D092) Keytop: Copy: EU Keytop: DOC: EU Keytop: Printer: EU Keytop: Scanner: EU Keytop: Function: EU (D091/D092) Keytop: 10Key: NA Keytop - 10Key AA Cover: Scanner: Front Cover: Front Right: Upper Carriage: No.2 Mirror: No.2: Concave Mirror: No.2: Convex Lens Unit Scale: Machine Or Copier Seal: Sheet Through Scale: Left Cover: Stepper Motor: Rear Drive Wire Holder: Connector Scale: Left: NA Frame: Scanner: Rear Ground Plate: Stay: Lens Gasket: RFSG-030100: 75 Bracket: Exterior: Rear Document Feeder: Connector: Bracket Cover: Scanner: Left Cover: Scanner: Right Cover: Scanner: Rear Seal: Scanner: Frame: Base Duct: Scanner Sheet: Fan: Duct: Scanner Seal: Duct: Front: Scanner Seal: Duct: Rear: Scanner Seal: Exposure Glass: Rear

D009/D011/D012/D013/D091/D092

Page and Index No. 17 17 17 17 17 17 17 17 17 17 43 43 43 45 41 41 41 47 43 47 41 41 45 45 47 41 15 15 15 47 47 47 47 47 41 -


39 34 33 36 32 39 21 21 35 37 7 9 10 4 3 5 6 13 19 29 6 9 8 9 14 17 1 11 12 5 21 22 24 25 20

14

Description Xenon Lamp - CS model Ground Plate: Rear Ground Plate: Reverse Gear: Z16 Guide Plate: Separator Housing: Manual Feed Cover: Manual Feed Unit Guide Plate: Exit Cover: Guide Plate: Exit Stay: Feed DC Solenoid: Pickup Spring: Release: Pickup Stay: Arm Torsion Spring: 27N Bracket: Arm: Manual Feed: Rear Decal: Scale Decal: Scale Decal: Side Fence Decal: Side Fence Guide Plate: Transport Unit: Exit Spring: Pressure: 5N Arm: Manual Feed: Front Arm: Manual Feed: Rear Arm: Manual Feed: Short: Front Arm: Manual Feed: Short: Rear Harness: Manual Feed Cover: Manual Feed Manual Feed Table Extension Tray Cover: Manual Feed: Entrance Spring: Cover: Manual Feed Gear: 16Z Spring Plate: Stopper Harness: Paper Size Sensor Side Fence: Rear

Page and Index No. 43 - 3 57 - 29 57 - 25 57 - 37 57 - 26 57 - 50 57 - 4 57 - 3 57 - 1 57 - 9 57 - 14 57 - 15 57 - 19 57 - 20 57 - 32 151 - 2 55 - 8 151 - 3 55 - 5 85 - 13 85 - 15 57 - 22 57 - 33 57 - 24 57 - 34 57 - 16 55 - 7 55 - 14 55 - 13 77 - 15 77 - 14 55 - 12 55 - 4 55 - 9 55 - 2

Parts Index


Description Side Fence: Front Spring - 11N Arm: Tightener Gear: 25Z Gear: Z31 Gear: Z28 Bracket: Stepper Motor Guide: Gear Drum Stay: Drive Manual Feed Table: EXP: Ass'y Heat Sink: Heater: NA Heat Sink: Heater: EU er - Left No.2 Rack: Manual Feed Positioning Cap - Short er - Right Bracket: Push Switch Grip: Side Fence: Manual Feed Decal: Paper Set Direction: Manual Feed: EXP Decal: Paper Set Direction: Manual Feed: EXP Stepper Motor: Ass'y Pickup Arm Feed Shaft Gear-24Z Ground Plate - Feed Paper End Feeler Harness Sheet Stay Sensor Bracket DC Solenoid 24V Ground Plate - Front Separate Driven Shaft Separate Drive Shaft Gear - 22Z Feed Guide

D009/D011/D012/D013/D091/D092

Page and Index No.


55 - 1 85 - 4 57 - 44 57 - 47 57 - 46 57 - 48 97 - 21 97 - 19 57 - 49 55 - * 109 - 17 109 - 17 109 - 1 55 - 11 109 - 4 109 - 3 95 - 10 55 - 3 151 - 4 55 - 6 97 - 22 53 - 22 53 - 26 53 - 25 53 - 21 53 - 1 53 - 12 53 - 9 53 - 4 53 - 8 53 - 13 53 - 29 53 - 34 53 - 35 53 - 17

15

Description Paper Tray Grip Grip Holder Lever - Release Inner Rise No.1 Shaft Lever: Release: Paper Tray: Outer Decal - Side Fence Rear Decal - Side Fence Rear Paper Tray: No.2: Ass'y Link - Paper Size Sensor Spacer End Fence Rise Lever Ground Plate - Paper Tray No.2 Front Side Fence Stopper Lever - Front Rear Side Fence Plate - Side Fence Plate - Side Fence Right Gear - 16Z Tray Bottom Plate Cover - Paper Tray No.2 Roller: Guide: PFA Roller: Auxiliary: Driven: DIA16: PFA Tension Spring: Gate Pawl: 1.6N Exit Tray Exit End Fence Stopper - Upper gate Pawl Shaft: Feeler: Overflow Guide Plate: Right Guide Plate: Left Lower Timing Belt: 30S2M312 Timing Belt: 30S2M182 Roller Clutch: T24 Spacer: Wire: Stopper Wire: Stopper: DIA1.5

Page and Index No. 51 - 8 51 - 13 51 - 10 51 - 24 51 - 15 51 - 30 151 - 5 51 - * 51 - 1 51 - 2 51 - 17 51 - 25 51 - 6 51 - 18 51 - 19 51 - 26 51 - 22 51 - 21 51 - 23 51 - 4 51 - 7 89 - 14 89 - 16 79 - 9 15 - 4 15 - 3 79 - 8 87 - 18 81 - 23 83 - 12 83 - 5 83 - 3 83 - 11 85 - 28 85 - 12

Parts Index


Description Wire: Stopper: DIA1.5 Tension Spring: Wire: 180N Timing Belt: 30S2M268 Pulley: T26/T24 Roller Clutch: T24 Guide Plate: Cover Roller Clutch: T26 Timing Belt: 30S2M234 Compression Spring Sheet: Cover: Duplex Pulley: T35/T33 Bushing: DIA4 Bushing: DIA4 Tension Spring: Driven Roller Tension Spring: Driven Roller Tightener Spring: Tightener Bracket: Sensor: Entrance Stay: Transport: Upper: Peen Gear: Pulley: Z24/T40 Stepper Motor: DC4.29V 1.7W Timing Belt: 30S2M128 Bracket: Stepper Motor Grip: Open And Close: Duplex Unit Pulley: T30 Shaft: Pulley: Wire Pulley: DIA13 Harness: SIO: Machine Or Copier Bracket: Total Counter Bracket: Base: Connector Retaining Rings-E Cover: Inner Back: Middle: EU Heater: Option: 120V: 9W Heater: Option: 230V: 9W Decal: Positioning Display: Development

D009/D011/D012/D013/D091/D092

Page and Index No.


109 - 6 77 - 17 81 - 15 83 - 8 83 - 6 77 - 12 83 - 9 83 - 4 77 - 10 77 - 16 83 - 7 83 - 14 81 - 8 83 - 13 81 - 7 81 - 12 81 - 14 81 - 4 81 - 27 81 - 20 81 - 17 81 - 21 81 - 19 77 - 3 81 - 16 85 - 20 85 - 18 47 - 10 97 - 26 103 - 12 69 - 5 15 - 7 47 - 26 47 - 26 83 - 26

16

Description Decal: Positioning Display: Development Decal - Main Switch EU OP Decal - Main Switch EU OP Decal - Main Switch On-Standby Decal - Main Switch On-Standby Cover - Right Base EU Rubber Foot Cover Cover - Connector Cover - Positioning Pin Lever - Front Upper Decal - Main Switch(On-Off) Decal - Main Switch(On-Off) Keytop - Start Keytop - Try Print Keytop - Interrupt Keytop - Counter Lens - Front Operation Bracket LCD Spacer A LCD Spacer B Sheet: Data: Display: NA Spacer - Keytop Operation Bracket - Right Keytop - Power Source Keytop - Keytop - Kantan Keytop - Clear Modes Timing Belt - 157ST1.5-4.0 Idler Pulley Pulley Seal: Exposure Glass Decal - Paper Set Direction No.2 Decal - Paper Set Direction No.2 Decal - Paper Size Decal - Paper Size

Page and Index No. 69 - 30 151 - 6 109 - 18 109 - 18 151 - 6 13 - 20 95 - 13 103 - 7 95 - 6 99 - 16 13 - 9 151 - 7 17 - 23 17 - 24 17 - 25 17 - 2 17 - 13 17 - 7 17 - 16 17 - 17 17 - 8 17 - 1 17 - 12 17 - 28 17 - 27 17 - 26 17 - 22 47 - 15 43 - 17 43 - 11 41 - 21 51 - 3 151 - 8 13 - 32 151 - 24

Parts Index


Description Decal - Grip Decal - Grip Decal - Grip Decal - Grip Tray Cover - Right Cover - Tray Left Gear - 16Z End Ring: Spring: DIA4 Roller: Lever: Pressure Screw Screw IC: TRIO2 Ball Bearing - 8x22x7 Developer - Black Tension Roller Gear - 18Z Spring: Belt: Paper Feed: 8N Spring - Paper Size Sensor Roller - Paper Feed Belt Pickup Collar Pressure Plate Tape PCB: DDR1-DIMM-32D: 512MB: Ass'y SD Card SD-Card: USB: Writer: BN-SDCGTY Decal: Size: Original Decal: Size: Original Decal: Caution: Original: 5-Lang Decal: Caution: Original: 5-Lang Decal: Caution: Original: 5-Lang Timing Belt: 40S2M144 Stepper Motor: PM: S2M: T15: Ass'y Timing Belt: B40S2M390 DC Solenoid: Transmitted Rubber Stamp Paper Feed Belt Roller Scanning Driven Shaft

D009/D011/D012/D013/D091/D092

Page and Index No. 151 - 9 51 - 9 51 - 9 151 - 10 95 - 7 95 - 12 59 - 15 73 - 5 73 - 7 31 - 1 35 - 19 145 - 1 93 - 7 63 - 5 25 - 3 33 - 16 23 - 15 37 - 22 23 - 14 23 - 7 39 - 13 107 - 22 153 - 6 153 - 7 151 - 11 21 - 4 151 - 12 13 - 28 19 - 1 97 - 17 33 - 11 37 - 15 27 - 24 23 - 22 27 - 23

17

Part No.

Description

B789 3712 B789 6031 B789 6031 B802 1121 B802 1131 B802 1212 B802 1231 B802 1236 B802 1246 B802 1252 B802 1261 B802 1266 B802 1321 B802 1361 B802 1412 B802 1612 B802 1616 B802 1621 B802 1624 B802 1629 B802 1631 B802 1632 B802 1633 B802 1641 B802 1642 B802 1643 B802 1651 B802 1661 B802 1671 B802 1681 B802 1715 B802 1721 B802 1731 B802 1736 B802 1741

Exit Driven Roller Decal - Original Table Decal - Original Table Positioning Plate: Front Positioning Plate: Rear Frame: Base Bracket: PCB: Right Bracket: PCB: Left Bracket: On Off Detector Feeler: Paper Size Sensor Grip: Lower Sponge: Base: 2mm Hinge: Left: Ass'y Damper: Hinge: Right: Ass'y Plate: Harness: Guide Bracket: Motor Stay: Motor Stepper Motor: DC24V 4.8W Bracket: Coupling Cooling Fan Bracket Timing Pulley: T31 Gear: Z18 Gear: Z19 Gear: Z18 Gear: Z37 Gear: Z26 Gear: Z25 Gear: Z21/Z23 Gear: Z17 Gear: Z18 Bracket: Stepper Motor Stepper Motor: DC1.76V 3.7W Stay: Motor: Scanning Bracket: Protect: Drive Timing Pulley: T31/T61

Page and Index No. 27 - 22 151 - 13 19 - 12 39 - 1 39 - 2 39 - 16 37 - 2 37 - 14 37 - 12 37 - 23 39 - 14 39 - 15 39 - 8 39 - 9 37 - 24 37 - 16 37 - 19 37 - 21 37 - 18 37 - 7 35 - 6 35 - 7 35 - 8 35 - 21 35 - 3 35 - 4 35 - 5 35 - 2 35 - 1 35 - 15 35 - 10 35 - 14 35 - 11 35 - 13 35 - 16

Parts Index


Description Timing Pulley: T31: Idler: Ass'y Bracket: Tension Bracket: Tension Timing Pulley: T31 Pulley: Idler: DIA16: Ass'y Bracket: Shaft: Side Plate: Front Timing Belt: 40S3M186 Knob: Misfeed Removal: T27 Stepper Motor: DC4.08V 2.4W Bracket: Reverse: Drive Bracket: Pickup: Drive Timing Pulley: T33-Z17 Cam: Pickup Stopper: Cam: Pickup Feeler: Cam: Pickup Gear: Drive: Arm: Pickup Cam: Stopper Pawl Gear: Stopper: Original Insert: Z25 Bracket: Sensor: Pickup Stopper Pawl: Paper Feed Lever: Stopper Pawl Guide: Reverse: Open And Close: Sub-ass'y Sheet: Guard Drum Stay: Guide: Reverse Guide: Reverse: Open And Close Guide: Reverse: Open And Close: Behind Shaft: Reverse: Drive: Press Fit Shaft: Roller: Reverse Gear: Z20 Torque Limiter Mechanical Clutch: Separator Roller: Reverse Exit: Driven Stopper: Guide: Reverse Original Table Original Table: Face Front Side Fence

