ANOTHER SOLUTION TO PROTECT THE ENVIRONMENT INCA ANAEROBIC SEPTIC TANK or SEWAGE TREATMENT PLANT (STP) The INCA sewage treatment plant (STP) system is based on the settling and the anaerobic filtration of household sewage. A septic chamber is combined with a filter chamber in one central treatment septic tank system. In this system, no mechanical parts are used to guarantee the function of the waste treatment septic tank. No electric power is necessary to operate the septic tank. No service works or permanent maintenance works are required or necessary during operation. The INCA septic tank is made from Linear Low Density Polyethylene (LLDPE). It is a one-piece rotationally molded plastic part manufactured from virgin LLDPE resin. The design of the septic tank provides maximum strength and ease of handling. Wall strength is further reinforced by a step-formed profile. The INCA septic tank is designed to be completely buried in the ground. Based on actual performance, it assures sanitation and hygiene and is suited for households, offices, factories, schools or churches. It saves space, easy to install and does not require sedimentation treatment. Choose from five models of the Inca Septic tank. Inca offers free supervision during the initial installations. ACCREDITED BY INNOVATIVE TECHNOLOGIES FOR HOUSING (AITECH) / HUDCC certificate no. 2003-0010

DWELLING STA 1000 House (200 ltrs./ person) 3-5 Office (50 ltrs./person) 12 Factory/ school (50 ltrs/ person) 12 FLOW RATE ltrs/ day 600 Inner width 952 DIMENSIONS Outer width 1346 (Millimeters) Height 1397 Inlet depth 200 SPECS Outlet depth 250 (Millimeters) Pipe 102 Septic zone 635 CAPACITY Filter zone 350 (Liters) Total 1000

STA 1200 6-7 20 20 800 952 1346 1638 200 250 102 850 350 1200

STA 1500 6-8 24 24 1200 952 1346 1676 200 250 102 1150 350 1500

STA 1700

8-10 32 32 1600 952 1346 1900 200 250 102 1350 350 1700

INCA PLASTICS PHILIPPINES, INC. Bldg. 4 Philcrest Compound, km 23 West Service Rd., Cupang Muntinlupa City, Philippines Tel. +63 2 850 0482; Fax +63 2 809 1108; TOLL FREE 1-800-1888-INCA; http://www.inca.com.ph

STA 2200 13-15 40 40 2000 952 1346 2260 200 250 102 1850 350 2200