D009/D011/D012/D013/D091/D092

Page and Index No. 31 31 35 35 31 25 25 25 33 33 33 33 33 33 33 33 33 33 33 25 25 25 25 25 25 25 25 25 25 25 25 27 19 19 19 -


3 2 20 18 7 1 4 2 1 3 10 17 22 18 20 21 14 15 7 23 26 28 27 14 16 21 20 13 15 12 19 17 25 13 11

18

Description Spring Plate: Side Fence Slider: Side Fence Guide: Original Insert Stay: Original Table: Point Plate: Point Spring Plate: 0.2T Stopper: Original Table Spring Plate Roller: Pull Out Roller: Scanning: Entrance Timing Pulley: T33 Timing Pulley: T33-T24 Roller: Scanning: Exit Timing Pulley: T33 Roller: Exit Timing Pulley: T26 Roller: Reverse Timing Pulley: T23 Guide: Paper Feed: Lower Bracket: Guide: Paper Feed: Lower Sheet: Roller: Scanning: Entrance Sheet: Scanning: Entrance Guide: Scanning: Entrance: Lower Sheet: Auxiliary: Scanning: Entrance Stay: Scanning: Entrance: Lower Bracket: Entrance: Pressure: Ass'y Compression Spring: 3.3N Sensor Bracket Roller: Scanning: Driven Shaft: Driven: Entrance Guide Plate: Scanning Guide: Scanning: Exit: Lower Stay: Scanning: Exit: Lower Plate: Exit: Pressure: Auxiliary Spring Plate: Scanning: Exit: Driven: Upper

Page and Index No. 19 19 19 19 19 19 19 29 31 29 29 29 29 29 31 31 31 31 31 29 27 27 27 27 27 27 27 27 27 27 27 27 27 27 27 -

15 14 21 9 24 17 10 5 17 9 14 11 10 12 21 8 27 24 15 2 2 3 1 26 8 6 7 27 4 25 9 11 15 12 13

Parts Index


Description Spring Plate: Scanning: Exit: Driven: Lower Shaft: Driven: Exit Exchange Pawl: Reverse Cushion: Exchange Pawl Lever: Exchange Pawl: Reverse Link: Solenoid Guide: Exit: Upper Guide: Exit: Upper: Sub-ass'y Spring Plate Stay: Reverse Discharge Brush: Reverse Discharge Brush: Exit DC Solenoid: 24V Shielding Plate: Sensor Bracket: Registration Sensor Bracket: Sensor: Scanning: Exit Cover: Paper Feed Grip: Cover Hook: Grip: Cover: Front Hook: Grip: Cover: Inner Back Shaft: Grip: Cover Stopper: Cover Guide: Upper Spring Plate: Upper Sheet: Driven Roller: Pull Out Drum Stay: Upper: Inner Back Drum Stay: Upper: Front Sheet: Guide: Upper Bracket: Cover: Inner Back Bracket: Cover: Front Bracket: Paper Size Sensor Feeler: Original Sensor Ground Plate Bracket: Driven Roller: Pull Out Ground Plate: Driven Roller: Pull Out

D009/D011/D012/D013/D091/D092

Page and Index No. 27 27 31 31 31 31 31 31 27 31 27 31 25 29 29 27 21 21 21 21 21 21 23 23 23 23 23 23 21 21 21 21 23 23 23 -


14 5 23 22 11 10 20 28 21 26 20 25 7 7 8 19 1 2 6 7 8 12 33 32 41 30 29 31 11 10 15 22 40 37 38

19

Description Driven Roller: Pull Out Paper Feed: Unit Shaft: Drive Holder Lever: Pickup: Release Collar: Shaft Gear: Z20 Bracket: Paper Feed Belt Shaft: Pickup Bracket: Pickup Gear: Z19 Timing Pulley: Gear: T19/Z22 Cushion: Pickup Roller: Pickup Timing Pulley: T21 Cover: Front Cover: Rear Pressure Plate Drum Stay: Pressure Plate Cushion: Left Sound Proofing Material Sound Proofing Material: Cover: Rear Cushion: Left Cushion: Inner Back ADF Main Board Harness: Interface Harness: Paper Feed Harness: Motor: Paper Feed Harness: Motor: Reverse Harness: Lift Up Harness: Solenoid Harness: Solenoid Harness: Registration Sensor Harness: Motor: Pick Up Interface harness - Fan

Page and Index No. 23 23 23 23 23 23 23 23 23 23 23 23 23 23 23 19 19 39 39 39 21 19 39 39 37 37 37 37 37 37 25 37 29 37 37 -

35 1 24 26 27 17 28 16 10 11 4 5 12 6 8 4 8 3 12 4 5 7 5 6 11 1 4 9 6 3 6 5 1 10 25

Parts Index

Part No.

Description

B802 5870 B802 5880 B802 6011 B802 6011 B802 6012 B802 6012 B802 6013 B802 6013 B802 6014 B802 6014 B802 6016 B802 6016 B802 6121 B814 6053 B814 6053 D029 1774 D029 2662 D029 2750 D029 2773 D029 2863 D029 2900 D029 5212 D029 5213 D029 5214 D029 5215 D029 5218 D362 1140 D362 5131 D362 5132 D362 5170 G020 1160 G020 1332 G021 9350 G024 1314 G029 1980

Harness: Sensor: Paper Feed Harness: Sensor: Original Table Decal: Side Fence Decal: Side Fence Decal: Misfeed Removal: Original Decal: Misfeed Removal: Original Decal: Display: Misfeed Removal: P1 Decal: Display: Misfeed Removal: P1 Decal: Display: Misfeed Removal: P2 Decal: Display: Misfeed Removal: P2 Decal: Display: Misfeed Removal: P3 Decal: Display: Misfeed Removal: P3 Screw: Fix: Hinge Decal - Scale Decal - Scale Seal: Guard: Exposure Glass: Document Feeder Manual Feed Table Paper Feed Unit Harness - Paper Feed Unit Release Shaft Paper Tray: No.2: Ass'y Harness: SIO: Sensor Harness: SIO: ARDF Harness: SIO: Lamp Regulator Harness: SIO: STM Harness: Lamp: Connecting HDD Bracket Cable - HDD Power Harness - HDD PCB - HDD Snap Ring Hinge - Front Cover Loop Back Connector Pulley Pin Decal - LD

D009/D011/D012/D013/D091/D092

Page and Index No.

Part No. G029 1980 G038 1299 G052 4892 G052 4892 G060 2652 G060 2932 G065 2308 G065 2354 G065 2681 G065 2681 G065 2767 G065 2774 G065 2775 G065 2776 G080 2682 G080 2900 G102 3837 G404 2810 G570 1133 G570 1160 G570 1225 G570 2832 G570 2833 G570 2834 G790 2329

21 - 16 19 - 22 19 - 16 151 - 14 151 - 17 21 - 3 19 - 5 151 - 15 25 - 17 151 - 16 31 - 19 151 - 18 19 - 3 151 - 27 41 - 22 41 - 23 55 - 14 53 - * 53 - 3 51 - 12 51 - * 41 - 15 41 - 18 47 - 9 47 - 17 47 - 27 107 - 12 107 - 13 107 - 14 107 - 18 31 - 12 13 - 13 153 - 10 67 - 13 49 - 3

H020 2318 H053 2208 H053 2208 H511 5007 J503 3116

20

Description Decal - LD Rivet - 5 Discharge Brush: Exit: Small Discharge Brush: Exit: Small Bushing - M4 Pick-up Arm - Manual Feed Electrode Plate: Charge: Rear Electrode Plate: Charge: Front Snap Ring - M6 Snap Ring - M6 Lever - Feed Pressure Lever Link Lever Release Lever Bushing: Feed Torque Limiter Stopper: Blade Spring Plate - 2nd Mirror Timing Pulley 73 Spacer Bushing Sensor Shielding Plate Guide - High Voltage Supply Cord Pulley Holder Pulley - High Voltage Supply Cord Brush Roller: Cleaner: Charge: AMABUKI: Ass'y Rivet - NRP345 Bushing - M4 Bushing - M4 Stamp Timing Belt: 40S2M128

Page and Index No. 151 - 23 13 - 31 23 - 39 29 - 4 85 - 3 57 - 13 65 - 31 65 - 17 65 - 18 63 - 3 53 - 24 53 - 32 53 - 38 53 - 37 57 - 28 57 - 40 69 - 11 43 - 8 47 - 7 47 - 4 33 - 6 43 - 13 43 - 12 43 - 14 65 47 87 89 13 33 -

46 28 8 4 33 5

Parts Index

Part No.

M308 5130

Description

HDD: 80GB: MHz2080BH: FUJITSU

D009/D011/D012/D013/D091/D092

Page and Index No.

Part No.

AA04 3320 AA04 3321 AA04 3322 AA04 3323 AA04 3328 AA04 3585 AA04 3601 AA04 3656 AA04 3658 AA06 0691

107 - 11

21

Description

Timing Belt: 40S1.5M150 Timing Belt: 40S1.5M378 Timing Belt: 40S1.5M157.5 Timing Belt: 40S2M120 Timing Belt: 40S2M130 Timing Belt: 40S3M162 Timing Belt - B40S2M118 Timing Belt - 60S3M177 Timing Belt - 60S2M300 Tension Spring

Page and Index No.

35 31 35 33 23 97 95 91 93 53 -

9 5 17 9 9 7 5 31 27 23

Parts Index

Part No. AA06 0693 AA06 0842 AA06 0842 AA06 0842 AA06 0843 AA06 0872 AA06 0948 AA06 0979 AA06 0980 AA06 1003 AA06 1014 AA06 1020 AA06 1022 AA06 1023 AA06 1024 AA06 1099 AA06 1100 AA06 2258 AA06 2259 AA06 2260 AA06 2262 AA06 2300 AA06 2310 AA06 2348 AA06 3303 AA06 3432 AA06 3435 AA06 3441 AA06 3445 AA06 3447 AA06 3448 AA06 3499 AA06 3566 AA06 3568 AA06 3648

Description Tension Spring Tension Spring Tension Spring Tension Spring Tension Spring Spring Tension Spring: Stripper Pawls: 50mN Tension Spring: Tension: 14720mN Tension Spring: Tension: 11300mN Tension Spring: Side Fence: Rear Tension Spring: Grip Spring: Release: Transfer Belt Spring - Driven Roller Compression Spring - Knob Tension Spring - Pressure Compression Spring: Cleaning Roller Spring: Pressure: Cleaning Blade Spring: Pressure: Cleaning Blade: No.2 Spring - Release Tension Spring Tension Spring Tension Spring Pressure Spring Pressure Spring Pressure Spring Spring - Intermediate Drawer Compression Spring: Paper Feed: t Compression Spring Spring - Laser Diode Unit Spring - Transfer Belt Pressure Spring - Transfer Unit Pressure Spring Pressure Spring Pressure Spring Pressure Spring

D009/D011/D012/D013/D091/D092

Page and Index No. 53 35 31 37 25 57 73 47 43 51 51 67 71 71 73 71 69 65 53 31 21 65 65 65 83 93 23 23 49 69 83 57 61 57 65 -


31 12 4 20 25 43 16 30 18 14 11 7 10 4 10 15 3 47 39 9 9 27 42 26 24 22 20 36 10 9 17 42 8 12 20

22

Description Spring Spring: Pressure Torsion Spring: Pickup: Pressure Spring Spring Bushing - M4 Bushing - M4 Bushing: 6x8x5 Bushing - 12x18x5.5 Bushing: DIA6 Bushing: Flange Type: DIA6 Bushing - 8mm Bushing - Cleaning Roller Bushing - Driven Roller Bushing - 4mm Bushing - 6mm Bushing - 7mm Bushing - 6mm Bushing - M4 Bushing - M8 Bushing - 8mm Bushing - 6x10x6 Bushing - 6x10x6 Bushing - 6x10x6 Bushing - 6x10x6 Bushing - 6x10x6 Bushing - 6x10x6 Bushing - 6x10x6 Bushing - 6x10x6 Bushing - 6x10x6 Bushing - 8x12x7 Bushing - 8x12x7 Bushing - 6x10x6 Bushing - 8x12x7 One-way Clutch

Page and Index No. 75 25 23 69 69 77 83 25 63 23 97 91 71 71 75 75 75 75 67 59 59 33 31 53 57 89 83 25 23 57 23 81 53 47 57 -

7 9 25 18 20 9 25 24 35 34 13 29 16 11 23 19 13 17 3 10 24 12 13 20 7 6 10 10 3 23 18 3 11 2 30

Parts Index


Description Retaining Ring C - Separate Retaining Ring C - Separate Retaining Ring C - Separate Rubber Bushing - 6 45HS Rubber Bushing - 6 45HS Rubber Bushing - 6 45HS Spacer Spacer - M6 Shaft: Feed Shaft: Separator: Drive Stepped Screw Stepped Screw - M4 Shoulder Screw - M3 Shoulder Screw - M3 Shoulder Screw - M3 Shoulder Screw - M3 Shoulder Screw - M3 Screw: DIA10: M3x8 Screw Screw - M3 Screw - M3 Stepped Screw Pin: Guide Plate: Paper Feed Shaft: Cleaner Screw: Point Screw: Point Screw: Drawer Screw: 6x1.7 Screw: A Screw - Scale Tapping Screw Stepped Screw - M3 Parallel Pin - 2x12mm Seal - Cleaning Pressure Seal - Toner Supply Unit Cover

D009/D011/D012/D013/D091/D092

Page and Index No.

Part No. AA15 3095 AA16 1163 AA16 1164 AA16 1167 AB01 0140 AB01 0141 AB01 0156 AB01 0157 AB01 0171 AB01 0172 AB01 0173 AB01 0174 AB01 0175 AB01 0176 AB01 0177 AB01 0178 AB01 0379 AB01 1218 AB01 1223 AB01 1252 AB01 1258 AB01 1259 AB01 1282 AB01 1379 AB01 1380 AB01 1387 AB01 1416 AB01 1523 AB01 1524 AB01 1525 AB01 1526 AB01 1527 AB01 1528 AB01 4060 AB01 4061

57 - 5 83 - 22 53 - 16 33 - 2 97 - 23 81 - 18 23 - 19 91 - 3 57 - 8 57 - 38 85 - 25 109 - 10 73 - 45 71 - 19 41 - 12 71 - 21 39 - 11 65 - 39 27 - 10 95 - 15 99 - 11 91 - 10 21 - 14 21 - 13 31 - 14 39 - 7 73 - 8 37 - 17 81 - 1 75 - 1 25 - 5 107 - 17 93 - 17 69 - 27 61 - 9

23

Description Shield - Development - Center Cushion Cushion: Stepper Motor Rubber Cushion Gear - 90Z Gear - 46Z Gear: Separate: Drive Gear: Separate: Drive Gear - 40Z Gear - 24Z/25Z Gear - 60Z Gear - 20Z/50Z Gear - 24Z Gear - 24Z Gear - 32Z Worm Gear Gear: Drum Gear - Roller Clutch Idler Gear - 25Z Gear - 20Z Gear - 38Z Gear - 32Z Gear - 31Z Gear - 19Z Cam - Cleaning Blade Gear - 23Z Gear - 20Z Gear - 24Z Gear - 36Z Gear - 32Z Gear - 24Z Gear - 14Z/32Z Gear - 14Z/32Z Gear - 21Z Gear - 13Z

Page and Index No. 63 - 18 109 - 5 97 - 15 107 - 16 93 - 25 93 - 15 53 - 33 53 - 30 73 - 39 73 - 34 75 - 20 75 - 5 75 - 6 75 - 22 75 - 16 75 - 15 93 - 9 53 - 19 57 - 45 53 - 15 97 - 6 97 - 9 67 - 14 65 - 29 65 - 28 57 - 10 57 - 36 91 - 18 91 - 19 91 - 21 91 - 20 91 - 22 91 - 23 63 - 9 63 - 7

Parts Index

Part No. AB01 4062 AB01 4161 AB01 4280 AB01 4281 AB01 4282 AB01 4283 AB01 4284 AB01 7493 AB01 7699 AB01 7743 AB01 7752 AB03 0744 AB03 0781 AB03 0815 AB03 0820 AB03 0821 AC01 5025 AC03 0142 AD02 5021 AD02 7012 AD04 1105 AD04 1135 AE01 0099 AE02 0199 AE03 0098 AE03 0099 AE04 0099 AE04 2098 AE04 4099 AE04 5099 AF01 3006 AF01 3016 AF03 0049 AF03 0090 AF03 1046

Description Gear - 17Z/25Z Reverse Roller Gear Gear - 26Z/90Z Gear - 40Z Gear - 26Z/30Z Gear - 24Z Gear - 24Z Gear Pulley Gear - 33Z/44Z Gear - 20Z Gear - 27TZ/42Z Timing Pulley - 27Z/40T Timing Pulley - 28Z/30T Timing Pulley - 24T Pulley - 31T Pulley - 31T Shield Glass 1st Mirror Pick-Off Pawl Roller: Charge: Apply Cleaning Blade: No.2: Ass'y Cleaning Blade - Transfer Belt Hot Roller Pressure Roller Ball Bearing - 8x22x7 Ball Bearing - 30x42x7 Holder Roller Cleaning Roller: Ass'y Stripper Pawls Cleaning Web Bottom Plate Pad Bottom Plate Pad Pick-up Roller Paper Feed Roller: Pickup Feed Roller - Manual Feed

D009/D011/D012/D013/D091/D092

Page and Index No. 63 81 91 91 91 91 91 97 97 91 93 95 97 91 93 93 49 43 65 65 65 69 73 73 73 73 75 71 73 75 51 57 57 53 57 -

Part No. AF03 1090 AF03 2046 AF03 2090 AF04 0571 AF04 0575 AF04 0599 AF04 0601 AG07 0513 AG07 0514 AG07 1012 AW01 0091 AW01 0107 AW01 0107 AW01 0107 AW01 0107 AW01 0122 AW01 0127 AW01 0128 AW01 0129 AW01 0133 AW01 0134 AW01 0140 AW01 0199 AW02 0145 AW02 0145 AW02 0145 AW02 0145 AW02 0146 AW02 0150 AW02 0154 AW02 0155 AW11 0098 AW11 0099 AW50 0023 AW50 0031

10 11 6 7 11 5 4 18 5 32 12 4 8 30 16 14 4 6 44 37 35 1 40 43 4 3 9 17 17 18 5 27 11 14 6

24

Description Paper Feed Roller: Feed Separation Roller - Manual Feed Paper Feed Roller: Separate Guide Roller Driven Roller Pressure Roller: 15 Pressure Roller: Entrance Magnet Catch Magnet Catch Magnet Catch: Ass'y Photo Reflection Sensor Paper Feed Sensor Paper Feed Sensor Paper Feed Sensor Paper Feed Sensor Paper Feed Sensor Paper Feed Sensor Paper Feed Sensor Photo Reflection Sensor Original Sensor - 66mm Original Sensor - 48mm Original Sensor - 76mm Entrance Sensor Photointerruptor: Flat Photointerruptor: Flat Photointerruptor: Flat Photointerruptor: Flat Photointerruptor: Flat: PICH2mm: M4 Photointerruptor: Flat: 7mm Photointerruptor: Entrance Photointerruptor: Paper Size Sensor Thermostat - 220C Thermostat - 219C Push Switch Paper Size Sensor

Page and Index No. 53 57 53 89 89 89 89 19 77 13 21 57 59 87 81 53 87 53 19 45 45 47 99 87 41 81 53 41 91 21 21 73 73 99 55 -

18 39 27 13 8 26 24 26 11 4 20 2 20 6 5 7 13 5 23 3 3 20 19 19 14 9 2 16 14 17 18 21 23 7 10

Parts Index

Part No. AW50 0035 AW50 0038 AX04 0154 AX04 0167 AX05 0292 AX06 0353 AX06 0354 AX06 0355 AX06 0355 AX06 0356 AX20 0289 AX20 2007 AX31 0045 AX43 0112 AX43 0113 AX44 0252 AX44 0253 AX64 0159 AX64 0164 AX64 0164 AX64 0194 AX64 0195 AZ24 0139 AZ24 0141 AZ32 0145 AZ50 0070 AZ50 0074 BC01 2002 GA14 3003 GW01 0007 GW01 0007 GW01 0007 GW01 0007 GW02 0020 GW02 0020

Description Paper End Sensor Push Switch: Paper Size Sensor DC Motor 24V Motor: DC5V 0.71W Toner Bottle Motor - DC 2.4W Polygon Mirror Motor - DC 16.8W Brushless Motor - DC 6W Brushless Motor - DC 11W Brushless Motor - DC 11W Brushless Motor: DC24V 18W Magnetic Clutch - 32Z Magnetic Clutch Total Counter: 7FIG: 24V Heater - 120V 550W Heater - 230V 550W Heater - 120V 750W Heater - 230V 750W Fan Motor MM80 Fan Motor: 15mm: 24V Fan Motor: 15mm: 24V Fan Motor - DC 2.16W Fan Motor - DC 2.16W Power Supply Unit - 120V Power Supply Unit - 230V Power Pack: CBT Stabilizer - CS Stabilizer - MS Exposure Glass: Sheet Through: 344x20 Screw: MM5: 2.5mm Photo Reflection Sensor: Exit Photo Reflection Sensor: Exit Photo Reflection Sensor: Exit Photo Reflection Sensor: Exit Photointerruptor: LG248NL1 Photointerruptor: LG248NL1

D009/D011/D012/D013/D091/D092

Page and Index No.

Part No.

57 - 21 95 - 11 95 - 8 91 - 26 99 - 2 49 - 5 93 - 4 91 - 27 93 - 5 91 - 13 97 - 11 57 - 31 97 - 24 73 - 41 73 - 41 73 - 42 73 - 42 103 - 1 47 - 23 45 - 11 101 - 19 107 - 25 105 - 21 105 - 21 93 - 2 47 - 8 47 - 8 41 - 4 21 - 23 27 - 18 19 - 20 29 - 6 21 - 19 37 - 13 21 - 21

25

Description

Page and Index No.

GW02 0020 GW23 0001 GX64 0028

Photointerruptor: LG248NL1 Toner End Sensor Fan Motor DC24V 1.92W

33 - 8 69 - 14 37 - 8

VSSM 9000

Digital Multimeter - FLUKE 187

153 - 3

Parts Index

Part No.

0314 0120N 0353 0030N 0353 0040N 0353 0040N 0353 0040N 0353 0050N 0353 0050N 0353 0050N 0353 0050N 0353 0060N 0353 0060N 0353 0060N

Description

Screw - M4x12 Screw: M3x3 Screw - M3x4 Screw - M3x4 Screw - M3x4 Screw-M3x5 Screw-M3x5 Screw-M3x5 Screw-M3x5 Bind Screw - M3x6 Bind Screw - M3x6 Bind Screw - M3x6

D009/D011/D012/D013/D091/D092

Page and Index No.

Part No. 0353 0080N 0353 0100N 0353 0100N 0360 3006N 0360 3006N 0360 3006N 0360 3006N 0360 3006N 0360 3006N 0360 3030N 0434 0100N 0450 3006N 0450 3006N 0450 3008N 0450 3008N 0450 3008N 0450 3008N 0450 3008N 0450 3008N 0450 3008N 0450 3008N 0450 3008N 0450 3008N 0450 3008N 0450 3008N 0450 3008N 0450 3008N 0450 3008N 0450 3008P 0450 3010N 0450 3010N 0450 3010N 0450 3010N 0450 3010N 0450 3012N

41 - 105 15 - 105 89 - 102 57 - 104 25 - 102 43 - 102 15 - 106 75 - 101 71 - 102 33 - 102 17 - 102 107 -105

26

Description Screw: M3x8 Screw-M3x10 Screw-M3x10 Screw - M3x6 Screw - M3x6 Screw - M3x6 Screw - M3x6 Screw - M3x6 Screw - M3x6 Screw: M3x30 Tapping Screw - 4x10 Tapping Screw - M3x6 Tapping Screw - M3x6 Tapping Screw - M3x8 Tapping Screw - M3x8 Tapping Screw - M3x8 Tapping Screw - M3x8 Tapping Screw - M3x8 Tapping Screw - M3x8 Tapping Screw - M3x8 Tapping Screw - M3x8 Tapping Screw - M3x8 Tapping Screw - M3x8 Tapping Screw - M3x8 Tapping Screw - M3x8 Tapping Screw - M3x8 Tapping Screw - M3x8 Tapping Screw - M3x8 Tapping Screw 3x8 Tapping Screw - M3x10 Tapping Screw - M3x10 Tapping Screw - M3x10 Tapping Screw - M3x10 Tapping Screw - M3x10 Tapping Screw: 3x12

Page and Index No. 97 - 108 81 - 103 87 - 104 73 - 101 71 - 101 65 - 105 75 - 102 107 -101 57 - 107 107 -106 97 - 106 59 - 101 87 - 109 79 - 101 37 - 102 85 - 102 49 - 102 27 - 101 19 - 102 83 - 101 25 - 103 29 - 102 101 -103 53 - 102 55 - 101 57 - 102 21 - 102 23 - 101 89 - 105 99 - 103 17 - 101 13 - 104 85 - 103 49 - 101 13 - 103

Parts Index

Part No. 0450 3012N 0450 4008N 0451 3006N 0451 3006N 0451 3006N 0451 3006N 0451 3006N 0451 3006N 0451 3006N 0451 3006N 0451 3006N 0451 3006N 0451 3006N 0451 3006N 0451 3006N 0451 3006N 0451 3006N 0451 3006N 0451 3006N 0451 3006N 0451 3006N 0451 3006N 0451 3006N 0451 3006N 0451 3006N 0451 3006N 0451 3006N 0451 3006N 0451 3006N 0451 3008N 0451 3008N 0451 3008N 0451 3008N 0451 3008N 0451 3008N

Description Tapping Screw: 3x12 Tapping Screw - M4x8 Tapping Screw - 3x6 Tapping Screw - 3x6 Tapping Screw - 3x6 Tapping Screw - 3x6 Tapping Screw - 3x6 Tapping Screw - 3x6 Tapping Screw - 3x6 Tapping Screw - 3x6 Tapping Screw - 3x6 Tapping Screw - 3x6 Tapping Screw - 3x6 Tapping Screw - 3x6 Tapping Screw - 3x6 Tapping Screw - 3x6 Tapping Screw - 3x6 Tapping Screw - 3x6 Tapping Screw - 3x6 Tapping Screw - 3x6 Tapping Screw - 3x6 Tapping Screw - 3x6 Tapping Screw - 3x6 Tapping Screw - 3x6 Tapping Screw - 3x6 Tapping Screw - 3x6 Tapping Screw - 3x6 Tapping Screw - 3x6 Tapping Screw - 3x6 Tapping Screw - M3x8 Tapping Screw - M3x8 Tapping Screw - M3x8 Tapping Screw - M3x8 Tapping Screw - M3x8 Tapping Screw - M3x8

D009/D011/D012/D013/D091/D092

Page and Index No.

Part No.

51 - 103 51 - 101 77 - 101 47 - 101 19 - 101 45 - 101 85 - 101 53 - 101 87 - 101 43 - 101 57 - 101 105 -102 41 - 101 39 - 101 97 - 101 37 - 101 21 - 103 107 -102 67 - 102 31 - 101 23 - 102 29 - 101 69 - 101 27 - 103 35 - 101 81 - 101 89 - 101 33 - 101 25 - 101 93 - 110 17 - 105 15 - 101 77 - 103 99 - 104 109 -102

0451 3008N 0451 3008N 0451 3008N 0451 3008N 0451 3010N 0451 3010N 0451 3020N 0451 3025N 0451 4008N 0452 3006N 0452 3006N 0452 3008N 0452 3008N 0452 3008N 0452 3010N 0453 3006N 0453 3006N 0453 3006N 0453 3006N 0453 3008N 0453 3008N 0453 4006N 0453 4006N 0454 3006Q 0454 3006Q 0454 3006Q 0454 3006Q 0454 3006Q 0454 3006Q 0454 3006Q 0454 3006Q 0454 3006Q 0454 3006Q 0454 3006Q 0454 3006Q

27

Description Tapping Screw - M3x8 Tapping Screw - M3x8 Tapping Screw - M3x8 Tapping Screw - M3x8 Tapping Screw: 3x10 Tapping Screw: 3x10 Tapping Screw: 3x20 Tapping Screw: M3x25 Tapping Screw: 4x8 Binding Self-tapping Screw: 3x6 Binding Self-tapping Screw: 3x6 Tapping Screw - M3x8 Tapping Screw - M3x8 Tapping Screw - M3x8 Binding Self-tapping Screw: 3x10 Tapping Screw - M3x6 Tapping Screw - M3x6 Tapping Screw - M3x6 Tapping Screw - M3x6 Binding Self Tapping Screw: 3x8 Binding Self Tapping Screw: 3x8 Binding Self Tapping Screw: 4x6 Binding Self Tapping Screw: 4x6 Tapping Screw - M3x6 Tapping Screw - M3x6 Tapping Screw - M3x6 Tapping Screw - M3x6 Tapping Screw - M3x6 Tapping Screw - M3x6 Tapping Screw - M3x6 Tapping Screw - M3x6 Tapping Screw - M3x6 Tapping Screw - M3x6 Tapping Screw - M3x6 Tapping Screw - M3x6

Page and Index No. 41 - 102 105 -109 57 - 106 13 - 101 41 - 103 21 - 101 37 - 108 101 -105 97 - 103 27 - 104 67 - 101 69 - 103 107 -103 57 - 103 61 - 101 27 - 102 87 - 105 59 - 104 41 - 104 41 - 106 51 - 102 35 - 102 37 - 103 109 -101 103 -101 61 - 103 39 - 102 97 - 102 65 - 101 63 - 101 87 - 102 95 - 101 105 -101 93 - 101 59 - 102

Parts Index

Part No. 0454 3006Q 0454 3006Q 0454 3006Q 0454 3006Q 0454 3006Q 0454 3006Q 0454 3006Q 0454 3006Q 0454 3006Q 0454 3008Q 0454 3008Q 0454 3008Q 0454 3008Q 0454 3008Q 0454 3008Q 0454 3008Q 0454 3008Q 0454 3008Q 0454 3008Q 0454 3020Q 0454 3020Q 0456 3008N 0456 3008N 0456 3008N 0456 3008N 0457 3008N 0573 0030E 0632 0100G 0632 0100G 0632 0120G 0712 0030N 0720 0025E 0720 0030E 0720 0030E 0720 0030E

Description Tapping Screw - M3x6 Tapping Screw - M3x6 Tapping Screw - M3x6 Tapping Screw - M3x6 Tapping Screw - M3x6 Tapping Screw - M3x6 Tapping Screw - M3x6 Tapping Screw - M3x6 Tapping Screw - M3x6 Tapping Screw: 3x8 Tapping Screw: 3x8 Tapping Screw: 3x8 Tapping Screw: 3x8 Tapping Screw: 3x8 Tapping Screw: 3x8 Tapping Screw: 3x8 Tapping Screw: 3x8 Tapping Screw: 3x8 Tapping Screw: 3x8 Tapping Screw: 3x20 Tapping Screw: 3x20 Tapping Screw - M3x8 Tapping Screw - M3x8 Tapping Screw - M3x8 Tapping Screw - M3x8 Tapping Screw - M3x8 Hexagonal Set Screw - M3x3 Pin - 2x10mm Pin - 2x10mm Parallel Pin - 2x12 Hexagonal Nut: M3 Retaining Ring - M2.5 Retaining Ring - M3 Retaining Ring - M3 Retaining Ring - M3

D009/D011/D012/D013/D091/D092

Page and Index No.

Part No.

73 - 105 101 -102 47 - 104 45 - 102 91 - 101 49 - 106 107 -104 81 - 102 15 - 103 101 -101 99 - 102 13 - 102 15 - 102 99 - 101 103 -102 95 - 102 57 - 105 91 - 104 53 - 106 45 - 103 93 - 103 69 - 102 63 - 102 65 - 102 61 - 102 65 - 103 75 - 104 23 - 106 29 - 106 25 - 104 49 - 105 89 - 103 73 - 107 63 - 103 81 - 106

0720 0030E 0720 0030E 0720 0030E 0720 0030E 0720 0030E 0720 0040E 0720 0040E 0720 0040E 0720 0040E 0720 0040E 0720 0040E 0720 0040E 0720 0040E 0720 0040E 0720 0040E 0720 0040E 0720 0040E 0720 0060E 0720 0060E 0720 0060E 0720 0080E 0720 0080E 0725 0110E 0733 0408 0740 3506 0740 3808 0741 3506 0741 3506 0741 3506 0741 3506 0742 3808 0802 5299 0802 5299 0802 5299 0802 5299

28

Description Retaining Ring - M3 Retaining Ring - M3 Retaining Ring - M3 Retaining Ring - M3 Retaining Ring - M3 Retaining Ring - M4 Retaining Ring - M4 Retaining Ring - M4 Retaining Ring - M4 Retaining Ring - M4 Retaining Ring - M4 Retaining Ring - M4 Retaining Ring - M4 Retaining Ring - M4 Retaining Ring - M4 Retaining Ring - M4 Retaining Ring - M4 Retaining Ring - M6 Retaining Ring - M6 Retaining Ring - M6 Retaining Ring - M8 Retaining Ring - M8 C Ring - M11 Bushing: 4x8 Ball Bearing - 6x12x4 mm Ball Bearing - 8x16x5mm Ball Bearing - 6x12x4 mm Ball Bearing - 6x12x4 mm Ball Bearing - 6x12x4 mm Ball Bearing - 6x12x4 mm Ball Bearing - 8x16x5 Tapping Screw - M3x8 Tapping Screw - M3x8 Tapping Screw - M3x8 Tapping Screw - M3x8

Page and Index No. 77 - 102 89 - 104 83 - 103 75 - 103 31 - 104 35 - 103 81 - 104 43 - 104 97 - 107 53 - 104 85 - 107 87 - 106 23 - 103 31 - 102 25 - 105 29 - 103 65 - 104 91 - 102 23 - 104 31 - 103 73 - 108 51 - 104 63 - 104 73 - 106 29 - 105 93 - 105 29 - 104 31 - 106 35 - 104 23 - 108 31 - 105 47 - 103 109 -106 43 - 103 99 - 105

Parts Index

Part No. 0802 5305 0804 6123 0804 6123 0805 0088 0805 0088 0805 0088 0805 0088 0805 0088 0805 0088 0805 0089 0805 0089 0805 0089 0805 0089 0805 0089 0805 0089 0805 0089 0805 0089 0805 0089 0805 0092 0805 0092 0805 0092 0805 0092 0805 0097 0951 3008N 0951 3020N 0954 3008N 0954 3010N 0954 3010N 0957 4008N 0957 4008N 0957 4008N 1100 1475 1101 0328 1102 4203 1102 4203

Description Tapping Screw - M3x6 Hexagonal Bolt: W/Washer: M3x8 Hexagonal Bolt: W/Washer: M3x8 Retaining Ring - M6 Retaining Ring - M6 Retaining Ring - M6 Retaining Ring - M6 Retaining Ring - M6 Retaining Ring - M6 Retaining Ring - M4 Retaining Ring - M4 Retaining Ring - M4 Retaining Ring - M4 Retaining Ring - M4 Retaining Ring - M4 Retaining Ring - M4 Retaining Ring - M4 Retaining Ring - M4 Retaining Ring - 3M Retaining Ring - 3M Retaining Ring - 3M Retaining Ring - 3M Ring Separator Screw: Polished Round: M3x8 Screw: Polished Round: M3x20 Screw - M3x8 Screw: Polished Round/Spring: M3x10 Screw: Polished Round/Spring: M3x10 Screw: Small Round/Spring: M4x8 Screw: Small Round/Spring: M4x8 Screw: Small Round/Spring: M4x8 Test Pin Connector Pin CT Header - 4P CT Header - 4P

D009/D011/D012/D013/D091/D092

Page and Index No.

Part No. 1102 4203 1102 4204 1102 4204 1102 4645 1102 4645 1102 6246 1102 6248 1102 6300 1102 6311 1102 6397 1102 6594 1102 6790 1102 6893 1102 7358 1102 7358 1102 7615 1102 8212 1102 8329 1102 8466 1102 8467 1102 8470 1102 8471 1102 8474 1102 8475 1102 8477 1102 8480 1102 8481 1102 8484 1102 8485 1102 8488 1102 8489 1102 8489 1102 8492 1102 8502 1102 8534

109 -104 73 - 102 47 - 102 109 -103 57 - 109 47 - 110 23 - 105 81 - 108 93 - 104 83 - 102 91 - 105 53 - 103 55 - 102 57 - 108 97 - 104 93 - 106 59 - 103 25 - 106 101 -104 89 - 106 79 - 102 87 - 103 79 - 103 49 - 103 49 - 104 85 - 104 93 - 107 73 - 103 91 - 103 73 - 104 105 -103 145 -101 145 -102 135 -101 145 -103

29

Description CT Header - 4P CT Header - 5P CT Header - 5P CT Connector - 4P CT Connector - 4P Relay Connector - 4P Connector - 5P Connector - 7P Connector - 4P Box Header Connector - 10P Connector - 100R-LT-N1 Connector: 53314-3065 (Color Only) Connector - 80P Connector - 80P Connector - B8B-XH-A Connector: TX24-50R-10ST-H1E Connector - USB - UBB-4R-D14C Connector: 55447-0210 Connector - 55447-0370 Connector - 55447-0610 Connector - 55447-071 Connector - 5 P Connector - 11P Connector - 13P Connector - 55447-1610 Connector - 55447-1760 Connector: 55447-2080 Connector - 55451-2210 Connector - 5451-2810 Connector - 55451-3010 Connector - 55451-3010 Connector - 55451-3610 Connector - 54679-1615 Connector - QR/P17-14S-B

Page and Index No. 139 -101 135 -102 139 -102 139 -103 135 -103 107 -108 57 - 111 145 -104 145 -105 145 -106 145 -107 123 -101 135 -104 135 -105 139 -104 123 -102 123 -103 123 -104 145 -108 145 -109 145 -110 145 -111 145 -112 145 -113 145 -114 145 -115 145 -116 139 -105 145 -117 145 -118 135 -106 139 -106 145 -119 105 -107 103 -106

Parts Index

Part No. 1102 8560 1102 8560 1102 9108 1102 9109 1102 9114 1102 9116 1102 9116 1102 9117 1102 9120 1102 9121 1102 9336 1102 9782 1102 9890 1102 9956 1103 3158 1103 3158 1103 3167 1103 3167 1103 3175 1103 3175 1103 3188 1103 3188 1103 3188 1103 3736 1103 3736 1103 4043 1103 4234 1104 0821 1104 0821 1104 0821 1105 0032 1105 0195 1105 0367 1105 0367 1105 0460

Description Connector - KX14-60K5D1E Connector - KX14-60K5D1E Connector - 353297-3 Connector - 353297-4 Connector - 353297-1 Connector - 353297-5 Connector - 353297-5 Connector - 353297-8 Connector - 2-292208-2 Connector: 2-353308-4 Connector: FPS009-2300-0 Connector: 51405-1819 Connector: 5-1605706-2 Connector: UBA-4R-D14T-4D(LF)(SN) Connector - FH12-10S-0.5SV(89) Connector - FH12-10S-0.5SV(89) Connector: FH12-28S-0.5SH(89) Connector: FH12-28S-0.5SH(89) Connector - FH12-40S-0.5SV(89) Connector - FH12-40S-0.5SV(89) Connector: FH12S-50S-0.5SH(89) Connector: FH12S-50S-0.5SH(89) Connector: FH12S-50S-0.5SH(89) Connector: FH12S-45S-0.5SH(89) Connector: FH12S-45S-0.5SH(89) Connector: 87825-1001 RHM-176P-SDK11-UH1L1C(LF)(SN) IC Socket: 16008-B0A0020N IC Socket: 16008-B0A0020N IC Socket: 16008-B0A0020N Clamp PCB Stud Spacer Spacer Clamp

D009/D011/D012/D013/D091/D092

Page and Index No.

Part No. 1105 0487 1105 0487 1105 0487 1105 0487 1105 0487 1105 0487 1105 0487 1105 0487 1105 0488 1105 0488 1105 0488 1105 0489 1105 0489 1105 0508 1105 0511 1105 0511 1105 0511 1105 0511 1105 0511 1105 0511 1105 0511 1105 0511 1105 0511 1105 0511 1105 0511 1105 0511 1105 0511 1105 0511 1105 0511 1105 0511 1105 0514 1105 0514 1105 0516 1105 0516 1105 0516

139 -107 135 -107 145 -120 145 -121 145 -122 139 -108 135 -108 145 -123 145 -124 145 -125 123 -106 103 -108 123 -107 123 -108 135 -109 139 -109 135 -110 139 -110 139 -111 135 -111 139 -112 145 -126 135 -112 135 -113 139 -113 123 -109 123 -105 135 -114 139 -114 123 -147 17 - 104 47 - 113 105 -106 93 - 102 47 - 109

30

Description Harness Clamp Harness Clamp Harness Clamp Harness Clamp Harness Clamp Harness Clamp Harness Clamp Harness Clamp Harness Clamp Harness Clamp Harness Clamp Harness Clamp - LWS 1316 Harness Clamp - LWS 1316 Harness Clamp - LWS-0711 Harness Clamp - LWS-0306ZC Harness Clamp - LWS-0306ZC Harness Clamp - LWS-0306ZC Harness Clamp - LWS-0306ZC Harness Clamp - LWS-0306ZC Harness Clamp - LWS-0306ZC Harness Clamp - LWS-0306ZC Harness Clamp - LWS-0306ZC Harness Clamp - LWS-0306ZC Harness Clamp - LWS-0306ZC Harness Clamp - LWS-0306ZC Harness Clamp - LWS-0306ZC Harness Clamp - LWS-0306ZC Harness Clamp - LWS-0306ZC Harness Clamp - LWS-0306ZC Harness Clamp - LWS-0306ZC Edge Saddle - EDS-0607l Edge Saddle - EDS-0607l Clamp Clamp Clamp

Page and Index No. 61 - 104 105 -104 91 - 108 101 -107 37 - 106 103 -105 85 - 105 107 -107 47 - 107 97 - 105 103 -103 103 -104 105 -105 47 - 111 33 - 103 37 - 104 47 - 112 81 - 105 79 - 104 35 - 105 41 - 108 57 - 113 91 - 106 29 - 108 17 - 103 89 - 108 53 - 105 85 - 106 87 - 107 45 - 105 29 - 107 37 - 107 45 - 106 47 - 105 61 - 105

Parts Index

Part No. 1105 0516 1105 0516 1105 0516 1105 0516 1105 0517 1105 0518 1105 0522 1105 0522 1105 0522 1105 0522 1105 0522 1105 0522 1105 0534 1105 0534 1105 0534 1105 0534 1105 0544 1105 0551 1105 0551 1105 0551 1105 0568 1105 0613 1105 0623 1105 0623 1107 1083 1107 1099 1109 0009 1109 0082 1150 0373 1150 0377 1204 2521 1204 2608 1204 2768 1204 2791 1206 0124

Description Clamp Clamp Clamp Clamp Harness Clamp - LWS-2111Z Edge Saddle - LES-1010 Edge Saddle - LES0510 Edge Saddle - LES0510 Edge Saddle - LES0510 Edge Saddle - LES0510 Edge Saddle - LES0510 Edge Saddle - LES0510 Clamp Clamp Clamp Clamp Edge Saddle: LES-2017 Clamp: LES-0505 Clamp: LES-0505 Clamp: LES-0505 Clamp: LWSS-0504 Clamp: EDS-1010L-V0 Clamp - LBWS-0206S-V0 Clamp - LBWS-0206S-V0 Fuse: SST 4 Fuse SST 5 IC - MINISMDC075-02 Fuse: SMD1812P110TF Power Supply Code: 125V 15A NA Power Supply Code: 250V: 10A: EU Micro Switch Rocker Switch: SDDJE33900 Dip Switch: NDIR-08HT-V DIP Switch: DM-04-V Lithium Cell: CR2032VO4H/Z

D009/D011/D012/D013/D091/D092

Page and Index No.

Part No. 1400 0728 1400 0902 1400 1209 1400 1212 1400 1214 1400 1240 1400 1240 1400 1240 1400 1241 1400 1241 1400 1241 1400 1243 1400 1243 1400 1244 1400 1244 1400 1246 1400 1258 1400 1259 1401 0972 1401 1318 1401 1414 1401 1414 1401 1414 1401 1415 1401 1448 1401 1457 1401 1466 1401 1475 1402 1336 1402 1365 1402 1662 1402 1663 1402 1798 1402 1798 1402 1929

33 - 104 23 - 107 21 - 104 87 - 108 47 - 108 47 - 106 57 - 110 103 -107 41 - 107 37 - 105 91 - 107 109 -105 45 - 104 43 - 105 93 - 108 101 -108 41 - 109 89 - 107 81 - 107 57 - 112 59 - 105 91 - 109 93 - 109 83 - 104 123 -110 123 -111 123 -112 145 -127 13 - 105 13 - 105 101 -106 105 -108 145 -128 123 -113 123 -114

31

Description Transistor - 2SD2170 Transistor - DTA113ZUA Transistor: 2SA1980UF Transistor: 2SA1980UF-Y Transistor: 2SC5343UF-G Transistor: SRC1202UF Transistor: SRC1202UF Transistor: SRC1202UF Transistor: SRC1206UF Transistor: SRC1206UF Transistor: SRC1206UF Transistor: SRC1210UF Transistor: SRC1210UF Transistor: SRA2206UF Transistor: SRA2206UF Transistor: SRC1205UF Transistor: 2SA1980UF-G Transistor: 2SC5343UF-L Transistor-2SB1260 FET - HAT2198R FET: Si3433BDV-E3 FET: Si3433BDV-E3 FET: Si3433BDV-E3 FET: SI3434DV-E3 FET: SI3447BDV-E3 FET: TP8102 FET: SI4800BDY-E3 FET: SI3867DV-E3 Diode - 1SS355 Diode-RB751V-40 Diode: PTZ6.2B Diode - ZTP12B Diode - RSX30 Diode - RSX30 Diode: RB160M-30

Page and Index No. 145 -129 145 -130 145 -131 145 -132 145 -133 135 -115 145 -134 139 -115 135 -116 145 -135 139 -116 139 -117 135 -117 139 -118 135 -118 145 -136 145 -137 145 -138 145 -139 123 -115 135 -119 139 -119 123 -116 123 -117 123 -118 123 -119 123 -120 123 -121 123 -122 123 -123 145 -140 145 -141 135 -120 139 -120 123 -124

Parts Index

Part No. 1402 1932 1402 1952 1402 1996 1402 2039 1403 0953 1403 0978 1403 0978 1403 0978 1403 0996 1403 0996 1403 1131 1404 0360 1407 1535 1407 2187 1407 2187 1407 2219 1407 4840 1407 4840 1407 4840 1407 4919 1407 5009 1407 5010 1407 5190 1407 5192 1407 5300 1407 5344 1407 5346 1407 5346 1407 5347 1407 5347 1407 5347 1407 5351 1407 5351 1407 5351 1407 5351

Description Diode: SDS142WMF Diode - TDZ12 Diode: SDS511Q Diode: RSX301LA-30 LED - SML-310MT LED - SML-310DT LED - SML-310DT LED - SML-310DT LED - SML-310VT LED - SML-310VT LED: SML-311UT Thermistor - 103HT IC - TD62308AP TTLIC - SN74LS07NS TTLIC - SN74LS07NS IC - TD62003AP IC - TC7SH04FU IC - TC7SH04FU IC - TC7SH04FU IC - 74VHCT244 TSSOP CMOS Logic: TC7SET04FU IC - TC7SET08FU CMOS Logic: TC7SZ08FU CMOS Logic: TC7SZ04FU CMOS Logic - 74LVC16244A TSSOP IC - SN74LV02APW IC - SN74LS74ANS IC - SN74LS74ANS IC - SN74LV08APW IC - SN74LV08APW IC - SN74LV08APW IC - SN74LV14APW IC - SN74LV14APW IC - SN74LV14APW IC - SN74LV14APW

D009/D011/D012/D013/D091/D092

Page and Index No.

Part No. 1407 5353 1407 5353 1407 5368 1407 5392 1407 5392 1407 5392 1407 5463 1407 5463 1407 5469 1407 5482 1407 5520 1407 5523 1407 5528 1407 5604 1407 5633 1407 5633 1407 5713 1407 5713 1407 5773 1407 6145 1407 6166 1407 6166 1407 6196 1407 6197 1407 6232 1407 6265 1407 6314 1407 6320 1407 6362 1407 6386 1407 6400 1407 6430 1407 6430 1407 6466 1407 6492

145 -142 145 -143 145 -144 123 -125 123 -126 139 -121 135 -121 123 -127 139 -122 135 -122 123 -128 145 -145 145 -146 145 -147 139 -123 145 -148 135 -123 139 -124 145 -149 123 -129 123 -130 123 -131 123 -132 123 -133 123 -134 145 -150 139 -125 135 -124 135 -125 145 -151 139 -126 135 -126 123 -135 139 -127 145 -152

32

Description IC - SN74LV244APW IC - SN74LV244APW IC - 74LVC245A TSSOP IC: SN74LV541APW IC: SN74LV541APW IC: SN74LV541APW IC - SN74LV245APW IC - SN74LV245APW IC - SN74LV07APW IC - SN74LVC07APW CMOS Logic: SN74LVC125APW ROM - I2C SOP 3V IC - SN74LVC126APW CMOS Logic: SN74LVC16245ADGG IC - SN74LV574APW IC - SN74LV574APW IC: SN74LV06APW IC: SN74LV06APW CMOS Logic: SN74LVC541APW IC: SN74LVC373APW IC - ESOC IC - ESOC Motor Control IC: STK672-610 Driver: M54563P LVDS: THC63LVD104A (Color Only) Real Time Clock: R2025S Motor Control IC: TB6561NG Motor Control IC: MTD1501S-7101 EEPROM: BR24I64-W U: RM7035C-533L-REV1.1 Clock Generator - ICS960013BFLF IC - GAVD Type-R IC - GAVD Type-R Field Memory: 3M: x12: 3.3V (Color Only) Clock Generator - ICS180M-51LF

Page and Index No. 139 -128 135 -127 139 -129 145 -153 139 -130 135 -128 139 -131 135 -129 145 -154 123 -136 123 -137 123 -138 123 -139 123 -140 139 -132 135 -130 135 -131 139 -133 139 -134 123 -141 135 -132 139 -135 145 -155 145 -156 135 -133 123 -142 145 -157 145 -158 105 -110 123 -143 123 -144 135 -134 139 -136 135 -135 145 -159

Parts Index

Part No. 1407 6613 1407 6613 1407 6641 1407 6641 1407 6671 1407 6723 1407 6741 1407 6751 1407 6759 1407 6787 1407 6787 1407 6801 1407 6801 1407 6801 1407 6803 1407 6803 1407 6803 1407 6823 1407 6847 1407 6853 1407 6863 1407 6898 1407 6899 1407 6944 1407 6951 1407 7190 1407 7190 1408 1204 1408 1383 1408 1779 1408 1779 1408 1779 1408 1826 1408 1826 1408 1826

Description Clock Generator: ICS7152M-01LF Clock Generator: ICS7152M-01LF Custom IC: LEO Custom IC: LEO USB Controller: UPD720102GC-YEB-A Custom IC: Cornet LAN Controller LSI: DP83848JSQ/NOPB CMOS Logic: HD74LV1GW07ACM Custom IC: EIO CMOS Logic: TC7SH125FU CMOS Logic: TC7SH125FU CMOS Logic: TC7PA17FU CMOS Logic: TC7PA17FU CMOS Logic: TC7PA17FU CMOS Logic: TC7SZ07FU CMOS Logic: TC7SZ07FU CMOS Logic: TC7SZ07FU Custom IC: GASIU Motor Control IC: STK672-600B-E CMOS Logic: HD74LV1GW17ACM Controller: ST19WP18FT28PVGI CMOS Logic: TC7WH126FK CMOS Logic: TC7WH125FK USB Controller IC: ST72681/R21 CMOS Logic: TC7MBL3245SFK Controller: RB5V871A Controller: RB5V871A IC - TA8083P Regulator - TA7812F IC - R3112Q281A IC - R3112Q281A IC - R3112Q281A IC - R3112Q421A IC - R3112Q421A IC - R3112Q421A

D009/D011/D012/D013/D091/D092

Page and Index No.

Part No. 1408 1826 1408 1829 1408 1829 1408 1850 1408 1850 1408 1907 1408 1907 1408 2024 1408 2024 1408 2029 1408 2030 1408 2053 1408 2062 1408 2087 1408 2088 1408 2088 1408 2122 1408 2180 1408 2449 1408 2463 1408 2468 1408 2484 1408 2524 1408 2524 1503 1004 1503 1110 1503 1110 1503 1138 1503 1215 1503 1215 1503 1355 1503 1362 1503 1363 1503 1379 1600 1880

135 -136 139 -137 135 -137 139 -138 123 -145 123 -146 123 -148 123 -149 145 -160 135 -138 139 -139 139 -140 135 -139 123 -150 135 -140 123 -151 139 -141 139 -142 145 -161 123 -152 123 -153 123 -154 123 -155 123 -156 123 -157 139 -143 135 -141 145 -162 145 -163 139 -144 135 -142 145 -164 123 -158 139 -145 145 -165

33

Description IC - R3112Q421A Op Amp - LM358PW Op Amp - LM358PW Regulator - R1170H181B Regulator - R1170H181B IC: R3112Q451A-FA IC: R3112Q451A-FA IC: R3112Q261A-FA IC: R3112Q261A-FA Comparator: LM2901PW Operational Amplifier - LM224D IC: R3112Q291A-FA IC: R3112Q221A-FA IC: LTC3736EμF#TRPBF IC: LTC3701EGN#TRPBF IC: LTC3701EGN#TRPBF Series Regulator - R1130H331A-FB IC - BD3531F DC/DC Converter: BD9104FVM DDR Terminator - TPS51116PWPG4 IC: R1250V401A-F IC: LTC3808EDE#PBF Series Regulator: R1171S181B-F Series Regulator: R1171S181B-F Oscillator - 19.6608MHz Crystal Oscillator: 28.7MHz Crystal Oscillator: 28.7MHz Crystal Oscillator - 48MHz Crystal Oscillator - 17.5MHz Crystal Oscillator - 17.5MHz Crystal Oscillator: 25MHz Crystal Oscillator: 30MHz Crystal Oscillator: 12MHz Crystal Oscillator: 14.31818MHz Resistor - 25M Ω±1% 1W

Page and Index No. 135 -143 135 -144 139 -146 139 -147 135 -145 135 -146 139 -148 139 -149 135 -147 145 -166 145 -167 123 -159 123 -160 123 -161 139 -150 135 -148 145 -168 123 -162 123 -163 123 -164 145 -169 123 -165 139 -151 135 -149 145 -170 135 -150 139 -152 123 -166 135 -151 139 -153 123 -167 123 -168 123 -169 123 -170 135 -152

Parts Index

Part No. 1600 1880 1601 7887 1601 7896 1601 7898 1601 7913 1601 7914 1601 7959 1601 7981 1604 4661 1604 4728 1604 4728 1604 4825 1604 4968 1604 4968 1604 5186 1604 5186 1604 5452 1604 5524 1604 5669 1604 5670 1604 5724 1605 1124 1605 1124 1605 1124 1605 1137 1605 1148 1605 1148 1605 1148 1605 1176 1605 1176 1605 1197 1605 1199 1605 1200 1605 1201 1605 1201

Description Resistor - 25M Ω±1% 1W Resistor Array - 10K Ω ±5% 1/32W Resistor Array - 56 Ω ±5% 1/32W Resistor Array Resistor 22 Ω ±5% 1/32W Resistor Array - 47 Ω ±5% Resistor Resistor Array - 100K Ω±5%1/16W Capacitor - 100μF ±20% 50V Capacitor - 100μF ±20% 16V Capacitor - 100μF ±20% 16V Capacitor - 220μF ±20% 35V Capacitor: 330μF: ±20%: 6.3V Capacitor: 330μF: ±20%: 6.3V Capacitor: 220μF: ±20%: 10V Capacitor: 220μF: ±20%: 10V Capacitor: 47μF: ±20%: 10V Capacitor - 100μF ±20% 50V Capacitor: 470μF: ±20%: 25V Capacitor: 10μF: ±20%: 25V Capacitor: 100μF: ±20%: 2V Capacitor - 4.7μF +80 -20% 10V Capacitor - 4.7μF +80 -20% 10V Capacitor - 4.7μF +80 -20% 10V Capacitor - 470pF ±10% 50V Capacitor - 0.1μF +80-20% 50V Capacitor - 0.1μF +80-20% 50V Capacitor - 0.1μF +80-20% 50V Ceramic Capacitor 0.47μF +80-20%16V Ceramic Capacitor 0.47μF +80-20%16V Capacitor - 6pF ±0.5pF 50V Capacitor - 8pF ±0.5pF 50V Capacitor - 10pF ±0.5pF 50V Capacitor - 12pF ±5% 50V Capacitor - 12pF ±5% 50V

D009/D011/D012/D013/D091/D092

Page and Index No.

Part No. 1605 1202 1605 1202 1605 1204 1605 1205 1605 1205 1605 1206 1605 1206 1605 1206 1605 1206 1605 1207 1605 1207 1605 1207 1605 1208 1605 1208 1605 1208 1605 1210 1605 1210 1605 1211 1605 1211 1605 1211 1605 1212 1605 1212 1605 1212 1605 1212 1605 1214 1605 1214 1605 1214 1605 1214 1605 1216 1605 1216 1605 1216 1605 1216 1605 1218 1605 1221 1605 1221

139 -154 123 -171 123 -172 123 -173 123 -174 123 -175 123 -176 123 -177 145 -171 135 -153 139 -155 145 -172 135 -154 139 -156 135 -155 139 -157 145 -173 145 -174 145 -175 145 -176 123 -178 135 -156 123 -179 139 -158 145 -177 139 -159 135 -157 145 -178 139 -160 135 -158 123 -180 123 -181 123 -182 139 -161 135 -159

34

Description Capacitor - 15pF ±5% 50V Capacitor - 15pF ±5% 50V Capacitor-pF50V Capacitor - 33pF ±5% 50V Capacitor - 33pF ±5% 50V Capacitor - 47pF ±5% 50V Capacitor - 47pF ±5% 50V Capacitor - 47pF ±5% 50V Capacitor - 47pF ±5% 50V Capacitor - 68pF ±5% 50V Capacitor - 68pF ±5% 50V Capacitor - 68pF ±5% 50V Capacitor: 100pF: ±5%: 50V Capacitor: 100pF: ±5%: 50V Capacitor: 100pF: ±5%: 50V Capacitor: 180pF: ±5%: 50V Capacitor: 180pF: ±5%: 50V Capacitor - 220pF ±10% 50V Capacitor - 220pF ±10% 50V Capacitor - 220pF ±10% 50V Capacitor - 470pF ±10% 50V Capacitor - 470pF ±10% 50V Capacitor - 470pF ±10% 50V Capacitor - 470pF ±10% 50V Capacitor - 1000pF ±10% 50V Capacitor - 1000pF ±10% 50V Capacitor - 1000pF ±10% 50V Capacitor - 1000pF ±10% 50V Capacitor - 2200pF±10%50V Capacitor - 2200pF±10%50V Capacitor - 2200pF±10%50V Capacitor - 2200pF±10%50V Capacitor: 4700pF: ±10%: 25V Capacitor - 0.1 μF+80-20%16V Capacitor - 0.1 μF+80-20%16V

Page and Index No. 139 -162 135 -160 123 -183 135 -161 139 -163 135 -162 145 -179 123 -184 139 -164 123 -185 139 -165 135 -163 123 -186 135 -164 139 -166 135 -165 139 -167 135 -166 139 -168 123 -187 123 -188 139 -169 135 -167 145 -180 139 -170 145 -181 135 -168 123 -189 139 -171 123 -190 145 -182 135 -169 123 -191 135 -170 139 -172

Parts Index

Part No. 1605 1221 1605 1221 1605 1234 1605 1234 1605 1240 1605 1240 1605 1240 1605 1281 1605 1282 1605 1282 1605 1284 1605 1285 1605 1285 1605 1289 1605 1289 1605 1289 1605 1291 1605 1293 1605 1293 1605 1294 1605 1295 1605 1295 1605 1295 1605 1296 1605 1296 1605 1296 1605 1299 1605 1299 1605 1301 1605 1303 1605 1303 1605 1303 1605 1305 1605 1305 1605 1306

Description Capacitor - 0.1 μF+80-20%16V Capacitor - 0.1 μF+80-20%16V Capacitor: 4700pF: ±10%: 50V Capacitor: 4700pF: ±10%: 50V Capacitor - 0.01μF ±10% 25V Capacitor - 0.01μF ±10% 25V Capacitor - 0.01μF ±10% 25V Capacitor - 0.22μF ±10% 16V Capacitor: 22μF: +80-20%: 10V Capacitor: 22μF: +80-20%: 10V Capacitor: 1500pF: ±10%: 50V Capacitor - 3300pF ±10% 50V Capacitor - 3300pF ±10% 50V Capacitor - 0.1μF ±10% 10V Capacitor - 0.1μF ±10% 10V Capacitor - 0.1μF ±10% 10V Capacitor: 2.2μF: ±10%: 10V Capacitor - 27pF±5%50V Capacitor - 27pF±5%50V Resistor - 1000pF ±5% 50V Capacitor: 10μF: +80-20%: 10V Capacitor: 10μF: +80-20%: 10V Capacitor: 10μF: +80-20%: 10V Capacitor - 330pF ±10% 50V Capacitor - 330pF ±10% 50V Capacitor - 330pF ±10% 50V Resistor - 56pF ±5% 50V Resistor - 56pF ±5% 50V Capacitor-6800pF ±10% 50V Capacitor - 0.01μF +80-20% 50V Capacitor - 0.01μF +80-20% 50V Capacitor - 0.01μF +80-20% 50V Capacitor - 1μF +80-20% 6.3V Capacitor - 1μF +80-20% 6.3V Capacitor - 1μF ±10% 10V

D009/D011/D012/D013/D091/D092

Page and Index No.

Part No. 1605 1307 1605 1347 1605 1347 1605 1353 1605 1354 1605 1358 1605 1367 1605 1376 1605 1387 1605 1387 1605 1391 1605 1391 1605 1396 1605 1406 1605 1447 1605 1451 1605 1452 1605 1453 1605 1474 1605 1474 1605 1474 1605 1475 1605 1481 1605 1489 1605 1531 1605 1544 1605 1544 1605 1544 1605 1563 1605 1583 1605 1587 1605 1602 1605 1605 1605 1605 1605 1607

123 -192 135 -244 139 -173 145 -183 139 -174 135 -171 123 -193 145 -184 135 -172 139 -175 123 -194 135 -173 139 -176 139 -177 135 -174 123 -195 123 -196 145 -185 123 -197 145 -186 123 -198 139 -178 135 -175 135 -176 139 -179 123 -199 135 -177 139 -180 123 -200 139 -181 135 -178 145 -187 135 -179 139 -182 123 -201

35

Description Capacitor - 2.2μF +80-20% 11V Capacitor - 1μF: +80-20%: 16V Capacitor - 1μF: +80-20%: 16V Capacitor - 0.1μF ±10% 25V Capacitor: 1200pF: ±5%: 50V Capacitor - 10μF ±10% 10V Capacitor - 0.033μF ±10% 16V Capacitor - 0.033μF - ±10%: 25V Capacitor - 0.68μF ±10% 10V Capacitor - 0.68μF ±10% 10V Capacitor - 22μF: ±20%: 6.3V Capacitor - 22μF: ±20%: 6.3V Capacitor - 0.33μF ±10% 50V Capacitor - 10μF ±10% 6.3V Resistor - 470pF ±5% 50V Capacitor: 0.47μF: ±10%: 6.3V Capacitor - 1μF ±10% 6.3V Capacitor: 0.022μF: ±10%: 16V Capacitor - 47μF ±20% 6.3V Capacitor - 47μF ±20% 6.3V Capacitor - 47μF ±20% 6.3V Resistor - 1μF ±10% 16V Capacitor: 1000pF: ±20%: 50V Resistor - 2.2μF ±10% 25V Capacitor: 470pF: ±20%: 50V Resistor - 330pF ±5% 50V Resistor - 330pF ±5% 50V Resistor - 330pF ±5% 50V Capacitor: 10μF: ±10%: 10V Capacitor - 0.1μF: ±10%: 16V Capacitor: 22μF: ±20%: 6.3V Capacitor: 3.3μF: ±10%: 6.3V Capacitor - 4.7μF ±10% 10V Capacitor - 4.7μF ±10% 10V Capacitor: 22μF: +80-20%: 6.3V

Page and Index No. 123 -202 139 -183 135 -180 145 -188 145 -189 123 -203 139 -184 123 -204 135 -181 139 -185 135 -182 139 -186 145 -190 123 -205 145 -191 123 -206 123 -207 139 -187 135 -183 123 -208 139 -188 123 -209 145 -192 145 -193 145 -194 135 -184 139 -189 123 -210 123 -211 123 -212 123 -213 123 -214 145 -195 123 -215 123 -216

Parts Index

Part No. 1605 1681 1605 1689 1605 1692 1605 1692 1606 2319 1607 0861 1607 0861 1607 1002 1607 1002 1607 1014 1607 1051 1607 1061 1607 1108 1607 1108 1607 1199 1607 1222 1607 1222 1607 1340 1607 1340 1607 1351 1607 1351 1607 1477 1607 1546 1607 1546 1607 1556 1607 1567 1607 1572 1607 1637 1607 1680 1607 1680 1607 1827 1607 1827 1607 1827 1607 1946 1609 0005

Description Capacitor: 22μF: ±20%: 10V Capacitor: 100μF: ±20%: 6.3V Capacitor: 47pF: ±10%: 50V Capacitor: 47pF: ±10%: 50V Capacitor: 100μF: ±20%: 6.3V Filter - BK2125HS101 Filter - BK2125HS101 IC - NFM60R30T222 IC - NFM60R30T222 EMI Filter - BLM11P600SPB Filter - FBMJ2125HS420 Filter - BLM11P300SPB Filter - BLM21PG220SN1B Filter - BLM21PG220SN1B Filter - BLM21PG600SN1B Inductor - 3.3UH ±20% 2.5A Inductor - 3.3UH ±20% 2.5A Inductor: SLF7045-220MR90-PF Inductor: SLF7045-220MR90-PF Filter BLM21PG221SN1B Filter BLM21PG221SN1B Inductor - RLF7030-4R7M3R4 Inductor - SLF6028-220MR77-PF Inductor - SLF6028-220MR77-PF Inductor: RLF7030-1R5N6R1 Filter: MPZ2012S101A Filter: MPZ1608S101A Coil: ACM2012-900-2P Inductor: SLF6028-6R8M1R5-PF Inductor: SLF6028-6R8M1R5-PF Inductor: RLF7030-2R2M5R4 Inductor: RLF7030-2R2M5R4 Inductor: RLF7030-2R2M5R4 Inductor: VLF10040-2R2N7R1 Resistor: 33 Ω: ±5%: 1/16W

D009/D011/D012/D013/D091/D092

Page and Index No.

Part No. 1609 0005 1609 0005 1609 0005 1609 0006 1609 0006 1609 0006 1609 0006 1609 0007 1609 0007 1609 0007 1609 0011 1609 0016 1609 0019 1609 0019 1609 0020 1609 0026 1609 0027 1609 0027 1609 0027 1609 0061 1609 0061 1609 0062 1609 0062 1609 0063 1609 0063 1609 0064 1609 0064 1609 0065 1609 0065 1609 0067 1609 0067 1609 0096 1609 0098 1609 0111 1609 0114

123 -314 123 -217 135 -185 139 -190 123 -218 139 -191 135 -186 135 -187 139 -192 123 -219 123 -220 123 -221 139 -193 135 -188 123 -222 139 -194 135 -189 135 -190 139 -195 139 -196 135 -191 123 -223 139 -197 135 -192 123 -224 123 -225 123 -226 123 -227 135 -193 139 -198 135 -194 123 -228 139 -199 123 -229 135 -195

36

Page and Index No.

Description Resistor: 33 Ω: ±5%: 1/16W Resistor: 33 Ω: ±5%: 1/16W Resistor: 33 Ω: ±5%: 1/16W Resistor: 10K Ω: ±5%: 1/16W Resistor: 10K Ω: ±5%: 1/16W Resistor: 10K Ω: ±5%: 1/16W Resistor: 10K Ω: ±5%: 1/16W Resistor - 68Ω ±5% 1/16W Resistor - 68Ω ±5% 1/16W Resistor - 68Ω ±5% 1/16W Resistor: 22Ω: ±5%: 1/16W Resistor: 56 Ω: ±5%: 1/16W Resistor: 0 Ω: 1608 Resistor: 0 Ω: 1608 Resistor: 10 Ω: ±5%: 1/16W Resistor - 47Ω ±5% 1/16W Resistor - 100KΩ±5% 1/16W Resistor - 100KΩ±5% 1/16W Resistor - 100KΩ±5% 1/16W Resistor Array: 4.7K Ω: ±5%: 1/1Ww: 4Number Resistor Array: 4.7K Ω: ±5%: 1/1Ww: 4Number Resistor Array: 10K Ω: ±5%: 1/16W: 4Number Resistor Array: 10K Ω: ±5%: 1/16W: 4Number Resistor Array: 100 Ω: ±5%: 1/16W: 4Number Resistor Array: 100 Ω: ±5%: 1/16W: 4Number Resistor Array: 33 Ω: ±5%: 1/16W: 4Number Resistor Array: 33 Ω: ±5%: 1/16W: 4Number Resistor Array: 68 Ω: ±5%: 1/16W: 4Number Resistor Array: 68 Ω: ±5%: 1/16W: 4Number Resistor Array: 100K Ω: ±5%: 1/16W: 4Number Resistor Array: 100K Ω: ±5%: 1/16W: 4Number Resistor Array: 10KΩ: ±5%: 1/16W: 4Number Resistor Array: 33Ω: ±5%: 1/16W: 4Number Resistor Array: 1KΩ: ±5%: 1/16W: 4Number Resistor Array: 68Ω: ±5%: 1/16W: 4Number

139 -200 145 -196 123 -230 123 -231 145 -197 139 -201 135 -196 139 -202 135 -197 123 -232 123 -233 123 -234 135 -198 139 -203 123 -235 123 -236 139 -204 123 -237 135 -199 135 -200 139 -205 135 -201 139 -206 139 -207 135 -202 139 -208 135 -203 135 -204 139 -209 139 -210 135 -205 145 -198 145 -199 145 -200 145 -201

Parts Index

Part No. 1610 1409 1610 1420 1610 1420 1610 1735 1610 1735 1610 1877 1610 1877 1610 1900 1610 1947 1610 1997 1610 2045 1610 2046 1610 2047 1610 2049 1623 1003 1633 0000 1633 0000 1633 0000 1634 0000 1634 0000 1634 0000 1634 0000 1640 5100 1650 2101 1650 2682 1650 3153 1650 3470 1650 4101 1650 4101 1650 4102 1650 4103 1650 4104 1650 4105 1650 4222 1650 4223

Description Chip Resistor - 6.8Ω ±5% Resistor - 0.075Ω ±1% 0.5W Resistor - 0.075Ω ±1% 0.5W Resistor: 0.05 Ω: ±1%: 1W Resistor: 0.05 Ω: ±1%: 1W Resistor: 0.24 Ω: ±1%: 2W Resistor: 0.24 Ω: ±1%: 2W Resistor: 56K Ω: ±0.5%: 1/16W 1005 Resistor: 220 Ω: ±5%: 1W: 6332 Resistor: 1.5 Ω: ±1%: 1W: 6332 Resistor: 115KΩ: ±0.1%: 1/10W: 2125 Resistor: 25.5KΩ: ±0.1%: 1/10W: 2125 Resistor: 30.1KΩ: ±0.1%: 1/10W: 2125 Resistor: 1.8 Ω: ±1%: 1W: 6332 Resistor: 100K Ω: ±1%: 1/4W Resistor - 0 Ω 1/10W Resistor - 0 Ω 1/10W Resistor - 0 Ω 1/10W Resistor - 0 Ω 1/16W Resistor - 0 Ω 1/16W Resistor - 0 Ω 1/16W Resistor - 0 Ω 1/16W Capacitor - 10μF +20% 50 Resistor - 100Ω ±5% 1/4W Resistor - 6.8KΩ ±5% 1/4W Resistor: 15KΩ: ±5%: 1/8W Resistor: 47 Ω: ±5%: 1/8W: 2125 Resistor - 100Ω±5%1/10W Resistor - 100Ω±5%1/10W Resistor - 1KΩ ±5% 1/10W Resistor - 10KΩ ±5% 1/10W Resistor - 100KΩ±5%1/10W Resistor - 1MΩ ±5% 1/10W Resistor - 2.2KΩ±5%1/10W Resistor - 22KΩ±5%1/10W

D009/D011/D012/D013/D091/D092

Page and Index No.

Part No. 1650 4330 1650 4470 1650 4472 1650 4472 1650 4472 1650 4510 1650 4560 1650 4621 1650 4681 1650 4681 1650 4681 1650 5100 1650 5100 1650 5100 1650 5101 1650 5101 1650 5101 1650 5102 1650 5102 1650 5102 1650 5102 1650 5103 1650 5103 1650 5103 1650 5103 1650 5104 1650 5104 1650 5104 1650 5104 1650 5105 1650 5105 1650 5109 1650 5122 1650 5122 1650 5122

145 -202 135 -206 139 -211 139 -212 135 -207 139 -213 135 -208 123 -238 145 -203 145 -204 123 -239 123 -240 123 -241 145 -205 135 -246 135 -209 139 -214 123 -242 135 -210 139 -215 123 -243 145 -206 145 -207 145 -208 145 -209 145 -210 139 -216 123 -244 145 -211 145 -212 145 -213 145 -214 145 -215 145 -216 145 -217

37

Description Chip Resistor - 33Ω ±5% 1/10W Resistor - 47Ω±5%1/10W Resistor - 4.7KΩ ±5% 1/10W Resistor - 4.7KΩ ±5% 1/10W Resistor - 4.7KΩ ±5% 1/10W Resistor - 51Ω±5%1/10W Chip Resistor - 56Ω ±5% 1/10W Resistor - 620Ω ±5% 1/10W 1608 Resistor - 680Ω ±5% 1/10W Resistor - 680Ω ±5% 1/10W Resistor - 680Ω ±5% 1/10W Chip Resistor - 10 Ω±5%1/16W Chip Resistor - 10 Ω±5%1/16W Chip Resistor - 10 Ω±5%1/16W Chip Resistor - 100 Ω±5%1/16W Chip Resistor - 100 Ω±5%1/16W Chip Resistor - 100 Ω±5%1/16W Chip Resistor - 1KΩ±5%1/16W Chip Resistor - 1KΩ±5%1/16W Chip Resistor - 1KΩ±5%1/16W Chip Resistor - 1KΩ±5%1/16W Chip Resistor - 10KΩ±5%1/16W Chip Resistor - 10KΩ±5%1/16W Chip Resistor - 10KΩ±5%1/16W Chip Resistor - 10KΩ±5%1/16W Chip Resistor - 100KΩ±5%1/16W Chip Resistor - 100KΩ±5%1/16W Chip Resistor - 100KΩ±5%1/16W Chip Resistor - 100KΩ±5%1/16W Chip Resistor - 1MΩ±5%1/16W Chip Resistor - 1MΩ±5%1/16W Chip Resistor 1Ω ±5% 1/16W Chip Resistor - 1.2KΩ±5%1/16W Chip Resistor - 1.2KΩ±5%1/16W Chip Resistor - 1.2KΩ±5%1/16W

Page and Index No. 145 -218 123 -245 145 -219 123 -246 135 -245 145 -220 145 -221 145 -222 135 -211 145 -223 139 -217 139 -218 145 -224 135 -212 139 -219 123 -247 135 -213 135 -214 123 -248 145 -225 139 -220 145 -226 135 -215 139 -221 123 -249 135 -216 145 -227 139 -222 123 -250 135 -217 139 -223 123 -251 123 -252 135 -218 139 -224

Parts Index

Part No. 1650 5152 1650 5203 1650 5204 1650 5220 1650 5220 1650 5220 1650 5221 1650 5222 1650 5222 1650 5222 1650 5222 1650 5244 1650 5244 1650 5272 1650 5330 1650 5330 1650 5330 1650 5330 1650 5331 1650 5331 1650 5332 1650 5332 1650 5333 1650 5333 1650 5470 1650 5472 1650 5472 1650 5472 1650 5472 1650 5473 1650 5511 1650 5511 1650 5513 1650 5513 1650 5560

Description Chip Resistor: 1.5KΩ: ±5%: 1/16W Resistor - 20KΩ ±5% 1/16W Chip Resistor - 200KΩ±5%1/16W Resistor - 22Ω ±5% 1/16W Resistor - 22Ω ±5% 1/16W Resistor - 22Ω ±5% 1/16W Chip Resistor - 220Ω±5%1/16W Resistor - 2.2KΩ ±5% 1/16W Resistor - 2.2KΩ ±5% 1/16W Resistor - 2.2KΩ ±5% 1/16W Resistor - 2.2KΩ ±5% 1/16W Resistor: 240K Ω: ±5%: 1/16W: 1005 Resistor: 240K Ω: ±5%: 1/16W: 1005 Chip Resistor: 2.7KΩ: ±5%: 1/16W Chip Resistor - 33Ω±5%1/16W Chip Resistor - 33Ω±5%1/16W Chip Resistor - 33Ω±5%1/16W Chip Resistor - 33Ω±5%1/16W Resistor - 330Ω ±5% 1/16W Resistor - 330Ω ±5% 1/16W Resistor - 3.3KΩ ±5% 1/16W Resistor - 3.3KΩ ±5% 1/16W Resistor: 33K Ω: ±5%: 1/16W: 1005 Resistor: 33K Ω: ±5%: 1/16W: 1005 Chip Resistor 47Ω ±5% 1/16W Chip Resistor: 4.7KΩ: ±5%: 1/16W Chip Resistor: 4.7KΩ: ±5%: 1/16W Chip Resistor: 4.7KΩ: ±5%: 1/16W Chip Resistor: 4.7KΩ: ±5%: 1/16W Chip Resistor - 47KΩ ±5% 1/16W Resistor - 510Ω ±5% 1/16W Resistor - 510Ω ±5% 1/16W Chip Resistor: 51KΩ: ±5%: 1/1W Chip Resistor: 51KΩ: ±5%: 1/1W Chip Resistor 56Ω ±5% 1/16W

D009/D011/D012/D013/D091/D092

Page and Index No.

Part No. 1650 5561 1650 5561 1650 5621 1650 5680 1650 5680 1650 5680 1650 5682 1650 5682 1650 5683 1650 5822 1654 1001 1654 1002 1654 1003 1654 1004 1654 1009 1654 1403 1654 1502 1654 1509 1654 1601 1654 1809 1654 2001 1654 2002 1654 2200 1654 2209 1654 2401 1654 3002 1654 3301 1654 3309 1654 3601 1654 4709 1654 4709 1654 5109 1654 5109 1654 5601 1654 6201

123 -253 123 -254 145 -228 145 -229 123 -255 135 -219 123 -256 145 -230 123 -257 139 -225 135 -220 135 -221 139 -226 123 -258 139 -227 135 -222 123 -259 145 -231 139 -228 135 -223 135 -224 139 -229 135 -225 139 -230 123 -260 145 -232 135 -226 139 -231 123 -261 145 -233 135 -227 139 -232 139 -233 135 -228 123 -262

38

Description Chip Resistor 560Ω ±5% 1/16W Chip Resistor 560Ω ±5% 1/16W Chip Resistor 620Ω ±5% 1/16W Resistor - 68Ω ±5% 1/16W Resistor - 68Ω ±5% 1/16W Resistor - 68Ω ±5% 1/16W Chip Resistor: 6.8KΩ: ±5%: 1/16W: 1005 Chip Resistor: 6.8KΩ: ±5%: 1/16W: 1005 Chip Resistor 68KΩ ±5% 1/16W Chip Resistor: 8.2KΩ: ±5%: 1/16W Resistor - 1KΩ±1%1/10W Resistor - 10KΩ±5%1/10W Resistor - 100KΩ±1%1/10W Chip Resistor - 1MΩ ±1% 1/10W Resistor - 10Ω±1% 1/10W Resistor: 140KΩ: ±1%: 1/10W Resistor - 15KΩ±1% 1/10W Chip Resistor: 15Ω: ±1%: 1/10W Chip Resistor - 1.6KΩ±1% 1/10W Resistor: 18 Ω: ±1%: 1/10W: 1608 Chip Resistor - 2KΩ ±1% 1/10W Resistor - 20KΩ±1%1/10W Resistor: 220Ω: ±1%: 1/10W: 1608 Resistor - 22Ω±1% 1/10W Resistor - 2.4KΩ ±1% 1/10W Resistor - 30KΩ±1%1/10W Resistor - 3.3KΩ ±1% 1/10W Resistor - 33Ω±1% 1/10W Resistor - 3.6KΩ ±1% 1/10W Resistor - 47Ω±1% 1/10W Resistor - 47Ω±1% 1/10W Resistor: 51Ω: ±1%: 1/10W Resistor: 51Ω: ±1%: 1/10W Resistor - 5.6KΩ±1% 1/10W Resistor - 6.2KΩ ±1% 1/10W

Page and Index No. 135 -229 139 -234 123 -263 135 -230 139 -235 145 -234 139 -236 135 -231 123 -264 123 -265 145 -235 123 -266 145 -236 123 -267 123 -268 145 -237 123 -269 123 -270 145 -238 123 -318 145 -239 145 -240 123 -271 123 -315 145 -241 123 -272 145 -242 123 -316 145 -243 135 -232 139 -237 135 -233 139 -238 145 -244 145 -245

Parts Index

Part No. 1654 6800 1654 6801 1654 7501 1654 9100 1655 0000 1655 0000 1655 0000 1655 1000 1655 1001 1655 1001 1655 1002 1655 1002 1655 1003 1655 1009 1655 1109 1655 1132 1655 1200 1655 1202 1655 1202 1655 1242 1655 1501 1655 1502 1655 1601 1655 1651 1655 2001 1655 2002 1655 2200 1655 2201 1655 2209 1655 2400 1655 2400 1655 2402 1655 2402 1655 2402 1655 2552

Description Resistor - 680 Ω ±1% 1/10W Resistor - 6.8KΩ±1% 1/10W Resistor - 7.5KΩ±1%1/10W-1608 Resistor: 910 Ω: ±1%: 1/10W: 1608 Chip Resistor - 0Ω±0%1/16W Chip Resistor - 0Ω±0%1/16W Chip Resistor - 0Ω±0%1/16W Chip Resistor: 100Ω: ±1%: 1/16W Chip Resistor - 1KΩ ±1% 1/16W Chip Resistor - 1KΩ ±1% 1/16W Chip Resistor - 10KΩ±1%1/16W Chip Resistor - 10KΩ±1%1/16W Chip Resistor - 100KΩ±1%1/16W Resistor - 10Ω ±1% 1/16W Resistor: 11 Ω: ±1%: 1/16W: 1005 Resistor: 11.3K Ω: ±1%: 1/16W: 1005 Resistor - 120 Ω ±1% 1/16W Resistor: 12K Ω: ±1%: 1/16W: 1005 Resistor: 12K Ω: ±1%: 1/16W: 1005 Resistor: 12.4K Ω: ±1%: 1/16W: 1005 Chip Resistor 1.5KΩ ±1% 1/16W Resistor - 15KΩ ±1% 1/16W Resistor: 1.6K Ω: ±1%: 1/16W: 1005 Resistor: 1.65K Ω: ±1%: 1/16W: 1005 Resistor - 2KΩ ±1% 1/16W Chip Resistor - 20KΩ±1%1/16W Resistor - 220Ω ±1% 1/16W Resistor: 2.2K Ω: ±1%: 1/16W: 1005 Resistor - 22Ω ±1% 1/16W Resistor: 240 Ω: ±1%: 1/16W: 1005 Resistor: 240 Ω: ±1%: 1/16W: 1005 Resistor - 24KΩ ±1% 1/16W Resistor - 24KΩ ±1% 1/16W Resistor - 24KΩ ±1% 1/16W Resistor: 25.5K Ω: ±1%: 1/16W: 1005

D009/D011/D012/D013/D091/D092

Page and Index No.

Part No. 1655 3012 1655 3309 1655 3742 1655 3742 1655 3902 1655 3909 1655 4700 1655 4701 1655 4701 1655 4701 1655 4701 1655 4702 1655 4709 1655 4871 1655 4999 1655 5102 1655 5103 1655 5600 1655 5600 1655 5600 1655 5601 1655 5609 1655 5609 1655 5621 1655 6809 1655 9101 1660 2101 1660 2120 1660 2150 1660 2330 1660 2470 1660 2471 1660 2471 1660 4102 1660 4103

123 -273 145 -246 145 -247 145 -248 123 -274 139 -239 135 -234 123 -275 123 -276 145 -249 145 -250 123 -277 123 -278 123 -279 123 -280 123 -281 123 -282 135 -235 139 -240 123 -283 123 -284 123 -285 123 -286 123 -287 139 -241 145 -251 123 -288 123 -289 123 -290 139 -242 135 -236 135 -237 139 -243 145 -252 123 -291

39

Description Resistor: 30.1K Ω: ±1%: 1/16W: 1005 Resistor - 33Ω ±1% 1/16W Resistor: 37.4K Ω: ±1%: 1/16W: 1005 Resistor: 37.4K Ω: ±1%: 1/16W: 1005 Resistor: 39K Ω: ±1%: 1/16W: 1005 Resistor 39Ω ±1% 1/16W Resistor - 470Ω ±1% 1/16W Chip Resistor - 4.7KΩ±1%1/16W Chip Resistor - 4.7KΩ±1%1/16W Chip Resistor - 4.7KΩ±1%1/16W Chip Resistor - 4.7KΩ±1%1/16W Chip Resistor: 47KΩ: ±1%: 1/16W: 1005 Resistor - 47Ω ±1% 1/16W Resistor: 4.87K Ω: ±1%: 1/16W: 1005 Resistor - 49.9Ω ±1% 1/16W Resistor: 51K Ω: ±1%: 1/16W: 1005 Resistor: 510K Ω: ±1%: 1/16W: 1005 Resistor - 560Ω ±1% 1/16W Resistor - 560Ω ±1% 1/16W Resistor - 560Ω ±1% 1/16W Resistor - 5.6KΩ ±1% 1/16W Resistor - 56Ω ±1% 1/16W Resistor - 56Ω ±1% 1/16W Resistor - 5.62KΩ ±1% 1/16W Chip Resistor - 68Ω±1%1/16w Resistor - 9.1K Ω ±1% 1/16W Capacitor - 100pF - ±10% - 50V Capacitor - 12 pF ±5% 50V Capacitor - 15pF ±5% 50V Capacitor - 33pF - ±5% - 50V Capacitor - 47pF ±5% 50V Capacitor - 470pF - ±5% - 50V Capacitor - 470pF - ±5% - 50V Capacitor - 1000pF ±10% 50V Capacitor - 10000pF - ±10% - 50V

Page and Index No. 123 -292 123 -293 135 -238 139 -244 145 -253 123 -294 123 -295 145 -254 135 -239 123 -296 139 -245 123 -297 123 -298 123 -299 123 -300 123 -301 123 -302 139 -246 135 -240 123 -303 123 -304 139 -247 123 -305 145 -255 123 -306 123 -307 123 -308 145 -256 145 -257 145 -258 145 -259 123 -309 145 -260 145 -261 145 -262

Parts Index

Part No.

Description

Page and Index No.

1660 4103 1660 4222 1660 4222 1660 4332 1660 4332 1660 4472 1660 6103 1660 8104 1660 8104 1902 0084 1902 0084 1906 0101 1906 0101 1906 0117 1906 0120 1907 0077

Capacitor - 10000pF - ±10% - 50V Capacitor - 2200pF - ±10% - 50V Capacitor - 2200pF - ±10% - 50V Capacitor - 3300pF - ±10% - 50V Capacitor - 3300pF - ±10% - 50V Capacitor - 4700pF±10% 50V Capacitor - 10000pF - +80%-20%50V Capacitor - 0.1μF +80-20% 25V Capacitor - 0.1μF +80-20% 25V SRAM: 4M: x16: TSOP44Type2: 3.3V SRAM: 4M: x16: TSOP44Type2: 3.3V Flash Memory: S29GL032A90TFIR40 Flash Memory: S29GL032A90TFIR40 Flash Memory: S29GL032A90TFIR20 NAND Flash: 1G: x8: 30NS: 3.3V: 2KB DDR512M: 8Mx16x4: 333MHZ: CL2.5G3

123 -310 139 -248 145 -263 135 -241 139 -249 145 -264 145 -265 145 -266 123 -311 135 -242 139 -250 135 -243 139 -251 123 -312 123 -317 123 -313

5203 1852 5203 9502 5206 2684 5206 2686 5206 2686 5206 2686 5215 2621 5215 2621 5442 1924 5447 2681 5447 2681 5447 2681 5447 2681

Bushing - 6x8x4mm Silicon Grease G-501 Shoulder Screw - M3 Snap Ring Snap Ring Snap Ring Snap Ring - M6 Snap Ring - M6 Exposure Glass Cushion Snap Ring Snap Ring Snap Ring Snap Ring

65 - 36 153 - 9 89 - 9 63 - 31 53 - 36 33 - 19 31 - 18 19 - 6 41 - 10 33 - 13 31 - 6 29 - 3 25 - 8

D009/D011/D012/D013/D091/D092

Part No. 5447 2681 5447 2681

40

Description Snap Ring Snap Ring

Page and Index No. 23 - 2 97 - 14

Parts Index

Parts Manual Mp 4000.pdf 636i2r

Overview 26281t

More details 6y5l6z

Related Documents 3h463d

Parts Manual Mp 4000.pdf 636i2r

Mp Control Manual 84x5x

Mp 277 Manual - S 53n4

Manual B52 Mp-5306 2h4g4m

Mp Series Manual 4y582e

More Documents from "Alejandro Hernandez" 2aq2z

Prueba De Hermeticidad Neumatica 3le6a

4p345f

133-112 Falk Type A Sizes 385,405-585 Horizontal Parallel Shaft Drives Parts Manual 606e4w

Parts Manual Mp 4000.pdf 636i2r

Drive Executive 5s4y3r

Nuevo Calendario Prepa 2d314n
